Installaon Steps and Precauons:
Nominal Impedance
Frequency Response (-3dB)
Power Handling (RMS)*
Power Handling (Peak)*
Recommended Power (RMS)*
Recommended High Pass Filter
Free Air Resonance (Fs)
*With Recommended High Pass FIlter
Specificaons and Recommendaons:
Dimensions:
Fitment Informaon:
Limited Warranty (USA): Audiofrog GBSSeries products sold in the USA through authorized
Audiofrog dealers are warranted to the original purchaser against defects in materials and
workmanship for one year aer the date of original purchase. They are warranted for an addional
year if they are installed by an authorized Audiofrog dealer. Please save your receipt. A valid receipt
from an authorized Audiofrog dealer is required for warranty service. If you purchased your GB
Series products outside the USA, please consult your local distributor for warranty terms and
condions.
Audiofrog and the Audiofrog logo are trademarks of Audiofrog, Inc, registered in the United States
and/or other countries. Audiofrog et le logo sant des marques est une marque commerciale de
Audiofrog, Inc déposée aux Étas-Unis et/ou dans d’autres pays.
Audiofrog, Inc. 419 S. Mission Dr. San Gabriel, CA 91776 +1 (707) 600-FROG
www.audiofrog.com
GS10OE-0007
4Ω
1.8kHz - 20kHz
70W
200W
15W - 75W
3500Hz, 24dB/Oct
1500Hz
Removal of OE tweeter:
• Remove the 3 screws from the tweeter frame
and remove the tweeter.
Installaon of Audiofrog OE tweeter:
• Screw in the Audiofrog tweeter with the same
3 screws.
Verified Fit:
• 2002-2010 Porsche 955, 957, and Cayenne models
with Bose systems.
Unverified but May Fit:
• Other Porsche models with Bose systems that have
tweeters in the rears.
Please check your car’s tweeter locaon and housing
dimensions to confirm that the GS10OE-0007 will fit.
17.3 mm
4 mm
104 mm
5 mm
