Installaon Steps and Precauons:
Nominal Impedance
Frequency Response (-3dB)
Power Handling (RMS)*
Power Handling (Peak)*
Recommended Power (RMS)*
Recommended High Pass Filter
Free Air Resonance (Fs)
*With Recommended High Pass FIlter
Specificaons and Recommendaons:
Dimensions:
Fitment Informaon:
Limited Warranty (USA): Audiofrog GS Series products sold in the USA through authorized
Audiofrog dealers are warranted to the original purchaser against defects in materials and
workmanship for one year aer the date of original purchase. They are warranted for an addional
year if they are installed by an authorized Audiofrog dealer. Please save your receipt. A valid receipt
from an authorized Audiofrog dealer is required for warranty service. If you purchased your GB
Series products outside the USA, please consult your local distributor for warranty terms and
condions.
Audiofrog and the Audiofrog logo are trademarks of Audiofrog, Inc, registered in the United States
and/or other countries. Audiofrog et le logo sant des marques est une marque commerciale de
Audiofrog, Inc déposée aux Étas-Unis et/ou dans d’autres pays.
Audiofrog, Inc. 419 S. Mission Dr. San Gabriel, CA 91776 +1 (707) 600-FROG
www.audiofrog.com
GS10OE-0012
4Ω
1.8kHz - 20kHz
70W
200W
15W - 75W
3500Hz, 24dB/Oct
1500Hz
Removal of OE tweeter:
• Carefully pull back the plasc tabs to unhook
the OE tweeter from the Bose grill. Make sure
to not break the plasc.
Installaon of Audiofrog OE tweeter:
• Posion the Audiofrog tweeter so that the
teeth of the frame align with the holes in the
tabs of the plasc Bose mount.
• Then press down firmly to clip into place.
Verified Fit:
• 2007-2013 Chevy Silverado and GMC Sierra trucks
with Bose systems.
Unverified but May Fit:
• Other GMC and Chevy trucks between 2007-2013
with Bose systems where the tweeters are in the A
pillars.
Please check your car’s tweeter locaon and housing
dimensions to confirm that the GS10OE-0012 will fit.
40 mm
32.1 mm
21.2 mm
11.2 mm
