EN
Quick Guide
1
THANK YOU FOR BUYING AHOTPOINT PRODUCT.
In order to receive amore complete assistance, please
register your appliance on: www.hotpoint.eu/register
SETTING MENU
1. Switch on the appliance by pressing the ON-OFF button.
2. Hold the Settings (Half Load ) button for 3 seconds, until you hear
a beep and the display shows „SEt”.
3. After one second the rst available setting (letter „ ”) will be displayed.
4. Press PREVIOUS /NEXT to scroll through the list of available settings
(see table below), then press START/Pause to view and change the
value of the currently selected setting.
5. Press PREVIOUS /NEXT to change the value, then press START/Pause
to save the new value or return to the main menu.
6. To change another setting, repeat points 4 and 5.
7. Press ON-OFF or wait 30 seconds to exit the menu.
LETTER
SETTING
VALUES
(Default - in bold)*
Cycle Counter - number of washing cycles
carried out by the dishwasher.
Eg. 25 cycles: 25;
Eg. 13.947 cycles:
13_947
(scrolling
for 3 times)
Water Hardness Level (see “SETTING THE WA-
TER HARDNESS” and “WATER HARDNESS TABLE”)
1 | 2 | 3 | 4 | 5
Rinse Aid Level
(see “ADJUSTING THE DOSAGE OF RINSE AID”)
0 | 1 | 2 | 3 | 4 | 5
ActiveDry (see “OPTIONS AND FUNCTIONS”)
“1” = On, “0” = O
1 | 0
Sound
“1” = On, “0” = O
1 | 0
Factory Settings - press START/Pause to re-
store to the factory default all the values of the
settings included in the settings menu.
-
*) The default value does not apply to the Cycle Counter.
FILLING THE SALT RESERVOIR
The use of salt prevents the formation of LIMESCALE on
the dishes and on the machine’s functional components.
The salt reservoir is located in the lower part of the dish-
washer (under the lower rack on the left side).
• It is mandatory that the salt reservoir never be empty.
• It is important to set the water hardness.
• Salt must be lled when the SALT REFILL indicator light on the control
panel is lit.
1. Remove the lower rack and unscrew the reservoir cap (anticlockwise).
2. Position the funnel (see gure) and ll the salt reservoir right up to its
edge (approximately 0,5 kg); it is not unusual for alittle water to leak out.
3. Only the rst time you do this: ll the salt reservoir with water.
4. Remove the funnel and wipe any salt residue away from the opening.
Make sure the cap is screwed on tightly so that no detergent can get into
the container during the wash program (this could damage the water sof-
tener beyond repair).
Run aprogram every time as soon as you completed relling the salt
reservoir to avoid corrosion.
WATER SOFTENING SYSTEM
Water softener automatically reduces water hardness, consequently pre-
venting scale buildup on the heater, contributing also to better cleaning ef-
ciency. This system regenerates itself with salt, therefore it is required
to rell the salt container when empty.
The frequency of regeneration depends on the water hardness level setting
- regeneration takes place once per 4-6 Eco cycles with the water hardness
level set to 3. The regeneration process occurs at the beginning of the cycle
with additional fresh water.
• Single regeneration consumes ~3 L of water;
• Takes up to 5 additional minutes for the cycle;
• Consumes below 0.005 kWh of energy.
A
B
FILLING THE RINSE AID DISPENSER
Rinse aid makes dish DRYING easier. The rinse aid dis-
penser Ashould be lled when the RINSE AID REFILL
indicator light in the control panel is lit.
1. Open the dispenser B by pressing and pulling up
the tab on the lid.
2. Pour in the rinse aid (max. 110 ml), making sure it
does not overow from the dispenser. If this hap-
pens, clean the spill immediately with adry cloth.
3. Press the lid down until you hear aclick to close it.
NEVER pour the rinse aid directly into the appli-
ance tub.
D
C
FILLING THE DETERGENT DISPENSER
To open the detergent dispenser use the opening
device C. Introduce the detergent into the dry dis-
penser D only. Place the amount of detergent for
pre-washing directly inside the tub.
1. When measuring out the detergent refer to the
mentioned earlier information to add the proper
quantity. Inside the dispenser D, there are indica-
tions to help the detergent dosing.
2. Remove detergent residues from the edges of the dispenser and close
the cover until it clicks.
3. Close the lid of the detergent dispenser by pulling it up until the closing
device is secured in place.
The detergent dispenser automatically opens up at the right time accord-
ing to the program.
Usage of detergent not designed for dishwashers may cause malfunc-
tion or damage to the appliance.
CONTROL PANEL
FIRST TIME USE
More information in the Daily Reference Guide on website.
Before using the appliance carefully read Safety and Installation Instructions.
After installation, please remember to remove all transport protection parts from
the dishwasher.
1. ON-OFF/Reset button with indicator light
2. PREVIOUS program button
3. NEXT program button
4. FAVOURITE program button
with indicator light
5. Salt reservoir empty indicator light
6. Rinse Aid reservoir empty indicator light
7. DESCALE indicator light
8. Closed Water Tap indicator light
9. Display
10. Program number and remaining time indicator
11. Turbo option button with indicator light
12. Half Load option button with indicator light/ Settings - 3 sec. press
13. Extra Dry option button with indicator light
14. Delay option button with indicator light
15. START/Pause button with indicator light
W11558344 panel
W20005966 button R
W11569657 button L
W11569647 display
1 2 3 4
11 12 13
15
5 6 7 8 9 10
14
PLEASE SCAN THE
QR CODE ON YOUR
APPLIANCE IN
ORDER TO HAVE
MORE DETAILED
INFORMATION
EN
2
Quick Guide
CYCLE COUNTER - This feature shows the number of cycles the
dishwasher has performed.
For the number of cycles from 0-999, a xed number will be displayed.
Example for 25 cycles.
When the cycle number is higher than 1000, the number will scroll in
the display. The “_” represents the “
.
”, as for instance: 1.000 = 1_000,
13.947= 13_947 (the number will scroll for 3 times).
Example for
13.947 cycles:
After the cycle visualization, the display will return to visualize
„ ”
.
NOTE: The dishwasher may have already performed about 30 cycles.
This is due to the extended quality process carried out during
production. It guarantees higher product quality.
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020.
Note for Test Laboratories:
For information on comparative EN testing conditions, please send an email to the following address: [email protected]
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programs other than the program Eco are indicative only. The actual time may vary depending on many factors such as temperature and
pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and sensor cali-
bration. The sensor calibration can increase program duration by up to 20 min.
EXTRA DRY - The higher temperature during the final rinse and the
extended drying phase allow improved drying. The EXTRA DRY option
results in the lengthening of the wash cycle.
DELAY - The start of the program may be delayed for a period of time
between 0:30 and 24 hours.
The DELAY function cannot be set once a program has been started.
WATER TAP CLOSED – Alarm - Flashes when there is no inlet water or
water tap is closed.
ActiveDry - It is aconvection drying system which automatically opens the
door during/after drying phase to ensure exceptional drying performance
every day. Door opens at the temperature that is safe to your kitchen fur-
niture. As additional steam protection, special designed protection foil is
added together with the dishwasher.
SENSING - When the sensor is detecting the soil level an animation
appears in the display (around 20 min.) and the cycle duration is
updated. SENSING is for the level of soiling on the dishes and is
present for all cycles (excepting Eco) adjusting the program accordingly.
HALF LOAD - If there are not many dishes to be washed, HALF LOAD is
used to save water, electricity or time, depending on the selected
program. Remember to halve the amount of detergent.
OPTIONS can be selected/ deselected, after choosing the program, directly by pressing the corresponding button (if available - the indicator
lights up) (see CONTROL PANEL). If an option is not compatible with the selected program (see PROGRAMS TABLE), the corresponding LED ashes rap-
idly 3 times and beeps will sound. The option will not be enabled. An option can change time or water or energy consumption for the program.
DESCALE – Alarm - Limescale accumulation was detected on the
internal components of the appliance. Check if the Water Hardness
Setting is at the correct value and salt is present in the salt container (see
FIRST TIME USE), then use a descaling product (WPro brand is recommended)
with Self-Clean program. After a successful descaling, the icon will stop
being displayed.
If the actions above are not performed, product performance will deteriorate.
DESCALE warning will start blinking and «dES» alarm will appear on the
display. If still no action is taken, the appliance will only allow a certain
number of cycles to be started (indicated during «dES» alarm display) and
then will be BLOCKED to prevent component damage, with only the Self-
Clean program available. Performing a full descaling will unblock the
product. In the case of extremely high amounts of limescale, descaling may
have to be performed twice to be ecient.
PROGRAMS TABLE
OPTIONS AND FUNCTIONS
Please scan the QR code on your product in order to have more detailed information.
Program Programs description
Drying
phase
ActiveDry
Available options
*)
Duration
of wash
program
(h:min)
**)
Water
consumption
(litres/cycle)
Energy
consumption
(kWh/cycle)
P1
Eco 50°- Program is suitable to clean normally soiled tableware, that
for this use, it is the most ecient program in terms of its combined
energy and water consumption, and that it is used to assess compli-
ance with the EU Ecodesign legislation.
3:30 9.9 0.77
P2
Auto Intensive 65° - Automatic program for
heavily soiled dishes and pans.
Senses the level of soil-
ing on the dishes and
adjusts the program
accordingly. When the
sensor is detecting the
soil level an animation
appears in the display
and the cycle duration
is updated.
2:25-3:10 17.0-25.0 1.30-1.70
P3
Auto Mixed 55° - Automatic program for nor-
mally soiled dishes with dried food residues.
1:20-3:20 7.5-20.5 0.75-1.20
P4
Auto Fast 50° - Automatic program for nor-
mally and lightly soiled dishes. The everyday
cycle that ensures optimal cleaning and dry-
ing performance in a shorter time.
1:00-1:50 8.0-16.0 0.70-1.10
P5
Rapid 45° - Program is recommended for limited amount of lightly-soiled
dishes with no dried food residues. Does not include the drying phase.
-
0:30-0:40 10.5-15.0 0.55-0.65
P6
Delicates 45° - Program for delicate items, which are more sensitive to
high temperatures, for example, glasses and cups.
1:40-1:50 12.5-17.0 0.95-1.20
P7
Good Night 55° - Suitable for night-time operation of the appliance. En-
sures optimal cleaning and drying performance with the lowest noise
emission.
3:50-4:10 10.5-14.5 0.80-1.15
P8
Sanitizing 65° - Normally or heavily soiled crockery, with additional anti-
bacterial wash. Can be used to perform maintenance of the dishwasher.
-
1:55-2:10 12.0-19.0 1.40-1.80
P9
Soak - Used to refresh crockery planned to be washed later. Nodeter-
gent is to be used with this program.
-
0:12 4.5 0.10
P10
Self Clean 65° -
Program to be used to perform maintenance of the
dishwasher, to be carried out only when the dishwasher is EMPTY using
specic detergents designed for dishwasher maintenance.
-
-
1:15 12.7 1.10
FAVOURITE PROGRAM - The FAVOURITE program may be saved and
will be easily accessible. Find the program using PREVIOUS/NEXT, and
then press the FAVOURITE program button for 3 seconds.
TURBO - Thanks to the Turbo option you can reduce time up to 40%
depending on the selected based program. Energy and water
consumption are increased.
EN
Quick Guide
3
CLEANING THE FILTER ASSEMBLY
A
A
B
C
1 2 3 4
The dishwasher must not be used without l-
ters or if the lter is loose.
It is important when reinstalling the lter that
the two triangles shown on the zoom meet (Fig 1).
In case you nd foreign objects (such as broken
glass, porcelain, bones, fruit seeds etc.) please re-
move them carefully.
Inspect the trap and remove any food residues.
NEVER REMOVE the wash-cycle pump protec-
tion (shown by an arrow) (Fig 4).
CARE AND MAINTENANCE
More information in the Daily Reference Guide on website.
LOADING THE RACKS
CAPACITY: 16 standard place-settings
CLEANING THE SPRAY ARMS
On occasions, food residue
may become encrusted onto
the spray arms and block the
holes used to spray the water. It
is therefore recommended that
you check the arms from time
to time and clean them with
asmall non-metallic brush.
To remove the upper spray you
must remove it together with
the manifold.
The lower spray arm may be removed
by pulling it upwards and rotating it an-
ti-clockwise. Mounting back the spray
arm is by pulling it down and rotating it
clockwise.
CUTLERY RACK
The third rack was designed to house the cutlery.
Arrange the cutlery as shown in the gure.
A separate arrangement of the cutlery makes
collection easier after washing and improves
washing and drying performance.
Knives and other utensils with sharp edges
must be positioned with the blades facing
downwards.
UPPER RACK
Load delicate and light dishes: glasses, cups,
saucers, low salad bowls.
The upper rack has tip-up supports which can
be used in a vertical position when arranging
tea/ dessert saucers or in a lower position to
load bowls and food containers.
(loading example for the upper rack)
ADJUSTING THE HEIGHT OF THE UPPER RACK
The height of the upper rack can be adjusted: ahigh po-
sition to place bulky crockery in the lower basket and
alow position to make the most of the tip-up supports
by creating more space upwards and avoiding collision
with the items loaded into the lower rack.
We strongly recommend that you do not adjust the
height of the rack when it is loaded. NEVER raise or
lower the basket on one side only.
FOLDABLE FLAPS WITH ADJUSTABLE POSITION
The side foldable aps can be folded or unfolded to opti-
mize the arrangement of crockery inside the rack. Wine
glasses can be placed safely in the foldable aps by insert-
ing the stem of each glass into the corresponding slots.
LOWER RACK
For pots, lids, plates, salad bowls, cutlery etc. Large
plates and lids should ideally be placed at the
sides to avoid interferences with the spray arm.
The lower rack has tip-up supports which can
be used in a vertical position when arranging
plates or in ahorizontal position (lower) to load
pans and salad bowls easily.
(loading example for the lower rack)
EN
4
Quick Guide
In case your dishwasher doesn’t work properly, check if the problem can be solved by going through the following list. For other errors or is-
sues please contact authorized After-sales Service whose contact details can be found in the warranty booklet. Spare parts will be available
for aperiod of either up to 7 or up to 10 years, according to the specic Regulation requirements.
PROBLEMS POSSIBLE CAUSES SOLUTIONS
Descale
indicator is lit
or blinking;"dES"
alarm is displayed.
Limescale is accumulating on internal components
of the appliance.
Descale the appliance immediately using the Self Clean program and acommercially available
descaling product (see OPTIONS AND FUNCTIONS). Rell the reservoir with salt. Check the water
hardness setting. If the appliance is not descaled, it will stop functioning.
The dishwasher
won’t drain.
Display shows:
F7 E3 or F9 E1
The lter is clogged with food residues or
limescale
Clean the lter and descale the appliance (see CLEANING THE FILTER ASSEMBLY and DESCALE
INSTRUCTION).
The drain hose is kinked. Check the drain hose (see INSTALLATION INSTRUCTION).
The sink drain pipe is blocked. Clean the sink drain pipe.
The dishwasher
does not ll the
water.
The display shows:
H
2
O and is
lit; acoustic alarm
sounds.
No water in the water supply or the tap is closed. Make sure there is water in the water supply and the water tap is open.
The water inlet hose is kinked.
Check the inlet hose (see INSTALLATION). Open dishwasher door, press START/Pause button and
close the door within 4 seconds.
The screen in the water inlet hose is clogged; it is
necessary to clean it.
Check and clean the screen in the water inlet hose. Open dishwasher door, press START/Pause
button and close the door within 4 seconds.
The dishwasher
nishes the cycle
prematurely.
The display shows:
F8 E3
The lter is clogged with food residues or limes-
cale.
Clean the lter and descale the appliance (see CLEANING THE FILTER ASSEMBLY and DESCALE
INSTRUCTION).
Drain hose positioned too low or siphoning into
the home sewage system.
Check if the end of the drain hose is placed at the correct height (see INSTALLATION). Check for
siphoning into the home sewage system, and install a siphon breaker/air admittance valve if neces-
sary.
An excessive amount of foam is present.
The detergent has not been measured out correctly or it is not suitable for use in dishwashers
(see FILLING THE DETERGENT DISPENSER).
Air in the water supply. Check water supply for leaks or other issues letting air inside.
The dishes are not
dried well.
Rinse aid is not present or the dosage is too low.
Make sure the rinse aid dispenser is lled (see FILLING THE RINSE AID DISPENSER). Multifunctional
tablets only will not provide as good drying eects as the actual use of liquid rinse aid.
The dishes have been unloaded after the door
was opened automatically but before the actual
cycle end.
Make sure the cycle has ended before starting to unload the dishes (see DAILY USE). For even
better drying results, it is recommended to let the dishes sit inside the dishwasher with the door
open for additional 15 minutes after the cycle ends.
The dishes are sitting too at.
If you notice puddles of water inside cavities of cups, mugs or bowls, try loading the dishes (es-
pecially in the upper rack) providing more inclination to let larger amounts of water drip down
before drying starts.
The selected cycle does not have the drying
phase.
Please check in the PROGRAMS TABLE if the selected program is equipped in the drying phase.
Acycle without the drying phase may not deliver desired drying eciency, so it is recommend-
ed to change cycle selection for the one that has the drying phase.
The dishes are made of non-stick or plastic. Some water drops remaining on this type of material are normal.
Dishes and glasses
are covered with
limescale or a whit-
ish lm.
The salt reservoir is empty.
Rell the reservoir with salt as soon as possible. Using the appliance without salt may cause
damage to its internal components.
The water hardness setting is too low.
Increase the setting (see WATER HARDNESS TABLE).
The cap of the salt reservoir is not properly closed.
Check and close the salt reservoir cap.
The rinse aid reservoir is empty or the rinse aid
dosage is insucient.
Rell the dispenser with rinse aid and check the dosage setting (for more information
- see FILLING THE RINSE AID DISPENSER).
The dishwasher
shows F8 E5
Valve is blocked or faulty. Close the water tap, if possible. Do not switch o the power supply. Call the service.
Detergent leaks.
Depends on the liquid detergent used and
can be emphasized in case of delay option is
activated.
Small leaks will not cause machine malfunction and can be avoided by changing liquid deter-
gent type or using tablets.
TROUBLESHOOTING
Please scan the QR code on your product in order to have more detailed information.
Policies, standard documentation, ordering of spare parts and additional product information can be found by:
• Using QR code on your product.
• Visiting our website docs.hotpoint.eu and parts-selfservice.europeanappliances.com
• Alternatively, contact our After-sales Service (See phone number in the warranty booklet).
When contacting our After-sales Service, please state the codes provided on your product’s identication plate.
The model information can be retrieved using the QR-Code reported in the energy label.
The label also includes the model identier that can be used to consult the portal of the registry at https://eprel.ec.europa.eu.
IEC 436
:
400020021888
03/2025 dk - Xerox Fabriano
