PE-TF015 Evaporative Cooler
SAFETY INSTRUCTIONS
KNOWING YOUR EVAPORATIVE COOLER
USING YOUR EVAPORATIVE COOLER
CLEANING AND MAINTENANCE
WARRANTY
SAFETY INSTRUCTIONS
BEFORE USING THIS APPLIANCE READ ALL INSTRUCTIONS AND CAUTIONARY
MARKINGS IN YOUR USER MANUAL AND ON THE APPLIANCE
DANGER!
DO NOT touch or hold the mains plug with wet hands.
DO NOT block or cover air flow to or from the fan while in operation.
DO NOT insert fingers or objects through the grille while in operation.
INTENDED USE
Close supervision is necessary when any appliance is used by or near children. Children
should be supervised to ensure that they do not play with the appliance. Cleaning and
user maintenance shall not be done by children unless they are older than 8 and
supervised.
Use the appliance only for intended household purposes as described in this User
Manual. Any other use is not recommended that may cause fire, electric shock, or injury
to people.
ELECTRICITY SAFETY
This appliance must be provided with correct voltage via a professionally installed power
socket. Make sure the voltage indicated on the label of the appliance is the same as your
local supply.
DO NOT operate the fan with a damaged cord or plug or if the product malfunctions, is
dropped or damaged in any manner.
To reduce the risk of fire or electric shock, DO NOT use this fan with any solid-state
speed control device.
IMPORTANT - This appliance has a polarized plug (one blade is wider than the other). To
reduce the risk of electric shock, this plug is intended to fit in a polarized outlet only one
way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact
a qualified electrician. Do not attempt to rig this safety feature.
.
RELATED TO USE
DO NOT use this fan to ventilate areas where flammable liquids or vapors are used,
stored or are present.
DO NOT attempt to disassemble, repair, modify or replace any part any part of your
product. All servicing should be performed by qualified personnel only.
Always make sure to place the fan on a flat, level surface before operation.
Keep the cord out of heavy traffic areas and where it will not be tripped over. To avoid fire
hazard, NEVER route cord under furniture or appliances.
Always unplug the appliance before cleaning, making any repairs or servicing, or
whenever not in use.
It is normal that there is noise during operation. If too loud, please set the fan to lower
speed.
FOR HOUSEHOLD USE ONLY
SAVE THESE INSTRUCTIONS
Regular
Check
HAVE YOUR EVAPORATIVE COOLER CHECKED REGULARLY FOR ANY
SIGN OF MALFUNCTION!
Check if plug, cord or appliance is
damaged.
Stop using, check FAQ and contact
Paris Rhône Support Team.
Specifications
Input
120V 60Hz
Rated Power
145W
Max Cap. Of Water
45L / 11.9 Gallon
MAX Air Flow Consumption
5,000m³/h
KNOWING YOUR EVAPORATIVE COOLER
Water Outlet 排水口
Hose Connector 水管接头
Rubber Plugs x 2 橡胶塞 x 2
Rubber Rings x 2 橡胶圈 x 2
Control Panel
Fan Speed
Press to cycle through Level 1-3 fan speed.
Oscillation
Press to start oscillating, and the louvers will begin to move left to right
automatically. You can manually adjust the louvers to change to the
vertical air flow.
Press again to cancel.
Timer for Turning ON/OFF
Press to set timer for turning on / off the fan (0-24h).
Cooling
Press to turn on or off cooling. If the fan speed is set to Level 2 or 3, it will
start at Level 1 and gradually increase to the target fan speed.
Power ON/OFF
Turn on / Standby mode. For the first use, the fan speed will start at Level 2
by default for 3 seconds, and then automatically switch to Level 1.
Air
Outlet
Cooling
Pads
Control
Panel
Water Level Window
Water Inlet
Remote Control
Water Tank
Ice Packs x 4
Power Cord & Plug
Back Cover
Display 根据实际图标调整
Remote Control
For added convenience, the same control buttons can be found on the remote control.
Press to mute, a beep will be heard and any operations with the control panel or
remote control will be mute. Press again to unmute without a notification.
USING YOUR EVAPORATIVE COOLER
Filling the Water Tank
Turn off the unit before emptying or refilling the water tank. Drain the water completely
after each use.
DO NOT tilt or move this unit after the water tank is filled with water.
Block the hose connector with a rubber plug when not taking Way 2.
Way 1
Open the top cover and fill the water tank with water, making sure that the water level is
Cooling
Fan Speed / Timer
Fan Speed
Power ON/OFF
Power ON/OFF
Oscillatio
n
Fan Speed-
Fan Speed+
Timer Settings
Cooling
Mute / Unmute
Oscillati
on
between the minimum and maximum marks.
Way 2 需图示
Connect the cooler and the water supply with a water pipe (not included). Turn on the water
supply, and the unit will automatically cut the water off by the time the water level rises to the
maximum mark.
When not using the unit for a long time, turn off the water supply to prevent water leakage.
Using the Ice Pack (Optional)
If no water is in the water tank, the cooler will beep, with flashing, and work with the
cooling function off.
The cooler includes four ice packs (can be frozen repeatedly and recycled) for added
cooling.
1. Freeze in the refrigerator for 3-4 hours.
2. Open the top cover and place the ice packs as per your needs.
3. Fill the water tank with water (below Max line).
Additional Features
Memory Function
The fan is designed with power off memory function, it will always remember your last settings
(except timer setting) once you turn it on again (the fan speed will start at Level 2 by default
for 3 seconds).
Replacement of Batteries
Note:
Replace with new batteries of the same type when replacement is required.
When not using the remote control for a long time, please take out the batteries.
DO NOT attempt to dismantle the batteries.
DO NOT dispose the batteries in fire, batteries may explode or leak.
DO NOT use rechargeable batteries.
1. Press the locking button to pop up the battery holder.
2. Replace the battery with the same type (CR2025, 3V), making sure the (+) side facing
up.
3. Push in the holder until securely locked into place.
WARNING:
Do not ingest battery, Chemical Burn Hazard. This product contains a coin / button cell
battery. If the coin / button cell battery is swallowed, it can cause severe internal burns in just
2 hours and can lead to death. Keep new and used batteries away from children. If the battery
compartment does not close securely, stop using the product and keep it away from children.
If you think batteries might have been swallowed or placed inside any part of the body, seek
immediate medical attention. The batteries contain materials, which are hazardous to the
environment; they must be removed from the appliance before it is scrapped and that they are
disposed of safely.
CLEANING AND MAINTENANCE
Always make sure the cooler is turned off and unplugged before cleaning.
Never immerse in water or allow water to drip into the motor housing.
DO NOT clean with abrasive chemicals or flammable cleaning agents.
Wipe the outer surface with a soft damp cloth. Completely dry before reconnecting to
power source.
Fill the water tank with clean water (below Max line), shake the cooler and drain the
water completely. Repeat several times.
After turning off the cooling function, allow the cooling pads to dry completely by letting
the cooler work for another 30 minutes.
Leave the cooler covered to protect it from dust. Store it in a cool, dry location and wrap
the cord around the cord wrap on the unit so that it will not be tripped over or damaged.
TROUBLESHOOTING
Why the cooler is not working
Make sure it is connected to a powered electrical
outlet.
Press (开关键) to power on.
Not cool enough
Make sure there is water in the tank.
Wait a few minutes for the cooling pads to be
fully saturated with water after turned on.
Empty and clean the water tank regularly to
ensure hygienic use (remove hard water and
mineral deposits).
Why the remote control is not
working
Make sure the fan is connected to a powered
electrical outlet.
Check that the remote control is powered and
move the obstacles between the fan and the
remote.
Operate the remote control near or in front of the
tower fan.
WARRANTY
Thanks for choosing Paris Rhône Evaporative Cooler.
This product is covered with Paris Rhône product and labor warranty for 12 months from the
date of its original purchase.
The warranty will not apply in cases of:
- Accident, misuse, or repairs performed by unauthorized personnel.
- Any unit that has been tampered with or used for commercial purpose.
- Normal wear and tear of wearable parts.
- Use of force, damage caused by external influences.
- Damage caused by non-observance of the User Manual, e.g. connection
to an unsuitable mains supply or non-compliance with the instructions.
- Partially or completely dismantled appliances.
- Defects caused by or resulting from damages from shipping or from repairs, service, or
alteration to the product or any of its parts that have been performed by a repair person not
authorized by Paris Rhône.
We can only provide after-sales service for products that are sold by Paris Rhône or Paris
Rhône authorized retailers and distributors. If you have purchased your unit from a different
place, please contact your seller for return and warranty issues.
※Please have your invoice and order ID ready before contacting Customer Support.
认证Logo：ETL，Made in China
