BIG MOUTH SLOW JUICER
OPERATING MANUAL
MODEL:SJ-003/SJ-014
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and doses not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.
- 1 -
MODEL:SJ-003/SJ-014
Have product questions? Need technical support? Please feel free to
contact us:
CustomerService@vevor.com
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
SHIPPING SCALE
SJ-003
SJ-014
- 2 -
Warning-To reduce the risk of injury, user must read
instructions manual carefully.
SPECIFICATIONS
Model
SJ-003
SJ-014
Input
120V~, 60Hz
120V~, 60Hz
Power
200W
100W
Juicing cup capacity
800ml
400ml
Pulp container capacity
600ml
370ml
Unit size
179*147*442mm
120*100*310mm
IMPORTANT
1. The Unit is designed for household use only.
2. Commercial users will not obtain the regular warranty as stated in the terms of
the warranty card.
3. This is not a toy. Please do not let children play with it or use it.
IMPORTANT SAFEGUARDS
1. Make sure the electricity supply is suitable for this unit.
2. This unit is intended for household use only. Do not use the unit outdoors or
for other purposes than intended.
3. Use the unit only as described in this manual.
- 3 -
4. Do not immerse the unit, cord set, and plug into the water to prevent electrical
shock.
5. This is not a toy and should not be used by children. Close supervision is
required when the unit is used near children.
6. Ensure to unplug the unit when not in use and assemble or disassemble it
before cleaning.
7. The continuous operation time of this product should be within 20 minutes.
8. No-load or overloaded operation of machine is prohibited.
9. Do not touch or move any moving parts during operation of machine.
10. Do not use a finger, spoon, or chopsticks to push fruits or vegetables into the
machine's chute. Only pusher is allowed.
11. Do not open the unit when it is operating.
12. Do not place the unit near explosives, heated ovens, or hot surfaces.
13. Operate the unit only on flat surface.
14. Do not let the cords hang over the edge of table or the like.
15. Please hold the plug to disconnect it from the power socket.
16. If the parts of the product structure are damaged (especially the safety device
and power cord), please stop using them and send them to the service center
for repair by a qualified technician.
17. This product is not intended to be operated by persons (including children)
with weak physical conditions, slow reactions, mental retardation, lack of
experience, and common sense unless they are under supervision or
instruction by the person responsible for their safety.
NOTE :
To avoid hazard of electric shock, unplug the unit from power outlet when
not in use or before cleaning. If the supply cord is damaged, stop using
immediately and bring it back to service centre for repair.
PARTS DIAGRAM
MODEL:SJ-003
- 4 -
1
Chute & Strainer Assembly
5
Juice Container
2
Squeezing Auger
6
Pulp Container
3
Juicing Bowl
7
Pusher
4
Power base
8
Cleaning Brush
SJ-003
- 5 -
MODEL:SJ-014
1
Chute & Strainer Assembly
7
Juice Container
2
Squeezing Auger
8
Pulp Container
3
Juicing Bowl
9
Pusher
4
Power base
10
Brusher
5
Switch
11
Pulp Spout
6
Power Cord
12,13
Juicer Stopper
SJ-014
- 6 -
USING FOR FIRST TIME
1. Remove all packaging materials, plastic bags and labels.
2. Make sure the electricity supply is 120V~60Hz .
3.
Clean the Food Tray / Chute & Strainer Assembly / Squeezing Auger / Juicing
Bowl/ Pusher with Soapy water. Then rinse and dry thoroughly.
NOTE : DO NOT IMMERSE THE POWER BASE UNIT IN WATER.
4. Assemble the parts per the instruction in the assembling method section.
Connect the power cord to the power source.
The unit is ready to use now.
ASSEMBLING METHOD
Please ensure the unit is not plugged in and the switch is turned to the "O" set
before assembling the machine.
1. Position the squeezing bowl on the Power base, aligning the spouts and axle
position. (Fig 1)
2. Push the squeezing auger firmly into the bowl's center, ensuring it touches
down the bottom or else the cover cannot be closed. (Fig 2)
3. Position the chute on the bowl to align the ▲ to the “ ” and twist it clockwise
until it clicks the safety lock. Please make sure that the arrow ▲ on “ ” the
cover aligns with the Lock graphic on the Bowl. (Fig 3)
4. Place the juice container and the pulp container under the relevant spouts. (Fig
4)
Fig1
Fig2
Fig3
Fig4
- 7 -
OPERATION INSTRUCTION
1. Connect the unit with Power.
2. Check and make sure all parts are well assembled in correct position.
3. Make sure the machine is at off “O” position.
4. Make sure the juice and pulp containers are in position.
5. Make sure the juice spout cover is closed.
6. Prepare the fruits or vegetables and cut them into pieces max 5cm x 2cm strips
or 3cm x 3cm cubes.
7. Put fruit strips/cubes into the chute.
8. Press the switch to Setting to start thejuicing operation.
9. Push the food down with the pusher only.
10. In case of food gets stuck inside the Bowl, please instantly switch to the “R"
reverse function.
NOTE :
Please do not use the juicer continuously longer than 20 minutes.
Open & Close of Juice Spout Cover
During the juicing process, you could keep the Drip-stop Cover closed before the
juice is full in the juicing bowl. (Fig 5)
Big mouth slow juicer SJ-003
Fig1
Fig2
Fig3
Fig4
Big mouth slow juicer SJ-014
- 8 -
BENEFITS OF DRIP-STOP COVER :
1. To stop dripping at the end of juicing.
2. To mix the juice with different fruits and veggies.
USAGE TIPS :
1. Remove hard pits or seeds prior to pressing to prevent possible damage to the
squeezing screw.
2.If mixed juices are to be made, please begin with the more complex fruit and
then squeeze the soft fruit.
3.Please let the juicer run for 30 seconds after feeding the last ingredient.
ATTENTION :
The juicer is not suitable for juicing very hard or fibrous and starchy fruits or
vegetables
such as Sugar Cane. There are some fruits which contain too much starch to juice.
Some examples are Avocado, Bananas, figs, Mango, Papaya, Dragon Fruit,
Strawberry,
Grape without seeds etc. They will clog up the stainless steel sieve.
DISASSEMBLING METHOD
NOTE :
Juicer spout
is opened
Juicer spout
is closed
Fig5
- 9 -
If the juicer gets overheated, it will turn off automatically to protect the machine. In
this case, please turn the juicer off “O” . Wait 10 minutes to let the juicer cool down
and then turn it on again.
To disassemble the unit after use and before cleaning. Please turn the juicer to “O”
position and disconnect the juicer from power source. Then, please follow the
steps below :
1. Remove the Juice and Pulp containers. (Fig 6)
2. Remove the Chute. Turn the chute anti-clockwise until the ▲ aligns with the
“ ” sign. (Fig7)
3. Remove the Squeezing Auger by pulling it out upward. If it is very hard, swing
gently and pull. (Fig 8)
4. Remove the Squeezing Bowl by lifting it upward vertically. (Fig 9)
MODEL:SJ-003
MODEL:SJ-014
Fig6
Fig7
Fig8
Fig9
- 10 -
CLEANING & MAINTENANCE
IMPORTANT :
Please wash the juicing parts every time immediately after each use. Otherwise,
the pulp might stick tightly in Juicing Bowl & Squeezing Auger, affecting the
disassembly, cleaning, and juicing performance.
1. Power off the machine and unplug the juicer.
2. Wash the disassembled parts (Fig 10) with water. If the meshes are clogged
with pulp, please use the provided cleaning brush to remove the dregs.
Attention:
• Do not use iron wire brush, abrasive or sharp object tool to clean the unit.
• Please do not use water above 40°C.
Fig6
Fig7
Fig8
Fig9
Fig10
- 11 -
Pull silicone valve
3. In case there is any residues remained in the mouth of the pulp spout, please
pull
out the silicone valve as shown in (Fig 11) below and clean under running water.
Press the silicone valve to close it property and tightly after cleaning.
4. To Clean the seal ring in the center of the squeezing bowl, please follow the
steps as below :
a. Turn the Squeezing Bowl upside down for easier handling; push the seal ring
out with your thumb (Fig 12a) and clean it with water.
b. After cleaning, please put it back in the center hole. The small ribbed surface
should face upward (Fig.12b). Make sure the seal ring groove fits well in the
squeezing bowl.
c. The big flat size of the seal ring will be inside while the small and ribbed side is
outside the Squeezing Bowl. (Fig 12c)
5. Do not put the Power Base into water for cleaning. Wipe it with damp cloth only.
6. After cleaning, please dry the parts thoroughly and store them in a dry, cool
place.
STORAGE
Follow cleaning instructions to maintain the unit before storage well.
Tidy up the power cord set.
Keep the unit away from children's easy access.
Fig11
Silicone valve
- 12 -
Store the unit and the accessories in a dry, cool place.
NOTE :
Please make sure the unit and parts are dry before storing it.
USEFUL TIPS
Item
Warning
Reason
1
Not for Ice cube.
The ice cube is too hard. It may
damage the squeezing parts.
2
The ingredient with long fiber needs
to be cut down to 5-10 cm thin strips
or 3 x 3 cm cubes.
Long fiber food is easy to wind
and block the spout.
3
The peel and pits/seeds must be
removed from oranges, lemons,
grapefruit and melons before use.
The hard pit or seeds may
damage the squeezing parts. The
peel may block the spout of pulp.
4
Do not use other accessory as a
pusher.
It may damage the juicer and
cause injury.
5
Each juicing cycle not longer than 20
minutes.
Working over time may cause
damage to the motor.
6
Never put the spoon,chopsticks into
the opening of the Chute, the juice
and pulp spouts.
It may damage the juicer.
- 13 -
TROUBLE SHOOTING
Trouble
Cause
Solutions
The juicer stops
running
suddenly.
Too many ingredients
put into the juicer.
Switch to "R" position instantly to make
the ingredients return upwards. If the
machine still stops running, please
clean the machine before use.
Hard fruits or
vegetables have not
been cut in small
pieces.
Hard fruits and vegetables
(such as carrot) shall be cut into thin
strips or small cubes before putting into
chute.
The juice yield
is low or juice
flows out of the
main housing.
The Bowl and the
silicone valve are not
installed properly.
Please re-install the Bowl silicone valve
by referring to the installation method.
Abnormal noise.
Parts cause extrusion
sound during
squeezing.
The sound is caused by extrusion of
fruits and vegetables, which is normal
phenomenon.
The Chute &
Strainer
Assembly
cannot be
opened.
There is too much pulps
inside the bowl.
Press switch to "R" setting to eject the
pulps backward.
There is hard foods
stuck inside.
Press switch to "R" to eject the object
backward.
The pulp mess is stuck.
Pour water into the Chute to soften the
stuck pulp mess overnight.
The container &
accessories are
dyed after use.
Dyed parts are due to
natural color of specific
fruits/veggies.
This is natural color and unavoidable.
- 14 -
Address：Floor 3-4, Building 7, No. 1, Road Zhengan Western District, Zhongshan
City, Guangdong
Manufacturer: Islow Electric(Zhongshan) Co., Ltd
Made In China
