2270-20
Contact Temperature Meter (Alkaline)
May 2012
FIG. PART NO. DESCRIPTION OF PART NO. REQ.
1 31-21-0065 Battery Cover with screw (1)
2 31-70-0115 Stand (1)
3 44-26-0110 Magnet Assembly with two screws (1)
4 23-76-0110 K-Type Bead Probe (2)
54-07-2335
REVISED BULLETIN
SERVICE PARTS LIST
BULLETIN NO.
WIRING INSTRUCTION
DATE
CATALOG NO.
SPECIFY CATALOG NO. AND SERIAL NO. WHEN ORDERING PARTS
SERIAL
NUMBER
MILWAUKEE ELECTRIC TOOL CORPORATION
13135 W. LISBON RD., BROOKFIELD, WI 53005
Drwg. 1
EXAMPLE:
Component Parts (Small #) Are Included
When Ordering The Assembly (Large #).
0
00
D13A
1 2
3
4
