FLOOR BIKE RACK
MODEL: XSJ20-T02
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and does not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.
- 1 -
MODEL: XSJ20-T02
Have product questions? Need technical support? Please feel free to
contact us:
Technical Support and E-Warranty Certificate
www.vevor.com/support
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
FLOOR BIKE RACK
- 2 -
IMPORTANT SAFEGUARDS
WARNING: Read and understand this entire manual before
operating or servicing this product. Failure to follow these
warnings and instructions can cause personal injury or
damage to valuable property.
Avoid children using floor bike rack. And this product is not a toy. Do not
allow children to play.
Keep away from sharp points,blades and other items.
Assembly precautions
1. Assemble only according to these instructions. Improper assembly can
create hazards.
2. Wear ANSI-approved safety goggles and heavy-duty work gloves during
assembly.
3. Keep assembly area clean and well-lit.
4. Keep bystanders out of the area during assembly.
5. Do not assemble when tired or when under the influence of alcohol,
drugs or medication.
6. Product capabilities apply to properly and completely assembled product
only.
7. For additional information regarding the parts listed in the following
pages, please refer to the Assembly Diagram of this manual. Unwrap and
separate all parts in a clean work area. Please keep small spare parts out
of children's reach.
SAVE THESE INSTRUCTIONS
PRODUCT SPECIFICATIONS:
Model#
L
(mm)
W
(mm)
H
(mm)
Number of bikes stored
XSJ20-T02
1600
970
780
10
- 3 -
PACKAGE INCLUDE
Part
Description
Qty
1
middle grid A
1
2
middle
grid
B
1
3
sidepiece
2
4
joint pipe A
2
5
joint pipe B
2
6
pipe plug
12
7
Bolt M6×12
4
8
Bolt M6×90
8
9
Washer φ6
8
10
Nut M6
8
11
tapeline
1
12
cross-head screwdriver
1
- 4 -
SIMPLE INSTRUCTION
Address：Baoshanqu Shuangchenglu 803long 11hao 1602A-1609shi Shanghai
EC REP: SHUNSHUN GmbH. Römeräcker 9 Z2021,76351
Linkenheim-Hochstetten, Germany
UK REP：Pooledas Group Ltd. Unit 5 Albert Edward House, The Pavilions Preston,
United Kingdom
Imported to AUS: SIHAO PTY LTD. 1 ROKEVA STREETEASTWOOD NSW 2122
Australia
Imported to USA: Sanven Technology Ltd. Suite 250, 9166 Anaheim Place,
Rancho Cucamonga, CA 91730
Made In China
Step1:Connect the middle grid A
and B, align it with the mounting
hole, and tighten it using m6*12
screw
Step2:Connect the
joint pipe A
and
B, align it with the mounting hole,
and tighten it using m6*12 screw
Step3:Connect the sidepiece pipe ,
align it with the mounting hole, and
tighten it using m6*90 screw,Washer
φ6 and Nut M6.
Step4:Cover the pipe plug.
