THANK YOU
We appreciate the trust and condence you have placed in Hampton Bay through the purchase of this light xture. We strive to continually
create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement
needs. Thank you for choosing Hampton Bay!
USE AND CARE GUIDE
CADE 3-LIGHT VANITY FIXTURE
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Item #1001220862
Model #NB33307
2
Table of Contents
Table of Contents ............................2
Safety Information ............................2
Warranty ..................................2
Pre-Installation .............................. 3
Planning Installation ...............................3
Tools Required ....................................3
Hardware Included .................................3
Package Contents .................................4
Installation .................................5
Operation .................................. 6
Care and Cleaning ............................ 6
Troubleshooting .............................6
Safety Information
□ Consult a qualied electrician if you have any electrical
questions.
CAUTION: Inspect the wire insulation for any cuts,
abrasions, or exposed copper that may have resulted during
shipping. If there is a defect in the wire, do not attempt
installation. Please call our Customer Service Team at
1-855-HD-HAMPTON.
WARNING: Before starting installation of this xture
or removal of a previous xture, disconnect the power by
turning off the circuit breaker or by removing the fuse at the
fuse box.
Warranty
The manufacturer warrants this lighting xture to be free from defects in materials and workmanship for a period of two (2) years from
date of purchase. This warranty applies only to the original consumer purchaser and only to products used in normal use and service. If
this product is found to be defective, the manufacturer’s only obligation, and your exclusive remedy, is the repair or replacement of the
product at the manufacturer’s discretion, provided that the product has not been damaged through misuse, abuse, accident, modications,
alterations, neglect, or mishandling. This warranty shall not apply to any product that is found to have been improperly installed, set-up,
or used in any way not in accordance with the instructions supplied with the product. This warranty shall not apply to a failure of the
product as a result of an accident, misuse, abuse, negligence, alteration, faulty installation, or any other failure not relating to faulty material
or workmanship. This warranty shall not apply to the nish on any portion of the product, such as surface and/or weathering, as this is
considered normal wear and tear. The manufacturer does not warrant and specially disclaims any warranty, whether express or implied,
of tness for a particular purpose, other than the warranty contained herein. The manufacturer specically disclaims any liability and
shall not be liable for any consequential or incidental loss or damage, including but not limited to any labor / expense costs involved in the
replacement or repair of said product.
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.HAMPTONBAY.com.
3 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Pre-Installation
PLANNING INSTALLATION
□ Read all instructions before installation.
□ This xture can be installed as an up-light or as a down-light.
□ To avoid damaging this product, assemble it on a soft, non-abrasive surface, such as carpet or cardboard.
□ Keep your receipt and these instructions for proof of purchase.
TOOLS REQUIRED
Ladder
Safety
goggles
Electrical
tape
Phillips
screwdriver
Flat blade
screwdriver
Pliers
Wire
strippers
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
AA CC BB
Part Description Quantity
AA Mounting bracket 1
BB Mounting screw 2
CC Wire nut 3
4
Pre-Installation (continued)
PACKAGE CONTENTS
C
B
A
Part Description Quantity
A Light xture 1
B Socket ring 3
C Shade 3
5 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Installation
1
Attaching the mounting bracket to the
junction box
□ Remove the preinstalled cap nut from the mounting unit
(AA) and put it in a safe location.
□ Attach mounting unit (AA) to the junction box (not included)
with mounting screws (BB).
NOTE: The preinstalled support screws on the mounting
unit (AA) should protrude out away from the junction box.
BB
AA
2
Making the electrical connections
□ Connect the copper wire on the light xture (A) to the
mounting bracket (AA) by securing it with the preinstalled
ground screw.
□ Connect the black to black (power), the white to white
(neutral) and copper wire to ground wire with the wire
nuts(CC) and secure with electrical tape (not included).
NOTE: If the wires from the xture are the same color,
attach the side with markings or letters to the black
(positive) wire and the other to the white (neutral) wire.
CC
3
Securing the light xture
□ Secure the light xture (A) to the junction box by placing it
over the preinstalled pipe nipple on the mounting unit (AA)
and securing with the previously removed cap nut.
□ Remove the preinstalled socket ring (B), add shade (C) and
re-secure the socket ring (B).
NOTE: Light xture (A) can be installed with the socket
facing either up or down.
A
C
B
4
Installing the light bulbs
□ Install three 60-watt max. medium- base incandescent
bulbs or three 13-watt max. CFL bulbs (none included).
6
Operation
1
Secure the light xture
□ Turn the light switch on to activate the xture.
Care and Cleaning
□ Clean the lamp with a soft, dry cloth.
□ Do not use any cleaners with chemicals, solvents, or harsh abrasives.
Troubleshooting
Problem Possible Cause Possible Cause
The bulb will not light. The bulb is burned out. Replace the light bulb.
The power is off. Ensure the power supply is On.
There is a faulty wire connection. Check the wiring.
The circuit breaker is off. Ensure the circuit breaker is in the ON position.
The fuse blows or circuit
breaker trips when the
light is turned on.
There are crossed wires or the
power wire is grounding out.
Check the wire connections.
Contact a qualied electrician or call the Customer Service Team at
1-855-HD-HAMPTON.
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Retain this manual for future use.
