BC678 4/21
© 2021 BARSKA
®
Pomona, CA 91767
www.barska.com
Your laser sight is equipped with a Picatinny Rail. This rail will attach your laser to your
firearm.
1. Slide the laser sight into the bore of the Picatinny rail.
2. Once the sight is in the rail tighten it in place by using an Allen wench.
3. Slide the rail onto your firearm, then tighten it in place.
This device is powered by one 3v (CR 123A) Lithium Battery.
1. Unscrew the cable switch by turning it counter clockwise
2. Insert the battery so that the positive pole of the battery faces out.
3. Replace the switch back on the laser sight. Turn clockwise to tighten
the cable switch onto the sight. Make sure that you have screwed the
switch on tightly.
Adjustments must be made in the shooter’s position of the sight.
This laser sight has been factory calibrated. Should you require
adjusting the windage and elevation remove turret caps and see
chart below to distinguish which of these knobs you need to turn
and in which direction.
CC: Counter Clockwise
C: Clockwise
WARNING: BE CERTAIN THAT YOUR FIREARM IS NOT LOADED AND
POINTED AWAY FROM YOU IN A SAFE DIRECTION
ATTENTION: THIS BARSKA LASER SIGHT IS A POWERFUL TARGETING
DEVICE THAT REQUIRES SPECIAL ATTENTION WHEN OPERATING.
CAREFULLY READ THE FOLLOWING INSTRUCTIONS AND SAFETY
PRECAUTIONS BEFORE USING THIS PRODUCT.
CAUTION: UNAUTHORIZED USE MODIFICATIONS OF ADJUSTMENTS OR
PERFORMANCE OF PROCEDURE OTHER THAN SPECIFIED HEREIN MAY RESULT IN
DANGEROUS/HAZARDOUS RADIATION EXPOSURE.
LASER LIGHT: AVOID DIRECT EYE EXPOSURE.
WARNING KEEP OUT OF REACH OF CHILDREN.
DO NOT POINT LASER AT PEOPLE, PETS, AIRPLANES, SHINY/HIGHLY REFLECTIVE
SURFACES, OR ANY OTHER OBJECT NOT INTENDED FOR DESIGNATED USE.
The BARSKA 5mW Green Laser Sight GLX features external riflescope style windage and
elevation (W/E) adjustments for quick, high precision targeting. Zeroing in your laser is a
quick and easy process. The tactical design integrates a tactical edged bezel into the
strong T6 aluminum body for added protection. The diamond cut exterior grip improves
the mounting capability of the picatinny 1” mounting ring included with the laser sight.
Length
Weight
Main Tube Diameter
Output Power
Wavelength
Reach
Operating Temperature
Adjustment
Material
Battery Type
138mm
204g
1 inch
<5mW
532(±10)nm
1000 YDS
59˚F-95˚F
Windage & Elevation
T6 Aluminum
CR-123A Lithim
• Continuous push button on/off cap • Momentary on/off long cable switch
• 1” picatinny rail ring with removable cross-bar
AVOID EXPOSURE LASER RADIATION IS EMITTED FROM
THIS APERTURE
DANGER
5mW Green Laser Sight
Model: AU11404
Made In China
Manufactured on 04/2021
BARSKA Optics
855 Towne Center Drive
Pomona, CA 91767
This product complies with 21 CFR
chapter 1, subchapter L.
LASER RADIATION AVOID DIRECT EYE EXPOSURE
Max Output<5mW
WAVELENGTH 532(±10)nm
Class IIIA Laser Product
FDA NO.:0720007
WARNING:
Battery
Elevation
Windage
Visible Laser Class IIIA Laser Product
GLX Green 5mW Tactical Laser
Sight w/Picatinny Rail and 1” Ring
CCC
CC C
Windage
Right
Left
Up
Down
Elevation
Note
- After 3 minutes of continuous use, turn laser off for 1 minute
- If operating laser in cold weather (under 68˚ F) let laser warm up by turning it on for
30 seconds before use. (Actual warm up time may vary depending on
surrounding environment)
- Test laser periodically during periods of non-usage to ensure adequate battery level
