Safety Instructions
Product May Vary
Slightly From Pictured.
When calling for parts or
service, please specify the
following model number:
50
-
0050C
MADE IN CHINA
2020 Stamina Products, Inc.
2020, 11
Safety Instructions
Customer Care
Warranty
1. Save these instructions and ensure that other exercisers read this manual prior to using the Doorway Trainer
Plus for the rst time.
2. Read this Owner’s Manual and follow it carefully before using the Doorway Trainer Plus.
3. Keep children away from the Doorway Trainer Plus. Do not allow children to use or play around the
Doorway Trainer Plus. Keep children and pets away from the Doorway Trainer Plus when it is in use.
4. The equipment can be used only if it is examined regularly for damage and wear. Before using, inspect the
Doorway Trainer Plus for worn or loose components, and securely tighten or replace any worn or loose
components prior to use. Please replace defective components immediately and keep the equipment out of
use until repair. Contact customer care (specic information is as below) for repair or component replacement.
5. Before use, carefully read and understand all of the directions of the Doorway Trainer Plus for proper
installation. Also, make sure the door frame and moldings are secure and solid before installing Doorway
Trainer Plus. A weak door frame and/or moldings can cause the unit to fail and dislodge from the doorway.
6. Before using the Doorway Trainer Plus, tug down on the Handlebars to make sure the unit is securely
installed into the door frame.
7. As the Doorway Trainer Plus is not designed for permanent installation, remove it from the door frame and
store away in a safe place until next use.
8. Injuries may result from incorrect or excessive training. Consult a physician prior to commencing an exercise
program. If at any time during exercise you feel faint, dizzy, or experience pain, stop and consult your
physician.
9. Always choose the workout which best ts your physical strength and exibility level. Know your limits and
train within them. Always use common sense when exercising.
10. Do not wear loose or dangling clothing while using the Doorway Trainer Plus.
11. The Doorway Trainer Plus should not be used by persons weighing over 250 pounds.
12. The Doorway Trainer Plus should only be used by one person at a time.
13. The Doorway Trainer Plus is for consumer use only. It is not for use in public or semipublic facilities.
14. The Doorway Trainer Plus has a total mass and dimension of: 37” x 15.25” x 12” weighing 7.0 lbs.
Owner's Manual
!
WARNING
Cancer and Reproductive Harm www.P65Warnings.ca.gov
!
WARNING
This equipment is for home use only. Do not use in institutional or commercial
applications. Failure to follow this warning could result in death or serious injury.
!
WARNING
To reduce the risk of serious injury, read the following Safety Instructions before
using the
Doorway Trainer Plus
.
This Product is Distributed Exclusively by
2040 N Alliance Ave, Springeld, MO 65803
Customer Care
1 (800) 375-7520
customer[email protected]
www.staminaproducts.com
Quickstart Guide
Go to the App Store on your device or
scan the QR Code for quick access.
Smart Audio Workouts for Your Door Gym
Download the app and get moving!
IMPORTANT
Apple, the Apple logo, iPhone, and iPod touch are trademarks of Apple Inc., registered in the U.S. and other countries. App Store is a service
mark of Apple Inc., registered in the U.S. and other countries. Google Play and the Google Play logo are trademarks of Google LLC.
Assembly video included in app.
Assembly Instructions
3
STEP 2: Insert the INNER BAR(2) into the OUTER BAR(1) and secure with
BUTTON HEAD BOLT(M6x1x15mm)(15).
STEP 3: Refer to the illustration below. Insert the HANDLEBARS(4)
into the ARCHED SUPPORTS(3) and secure with CARRIAGE
BOLTS(M6x1x33mm)(12), LOCK WASHERS(M6)(16), and ACORN
NUTS(M6x1)(17).
STEP 4: Bolt the ARCHED SUPPORTS(3), HANDLEBARS(4), OUTER
BAR(1), and INNER BAR(2) together with CARRIAGE BOLTS
(M6x1x58mm)(13), LOCK WASHERS(M6)(16), and ACORN NUTS
(M6x1)(17). Tighten all bolts from STEP 1 to STEP 4.
NOTE:
Do not tighten any bolts until STEP 4.
STEP 1
Attach the ARCHED SUPPORTS(3)
to the PLASTIC BAR(5) with
CARRIAGE BOLTS(M6x1x45mm)
(14), LOCK WASHERS(M6)(16), and
ACORN NUTS(M6x1)(17).
Product Parts Drawing and Parts List
4
1
2
3
4
5
6
7
8
9
10
11
Part No. and Description Qty Part No. and Description Qty
12
13
14
15
16
17
18
19
20
21
22
Outer Bar 1
Inner Bar 1
Arched Support 2
Handlebar 2
Plastic Bar 1
EVA Pad 1
Foam Tube 2
Foam Grip 2
Hand Grip 4
Foam Pad 2
Endcap (25.4mm) 2
Carriage Bolt (M6 x 1 x 33mm) 2
Carriage Bolt (M6 x 1 x 58mm) 4
Carriage Bolt (M6 x 1 x 45mm) 2
Bolt, Button Head (M6 x 1 x 15mm) 1
Lock Washer (M6) 8
Acorn Nut (M6 x 1) 8
Round Plug (25.4mm) 4
Safety Wedge 1
Wrench 1
Allen Wrench (5mm) 1
Owner's Manual 1
Limited Warranty
5
MODEL 50-0050C
Stamina Products, Inc. (“Stamina”) warrants to the original purchaser that this product
will be free from defects in materials and workmanship that arise under normal use,
service, proper assembly and proper operation in accordance with product warnings/
instructions for a period of 90 days on the parts and one year on the frame from the date
of the original purchase from an authorized retailer. THIS WARRANTY SHALL NOT
APPLY TO ANY PRODUCT WHICH HAS BEEN SUBJECT TO COMMERCIAL USE,
ABUSE, MISUSE, ALTERATION OF ANY KIND OR TO ANY DEFECT OR CHANGE
CAUSED BY IMPROPER ASSEMBLY, REPAIR, REPLACEMENT, SUBSTITUTION
OR USE WITH PARTS NOT PROVIDED BY STAMINA. Commercial use includes use
of product in athletic clubs, health clubs, spas, gyms, and all other public or semipublic
facilities whether or not the product’s use is in furtherance of a prot making enterprise,
and all other use which is not for personal purposes.
To implement this limited warranty, send a written notice stating your name, date, and
place of purchase and a brief description of the defect along with your receipt to Stamina
Products, Inc. 2040 N Alliance Ave, Springeld, Missouri, USA, MO 65803, or email us
at customer[email protected], or call us at 1-800-375-7520. If the defect is
covered under this limited warranty, you will be requested to return the product or part to
us for free repair or replacement at our option.
NO ACTION FOR BREACH OF THIS LIMITED WARRANTY MAY BE COMMENCED
MORE THAN ONE (1) YEAR AFTER THE DATE THE ALLEGED BREACH WAS OR
SHOULD HAVE BEEN DISCOVERED. NO ACTION FOR BREACH OF ANY IMPLIED
WARRANTY (INCLUDING MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE) MAY BE COMMENCED MORE THAN ONE (1) YEAR AFTER DELIVERY
OF THE PRODUCT TO THE PURCHASER. These warranties are not transferable.
IF ANY PART OF THE PRODUCT IS NOT IN COMPLIANCE WITH THIS LIMITED
WARRANTY OR ANY IMPLIED WARRANTY, THE REMEDY OF REPAIR OR
REPLACEMENT IS THE EXCLUSIVE REMEDY. If any claim is made under this limited
warranty or any implied warranty, Stamina reserves the right to require the product to be
returned for inspection, at the purchaser’s expense, to Stamina’s premises in Springeld,
Missouri. Return of the enclosed warranty registration card is not required for warranty
coverage, but is merely a way of establishing the date and place of purchase.
Stamina SHALL NOT BE LIABLE FOR THE LOSS OF USE OF ANY PRODUCT, LOSS
OF TIME, INCONVENIENCE, COMMERCIAL LOSS OR ANY OTHER INDIRECT,
CONSEQUENTIAL, SPECIAL OR INCIDENTAL DAMAGES DUE TO BREACH OF
THE ABOVE WARRANTY OR ANY IMPLIED WARRANTY.
THIS LIMITED WARRANTY IS THE ONLY EXPRESS WARRANTY. NO ORAL OR
WRITTEN INFORMATION GIVEN BY STAMINA, ITS AGENTS OR EMPLOYEES,
SHALL CREATE A WARRANTY OR IN ANY WAY INCREASE THE SCOPE OF THIS
WARRANTY. This warranty gives you specic legal rights, and you may also have other
legal rights which vary from state to state. ANY OTHER RIGHT WHICH YOU MAY
HAVE, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE, IS LIMITED IN DURATION TO THE DURATION OF
THIS WARRANTY.
The laws in some states affect the disclaimer or limitation of implied warranties and
consequential and incidental damages. If any such law is found applicable, the foregoing
disclaimers and limitations of and on implied warranties and consequential and
incidental damages shall be deemed to be modied to the extent necessary to comply
with applicable law.
