MANUAL MLR010016N
ultra brew
coffee maker
12-CUP CAPACIT Y
12
10
8
6
4
12
10
8
6
4
2
2 |IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY
INSTRUCTIONS
When using electrical appliances, basic safety precautions should
always be followed to reduce the risk of fire, electric shock, and/or
injury to persons.
READ ALL INSTRUCTIONS thoroughly before use and save it for
future reference.
– Make sure that your outlet voltage corresponds to the voltage stated
on the rating label of the Ultra Brew Coffee Maker.
– To protect against fire, electric shock and injury, do not submerge
the cord or the plug in water or other liquids.
– This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge unless they are supervised during their use of the appliance
by a person responsible for their safety and care.
– Do not operate the appliance with a damaged cord or plug or after
the appliance malfunctions, or has been damaged in any manner.
Return appliance to an authorized service facility for examination,
repair, or adjustment.
– Do not touch hot surfaces. Use handles and knobs.
– Always unplug from the outlet when not in use and before cleaning.
– Allow it to cool before putting on or taking off parts and before
cleaning the appliance.
– The use of accessories not recommended by the appliance manufacturer
may result in fire, electric shock, or injury.
– Do not use outdoors.
– Do not let the cord hang over the edge of a table or counter or touch
hot surfaces.
– Always grasp the power plug to remove it from the wall outlet.
Do not pull on the power cord itself.
– Do not place on or near a hot gas or electric burner, or in a heated oven.
– Do not use the appliance for other than its intended use.
– Always fill the water reservoir first, then plug the cord into the wall outlet.
To disconnect, push the “On/Off” button, then remove the plug from the
wall outlet.
– Do not clean the Carafe with cleansers, steel wool pads, or other
abrasive material.
– Scalding may occur if the Top Lid is removed during the brewing cycles.
– Make sure the Carafe Lid is secure before serving any beverages.
– The Carafe is designed for use with this Ultra Brew Coffee Maker
only. It must never be used on a range top.
IMPORTANT SAFETY INSTRUCTIONS | 3
WARNING!
To reduce the risk of fire or electric shock, do not remove
the Bottom Cover. No user-serviceable parts are inside.
Repairs should be done only by authorized personnel.
Do not touch or clean the Warming Plate while
appliance is in use.
NOTE: Your Coffee Maker has a two prong plug. To reduce the risk of
electrical shock, this plug will fit in an outlet only one way. If the plug
does not fit in the outlet, contact a qualified electrician. Do not modify
the plug in any way.
ELECTRICAL
Risk of Fire or Electric Shock. Do not open.
No user serviceable parts inside. Repair
should be done by authorized service
personnel only.
– Never leave the empty Carafe on the Warming Plate; otherwise,
the Carafe might crack.
– Do not place a hot Carafe on a wet, hot, or cold surface.
– Do not use a cracked Carafe or a Carafe having a loose or weakened handle.
– Do not operate the Coffee Maker without water.
– Do not place cloth beneath the Coffee Maker or otherwise restrict airflow.
– Do not operate your appliance in an appliance garage or under
a wall cabinet.
– When storing in an appliance garage, always unplug the unit from
the electrical outlet. Not doing so could create a risk of fire especially
if the appliance touches the walls of the garage or the door touches
the unit as it closes.
– Avoid contact with moving parts.
– Do not use outdoors.
SAVE THESE INSTRUCTIONS
FOR HOUSEHOLD USE ONLY
SHOCK HAZARD
4 | OvERvIEw OF PARTS | CONTROL PANEL
OVERVIEW OF PARTS
CONTROL PANEL
Permanent
Filter
Carafe Lid
Carafe
Handle
Carafe
Top
Lid
Sprayer
Water
Tank
Water
Gauge
Main
Housing
Warming
Plate
Bottom
Cover
Control
Panel
Spoon
Funnel
5–7 min
Open the Top Lid and fill the
Water Tank with drinking
water. The water level should
not exceed the MAX level, as
indicated on the Water Gauge.
Install the Funnel
properly and then
place the Permanent
Filter into the Funnel.
Make sure it is
assembled correctly;
otherwise, the Top
Lid cannot be closed.
Insert the Carafe with
closed Lid onto the
Warming Plate,
horizontally.
Add coffee
grounds into the
Permanent Filter.
Close the Top Lid
completely.
BEFORE THE FIRST USE
HOW TO MAKE COFFEE
Check that all accessories are there, and unit is not damaged.
Fill water into the Water Tank to the MAX and brew at least 2 times with
a full tank of water (without coffee grounds), then discard the water. Clean and
dry all detachable parts thoroughly according to the section “Cleaning and
Maintenance”. To set the clock, follow Step 1 in “Delay Function” on Page 7.
Make sure to perform these steps before brewing
your coffee for the first time!
NOTE: For best
results, always
use cold, fresh
tap water.
NOTE: Use the provided scoop
with a level spoonful of coffee
grounds per cup to start. Adjust
according to personal taste.
STEP 1 STEP 2
STEP 3
STEP 4
*Measuring
cup not
included.
*Measuring
cup not
included.
Plug the power
cord into the
outlet.
STEP 5
5–7 min
BEFORE THE FIRST USE | HOw TO MAKE COFFEE | 5
5–7 min
IMPORTANT!
5–7 min
5–7 min
6 | HOw TO MAKE COFFEE
To increase the coffee strength,
press the “Strength” button once.
The indicator will illuminate in
red, and the appliance will brew
strong coffee. If you do not wish
to increase the coffee strength,
continue with Step 7 to brew
regular coffee.
Press the “On/Off” button once.
The indicator will illuminate in
red, and the LCD will display
“AM 12:00” (or the time you
previously set). The appliance
will begin to work.
The brewing process can be interrupted by
pressing the “On/Off” button at any time.
The indicator of the “On/Off” button will turn
off. The appliance will continue brewing
once the “On/Off” button is pressed again.
– The Coffee Maker will take
5 to 7 minutes to brew your coffee
depending on the amount of
coffee and water you are using.
– You can take out the Carafe, pour,
and serve your coffee at any time.
The appliance will stop dripping
automatically for 30 seconds.
– Need more time? Pause the
brewing by pressing the
“On/Off” button, pour your coffee,
then replace the Carafe and press
the “On/Off” button to continue
brewing.
– During the brewing process, the
buttons “Program” “Delay Brew”
“Hour” and “Minute”
are not adjustable.
STEP 6 STEP 7
STEP 8
5–7 min
5–7 min
5–7 min
NOTE: Coffee grounds
will absorb some water
during brewing. For
the best tasting coffee,
serve immediately after
brewing. Take care when
pouring hot coffee to avoid
burns or serious injury.
DELAY FUNCTION | 7
Once the brewing is completed,
if you do not want to serve
immediately, coffee can be
kept warm in the Carafe on the
Warming Plate. The appliance
will shut off automatically after
two hours unless you manually
turn it off by pressing the “On/Off”
button.
Always turn the
Coffee Maker off
and disconnect
the power supply
when not in use.
STEP 9
STEP 10
DELAY FUNCTION
“Delay Brew” allows you to automatically brew coffee at a specific time within
a 24-hour period. This convenient features saves you time in your wakeup routine.
For example, follow these steps to set a delay brew for the next day
at 8:10 AM the next morning.
Set the clock on the Coffee Maker
to the current time by separately
holding the “Hour” button
and “Minute” buttons until the
numbers change to the correct
hour and minute. AM indicates
the time before noon and PM
indicates after noon (12:00 PM)
and before midnight.
NOTE:
The time cycle
is 12 hours.
Press the
“Program”
button once.
The “On/Off”
button indicator
will display
flashing green.
Press the “Hour”
and “Minute” buttons to set the
time to which you would like
to delay the brew (in this case,
8:10 AM).
STEP 1
STEP 2
STEP 3
8 | CLEANING AND MAINTENANCE
Press the “Delay
Brew” button.
The “On/Off”
button indicator
will illuminate
in green.
Add water
and coffee
grounds to the
Coffee Maker
as you normally
would with the
Permanent
Filter in place.
After a while, the
LCD will display
the current time.
You may see the
delayed brew start
time by pressing
the “Program” button.
STEP 4 STEP 5
STEP 6
NOTE: You may cancel the
automatic start function by
pressing “On/Off” . If you want to
change the delay brew start time,
follow only the steps 2–4.
Always turn the Coffee Maker off and remove the plug from
the electrical outlet before cleaning. To protect against
electrical shock, do not submerge the cord, plug,
or the unit in the water or liquid.
NOTE: Do not put any water in the unit once the Filter and Funnel have
been removed. Wipe that area with a damp cloth.
CLEANING AND MAINTENANCE
– Lift up the Top Lid, remove all removable parts such as Permanent Filter, Funnel
and Carafe, and wash them with warm soapy water.
– Never immerse the unit in water or other liquid. To clean the exterior surface,
simply wipe with a clean, damp cloth, and dry before storing.
– Water droplets may buildup in the area above the Funnel and drip onto the
product base during brewing. To prevent the buildup, wipe off the area with
a clean, dry cloth after each use.
– Use a clean, damp cloth to clean the Warming Plate. Never use rough, abrasive
materials or cleansers to clean the Warming Plate.
– Do not dry the inside of the Water Tank with a cloth, as lint may remain.
– Keep your Coffee Maker in a dry and cool place.
REMOvING MINERAL DEPOSITS | TIPS & COFFEE BEST PRACTICES | 9
REMOVING MINERAL DEPOSITS
Depending on the mineral content of your water, calcium deposits or scale may
build up in your coffee machine. We recommend regular descaling of your Coffee
Maker every 3–6 months to help maintain the heating element and other internal
parts that come in contact with water. Calcium deposits may build up faster,
making it necessary to descale more often.
1 Fill the Water Tank with a water-vinegar (1:1 ratio) solution of 3.4 oz (100 ml) white
vinegar and 3.4 oz (100 ml) clean water. You may also use citric acid to create the
descaler solution by mixing 3.4 oz (100 ml) of water with 0.1 oz (3 ml) of citric acid.
2 Make sure the Funnel and the Filter are in place.
3 Place a coffee cup onto the Warming Plate.
4 Start a brew cycle by pressing the “On/Off” button, until it start to brew hot
water to Carafe for around 10–30 seconds, press the “On/Off” button to pause
and let the solution set for 30–60 minute, depending on how much build-up
you need to remove.
5 After 30–60 minutes, press the “On/Off” button again and let the
brew cycle finish.
6 Perform the brew cycles until there is no more water-vinegar solution inside
the Water Tank, allowing your Coffee Maker to cool between brews.
7 If scale is still present in the Coffee Maker, repeat steps 1–6.
8 Rinse the Funnel, Filter, and Water Tank with water a couple of times.
9 Finally, the appliance needs to be cleaned with water to remove the descaling
solution. Fill the Water Tank with fresh water to the MAX fill line and perform
the brew cycle until the Water Tank is empty, allowing your Coffee Maker to
cool between brews.
TIPS & COFFEE BEST PRACTICES
– Always use fresh, cold water in the Coffee Maker.
– For an optimum coffee taste, buy whole coffee beans and finely grind them just
before brewing.
– A clean Coffee Maker is essential for making great-tasting coffee. Regularly clean
the Coffee Maker as specified in the “Cleaning and Maintenance” section.
– Store the coffee grounds in a cool, dry place. After opening a package of coffee
powder, reseal it tightly and store it.
– Do not reuse coffee grounds since this will significantly reduce the flavor.
Reheating coffee is not recommended because coffee is at its ultimate flavor
right after brewing.
10 | TROUBLESHOOTING
Problem Possible Cause Solution
Coffee Maker
indicator lights
and clock are
not lit.
The Coffee Maker is not
plugged in securely or is
not turned on.
Connect the power plug
and press the “On/Off”
power button.
Coffee Maker
does not have
power.
The Coffee Maker is not
plugged in securely.
Plug into a different outlet.
The Top Lid
cannot close.
The Funnel and
Permanent Filter are
assembled incorrectly.
Make sure the Funnel
and Permanent Filter are
assembled correctly
(See Page 5).
Coffee Maker
will not brew.
The Brew Head is not
closed properly or not
closed at all.
Close the Brew Head by
pressing firmly down on
the Handle.
Brewing
a partial mug.
Calcium or scale is built
up in the Coffee Maker.
De-scale the Coffee Maker.
Clock is showing
the wrong time.
Clock needs to be
programmed.
Set the clock to the correct
time (See Step 1, Page 7).
TROUBLESHOOTING
SPECIFICATIONS | wARRANTY | 11
1-YEAR LIMITED WARRANTY
This product is warranted to be free from defects in material and workmanship
under normal use and service for one year from the date of the original purchase
with the receipt. The manufacturer’s obligation shall be limited to repairing
or replacing any part of the product that is defective. Such warranty shall
not apply to damages resulting from accidents, abuse, or misuse.
If there is any problem with Mueller
Ultra Brew Coffee Maker, please
contact Customer Service.
SPECIFICATIONS
Model
Number
Voltage Power Capacity Dimension Weight
DC 750
120 V~
60 Hz
900 W
12 Cup
60.86 oz
(1.8 L)
10.78 × 7.2 × 13.77 in
(27.4 × 18.3 × 35 cm)
3.92 lb
(1.78 kg)
MUELLERDIRECT.COM
SUPPORT@MUELLERDIRECT.COM
888-632-9981
ultra brew coffee maker
12-CUP CAPACIT Y
37 E 18TH STREET
NEw YORK, NY 10003
UNITED STATES
MUELLERDIRECT.COM
SUPPORT@MUELLERDIRECT.COM
888-632-9981
SKU: MLR010016N
MADE IN CHINA
happiness is homemade
