Vital 100S-P
Smart Air Purifier
Questions or Concerns?
Please contact us Mon–Fri, 9:00 am–5:00 pm PST/PDT
at [email protected] or at 1-888-726-8520.
USER MANUAL
2
Table of Contents
Package Contents
Specifications
Safety Information
Getting to Know Your Smart Air Purifier
Controls & Display
Getting Started
Using Your Smart Air Purifier
About the Filter
Care & Maintenance
Troubleshooting
Warranty Information
Customer Support
2
2
3
5
6
7
10
14
16
20
24
26
Package Contents
1 x Smart Air Purifier
1 x Washable Pre-Filter (Pre-Installed)
1 x The Main / Activated Carbon Filter
(Pre-Installed)
1 x User Manual
1 x Quick Start Guide
1 x AC Power Adapter
Specifications
Model LAP-V102S-AUSR
Power Supply 24V 1.5A
Rated Power 32W
Operating
Conditions
Temperature: 14°–104°F /
-10°–40°C
Humidity: ≤ 85% RH
Dimensions 12.6 x 6.3 x 16.0 in /
32.1 x 16.0 x 40.6 cm
Weight 8.6 lb / 3.9 kg
Power
Adapter
Input: 100–240V
50/60Hz
Output: 24V 1.5A
Note: To access additional smart functions,
download the free VeSync app (see page 9).
~
3
SAFETY INFORMATION
• Only use your air purifier as described in
this manual.
• Do not use without removing the plastic
wrap from the filter. The air purifier will not
filter air and may overheat, causing a fire
hazard.
• Do not use your air purifier outdoors.
• Keep your air purifier away from water,
and wet or damp areas. Never place in
water or liquid.
• Do not use in excessively humid areas.or
near humidifiers
• Keep your air purifier away from heat
sources.
• Do not use where combustible gases,
vapors, metallic dust, aerosol (spray)
products, or fumes from industrial oil are
present.
• At least keep 5 ft / 1.5 m away from where
oxygen is being administered.
• Children should be supervised to ensure
that they do not play with the air purifier.
• Do not allow children to play with the
plastic packaging. Immediately discard the
plastic after unwrapping the filter.
• Do not place anything into any opening
on the air purifier.
• Children should be supervised to ensure
they do not insert fingers or objects into
the vent openings.
• WARNING: To Reduce The Risk Of Fire,
Electric Shock Or Injury To Persons, Do
Not Use Replacement Parts That Have Not
Been Recommended By The Manufacturer
(e.g. Parts Made At Home Using A 3D
Printer).
To reduce the risk of fire, electric shock, or other injury, follow all instructions and safety
guidelines.
General Safety
READ AND SAVE THESE
INSTRUCTIONS
• Do not sit or place heavy objects on the
air purifier.
• Keep the inside of the air purifier dry. To
prevent moisture buildup, avoid placing in
rooms with major temperature changes.
• Always unplug your air purifier before
servicing, cleaning or any other
maintenances (such as changing the filter).
• Do not use your air purifier if it is
damaged or not working correctly, or if
the cord or plug is damaged. Do not try
to repair it yourself. Contact Customer
Support (see page 26).
• WARNING: To reduce the risk of fire or
electric shock, do not use this air purifier
with any solid-state speed controls (such
as a dimmer switch).
• Children should not clean or perform
maintenance on the air purifier without
supervision.
• This air purifier is not to be used by
persons (including children) with reduced
physical, sensory, or mental capacities,
or lack of experience and knowledge,
unless they have been given supervision
or instruction concerning the use of the
appliance by a person responsible for their
safety.
• Not for commercial use. Household use
only.
4
SAFETY INFORMATION (CONT.)
Electromagnetic Fields (EMF)
Your Levoit air purifier complies with all
standards regarding electromagnetic fields
(EMF). If handled properly and according to the
instructions in this user manual, the appliance
is safe to use based on scientific evidence
available today.
Power Adapter & Cord
• Keep the air purifier near the outlet it is
plugged into.
• Never place the cord near any heat source.
• Do not cover the cord with a rug, carpet, or
other covering. Do not place the cord under
furniture or appliances.
• Keep the cord out of areas where people
walk often. Place the cord where it will not
be tripped over.
• This air purifier is only to be used with the
power supply adapter provided with the air
purifier
• If the power adapter cord is damaged, it
must be replaced by Arovast Corporation or
similarly qualified persons in order to avoid
an electric or fire hazard. Please contact
Customer Support (see page 26).
• This air purifier’s power adapter uses
standard North American 120V, 60Hz
outlets. If using outside the US or Canada,
check for compatibility.
• Unplugging the power adapter will disable
remote control of the air purifier and
temporarily disconnect the air purifier from
VeSync and other third-party apps.
5
GETTING TO KNOW YOUR SMART AIR PURIFIER
A. Check Filter Indicator
B. Fan Speed Indicators
C. Auto Mode Button
D. On/O Button
E. Wi-Fi® Indicator
F. Display Lock Indicator
G. Timer Indicators
H. Light Sensor
I. Sleep Mode Button
J. Fan Speed Button
K. Air Quality Indicator
L. Display Lock Button
M. Timer Button
N. Pet Mode Button
O. Front Cover
P. Washable Pre-Filter
Q. The Main / Activated Carbon Filter
R. AirSight™ Infrared Dust Sensor
S. Dust Sensor Cover
T. Power Adapter Input
U. Power Adapter
A
J
B
I
C D E
K
F
L
G
M
H
N
U
R
QO P
S
T
6
CONTROLS & DISPLAY
Auto Mode Button
• Turns Auto Mode on (see
page 10).
On/O Button
• Turns the air purifier on/o.
• Press and hold for 5
seconds to connect the air
purifier to the VeSync app.
See the in-app instructions
for more information (see
page 9).
• Press and hold for 15
seconds to reset the air
purifier and disconnect from
Wi-Fi® (see page 9).
Wi-Fi Indicator
• Blinks when connecting
to the VeSync app, lights
up when connected to
VeSync, and is o when
disconnected from
VeSync. See the VeSync
in-app instructions for more
information (see page 9).
Sleep Mode Button
• Turns Sleep Mode on (see
page 10).
• Press and hold for 3
seconds to reset the Check
Filter Indicator.
Check Filter Indicator
• Lights up red when the filter
should be checked (see
Check Filter Indicator, page
16).
• To reset the Check Filter
Indicator, press and hold
for 3 seconds. The Check
Filter Indicator will flash 3
times, and turn o.
Fan Speed Button & Indicators
• Cycles through fan speeds:
low (1 indicator will light up),
medium (2 indicators), high
(3 indicators), and turbo (4
indicators).
• Tapping while the air
purifier is in Auto Mode,
Sleep Mode, or Pet Mode
(when the display is lit up)
will exit that mode.
Air Quality Indicator
• These indicator rings use
an automatic infrared dust
sensor to display the air
quality: Blue (Very Good),
Green (Good), Orange
(Moderate), Red (Bad).
Timer Button & Indicators
• Cycles through timer
options: 2 hours, 4 hours,
and 8 hours (see page 11).
Note: You can also use the VeSync app to control these functions, as well as additional
app-only features (see page 13).
Note: The timer indicators
will light up with the
corresponding timer selected.
• lights up when the timer
function is used through the
VeSync app.
7
Display Lock Button &
Indicator
• Prevents current settings
from being changed (see
page 12). Press and hold
for 3 seconds to lock and
unlock the display.
Pet Mode Button
• Turns Pet Mode on (see
page 12).
CONTROLS & DISPLAY (CONT.)
Light Sensor
The Light Sensor detects the
amount of light in the room to
automatically adjust the air purifier
settings (see Light Detection,
page 11).
• Light Detection can be turned
on/o in the VeSync App.
• Press and hold display
button for 3 seconds
also turns on/o the light
detection function.
Note: Display Lock can also
be controlled through the
VeSync app.
GETTING STARTED
1. Place the air purifier on a flat, stable
surface such as the floor.
2. Pull both sides of the front cover to
remove it. [Figure 1.1]
Figure 1.1
3. Push the pre-filter’s tabs downward and
pull to remove the pre-filter from the air
purifier. [Figure 1.2]
• The Display Lock Indicator
will light up when the
display is locked and blink
when any other button
is tapped to indicate the
display is locked.
Figure 1.2
8
GETTING STARTED (CONT.)
Note: Make sure the Main filter (the side with the
ribbon handle) is facing outward when you insert
the filter. [Figure 1.4]
4. Remove the Main / Activated Carbon
Filter from inside the air purifier.
5. Remove the plastic packaging from the
filter and place the filter and the pre-filter
back into the air purifier. [Figure 1.3]
Figure 1.3
Figure 1.5
Figure 1.4
Figure 1.6
Figure 1.7
6. Place the front cover on the air purifier.
Make sure to align the tabs on the cover
with the slots on the bottom of the air
purifier. [Figure 1.5]
7. Insert the power adapter plug into the
back of the air purifier. [Figure 1.6]
8. When using the air purifier, allow at least
15 inches / 38 cm of clearance from the
front of the air purifier. Keep away from
anything that would block air flow, such
as curtains. [Figure 1.7]
MIN
15 in /
38 cm
9
• To disconnect Wi-Fi®, press and hold for
15 seconds until the Wi-Fi indicator turns
o. This will restore the smart air purifier’s
default settings and disconnect it from the
VeSync app.
• To reconnect, please follow the instructions
in the VeSync app for adding a device.
Note: You must create your own VeSync account
to access voice assistants.
Note: For Android™ users, choose “Allow” to
use VeSync.
Note: You must create your own VeSync
account to use third-party services and
products. These will not work with a guest
account. With a VeSync account, you can
also allow your family and friends to control
your smart air purifier.
Note: Your phone must have Location
turned on while your phone is connecting to
your smart air purifier. This is required to
establish the Bluetooth® connection. You
can turn Location o after your smart
air purifier is finished connecting to
the VeSync app.
Note: The VeSync app is continually being
improved and may change over time. If there are
any dierences, follow the in-app instructions.
1. To download the VeSync app, scan the
QR code or search “VeSync” in the Apple
App Store or Google Play Store.
You can use the VeSync app to connect
your smart air purifier to Amazon Alexa or
Google Assistant™. Please follow the in-app
instructions to set up your voice assistant.
VeSync App Setup Wi-Fi® Connection
Connect with Amazon Alexa or
Google Assistant™
2. Open the VeSync app. Log In or Sign
Up.
3. Follow the in-app instructions to set up
your smart air purifier.
10
Sleep Mode operates quietly by using a fan
speed lower than low speed.
1. Tap to turn Sleep Mode on.
2. Sleep Mode will turn o the display after
6 seconds if no other buttons are tapped.
3. To switch from Sleep Mode, tap Auto
Mode, Pet Mode, or select a fan speed
on the air purifier’s display or in the
VeSync app.
Note:
• When the display is turned o, tap
any button to turn the display back
on. If you don’t tap another button,
the display will turn o again after 6
seconds.
• will still turn on and stay on if it’s
time to check your filter (see page
16).
Auto Mode
Sleep Mode
USING YOUR SMART
AIR PURIFIER
1. Plug in and tap to turn on the air
purifier. The fan will start on low.
2. Tap to change fan speed between
low, medium, high, and turbo.
Note:
• The fan speed indicators are not
buttons and only display the fan speed
setting.
• The fan speed indicators will light up
when active, 1 indicator will light up for
low, 2 for medium, 3 for high, and 4 for
turbo.
• Turbo fan speed (4 indicator lights) is
the loudest, but cleans air the quickest.
• For best results, or to address a specific
air quality issue such as smoke, run the
air purifier on turbo for 15–20 minutes
before using a lower speed.
• To eectively clean air, keep windows
and doors closed while the air purifier
is on.
Note: Using the VeSync app allows you to control
your air purifier remotely and access additional
functions and features (see page 13).
Auto Mode uses AirSight™, an infrared dust
sensor inside the air purifier, to adjust the fan
speed automatically based on air quality. For
example, if the air quality is bad, the fan will
automatically be set to high speed.
1. Tap to turn Auto Mode on.
2. will light up while Auto Mode is on.
3. To switch from Auto Mode, tap Sleep
Mode or select a fan speed on the air
purifier’s display or in the VeSync app.
Air Quality Indicator Chart
Indicator
Color
Air
Quality
Auto Mode
Fan Speed
Blue Very Good Sleep Mode
Green Good Low
Orange Moderate Medium
Red Bad High
Note:
• Auto Mode does not use the turbo fan
speed.
• The VeSync app also supports Ecient
Auto Mode and Quiet Auto Mode (see
page 13).
11
USING YOUR SMART AIR PURIFIER (CONT.)
Timer
You can manually set the timer for 2, 4, or 8
hours using the button. You can also set
the timer for 1–24 hours through the VeSync
app.
1. Tap repeatedly to select a time. The
timer will start automatically.
Note:
• The indicators are not buttons and
cannot be used to select a time.
• The timer indicators will light up blue
when active.
• When the timer is set through the
VeSync app, the indicator will light
up instead. Once the timer has finished,
the air purifier will turn o.
Note:
• You can change the fan speed at any
time while the timer is on.
• The timer will restart if the time is
changed.
2. To cancel the timer, tap until all timer
indicators are o. You can also turn the
timer o in the VeSync app.
Light Detection
1. The light sensor is o by default. You
can turn on/o Light Detection in the
Vesync APP. You can also press and hold
display button for 3 seconds to turn on/
o Light Detection, and the air quality
indicator blinks once when the operation
is complete.
2. While the air purifier is operating, the
Light sensor will detect the brightness
of the room and work according to the
ambient light.
Note:
• When the light detection on and room
is in darkness, if the air purifier is in
Auto Mode or Pet Mode, it will not use
the high or turbo fan speed to avoid
making too much noise.
• When the room becomes light again,
the air purifier will return to its previous
setting. The display will automatically
turn back on.
• With the light detection on, if you click
display o, the screen will stay o;
however, you can’t get the screen to
stay on in a dark room.
Room light Display
Dark
Display o
Light Display on
12
Memory Function
Standby Mode
Display LockPet Mode
When the air purifier is in standby or turned o
and unplugged, it will remember its previous
fan speed, Sleep Mode, Auto Mode, Pet Mode,
and in-app Display and Light Detection settings.
The air purifier is in Standby Mode when it is
turned o, but plugged in.
When the air purifier is on, you can lock
the display to prevent settings from being
accidentally changed. Buttons will not respond
to being tapped.
Pet Mode is ecient at filtering allergens from
the air while conserving energy.
1. Press and hold for 3 seconds to lock
the display. The Display Lock Indicator
will light up above the button.
Note: The air purifier will not remember timers.
Note: If the display is turned o, the Display Lock
Indicator will flash 3 times to show that the display
has been locked, then turn o.
Note:
• In Standby Mode, the infrared dust sensor
will still detect the surrounding air quality
and give you updates in the VeSync app.
• Display Lock (available in the VeSync
app) can be used while the air purifier is in
Standby Mode to keep the air purifier from
being turned back on.
Note:
• If the light sensor detects the room is
dark, the display will turn o and limit
Pet Mode to medium fan speed, to
avoid making too much noise.
• When the light sensor detects that
the room is lit again, Pet Mode will no
longer be limited, and the air purifier
will run at medium fan speed for 30
minutes, then run at high for 15 minutes.
• After this, the normal Pet Mode cycle
will start (15 minutes at high speed, then
60 minutes at medium speed).
USING YOUR SMART AIR PURIFIER (CONT.)
• Tap to turn Pet Mode on.
• will light up while Pet Mode is on.
• The air purifier will run for 15 minutes
at high speed, then 60 minutes at
medium speed, and cycle between
the two fan speeds.
• Pet Mode will stay on unless you
select a dierent mode or fan speed.
• To switch from Pet Mode, tap Auto
Mode, Sleep Mode, or select a fan
speed on the air purifier’s display or
in the VeSync app.
2. The Display Lock Indicator will blink when
any other button is tapped to indicate
that Display Lock is on.
3. Press and hold again for 3 seconds
to unlock the display. The Display Lock
Indicator will turn o.
13
• The VeSync app allows you to access
additional smart air purifier functions,
including those listed below.
• As Vesync App develops, the design,
functions, content, etc., of Vesync
App may be subject to change or be
discontinued without prior notice.
Remote Control
• Change any air purifier settings
through the app, even while Display
Lock is on.
Air Quality Updates
• View real-time air quality updates in
the app.
• See your air quality history for the
previous 4 weeks.
VeSync App Functions
USING YOUR SMART AIR PURIFIER (CONT.)
Auto Mode
Access additional auto modes: Quiet Auto
Mode and Ecient Auto Mode.
• Quiet Auto Mode uses the medium
fan speed (2 indicator lights) instead
of the high or turbo fan speeds, even
when the air quality is poor, to avoid
making too much noise.
• Ecient Auto Mode lets you choose
the size of the area you want to
purify. The air purifier will use the
turbo fan speed to clean the air for a
designated amount of time. This time
is based on 1 ACH and the size of
the room, meaning how long it takes
for the air purifier to clean all the air
in your room one time, regardless of
the air quality. After this, the mode
will adjust the fan speed according
to the actual detected air quality in
the room.
Note: Ecient Auto Mode is useful for purifying
odors from the air. The air purifier’s dust sensor
can only detect particles in the air, not smells.
Ecient Auto Mode does not rely on the dust
sensor, but the room size instead.
Note:
• The Check Filter Indicator will still turn on
and stay on if it’s time to check your filter
(see page 16).
• With light detection on, it is unable to keep
the screen lit in a dark room.If you prefer to
keep the display lit up, you can turn o the
light detection by pressing and holding the
display button for 3 seconds or Vesync APP.
Schedules
• Create and customize schedules
for your air purifier to match your
routines.
Display O
• Turns o the display lights on the air
purifier, including button lights and
indicator lights (except the Check
Filter Indicator).
Filter Replacement Info
• Keep tabs on the remaining filter life
by checking the filter life percentage
in the app.
• Shop for replacement filters.
Timer Function
• Set a timer between 1–24 hours.
• Easily view the exact time remaining
on a timer.
14
ABOUT THE FILTER
The air purifier uses a 3-stage filtration system to purify air.
A. Washable Pre-Filter
• Captures large particles such as dust,
lint, fibers, hair, and pet fur.
• Maximizes the filter’s life by
protecting it.
• Removable and washable to increase
filtering eciency (see Cleaning the
Pre-Filter, page 17).
B. The Main Filter
• 99.97% filtration eciency for
0.1–0.3μm airborne particulates,
including pollen, dust, and animal
dander allergens*.
A B C
C. High-Eciency Activated Carbon Filter
• Physically adsorbs smoke, odors, and
fumes.
• Filters compounds such as
formaldehyde, benzene, ammonia,
hydrogen sulfide, and volatile organic
compounds (VOCs).
*Disclaimer: Tested by an independent lab.
15
Moisture may damage the filter. This air
purifier should be used in an area with a
humidity level 85% RH or below. If you use
the air purifier in excessively humid areas, the
surface of the filter may become moldy.
Do not add essential oils to the air purifier or
filter. The filter will become damaged by the
oil and will eventually release an unpleasant
smell. Do not use diusers near the air
purifier.
Humidity
Essential Oils
Note: Water or moisture will allow mold to
grow. To solve a mold problem, get rid of
the source of the moisture and clean up the
mold and change filter.
16
CARE & MAINTENANCE
will light up as a reminder to check the
filter. Depending on how often you use the
air purifier, the indicator should turn on after
about 9 months. You may not need to change
your filter yet, but you should check it when
lights up.
When your air purifier is set up with the
VeSync app, you can also check the app
to see the remaining filter life. You will also
receive a notification from VeSync when it’s
time to check your filter.
Reset the Check Filter Indicator when:
Check Filter Indicator
Resetting the Check Filter
Indicator
Cleaning the Smart Air Purifier
• Unplug before cleaning.
• Wipe the outside of the air purifier with
a soft, dry cloth. If necessary, wipe
the housing with a damp cloth, then
immediately dry.
• Vacuum the inside of the air purifier.
• Do not clean with abrasive chemicals or
flammable cleaning agents.
Note: The VeSync app uses a scientific
algorithm to determine your filter life based
on air quality, amount of use, and other
factors. The filter life percentage is based
on 12 hours of daily use.
A. lights up. This is the Check Filter
Indicator light.
• Replace the filter (see page 18).
• Turn on the air purifier.
• To reset the Check Filter Indicator,
press and hold for 3 seconds.
• The Check Filter Indicator light will
flash, and turn o when successfully
reset. The filter life will show as 100%
in the VeSync app.
B. The filter was changed before lit up.
• After replacing the filter, turn on the
air purifier.
• To reset the Check Filter Indicator,
press and hold for 3 seconds.
• The Check Filter Indicator will flash,
and turn o when successfully reset.
The filter life will show as 100% in the
VeSync app.
17
Filter When to Clean How to Clean When to Replace
Washable
Pre-Filter
Every 2–4 weeks
Use a soft cloth or
vacuum hose
Does not need to be
replaced
Wash with water and
mild detergent
The Main /
Activated
Carbon Filter
Do not clean
Approximately
9–12 months
CARE & MAINTENANCE (CONT.)
The Washable Pre-Filter should be cleaned
approximately every 2–4 weeks to increase
eciency and extend the life of your filter.
You can set a reminder in the VeSync app
to clean the pre-filter every 2, 3, or 4 weeks.
Clean the pre-filter using a soft brush or
vacuum hose to remove hair, dust, and
large particles. Optionally, you can wash the
pre-filter with water and a mild detergent to
remove dirt and dust.
Note: Avoid scrubbing, scraping, or
vigorously brushing the pre-filter. Do not
use abrasive cleaning materials.
To wash the pre-filter:
1. Turn o the air purifier.
2. Open the front cover
3. Push the pre-filter’s tabs downward and
pull to remove the pre-filter.
4. Clean the surface of the pre-filter with a
vacuum. [Figure 2.1]
Cleaning the Pre-Filter
Figure 2.3
Figure 2.2
Figure 2.1
5. Rinse the pre-filter with water under a
faucet.
6. Wash the pre-filter with mild detergent
and a soft cloth. [Figure 2.2]
7. Allow the pre-filter to air-dry. Once
completely dry, place the pre-filter back
into the air purifier. [Figure 2.3]
18
Replacing the Filter
CARE & MAINTENANCE (CONT.)
The Main / Activated Carbon Filter should
be replaced approximately every 9 months.
You may need to replace your filter earlier
or later depending on how often you use
your air purifier. Using your air purifier in an
environment with relatively high pollution may
mean you will need to replace the filter more
often, even if the Check Filter Indicator is o.
You may need to replace your filter if you
notice:
• The air purifier does not eectively filter
certain odors anymore
• Increased noise when the air purifier is on
• Decreased airflow from the top of the air
purifier
• Unusual odors
• The Main filter is visibly dusty or discolored
after removing the pre-filter
When Should I Replace the
Filter?
Note:
• To maintain the performance of your air
purifier, only use ocial Levoit filters.
For more information, contact Customer
Support (see page 26).
• Remember to reset the Check Filter
Indicator after replacing the filter (see
page 16).
1. Unplug the air purifier, then pull the front
cover to remove it (see Getting Started,
page 7).
2. Push the pre-filter’s tabs downward and
pull to remove the pre-filter.
3. Remove the old filter from the air purifier.
4. Clean out any remaining dust or hair inside
the air purifier using a vacuum hose.
5. Remove the plastic packaging from the
new filter and place the filter and pre-
filter inside the air purifier (see Getting
Started, page 7)
6. Replace the front cover.
7. Plug in and turn on the air purifier. Reset
the Check Filter Indicator (see page 16).
Note: Do not use water or liquids to clean
the air purifier.
19
Cleaning the Dust Sensor
If not using the air purifier for an extended
period of time, wrap both the air purifier and
the filter in plastic packaging and store in a
dry place to avoid moisture damage.
Storage
It is recommended to clean the AirSight™
Infrared Dust Sensor at least lens every 2
months to help maintain the eciency of
the sensor. If the Air Quality Indicator is red
(indicating “Bad” air quality) more than usual,
you may need to clean your dust sensor.
Note: How often you clean the dust sensor
will depend on the air quality of your
environment. If your air is often polluted with
dust, dander, smoke, and other particles,
you may need to clean your dust sensor
more often.
Note: Do not remove the foam piece
attached to the dust sensor cover
unless instructed by Customer Support.
[Figure 3.3]
1. Unplug the air purifier.
2. Open the dust sensor cover. [Figure 3.1]
CARE & MAINTENANCE (CONT.)
Figure 3.1
Figure 3.2
Figure 3.3
3. Use a cotton swab dipped in water to
clean the dust sensor lens. [Figure 3.2]
4. Wipe the lens dry with a dry cotton swab.
5. Replace the dust sensor cover.
Do not
remove
20
Problem Possible Solution
Air purifier will not turn on or
respond to button controls.
Plug in the air purifier.
Check to see if the power cord is damaged. If it is, stop using
the air purifier and contact Customer Support (see page 26).
Plug the air purifier into a dierent outlet.
The air purifier may be malfunctioning. Contact Customer
Support (see page 26).
Airflow is significantly
reduced.
Make sure the filter is removed from its packaging and
properly in place (see page 7).
Tap to increase the fan speed.
Leave 15 inches / 38 cm of clearance from the front of the air
purifier.
The pre-filter may be clogged by large particles, such as hair
or lint, blocking airflow. Clean the pre-filter (see page 17).
Replace the filter (see page 18).
Air purifier makes an unusual
noise while the fan is on.
Make sure the filter is properly in place with plastic packaging
removed (see page 7).
Make sure the air purifier is operating on a hard, flat, level
surface.
Replace the filter (see page 18).
The air purifier may be damaged, or a foreign object may
be inside. Stop using the air purifier and contact Customer
Support (see page 26). Do not try to repair the air purifier.
Poor air purification quality.
Tap to increase the fan speed.
Make sure no objects are blocking the front, sides, or top of
the air purifier (the inlet or outlet).
Make sure the filter is removed from its packaging and
properly in place (see page 7).
Close doors and windows while using the air purifier.
If the room is larger than 222 ft² / 21 m², air purification will
take longer.
Replace the filter (see page 18).
TROUBLESHOOTING
21
If your problem is not listed, please contact Customer Support (see page 26).
TROUBLESHOOTING (CONT.)
Problem Possible Solution
Strange smell coming from
the air purifier.
Clean the filter, or replace if necessary.
Contact Customer Support (see page 26).
Make sure not to use your air purifier in an area with high
humidity or while diusing essential oils.
Air Quality Indicator always
stays blue, even when the air
quality is poor.
Clean the dust sensor lens (see page 19).
The dust sensor detects airborne particles, but it cannot
detect gas. Make sure there aren’t gasses polluting the air.
Air Quality Indicator always
stays red.
Clean the dust sensor lens (see page 19).
If you’re using an ultrasonic humidifier near the air purifier,
the mist may aect the accuracy of the dust sensor. The dust
sensor will detect the large mist particles, and the Air Quality
Indicator may turn red. Avoid using an ultrasonic humidifier
near the air purifier, or avoid using Auto Mode.
Air purifier randomly turns
o.
Air purifier is malfunctioning. Stop using the air purifier and
contact Customer Support (see page 26).
is still on after replacing
the filter.
Reset the Check Filter Indicator (see page 16).
has not turned on after 9
months.
is a reminder for you to check the filter and will light up
based on how much the air purifier has been used, as well as
other factors (see page 16). If you don’t use your air purifier
often, will take longer to turn on.
turned on before 9
months.
is a reminder for you to check the filter and will light up
based on how much the air purifier has been used, as well
as other factors (see page 16). If you run your air purifier
frequently, will turn on sooner.
The display does not stay on
in darkness room.
Make sure that the Light detection is o(see page11).
The purifier always shuts o
automatically in a dark room.
Make sure that the Light detection is o(see page11).
22
If your problem is not listed, please contact Customer Support (see page 26).
VESYNC APP TROUBLESHOOTING
My smart air purifier isn’t connecting to the VeSync app.
• Make sure your phone has Bluetooth® turned on and is not currently connected to another
Bluetooth device.
• During the setup process, you must be on a secure 2.4GHz Wi-Fi® network. Confirm that the
network is working correctly.
• Make sure the Wi-Fi password you entered is correct.
• There should be no spaces at the beginning or end of the password.
• Test the password by connecting a dierent electronic device to the router.
• If you’re manually typing in the SSID and password, double check that both are entered
correctly.
• Try moving your air purifier closer to the router. Your phone should be as close as possible
to your air purifier.
• Your router may need to be at a higher location, away from obstructions.
• Make sure your air purifier and router are away from appliances (such as microwave ovens,
refrigerators, electronic devices, etc.) to avoid signal interference.
• If you’re using a VPN, make sure it’s turned o while setting up your air purifier.
• Disable portal authentication for your Wi-Fi network. If portal authentication is enabled, the
air purifier will not be able to access your Wi-Fi network, and setup will fail.
My air purifier is oine.
• Make sure the air purifier is plugged in and has power, then refresh the VeSync menu by
swiping down on the screen.
• Make sure your router is connected to the internet and your phone’s network connection is
working.
• Delete the oine air purifier from the VeSync app. Swipe left (iOS®) or press and hold
(Android™), then tap Delete. Reconfigure the air purifier with the VeSync app.
Note: Portal authentication means that you need to sign in to your Wi-Fi network through a
web page before you can use the Internet.
Note: Power outages, internet outages, or changing Wi-Fi routers may cause the air purifier
to go oine.
23
FEDERAL COMMUNICATION COMMISSION
INTERFERENCE STATEMENT – PART 15
FCC RADIATION EXPOSURE STATEMENT
FCC SDOC SUPPLIER’S DECLARATION
OF CONFORMITY
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause
undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment o and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate this equipment.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. End users must follow the specific operating instructions for satisfying RF exposure
compliance. To maintain compliance with FCC RF exposure compliance requirements, please
follow operation instructions as documented in this manual. This transmitter must not be co-
located or operating in conjunction with any other antenna or transmitter. This equipment should
be installed and operated with a minimum distance of 20 cm between the radiator and your
body. The availability of some specific channels and/or operational frequency bands are country
dependent and are firmware programmed at the factory to match the intended destination. The
firmware setting is not accessible by the end user.
Arovast Corporation hereby declares that this equipment is in compliance with the FCC
requirements. The declaration of conformity may be consulted in the support section of our
website, accessible from www.levoit.com
24
Product Name Vital 100S-P
Smart Air Purifier
Model LAP-V102S-AUSR
Date of Purchase
Order ID
WARRANTY INFORMATION
Levoit Limited Product Warranty
Register your products at https://warranty.levoit.
com/warranty to stay up to date with important
product information such as product updates, limited
warranties, usage and maintenance recommendations,
and notifications concerning safety warnings or
product recalls. Registration is not required to claim
your limited warranty.
Two (2) Year Limited Consumer Product Warranty
Arovast Corporation (“Arovast”) warrants that the
product shall be free from defects in material and
workmanship for a period of 2 years from the date of
original purchase (“Limited Warranty Period”), provided
the product was used in accordance with its use and
care instructions (e.g., in the intended environment and
under normal circumstances).
Your Limited Warranty Benefits
During the Limited Warranty Period and subject to this
limited Warranty Policy, Arovast will, in its sole and
exclusive discretion, either (i) refund the purchase
price if the purchase was made directly from the
online Levoit store, (ii) repair any defects in material
or workmanship, (iii) replace the product with another
product of equal or greater value, or (iv) provide store
credit in the amount of the purchase price.
Who is Covered?
This limited warranty extends only to the original
consumer purchaser of the product and is not
transferable to any subsequent owner of the product,
regardless of whether the product transferred
ownership during the specified term of the limited
warranty. The original consumer purchaser must
provide verification of the defect or malfunction and
proof of the date of purchase to claim the Limited
Warranty Benefits.
Be Aware of Unauthorized Dealers or Sellers
This limited warranty does not extend to products
purchased from unauthorized dealers or sellers.
Arovast’s limited warranty only extends to products
purchased from authorized dealers or sellers that
are subject to Arovast’s quality controls and have
agreed to follow its quality controls. Please be aware,
products purchased from an unauthorized website or
dealer may be counterfeit, used, defective, or may not
be designed for use in your country. You can protect
yourself and your products by making sure you only
purchase from Arovast or its authorized dealers.
If you have any questions about a specific seller, or if
you think you may have purchased your product from
an unauthorized seller, please contact our Customer
Support Team via [email protected].
What’s Not Covered?
• Normal wear and tear, including parts that
might wear out over time (e.g., batteries, filters,
cleaning brush, essential oil pads, etc.).
• If the proof-of-purchase has been altered in any
way or is made illegible.
• If the model number, serial number or production
date code on the product has been altered,
removed or made illegible.
• If the product has been modified from its original
condition.
• If the product has not been used in accordance
with directions and instructions in the user
manual.
• Damages caused by connecting peripherals,
additional equipment or accessories other than
those recommended in the user manual.
• Damages or defects caused by accident, abuse,
misuse, or improper or inadequate maintenance.
• Damages or defects caused by service or repair
of the product performed by an unauthorized
service provider or by anyone other than
Arovast.
• Damages or defects occurring during
commercial use, rental use, or any use for which
the product is not intended.
• If the unit has been damaged, including but
not limited to damage by animals, lightning,
abnormal voltage, fire, natural disaster,
transportation, dishwasher, or water (unless the
user manual expressly states that the product is
dishwasher-safe).
• Incidental and consequential damages.
• Damages or defects exceeding the cost of the
product.
Claiming Your Limited Warranty Service in 5 Simple
Steps:
1. Make sure your product is within the specified
limited warranty period.
2. Make sure you have a copy of the invoice and
order ID or proof-of-purchase.
3. Make sure you have your product. DO NOT
dispose of your product before contacting us.
4. Contact our Customer Support Team via
5. Once our Customer Support Team has approved
your request, please return the product with a
copy of the invoice and order ID.
Sole and Exclusive Remedy
THE FOREGOING LIMITED WARRANTY CONSTITUTES
AROVAST CORPORATION’S EXCLUSIVE LIABILITY,
AND YOUR SOLE AND EXCLUSIVE REMEDY, FOR
ANY BREACH OF ANY WARRANTY OR OTHER
NONCONFORMITY OF THE PRODUCT COVERED BY
THIS LIMITED PRODUCT WARRANTY STATEMENT.
THIS LIMITED WARRANTY IS EXCLUSIVE, AND IN
LIEU OF ALL OTHER WARRANTIES. NO EMPLOYEE OF
25
WARRANTY INFORMATION (CONT.)
AROVAST CORPORATION OR ANY OTHER PARTY IS
AUTHORIZED TO MAKE ANY WARRANTY IN ADDITION
TO THE LIMITED WARRANTY IN THIS LIMITED
PRODUCT WARRANTY STATEMENT.
Disclaimer of Limited Warranties
TO THE FULLEST EXTENT PROVIDED BY
APPLICABLE LAW, EXCEPT AS WARRANTED IN THIS
LIMITED PRODUCT WARRANTY POLICY, AROVAST
CORPORATION PROVIDES THE PRODUCTS YOU
PURCHASE FROM AROVAST CORPORATION “AS IS”
AND AROVAST CORPORATION HEREBY DISCLAIMS
ALL WARRANTIES OF ANY KIND, WHETHER
EXPRESS OR IMPLIED, STATUTORY, OR OTHERWISE,
INCLUDING BUT NOT LIMITED TO ANY WARRANTIES
OF MERCHANTABILITY, NON-INFRINGEMENT, AND
FITNESS FOR PARTICULAR PURPOSE.
Limitations of Liability
TO THE FULLEST EXTENT PROVIDED BY APPLICABLE
LAW, IN NO EVENT WILL AROVAST CORPORATION,
ITS AFFILIATES, OR THEIR LICENSORS, SERVICE
PROVIDERS, EMPLOYEES, AGENTS, OFFICERS, OR
DIRECTORS BE LIABLE FOR:
(a) DAMAGES OF ANY KIND ARISING OUT OF OR
IN CONNECTION WITH PRODUCTS PURCHASED
FROM AROVAST CORPORATION IN EXCESS OF THE
PURCHASE PRICE PAID BY THE PURCHASER FOR
SUCH PRODUCTS, OR
(b) INDIRECT, SPECIAL, INCIDENTAL,
CONSEQUENTIAL, OR PUNITIVE DAMAGES EVEN IF
AROVAST CORPORATION OR ONE OF ITS SUPPLIERS
HAS BEEN ADVISED OF THE POSSIBILITY OR
LIKELIHOOD OF SUCH DAMAGES.
AND REGARDLESS OF WHETHER CAUSED BY TORT
(INCLUDING NEGLIGENCE), BREACH OF CONTRACT,
OR OTHERWISE. OUR LIABILITY SHALL UNDER NO
CIRCUMSTANCES EXCEED THE ACTUAL AMOUNT
PAID BY YOU FOR THE DEFECTIVE PRODUCT, NOR
SHALL WE UNDER ANY CIRCUMSTANCES BE LIABLE
FOR ANY CONSEQUENTIAL, INCIDENTAL, SPECIAL OR
PUNITIVE DAMAGES OR LOSSES, WHETHER DIRECT
OR INDIRECT.
EXCEPT AS COVERED BY THIS LIMITED PRODUCT
WARRANTY STATEMENT, AROVAST CORPORATION
SHALL NOT BE LIABLE FOR COSTS ASSOCIATED
WITH THE REPLACEMENT OR REPAIR OF PRODUCTS
PURCHASED FROM IT, INCLUDING, BUT NOT LIMITED
TO, LABOR, INSTALLATION, OR OTHER COSTS
INCURRED BY THE USER AND, IN PARTICULAR,
ANY COSTS RELATING TO THE REMOVAL OR
REPLACEMENT OF ANY PRODUCT.
OTHER RIGHTS YOU MAY HAVE
SOME JURISDICTIONS DO NOT ALLOW FOR: (1)
EXCLUSION OF IMPLIED WARRANTIES; (2) LIMITATION
ON THE DURATION OF IMPLIED WARRANTIES; AND/
OR (3) EXCLUSION OR LIMIATION OF INCIDENTAL OR
CONSEQUANTIAL DAMAGES; SO THE DISCLAIMERS
IN THIS POLICY MAY NOT APPLY TO YOU. IN THESE
JURISDICTIONS YOU HAVE ONLY THE IMPLIED
WARRANTIES THAT ARE EXPRESSLY REQUIRED TO
BE PROVIDED IN ACCORDANCE WITH APPLICABLE
LAW. THE LIMITATIONS OF WARRANTIES, LIABILITY,
AND REMEDIES APPLY TO THE MAXIMUM EXTENT
PERMITTED BY LAW.
ALTHOUGH THIS LIMITED WARRANTY GIVES YOU
SPECIFIC LEGAL RIGHTS, YOU MAY HAVE OTHER
RIGHTS IN YOUR JURISDICTION. THIS STATEMENT
OF LIMITED WARRANTY IS SUBJECT TO APPLICABLE
LAWS THAT APPLY TO YOU AND THE PRODUCT.
PLEASE REVIEW THE LAWS IN YOUR JURISDICTION
TO UNDERSTAND YOUR RIGHTS FULLY.
CHANGES TO THIS POLICY
We may change the terms and availability of this limited
warranty at our discretion, but any changes will not be
retroactive.
This warranty is made by:
Arovast Corporation
1775 Flight Way, Suite 150
Tustin, CA 92782, USA
26
CUSTOMER SUPPORT
If you have any questions or concerns about
your new product, please contact our helpful
Customer Support Team.
Email: [email protected]
Toll-Free: 1-888-726-8520
Mon–Fri, 9:00 am–5:00 pm PST/PDT
Support Hours
*Please have your order invoice and order ID
ready before contacting Customer Support.
ATTRIBUTIONS
Amazon, Alexa, and all related logos are trademarks of Amazon.com, Inc. or its aliates.
Google, Android, and Google Play are trademarks of Google LLC.
App Store® is a trademark of Apple Inc.
Wi-Fi® is a registered trademark of Wi-Fi Alliance®.
iOS is a registered trademark of Cisco Systems, Inc. and/or its aliates in the United States and
certain other countries.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and
any use of such marks by Arovast Corporation is under license. Other trademarks and trade names
are those of their respective owners.
The energy eciency of this ENERGY STAR
certified model is measured based on a
ratio between the model’s CADR for Smoke
and the electrical energy it consumes, or
CADR/Watt.
NOTES
A4_24H19 us retail
