Features
• Only 30" (762 mm) wide.
• Stores 200 lbs (91 kg) of ice.
• Direct Dispense — ensures that ice hits the glass every time.
• Ultra-low profile design.
• User friendly push-to-dispense operation.
• Quick Stop — prevents ice overflow and waste.
• Perfect for cube or Pearl Ice® ice makers.
• Power Clean allows access to the bin for easy cleaning
without moving the ice machine. Interlock safety switch
turns off machine agitation when tip-front access panel
is removed.
• 1" (25 mm) foam-insulation for maximum ice preservation–
no more quick–melting ice.
• Constructed from corrosion-resistant stainless steel and
fingerprint-proof plastic.
• Auto Rotate — turns the ice every hour to consistently
provide more dispensable ice.
IOD200 - ICE ONLY OR WATER/ICE DISPENSER
IOD200 ICE ONLY OR WATER/ICE DISPENSER
Ice. Pure and Simple
Options & Accessories
CIM0430 ON IOD200
Model No. CIM0320 CIM0330 CIM0430 CIM0520 CIM0530 CIM0636 CIM0826 CIM0836 CIM1126 CIM1136 ICE1506 GEM0450 GEM0650 GEM0956 GEM1306
Air-Cooled
313 (143) 313 (143) 435 (197) 561 (254) 561 (254) 600 (272) 896 (406) 896 (406) 932 (423) 932 (423) 1430 (649) 464 (210) 740 (336) 1053 (336) 1350 (612)
Water-Cooled
316 (143) 316 (143) 460 (209) 586 (266) 586 (266) 620 (281) 896 (406) 896 (406) 968 (439) 968 (439) N /A 508 (230) 770 (349) 1053 (336) 1350 (612)
Remote-Cooled
N /A N /A N /A 525 (238) 525 (238) 615 (279) 906 (411) 906 (411) 968 (439) 968 (439) 1432 (650) N /A 770 (349) 1011 (459) 1350 (612)
Voltage Char.
115/60/1 115/60/1 115/60/1 115/60/1 115/60/1 208-230/60/1 208-230/60/1 208-230/60/1 208-230/60/1 208-230/60/1 208-230/60/1 115/60/1 115/60/1 208-230/60/1 208-230/60/1
ICE PRODUTION FOR OPTIONAL CUBE OR PEARL ICE MAKERS*
Tested at 70°F Air/50°F Water.
*Pounds (Kilograms) per 24 hours.
Item
Number
Description
Approximate
Shipping Weight
lbs (kg)
KWGFID Water Glass Filler Kit for 30" IOD 2 (1)
KBT25022 Adapter for 22" Cubers or 21" GEM on 30" IOD 24 (11)
KBT25030 Adapter for 30" Cubers or GEM on 30” IOD 24 (11)
KEBIOD Required for GEM on 30" IOD 3 (1)
Ice Form
PEARL ICE
H x Dia. (in.)
1/2 x 3/8
H x Dia. (mm)
12.7 x 9.5
PEARL ICE DIMENSIONS
CUBE
FULL CUBE DIMENSIONS
W x D x H (in.) 7/8 x 7/8 x 7/8
W x D x H (mm) 22 x 22 x 22
HALF CUBE DIMENSIONS
W x D x H (in.) 3/8 x 7/8 x 7/8
W x D x H (mm) 10 x 22 x 22
Ice Form
Rev: 01/18
Part: 4001
11100 E. 45th Avenue • Denver, CO 80239 • Phone: 1. 866. PURE. ICE • Fax: 303. 371. 6296 • www.iceomatic.com
Ice. Pure and Simple
IOD200 ICE ONLY OR WATER/ICE DISPENSER
NOTES:
Number of Wires: 3 (including ground)
Approx. Shipping Weight lbs (kg): 193 (88)
IOD200 - ICE ONLY OR WATER/ICE DISPENSER
All specifications and performance data are subject to normal manufacturing variances.
Ice-O-Matic’s® machines are not designed for outdoor installations. Ice-O-Matic® remote condensers are designed for outdoor installations.
Machine requires voltage indicated on rating name plate. Failures caused by improper voltage are not considered factory defects. Extended periods of operation at temperature exceeding
limitations constitutes misuse under the terms of Ice-O-Matic® Manufacturer’s Limited Warranty, resulting in a loss of warranty coverage. Specifications and design are subject to change
without notice.
Specifications
ALL MODELS
Dimensions
W x D x H (in.)
30.25 x 30.69 x 35.62
W x D x H (mm)
768 x 779 x 905
Model Number
Dispenser
Operation
Bin Storage
lbs (kg)
Voltage
Characteristics
No. of
Wires
Min. Circuit
Ampacity
Maximum
Fuse Size
Approximate
Shipping Weight
lbs (kg)
IOD200 Push Bar 200 (91) 115/60/1 Cord 3.5 15 193 (88)
12¼"
(311 mm)
30¼"
(768 mm)
2 7⁄8"
(73 mm)
35
5⁄8"
(905 mm)
7¾"
(199 mm)
2¾"
(70 mm)
10
1⁄16"
(275 mm)
Cup
Clearance
21¼"
(540 mm)
29"
(737 mm)
30
11⁄16"
(779 mm)
30 7⁄16"
(773 mm)
30"
(750 mm)
7⁄16" (4) plcs
(11 mm)
113⁄16"
(45 mm)
15⁄16"
(33 mm)
185⁄8"
(473 mm)
23"
(584 mm)
3½"
(89 mm)
11"
(295 mm)
267⁄16"
(672mm)
93⁄16"
(233 mm)
30 11⁄16"
(779 mm)
Removable
Sink
To front of
drip tray on
counter top
To front top of
drip tray
29"
(737 mm)
21¼"
(531 mm)
12"
(300 mm)
9"
(225 mm)
Opening
Mounting
Template
Recommended counter opening size 9" (229 mm) x 12" (305 mm)
for utilities and tubing. Opening can be located
anywhere within the shaded area.
Counter OpeningSideFront
355⁄8"
(905 mm)
30¼"
(768 mm)
30"
(762 mm)
3011⁄16"
(779 mm)
Operating Requirements
MAXIMUM
60 Hz
AmbientTemp. Range Air 50˚F (10˚C)
100˚F (38˚C)
WaterTemp. 40˚F (4.4˚C)
Water Pressure
20 PSIG (1.4 BAR) 60 PSIG (4.1 BAR)
MINIMUM
