ANG180 Digital Angle Gauge
• Single and dual axis calibration
• User programmable target angle with audible alarm
• Zero button sets a user reference plane
other than true horizontal level
• Magnetic base attaches to pipes, table saws,
and other ferromagnetic surfaces
• V-groove on the top and bottom surface easily
aligns to the axis of conduit and pipes
• Functionsasabullseyelevelwhenlaidat
• Hold button freezes the reading on the display
• Autooconservesbatterylife
• Onscreen battery icon indicates when
the batteries need replacing
• Includes (2) AA batteries
• 1 year warranty
Ordering Information:
ANG180 Digital Angle Gauge
Features:
Applications:
Finds and sets angles, check relative angles,
works as a standard or bullseye level
Detects the degree of oset from true level
850 Perimeter Road • Manchester, NH • (603) 669-6400 • [email protected]
Specifications
Measurement Range
Accuracy: Vertical/Horizontal
Accuracy: Bullseye
Drop Proof
Water Resistant
Power
Dimensions
Weight
0 to 90°; 0 to 180°
±0.2° (when measuring using the Magnetic Base)
±0.5°(when measuring using the back surface)
6.6ft (2m)
(IP42)
(2) AA Batteries
4.8 x 2.4 x 1.4” (121 x 62 x 35mm)
6.4oz (181g)
