EVLBE08X
EN User Manual | Microwave combi-oven
WE’RE THINKING OF YOU
Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings
with it decades of professional experience and innovation. Ingenious and stylish, it has
been designed with you in mind. So whenever you use it, you can be safe in the
knowledge that you’ll get great results every time.
Welcome to Electrolux.
Visit our website to:
Get usage advice, brochures, trouble shooter, service and repair information:
www.electrolux.com/support
Register your product for better service:
www.registerelectrolux.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.electrolux.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the following data
available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
CONTENTS
1. SAFETY INFORMATION................................................................................ 3
2. SAFETY INSTRUCTIONS.............................................................................. 6
3. PRODUCT DESCRIPTION............................................................................. 9
4. CONTROL PANEL........................................................................................ 10
5. BEFORE FIRST USE....................................................................................11
6. DAILY USE....................................................................................................11
7. CLOCK FUNCTIONS.................................................................................... 15
8. USING THE ACCESSORIES........................................................................17
9. ADDITIONAL FUNCTIONS...........................................................................18
10. HINTS AND TIPS........................................................................................ 19
11. CARE AND CLEANING.............................................................................. 22
12. TROUBLESHOOTING................................................................................ 23
13. ENERGY EFFICIENCY...............................................................................25
14. MENU STRUCTURE...................................................................................25
15. IT'S EASY!...................................................................................................26
16. ENVIRONMENTAL CONCERNS................................................................27
2 ENGLISH
1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully read
the supplied instructions. The manufacturer is not responsible
for any injuries or damage that are the result of incorrect
installation or usage. Always keep the instructions in a safe
and accessible location for future reference.
1.1 Children and vulnerable people safety
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
the use of the appliance in a safe way and understand the
hazards involved. Children of less than 8 years of age and
persons with very extensive and complex disabilities shall
be kept away from the appliance unless continuously
supervised.
• Children should be supervised to ensure that they do not
play with the appliance.
• Keep all packaging away from children and dispose of it
appropriately.
• WARNING: The appliance and its accessible parts become
hot during use. Keep children and pets away from the
appliance when in use and when cooling down.
• If the appliance has a child safety device, it should be
activated.
• Children shall not carry out cleaning and user maintenance
of the appliance without supervision.
1.2 General Safety
• This appliance is for cooking purposes only.
• This appliance is designed for single household domestic
use in an indoor environment.
• This appliance may be used in, offices, hotel guest rooms,
bed & breakfast guest rooms, farm guest houses and other
ENGLISH 3
similar accommodation where such use does not exceed
(average) domestic usage levels.
• Only a qualified person must install this appliance and
replace the cable.
• Do not use the appliance before installing it in the built-in
structure.
• Disconnect the appliance from the power supply before
carrying out any maintenance.
• If the supply cord is damaged, it must be replaced by the
manufacturer, its Authorised Service Centre or similarly
qualified persons to avoid an electrical hazard.
• WARNING: Ensure that the appliance is switched off before
replacing the lamp to avoid the possibility of electric shock.
• WARNING: The appliance and its accessible parts become
hot during use. Care should be taken to avoid touching
heating elements or the surface of the appliance cavity.
• Always use oven gloves to remove or insert accessories or
ovenware.
• Do not activate the microwave function when the appliance
is empty. Metal parts inside the cavity can create electric
arcing.
• Metallic containers for food and beverages are not allowed
during microwave cooking. This requirement is not
applicable if the manufacturer specifies size and shape of
metallic containers suitable for microwave cooking.
• WARNING: If the door or door seals are damaged, the
appliance must not be operated until it has been repaired by
a qualified person.
• WARNING: Only a qualified person can carry out any
service or repair operation that involves the removal of a
cover which gives protection against exposure to
microwave energy.
• WARNING: Do not heat liquids and other foods in sealed
containers. They are liable to explode.
• Use only utensils that are suitable for use in microwave
ovens.
4 ENGLISH
• When heating food in plastic or paper containers, observe
the appliance due to the possibility of ignition.
• The appliance is intended for heating food and beverages.
Drying of food or clothing and heating of warming pads,
slippers, sponges, damp cloth and similar may lead to risk
of injury, ignition or fire.
• If smoke is emitted, switch off or unplug the appliance and
keep the door closed in order to stifle any flames.
• Microwave heating of beverages can result in delayed
eruptive boiling. Care must be taken when handling the
container.
• The contents of feeding bottles and baby food jars shall be
stirred or shaken and the temperature checked before
consumption, in order to avoid burns.
• Eggs in their shell and whole hard-boiled eggs should not
be heated in the appliance since they may explode, even
after microwave heating has ended.
• To remove the shelf supports first pull the front of the shelf
support and then the rear end away from the side walls.
Install the shelf supports in the opposite sequence.
• The appliance should be cleaned regularly and any food
deposits removed.
• Do not use a steam cleaner to clean the appliance.
• Do not use harsh abrasive cleaners or sharp metal scrapers
to clean the glass door since they can scratch the surface,
which may result in shattering of the glass.
• Failure to maintain the appliance in a clean condition could
lead to deterioration of the surface that could adversely
affect the life of the appliance and possibly result in a
hazardous situation.
ENGLISH 5
2. SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualified person must install this
appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Follow the installation instructions supplied
with the appliance.
• Always take care when moving the
appliance as it is heavy. Always use safety
gloves and enclosed footwear.
• Do not pull the appliance by the handle.
• Install the appliance in a safe and suitable
place that meets installation requirements.
• Keep the minimum distance from other
appliances and units.
• Before mounting the appliance, check if
the appliance door opens without restraint.
• The appliance is equipped with an electric
cooling system. It must be operated with
the electric power supply.
• The built-in unit must meet the stability
requirements of DIN 68930.
Cabinet minimum height
(Cabinet under the worktop
minimum height)
444 (460) mm
Cabinet width 560 mm
Cabinet depth 550 (550) mm
Height of the front of the
appliance
455 mm
Height of the back of the
appliance
440 mm
Width of the front of the ap‐
pliance
595 mm
Width of the back of the ap‐
pliance
559 mm
Depth of the appliance 567 mm
Built in depth of the appli‐
ance
546 mm
Depth with open door 882 mm
Ventilation opening mini‐
mum size. Opening placed
on the bottom rear side
560x20 mm
Mains supply cable length.
Cable is placed in the right
corner of the back side
1500 mm
Mounting screws 3.5x25 mm
2.2 Electrical connection
WARNING!
Risk of fire and electric shock.
• All electrical connections should be made
by a qualified electrician.
• The appliance must be earthed.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to the
mains plug and to the mains cable. Should
the mains cable need to be replaced, this
must be carried out by our Authorised
Service Centre.
• Do not let mains cables touch or come
near the appliance door or the niche below
the appliance, especially when it operates
or the door is hot.
• The shock protection of live and insulated
parts must be fastened in such a way that
it cannot be removed without tools.
• Connect the mains plug to the mains
socket only at the end of the installation.
Make sure that there is access to the
mains plug after the installation.
• If the mains socket is loose, do not
connect the mains plug.
• Do not pull the mains cable to disconnect
the appliance. Always pull the mains plug.
• Use only correct isolation devices: line
protecting cut-outs, fuses (screw type
fuses removed from the holder), earth
leakage trips and contactors.
6 ENGLISH
• The electrical installation must have an
isolation device which lets you disconnect
the appliance from the mains at all poles.
The isolation device must have a contact
opening width of minimum 3 mm.
• This appliance is supplied only with a main
cable.
2.3 Use
WARNING!
Risk of injury, burns and electric shock or
explosion.
• Do not change the specification of this
appliance.
• Make sure that the ventilation openings
are not blocked.
• Do not let the appliance stay unattended
during operation.
• Deactivate the appliance after each use.
• Be careful when you open the appliance
door while the appliance is in operation.
Hot air can release.
• Do not operate the appliance with wet
hands or when it has contact with water.
• Do not apply pressure on the open door.
• Do not use the appliance as a work
surface or as a storage surface.
• Open the appliance door carefully. The
use of ingredients with alcohol can cause
a mixture of alcohol and air.
• Do not let sparks or open flames to come
in contact with the appliance when you
open the door.
• Do not put flammable products or items
that are wet with flammable products in,
near or on the appliance.
• Do not use microwave function to preheat
the appliance.
WARNING!
Risk of damage to the appliance.
• To prevent damage or discoloration to the
enamel:
– do not put aluminium foil directly on
the bottom of cavity of the appliance.
– do not put water directly into the hot
appliance.
– do not keep moist dishes and food in
the appliance after you finish the
cooking.
– be careful when you remove or install
the accessories.
• Discoloration of the enamel or stainless
steel has no effect on the performance of
the appliance.
• Use a deep pan for moist cakes. Fruit
juices cause stains that can be
permanent.
• Always cook with the appliance door
closed.
• If the appliance is installed behind a
furniture panel (e.g. a door) make sure the
door is never closed when the appliance
operates. Heat and moisture can build up
behind a closed furniture panel and cause
subsequent damage to the appliance, the
housing unit or the floor. Do not close the
furniture panel until the appliance has
cooled down completely after use.
2.4 Care and cleaning
WARNING!
Risk of injury, fire, or damage to the
appliance.
• Before maintenance, deactivate the
appliance and disconnect the mains plug
from the mains socket.
• Make sure the appliance is cold. There is
the risk that the glass panels can break.
• Replace immediately the door glass
panels when they are damaged. Contact
the Authorised Service Centre.
• Be careful when you remove the door from
the appliance. The door is heavy!
• Make sure the cavity and the door are
wiped dry after each use. Steam produced
during the operation of the appliance
condensates on cavity walls and can
cause corrosion.
• Clean regularly the appliance to prevent
the deterioration of the surface material.
• Fat and food remaining in the appliance
can cause fire and electric arcing when
the microwave function operates.
• Clean the appliance with a moist soft
cloth. Use only neutral detergents. Do not
use abrasive products, abrasive cleaning
pads, solvents or metal objects.
• If you use an oven spray, follow the safety
instructions on its packaging.
ENGLISH 7
2.5 Glassware use
Handling your glassware without an
appropriate degree of care could result in
breakage, chipping, cracking or severe
scratching:
• Do not spill cold water or other liquids on
the glassware because a sudden
temperature drop may cause immediate
breakage of the glass. Broken glass
pieces may be extremely sharp and
difficult to locate.
• Do not place hot glassware on a wet or
cool surface, directly on countertop or
metal surface, or in sink; or handle hot
glassware with wet cloth.
• Do not use or repair any glassware that is
chipped, cracked or severely scratched.
• Do not drop or hit glassware against a
hard object or strike utensils against it.
• Do not heat empty or nearly empty
glassware in microwave, or overheat oil or
butter in microwave (use minimum amount
of cooking time).
Allow hot glassware to cool on a cooling rack,
a potholder or a dry cloth. Make sure that the
glassware is cool enough before washing,
refrigerating or freezing.
Avoid handling hot glassware (including ware
with silicone gripping surfaces) without dry
potholders.
Avoid microwave misuse (i.e. running the
oven without any load or small load).
2.6 Internal lighting
WARNING!
Risk of electric shock.
• Concerning the lamp(s) inside this product
and spare part lamps sold separately:
These lamps are intended to withstand
extreme physical conditions in household
appliances, such as temperature,
vibration, humidity, or are intended to
signal information about the operational
status of the appliance. They are not
intended to be used in other applications
and are not suitable for household room
illumination.
• This product contains a light source of
energy efficiency class G.
• Use only lamps with the same
specifications.
2.7 Service
• To repair the appliance contact the
Authorised Service Centre.
• Use original spare parts only.
2.8 Disposal
WARNING!
Risk of injury or suffocation.
• Contact your municipal authority for
information on how to dispose of the
appliance.
• Disconnect the appliance from the mains
supply.
• Cut off the mains electrical cable close to
the appliance and dispose of it.
• Remove the door catch to prevent children
or pets from becoming trapped in the
appliance.
8 ENGLISH
3. PRODUCT DESCRIPTION
3.1 General overview
1 2
8
4
3
1
2
3
6
4
5
7
Control panel
Display
Heating element
Microwave generator
Lamp
Fan
Shelf support, removable
Shelf positions
3.2 Accessories
Wire shelf
For cookware, cake tins, roasts.
Baking tray
For cakes and biscuits.
Microwave bottom glass plate
To prepare food in microwave mode.
ENGLISH 9
4. CONTROL PANEL
4.1 Control panel overview
1 2 3 4
5 6 7
1
ON / OFF Press and hold to turn the appliance on and off.
2
Menu Lists the appliance functions.
3
Favourites Lists the favourite settings.
4
Display Shows the current settings of the appliance.
5
Lamp switch To turn the lamp on and off.
6
Fast Heat Up To turn on and off the function: Fast Heat Up.
7
Microwave quick start To turn on microwave function (1000 W and 30 seconds).
Press Move
3s
Press and hold
Touch the surface with fingertip. Slide fingertip over the surface. Touch the surface for 3 seconds.
4.2 Display
150°C
12:30
15min
START
E CD B
A
Display with key functions set.
A. Time of day
B. START/STOP
C. Temperature / Microwave timer
D. Heating functions
E. Timer
10 ENGLISH
Display indicators
Basic indicators - to navigate on the display.
To confirm the selection / setting.
To go one level
back in the menu.
To undo the last
action.
To turn the options on and off.
Sound alarm function indicators - when the set time of cooking ends, the signal sounds.
The function is on.
The function is on.
Cooking stops automatically.
Sound alarm is off.
Timer indicators
To set the function: Delayed start.
To cancel the setting.
5. BEFORE FIRST USE
WARNING!
Refer to Safety chapters.
5.1 Initial Cleaning
Step 1 Step 2 Step 3
Remove all accessories and remov‐
able shelf supports from the appli‐
ance.
Clean the appliance and the acces‐
sories only with a microfibre cloth,
warm water and a mild detergent.
Place the accessories and the re‐
movable shelf supports in the appli‐
ance.
5.2 First connection
The display shows welcome message after the first connection.
You have to set: Language, Display brightness, Key tones, Buzzer volume, Time of day.
6. DAILY USE
WARNING!
Refer to Safety chapters.
ENGLISH 11
6.1 How to set: Heating functions
Step 1 Turn on the oven. The display shows the default heating function.
Step 2
Press the symbol of the heating function to enter the submenu.
Step 3
Select the heating function and press: . The display shows: temperature.
Step 4
Set: temperature. Press: .
Step 5
Press: .
- press to turn off the heating function.
Step 6 Turn off the oven.
6.2 How to set: Microwave functions
Step 1 Remove all accessories and turn on the appliance.
Insert microwave bottom glass plate.
Step 2 Press the symbol of the heating function to enter the submenu.
Step 3
Select the microwave heating function and press: . The display shows: microwave power.
Step 4
Set: microwave power. Press: .
Step 5
Press: .
- press to turn off the function.
Step 6 Turn off the appliance.
The maximum time of microwave functions
depends on microwave power you set:
MICROWAVE POWER
W
MAXIMUM TIME
min
100 - 600 59:55
> 600 7
If you open the door, the function stops.
To start it again, press .
6.3 How to use: Microwave quick
start
Step 1
Press and hold: .
The microwave runs for 30 s.
12 ENGLISH
Step 2 To extend the cooking time:
Press on the run‐
ning time value to
go to the time
settings. Set the
cooking time.
Press +30 s.
The microwave can be switched on at any time with:
Microwave quick start.
6.4 How to set: Assisted Cooking
Every dish in this submenu has a recommended function and temperature. You can adjust the
time and the temperature.
For some of the dishes you can also cook with:
• Weight Automatic
Step 1 Turn on the oven.
Step 2
Press: .
Step 3
Press: . Enter: Assisted Cooking.
Step 4 Choose a dish or a food type.
Step 5
Press: .
6.5 Heating functions
STANDARD
Heating function Application
Grill
To grill thin pieces of food and to toast bread.
Turbo Grilling
To roast large meat joints or poultry with bones on one shelf position. To make gratins
and to brown.
True Fan Cooking
To bake on up to two shelf positions at the same time and to dry food. Set the temper‐
ature 20 - 40 °C lower than for Conventional Cooking.
Frozen Foods
To make convenience food (e.g., french fries, potato wedges or spring rolls) crispy.
Conventional Cooking
To bake and roast food on one shelf position.
ENGLISH 13
Heating function Application
Pizza Function
To bake pizza. To make intensive browning and a crispy bottom.
Bottom Heat
To bake cakes with crispy bottom and to preserve food.
SPECIALS
Heating function Application
Preserving
To preserve vegetables (e.g., pickles).
Dehydrating
To dry sliced fruit, vegetables and mushrooms.
Plate Warming
To preheat plates for serving.
Dough Proving
To speed up the rising of the yeast dough. It prevents dough surface from drying and
keeps the dough elastic.
Au Gratin
For dishes such as lasagna or potato gratin. To make gratins and to brown.
Slow Cooking
To prepare tender, succulent roasts.
Keep Warm
To keep food warm.
Bread Baking
Use this function to prepare bread and bread rolls with a very good professional-like
result in terms of crispiness, colour and crust gloss.
14 ENGLISH
MICROWAVE
Heating function Application
Microwave
Heating up, cooking, pow‐
er range: 100 - 1000 W
Defrost
Defrosting meat, fish,
cakes, power range: 100 -
200 W
Reheat
Heating up pre-prepared
meals and delicate food,
power range: 300 - 700 W
Liquid
Heating up drinks and
soups, power range: 800 -
1000 W
MICROWAVE COMBINATION
Heating function Application
True Fan Cooking +
MW
Baking on one shelf posi‐
tion. The function with
MW boost, power range:
100 - 600 W.
Conventional Cooking
+ MW
Baking and roasting food
on one shelf position. The
function with MW boost,
power range: 100 - 600
W.
Grill + MW
To cook food in a short
time and to brown it. The
function with MW boost,
power range: 100 - 600
W.
Turbo Grilling + MW
To roast large pieces of
meat on one level. To
make gratins and to
brown. The function with
MW boost, power range:
100 - 600 W.
7. CLOCK FUNCTIONS
7.1 Clock functions description
Clock function Application
Cooking time To set the length of cooking. Maximum is 23 h 59 min.
Maximum for combined functions (microwave + standard) is: 23 h 59 min.
End action To set what happens when the timer ends counting.
Delayed start To postpone the start and / or end of cooking.
Time extension To extend cooking time.
Reminder To set a countdown. Maximum is 23 h 59 min. This function has no effect on the
operation of the appliance.
Uptimer Monitors how long the function operates. Uptimer - you can turn it on and off.
End action and Delayed start are not
available for microwave functions.
ENGLISH 15
7.2 How to set: Clock functions
How to set the clock
Step 1 Turn on the oven.
Step 2 Press: Time of day.
Step 3
Set the time. Press: .
How to set cooking time
Step 1 Choose the heating function and set the temperature.
Step 2
Press: .
Step 3
Set the time. Press: .
How to choose end option
Step 1 Choose the heating function and set the temperature.
Step 2
Press: .
Step 3 Set the cooking time.
Step 4
Press: .
Step 5 Press: End action.
Step 6 Choose the preferred: End action.
Step 7
Press: . Repeat the action until the display shows the main screen.
How to delay start of cooking
Step 1 Set the heating function and the temperature.
Step 2
Press: .
Step 3 Set the cooking time.
Step 4
Press: .
Step 5 Press: Delayed start.
Step 6 Choose the value.
Step 7
Press: . Repeat the action until the display shows the main screen.
How to extend cooking time
When 10% of cooking time is left and the food seems not to be ready, you can extend cooking time. You can also
change the heating function.
Press +1min to extend the cooking time.
16 ENGLISH
How to change timer settings
Step 1
Press: .
Step 2 Set the timer value.
Step 3
Press: .
You can change the set time during cooking at any time.
8. USING THE ACCESSORIES
WARNING!
Refer to Safety chapters.
8.1 Inserting accessories
Use only suitable cookware and material.
Refer to "Hints and tips" chapter, Microwave
suitable cookware and materials.
A small indentation at the top increases
safety. The indentations are also anti-tip
devices. The high rim around the shelf
prevents cookware from slipping of the shelf.
Wire shelf:
Push the shelf between the guide bars of the shelf
support and make sure that the feet point down.
Baking tray:
Push the tray between the guide bars of the shelf
support.
ENGLISH 17
Microwave bottom glass plate:
Use the microwave bottom glass plate only with
microwave function. It is not suitable for combined
microwave function (e.g. microwave grilling).
Put the accessory on the bottom of the cavity.
You can put the food directly on the microwave
bottom glass plate.
9. ADDITIONAL FUNCTIONS
9.1 How to save: Favourites
You can save your favourite settings, such as the heating function, the cooking time, the
temperature or the cleaning function. You can save 3 favourite settings.
Step 1 Turn on the appliance.
Step 2 Select the preferred setting.
Step 3
Press: . Select: Favourites.
Step 4 Select: Save current settings.
Step 5
Press + to add the setting to the list of: Favourites. Press .
- press to reset the setting.
- press to cancel the setting.
9.2 Function lock
This function prevents an accidental change of the heating function.
Step 1 Turn on the appliance.
Step 2 Set a heating function.
Step 3
, - press at the same time to turn on the function.
To turn off the function repeat step 3.
9.3 Automatic switch-off
For safety reasons the appliance turns off
after some time, if a heating function works
and you do not change any settings.
(°C) (h)
30 - 115 12.5
120 - 195 8.5
200 - 230 5.5
18 ENGLISH
The Automatic switch-off does not work with
the functions: Light, End time, Slow Cooking.
9.4 Cooling fan
When the appliance operates, the cooling fan
turns on automatically to keep the surfaces of
the appliance cool. If you turn off the
appliance, the cooling fan can continue to
operate until the appliance cools down.
10. HINTS AND TIPS
10.1 Cooking recommendations
The temperature and cooking times in the tables are guidelines only. They depend on the recipes and the quality
and quantity of the ingredients used.
Your appliance may bake or roast differently to the appliance you had before. The hints below show recommen‐
ded settings for temperature, cooking time and shelf position for specific types of the food.
If you cannot find the settings for a special recipe, look for the similar one.
For more cooking recommendations refer to cooking tables on our website. To find the Cooking Hints, check the
PNC number on the rating plate on the front frame of the appliance cavity.
10.2 Microwave recommendations
Let's cook!
Place the food on the microwave bottom
glass plate on the bottom of the cavity.
Place the food on a plate on the bottom of the
cavity.
Turn or stir the food halfway through the
defrosting and cooking time.
Stir liquid dishes from time to time.
Stir the food before serving.
Cover the food for cooking and reheating.
Put the spoon to the bottle or glass when
heating drinks to ensure better heat
distribution.
Put the food into the appliance without
packaging. The packaged ready meals can
be put into the appliance only when the
packaging is microwave safe (check
information on the packaging).
Microwave cooking
Cook food covered. If you want to keep a
crust cook food without a cover.
Do not overcook the dishes by setting the
power and time too high. The food can dry
out, burn or cause fire.
Do not use the appliance to cook eggs or
snails in their shells, because they can burst.
Pierce the yolk of fried egg before reheating
it.
Pierce food with skin or peel several times
before cooking.
Cut vegetables into similar-sized pieces.
After you turn off the appliance, take the food
out and let it stand for a few minutes to allow
the heat distribute evenly.
Microwave defrosting
Put the frozen, unwrapped food on a small
upturned plate with a container below it, or on
a defrosting rack or plastic sieve so that the
defrosting liquid can leak out.
Remove defrosted pieces subsequently.
To cook fruit and vegetables without
defrosting them first, you can use a higher
microwave power.
10.3 Microwave suitable cookware and materials
For the microwave use only suitable cookware and materials. Use below table as a reference.
ENGLISH 19
Check the cookware / material specification before use.
Cookware / Material
Ovenproof glass and porcelain with no
metal components, e.g. heat-proof
glass
Non-ovenproof glass and porcelain
without any silver, gold, platinum or
other metal decorations
X X
Glass and glass ceramic made of
ovenproof / frost-proof material
Ovenproof ceramic and earthenware
without any quartz or metal compo‐
nents and glazes which contain metal
Ceramic, porcelain and earthenware
with unglazed bottom or with small
holes, e.g. on handles
X X X
Heat-resistant plastic up to 200 °C X
Cardboard, paper X X
Clingfilm X X
Microwave clingfilm X
Roasting dishes made of metal, e.g.
enamel, cast iron
X X X
Baking tins, black lacquer or silicon-
coated
X X X
Baking tray X X X
Wire shelf X X
Microwave glass bottom plate X
Cookware for microwave use, e.g.
crisp pan
X X
10.4 Recommended power settings for different kinds of food
The data in the table is for guidance only.
700 - 1000 W
Searing at the start of the cooking process Heating liquids
20 ENGLISH
500 - 600 W
Cooking vegetables
Cooking egg
dishes
Simmering stews
Heating one-plate
meals
Defrosting and
heating frozen
meals
300 - 400 W
Melting cheese,
chocolate, butter
Simmering rice
Heating baby food
Cooking / Heating deli‐
cate food
Continuing cooking
100 - 200 W
Defrosting bread Defrosting fruit and cakes
Defrosting cheese, cream,
butter
Defrosting meat, fish
10.5 Cooking tables for test
institutes
Information for test institutes
Tests according to IEC 60705.
Microwave function
Use wire shelf unless otherwise specified.
W
kg
min
Sponge cake 600 0.475 Bottom 8 - 9 Turn container around by
1/4, halfway through the
cooking time.
Meatloaf 400 0.9 1 25 - 27 Turn container around by
1/4, halfway through the
cooking time.
Egg custard 500 1 2 30 - 33 -
Meat defrosting 100 0.5 1 15 Turn the meat upside
down halfway through
the cooking time.
Microwave Combi function
Use the wire shelf.
ENGLISH 21
W °C min
Cake, 0.7 kg Conventional
Cooking + MW
100 200 2 23 - 27 Turn container around
by 1/4, halfway through
the cooking time.
Potato gra‐
tin, 1.1 kg
True Fan
Cooking + MW
300 180 2 38 - 42 Turn container around
by 1/4, halfway through
the cooking time.
Chicken, 1.1
kg
Turbo Grilling +
MW
400 230 1 35 - 40 Put the meat in round
glass container and
turn it upside down
halfway through the
cooking time.
11. CARE AND CLEANING
WARNING!
Refer to Safety chapters.
11.1 Notes on cleaning
Cleaning Agents
Clean the front of the appliance only with a microfibre cloth with warm water and a mild de‐
tergent.
Use a cleaning solution to clean metal surfaces.
Clean stains with a mild detergent.
Everyday Use
Clean the cavity after each use. Fat accumulation or other residue may cause fire.
Clean the appliance ceiling carefully from residue and fat.
Do not store the food in the appliance for longer than 20 minutes. Dry the cavity only with a
microfibre cloth after each use.
Accessories
Clean all accessories after each use and let them dry. Use only a microfibre cloth with warm
water and a mild detergent. Do not clean the accessories in a dishwasher.
Do not clean the non-stick accessories using abrasive cleaner or sharp-edged objects.
11.2 How to remove: Shelf supports
Remove the shelf supports to clean the oven.
22 ENGLISH
Step 1 Turn off the oven and wait until it is cold.
Step 2 Carefully pull the shelf supports up
and out of the front catch.
2
3
1
Step 3 Pull the front end of the shelf support
away from the side wall.
Step 4 Pull the supports out of the rear
catch.
Install the shelf supports in the opposite sequence.
11.3 How to replace: Lamp
WARNING!
Risk of electric shock.
The lamp can be hot.
Always hold the halogen lamp with a cloth to
prevent grease residue from burning on the
lamp.
Before you replace the lamp:
Step 1 Step 2 Step 3
Turn off the oven. Wait until the
oven is cold.
Disconnect the oven from the
mains.
Put a cloth on the bottom of the cav‐
ity.
Top lamp
Step 1 Turn the glass cover to remove it.
Step 2 Clean the glass cover.
Step 3 Replace the lamp with a suitable 300 °C heat-resistant lamp.
Step 4 Install the glass cover.
12. TROUBLESHOOTING
WARNING!
Refer to Safety chapters.
ENGLISH 23
12.1 What to do if...
The appliance does not turn on or does not heat up
Possible cause
Remedy
The appliance is not connected to an electrical supply
or it is connected incorrectly.
Check if the appliance is correctly connected to the
electrical supply.
The clock is not set. Set the clock, for details refer to Clock functions chap‐
ter, How to set: Clock functions.
The door is not closed correctly. Fully close the door.
The fuse is blown. Make sure the fuse is the cause of the problem. If the
problem recurs, contact a qualified electrician.
The appliance Child Lock is on. Refer to "Menu" chapter, Submenu for: Options.
Components
Description
Remedy
The lamp is burnt out. Replace the lamp, for details refer to "Care and Clean‐
ing" chapter, How to replace: Lamp.
12.2 How to manage: Error codes
When the software error occurs, the display shows error message.
In this section, you will find the list of the problems that you can handle on your own.
Code and description Remedy
F240, F439 - the touch fields on the display do not
work properly.
Clean the surface of the display. Make sure there is no
dirt on the touch fields.
F908 - the appliance system cannot connect with the
control panel.
Turn the appliance off and on.
When one of these error messages continues to appear on the display, it means a faulty
subsystem may have been disabled. In such a case contact your dealer or an Authorized
Service Centre. If one of these errors occurs, the rest of the appliance functions will continue to
work as usually.
Code and description Remedy
F131 - the temperature of magnetron sensor is too
high.
Turn the appliance off and wait until it cools down. Turn
the appliance on again.
24 ENGLISH
12.3 Service data
If you cannot find a solution to the problem yourself, contact your dealer or an Authorised
Service Centre.
The necessary data for the service centre is on the rating plate. The rating plate is on the front
frame of the appliance cavity. Do not remove the rating plate from the appliance cavity.
We recommend that you write the data here:
Model (MOD.) .........................................
Product number (PNC) .........................................
Serial number (S.N.) .........................................
13. ENERGY EFFICIENCY
13.1 Energy saving
Make sure that the appliance door is closed
when the appliance operates. Do not open
the appliance door too often during cooking.
Keep the door gasket clean and make sure it
is well fixed in its position.
Use metal cookware to improve energy
saving (only when you use a non-microwave
function).
When possible, do not preheat the appliance
before cooking.
Keep breaks between baking as short as
possible when you prepare a few dishes at
one time.
Cooking with fan
When possible, use the cooking functions
with fan to save energy.
Residual heat
If a programme with Duration is activated and
the cooking time is longer than 30 min, the
heating elements automatically turn off earlier
in some appliance functions.
The fan and lamp continue to operate. When
you turn off the appliance, the display shows
the residual heat. You can use that heat to
keep the food warm.
When the cooking duration is longer than 30
min, reduce the appliance temperature to
minimum 3 - 10 min before the end of
cooking. The residual heat inside the
appliance will continue to cook.
Use the residual heat to warm up other
dishes.
Keep food warm
Choose the lowest possible temperature
setting to use residual heat and keep a meal
warm. The residual heat indicator or
temperature appears on the display.
Cooking with the lamp off
Turn off the lamp during cooking. Turn it on
only when you need it.
14. MENU STRUCTURE
14.1 Menu
Menu item Application
Assisted Cooking Lists automatic programmes.
Favourites Lists the favourite settings.
ENGLISH 25
Menu item Application
Options To set the appliance configuration.
Settings Setup To set the appliance configuration.
Service Shows the software version and configura‐
tion.
14.2 Submenu for: Options
Submenu Application
Light Turns the lamp on and off.
Child Lock Prevents accidental activation of the appliance. When the option is on, the text
Child Lock appears in the display when you turn on the appliance. To enable the
appliance use, choose the code letters in the alphabetical order. Access to the
timer, the remote operation and the lamp is available with the option on.
Fast Heat Up Shortens the heat up time. It is available only for some of the appliance functions.
Time indication Turns the clock on and off.
Digital clock style Changes the format of the displayed time indication.
14.3 Submenu for: Setup
Submenu Description
Language Sets the appliance language.
Display brightness Sets the display brightness.
Key tones Turns the tone of the touch fields on and off. It is not possible to mute the tone for:
.
Buzzer volume Sets the volume of key tones and signals.
Time of day Sets the current time and date.
14.4 Submenu for: Service
Submenu Description
Demo mode Activation / deactivation code: 2468
Software version Information about software version.
Reset all settings Restores factory settings.
15. IT'S EASY!
Before first use you have to set:
Language Display brightness Key tones Buzzer volume Time of day
26 ENGLISH
Familiarize yourself with the basic icons on the control panel and the display:
ON / OFF Menu Favourites
Timer
/
Start using the appliance
Quick start Turn on the appli‐
ance and start cook‐
ing with the default
temperature and
time of the function.
Step 1 Step 2 Step 3
Press and hold: . - select the
preferred function.
Press: .
Quick Off Turn off the appli‐
ance, any screen or
message at any
time.
- press and hold until the appliance turns off.
MW quick start Start Microwave at
any time with default
settings: 30 sec /
1000 W.
Press: .
Start cooking
Step 1 Step 2 Step 3 Step 4 Step 5
- press to turn on the
appliance.
- select the heating
function.
- set the tempera‐
ture.
- press to confirm.
- press to start cook‐
ing.
Get to know how to cook quickly
Use the automatic programmes to prepare a dish quickly with the default settings:
Assisted Cook‐
ing
Step 1 Step 2 Step 3 Step 4
Press: . Press: . Press: Assisted
Cooking.
Choose the dish.
Use quick functions to set the cooking time
10% Finish assist
Use 10% Finish assist to add extra time when 10% of
the cooking time is left.
To extend the cooking time press +1min.
16. ENVIRONMENTAL CONCERNS
Recycle materials with the symbol . Put the
packaging in relevant containers to recycle it.
Help protect the environment and human
health by recycling waste of electrical and
electronic appliances. Do not dispose of
appliances marked with the symbol with
the household waste. Return the product to
your local recycling facility or contact your
municipal office.
ENGLISH 27
*
867370929-B-202023
