Handgun Mounting
WARNING: BE CERTAIN THAT YOUR FIREARM IS NOT
LOADED AND POINTED AWAY FROM YOU IN A SAFE
DIRECTION
ATTENTION: THIS BARSKA LASER SIGHT IS A POWERFUL
TARGETING DEVICE THAT REQUIRES SPECIAL ATTENTION WHEN
OPERATING. CAREFULLY READ THE FOLLOWING INSTRUCTIONS AND
SAFETY PRECAUTIONS BEFORE USING THIS PRODUCT.
CAUTION: UNAUTHORIZED USE MODIFICATIONS OF ADJUSTMENTS OR
PERFORMANCE OF PROCEDURE OTHER THAN SPECIFIED HEREIN MAY
RESULT IN DANGEROUS/HAZARDOUS RADIATION EXPOSURE.
LASER LIGHT: AVOID DIRECT EYE EXPOSURE.
WARNING KEEP OUT OF REACH OF CHILDREN.
DO NOT POINT LASER AT PEOPLE, PETS, SHINY/HIGHLY REFLECTIVE
SURFACES, AIRPLANES OR ANY OTHER OBJECT NOT INTENDED FOR
DESIGNATED USE.
2
1
3
11
5
4
6
7
8
9
10
Handgun Mounting:
1. Use included allen wrench to remove the side of the rail mount by
unscrewing the two screws on the side of the compact mount. Remove the
stabilizing cross bar from inner channel, use cross bar if needed by
inserting into rail channel.
2. Slide laser sight on to hand guns lower frame rail.
3. Replace side of mount on to laser and gun rail insert the two mounting
screws and tighten with allen wrench.
Rifle Rail Mounting:
1. Use included allen wrench to remove the side of the rail mount by
unscrewing the two screws on the side of the compact mount. Remove the
stabilizing cross bar from inner channel, use cross bar if needed by
inserting into rail channel.
2. Slide laser sight on to rifles weaver / piccitanny rail. Ideally on rifles
bottom rail.
3. Replace side of mount on to laser and gun rail. Insert the two mounting
screws and tighten with allen wrench.
Turn Laser On/Off:
(See item #6)
Turn On: Slide on/off switch to the left.
Turn Off: Slide on/off switch to the right.
Zeroing Windage and Elevation Adjustment:
1. At the front side and bottom of laser there are adjustment screws for the
laser’s windage and elevation. (See item #2) Use the included allen wrench
to turn the adjustments screws clockwise or counter clockwise. The
bottom screw will move the laser dot up or down and the side screw will
move the dot from side to side.
2. Using the windage and elevation adjustments zero the laser dot in at the
set distance you will be targeting. When changing shooting distance you
will need to reset the elevation (Reset both W/E if laser is side mounted).
Attaching Cable Switch:
To bypass the slide switch and use the included cable switch you will need to
remove the cover at the back of the laser, use a coin to unscrew the cover.
Then screw the cable switch into the back of the laser.
Replacing Battery:
Unscrew the front laser head to insert new battery, replace laser head and
tighten.
Note: Test laser periodically during periods of non-usage to ensure adequate
battery level.
Product parts:
1. Laser diode head
2. Windage and elevation adjustment
3. CR123A battery
4. Compact weaver / picitanny mount with removable
stabilizing cross bar. That can be attached to a
hand guns lower frame rail, rifles weaver/piccitiny
rail, or in combination with Barska multi-rail scopes
5. Weaver / Picitanny accessory rail
6. On / Off slide switch
7. Back cover
8. Cable switch
9. Two side mounting screws
10. Side rail mount
11. Stabilizing cross bar
Note: When mounting laser sight, place weapons safety on and unload all
ammunition from the firearm. When mounting laser to weapon keep the laser in
off position to avoid exposure to eyes.
BC676
©2021 BARSKA
®
Pomona, CA 91767, USA
www.barska.com
<5mW
650(±10)nm
1000 YDS
32˚F-104˚F
Windage / Elevation
CR-123A 1
Technical Data:
Output Power
Wavelength
Max Reach Capacity
Operating Temperature
Adjustments
Battery Type
©2021 BARSKA
®
04/21
BC305
RED LASER SIGHT
1 YEAR LIMITED WARRANTY
BARSKA® Optics, as manufacturer, warrants this new precision optical product to be free of original
defects in materials and/or workmanship for the length of time specified by this warranty. This warranty
does not include damage caused by abuse, improper handling, installation, maintenance, normal
wear-and-tear, unauthorized repairs or modifications and tampering in anyway.
This warranty is limited to the original purchaser and is not transferable. This warranty applies only to
products purchased in the United States of America.
In the event of a defect within 30 days, the consumer must return the defective unit to the BARSKA
dealer (the place of purchase) at his/her own expense.
Beyond 30 days, BARSKA products should be sent to the following address for warranty repairs.
Products must be packed carefully and sturdily to prevent damage in transit, and returned freight
prepaid to:
BARSKA
855 Towne Center Drive
Pomona, CA 91767, USA
For additional and updated information
please visit our website at www.barska.com
Please email [email protected] or call 1-888-666-6769 for Return Merchandise Number (RMA#) before
any returns.
NOTE: All merchandise received without a valid RMA # will be returned to shipper at his/her own
expense.
Please include all of the following when returning BARSKA products for service and/or replacement:
1. Please write your complete details (Name, Address, Telephone #, E-mail address, RMA#, etc.)
2. Purchase receipt or Proof of Purchase. (Original/Copy)
3. A brief explanation of the defect.
4. A Check/Money Order of $20.00 to cover inspection, shipping and handling.
*Please allow 6-8 weeks for delivery.
This product will either be replaced or repaired at the discretion of the warrantor. If it's a discontinued
item, we will replace the product with an equivalent product. Should the repair not be covered by this
warranty, an estimate will be sent for your approval. Non-warranty repairs or refurbishing of your optical
products are always provided at a reasonable cost.
BARSKA® Optics shall not be liable for any consequential, incidental and/or contingent damages
whatsoever. This warranty supersedes all previous BARSKA® Optics warranties.
Rifle Rail Mounting
AVOID EXPOSURE LASER RADIATION
IS EMITTED FROM THIS APERTURE
5mW Red Laser Sight
Model:AU11406
Made In China
Manufactured on 04/2021
BARSKA Optics
855 Towne Center Drive
Pomona, CA 91767, USA
www.barska.com
LASER RADIATION AVOID DIRECT
EYE EXPOSURE
WARNING:
This product complies
with 21 CFR chapter 1,
subchapter L.
Max Output<5mW
WAVELENGTH 650(±10)nm
Class IIIA Laser Product
FDA NO.:9922878
