M5-800X4
M5-1000X1
AMPLIFIERS PRE-TUNED: NO ADJUSTMENT NECESSARY
The amplifiers included in your kit are already configured for optimum performance with factory source units.
No adjustment is needed unless using an aftermarket source unit. Please use our C.L.E.A.N. setup proce-
dure to match the INPUT LEVEL on both amplifiers to the aftermarket source unit and leave the remaining
amp settings as shown below. Download the “RF Connect” App for test tones & instructions.
10-27-2023
1220-79049-01
REAR INPUT:
12:00 O’Clock
FRONT INPUT:
12:05 O’Clock
PUNCH EQ:
MIN
CROSSOVER:
50Hz
PRESET:
OFF
CROSSOVER:
AP (All-Pass)
INPUT:
4CH (4-Inputs)
These are the default amplifier settings for the M5-1000X1.
Adjusting these settings will void your warranty.
These are the default amplifier settings for the M5-800X4.
Adjusting these settings will void your warranty.
INPUT:
01:30 O’Clock
PUNCH EQ:
MIN
CROSSOVER:
250Hz (Low-Pass)
PRESET:
OFF
2018+ Wrangler/2020+ Gladiator
Default Settings
BALANCE/FADER
BASE RADIO
EQUALIZER SPEED VOLUME
10-27-2023
1220-79049-01
Set LOW, MID, BASS to their centered
position. Keep settings within -/+2 dB
to prevent potential speaker damage.
Set SPEED ADJUSTMENT VOLUME
to OFF position to prevent potential
speaker damage.
Start with BALANCE and FADER
settings to center position, then adjust
to your personal preference.
BALANCE/FADER
PREMIUM RADIO
EQUALIZER SPEED VOLUME
Set LOW, MID, BASS to their centered
position. Keep settings within -/+2 dB
to prevent potential speaker damage.
Set SPEED ADJUSTMENT VOLUME
to OFF position to prevent potential
speaker damage.
Start with BALANCE and FADER
settings to center position, then adjust
to your personal preference.
2018+ Wrangler/2020+ Gladiator
Radio Settings
