Installaon Steps and Precauons:
Nominal Impedance
Frequency Response (-3dB)
Power Handling (RMS)*
Power Handling (Peak)*
Recommended Power (RMS)*
Recommended High Pass Filter
Free Air Resonance (Fs)
*With Recommended High Pass FIlter
Specificaons and Recommendaons:
Dimensions:
Fitment Informaon:
Limited Warranty (USA): Audiofrog GS Series products sold in the USA through authorized
Audiofrog dealers are warranted to the original purchaser against defects in materials and
workmanship for one year aer the date of original purchase. They are warranted for an addional
year if they are installed by an authorized Audiofrog dealer. Please save your receipt. A valid receipt
from an authorized Audiofrog dealer is required for warranty service. If you purchased your GB
Series products outside the USA, please consult your local distributor for warranty terms and
condions.
Audiofrog and the Audiofrog logo are trademarks of Audiofrog, Inc, registered in the United States
and/or other countries. Audiofrog et le logo sant des marques est une marque commerciale de
Audiofrog, Inc déposée aux Étas-Unis et/ou dans d’autres pays.
Audiofrog, Inc. 419 S. Mission Dr. San Gabriel, CA 91776 +1 (707) 600-FROG
www.audiofrog.com
GS10OE-0003
4Ω
1.8kHz - 20kHz
70W
200W
15W - 75W
3500Hz, 24dB/Oct
1500Hz
Removal of OE tweeter:
• Gently pull up the foam cover piece inside the
BMW housing to expose the BMW tweeter.
DOn’t destroy the foam. You’ll need it later.
• Then, carefully pry open the tabs holding the
BMW tweeter in place.
Installaon of Audiofrog OE tweeter:
• Posion the Audiofrog tweeter with the bevel
toward the top and the holes are aligned with
the BMW housing tabs.
• Then, gently press the Audiofrog tweeter
securely into place.
• Press BMW foam back into place. Secure
with addional glue, if necessary.
19.5 mm
14.0 mm
44.3 mm
43.1 mm
44.3 mm
Verified Fit:
• BMW models aer 2003 that have tweeters in sail
panel locaon.
Unverified but May Fit:
• Unknown
Please check your car’s tweeter locaon and housing
dimensions to confirm that the GS10OE-0003 will fit.
