English 2 - 7
´¸∂w
١٣ - ٨
instructions
TYPE ZJP04
TYPE ZJP05
Kenwood Ltd
New Lane
Havant
Hampshire
PO9 2NH
kenwoodworld.com
© Copyright 2021 Kenwood Limited. All rights reserved 140901/3
A
C
B
Safety
l
Read these instructions carefully and
retain for future reference.
l
Remove all packaging and any labels.
l
If the plug or cord is damaged it must,
for safety reasons, be replaced by
Kenwood or an authorised Kenwood
repairer in order to avoid a hazard.
l
Never use a damaged appliance. Get it
checked or repaired: see ‘service and
customer care’.
l
Always use the filter and never overfill -
boiling water may splash out.
l
Avoid contact with steam coming
out of the spout area when pouring
and out of the lid or spout area when
refilling.
l
Beware: the body of the kettle will get
hot during operation.
l
The heating element surface is subject
to residual heat after use.
l
Never let the cord hang down where a
child could grab it.
l
Always unplug your kettle when not
in use.
l
Never put the kettle, powerbase, cord
or plug in liquid.
l
Caution: Do not operate the kettle on
an inclined surface.
l
Only use the powerbase supplied and
keep it clean and dry.
l
WARNING: Be careful to avoid any
spillage on the connector, during
cleaning, filling or pouring.
English
2
8
5
2
3
4
6
7
1
English
3
l
Make sure the lid is secure before
switching the kettle on.
l
Warning: Do not open the lid while the
water is boiling.
l
Take care when opening the lid -
droplets of hot water may be ejected.
l
Make sure the kettle is switched off
before lifting or pouring.
l
DO NOT spout fill, lid fill only.
l
Remove the kettle from the base
before filling or pouring.
l
Never put the kettle near or on cooker
hot plates or gas burners.
l
This kettle is for boiling water only.
l
Misuse of your appliance can result in
injury.
l
Children from 8 years and above
can use, clean and perform user
maintenance on this appliance in
accordance with the User Instructions
provided they are supervised by a
person responsible for their safety and
have been given instruction concerning
the use of the appliance and are aware
of the hazards.
l
Persons with reduced physical,
sensory or mental capabilities or lack
of knowledge using this appliance
must have been given supervision
or instruction on its safe use and are
aware of the hazards.
l
Children must not play with the
appliance and both appliance and cord
must be out of reach of children less
than 8 years.
English
4
Before plugging in
l
Make sure your electricity supply is the same as the one shown on
the underside of your kettle.
Important – Plug and Fuse Information
l
The wires in the cord are coloured as follows:
Green and Yellow = Earth
Blue = Neutral
Brown = Live.
l
If the plug supplied with your appliance has a fuse fitted and the
fuse fails it must be replaced with one of the same rating.
l
If the plug or cord requires replacing a new cord set should be
fitted by an Authorised Kenwood Repairer.
l
WARNING: THIS APPLIANCE MUST BE EARTHED.
Note:
l
For non-rewireable plugs the fuse cover MUST be refitted when
replacing the fuse. If the fuse cover is lost then the plug must not
be used until a replacement can be obtained. The correct fuse
cover is identified by colour and a replacement may be obtained
from your Kenwood Authorised Repairer (see Service).
l
If a non-rewireable plug is cut off it must be DESTROYED
IMMEDIATELY. An electric shock hazard may arise if an unwanted
non-rewireable plug is inadvertently inserted into a socket outlet.
l
This appliance conforms to EC Regulation 1935/2004 on materials
and articles intended to come into contact with food.
l
Only use the appliance for its intended
domestic use. Kenwood will not accept
any liability if the appliance is subject to
improper use, or failure to comply with
these instructions.
Before using for the first time
1 Wrap any excess cord around
the bracket
7
on the underside
of the powerbase.
2 Fill to ‘MAX’, boil, then pour the
water away. Repeat 3 times.
Key
1
Spout
2
Flip top lid
3
Lid release button
4
On/off switch with indicator
light
5
Water level gauge
6
360° Powerbase
7
Cord wrap
8
Filter
To use your kettle
1 Fill the kettle by opening the
lid
(A). The water level must
be between ‘MAX’ and ‘MIN’
(500mls) on the water level
gauge.
l
If you live in a hard water
area we recommend that you
use filtered water in order to
maintain the appearance and
efficiency of your kettle.
l
Be economical: do not boil
more water than you need.
l
To improve the quality of your
drinks always use fresh water.
l
Empty the kettle after each use.
English
5
l
Rinse out with fresh water if the
kettle has not been used for
more than 2 days.
2 Close the lid by pushing down
on the lid.
3 Plug in and switch on. The
power on light
4
will come on.
4 Your kettle will boil and switch
off automatically. To re-boil,
wait a few seconds - the on/off
switch needs time to reset.
Note - To interrupt the boiling
ensure that the switch is in the
off position before removing
from the powerbase.
l
If you experience problems
with your kettle switching on
and off during use or switching
off before boiling, check that
the flat element is free from
scale - see “descaling”.
l
Your kettle is fitted with a filter
to hold back limescale particles.
l
If you find drops of water under
your kettle, do not worry - it is
just condensation.
Boil-dry protection
l
If you switch on with too little
water, your kettle will cut
out automatically. Switch off,
remove from the powerbase
and let it cool down before
re-filling. When it has cooled
down, the switch will reset itself.
Care and cleaning
l
Before cleaning, unplug your
kettle and let it cool down.
The outside and powerbase
l
Wipe with a damp cloth, then
dry. Do not use abrasives -
they will scratch the metal and
plastic surfaces.
The inside
l
Wipe with bicarbonate of
soda on a damp cloth. Rinse
thoroughly.
l
Even though your kettle comes
with a filter, you still need to
clean the inside (and the filter)
regularly.
The filter
(B)+(C)
1 Open the lid.
2 Unclip and slide out the filter
(B).
3 Either rinse under the tap
or use a soft brush or when
descaling your kettle, drop the
filter in too. Rinse thoroughly.
4 Replace the filter by locating
the front of the filter into the
spout area then clip into place
(C).
Descaling
l
Regular descaling of the flat
element will improve the
performance of your kettle.
If the kettle is not descaled
regularly the build up of
limescale may result in the
following:
l
problems may be
experienced with the kettle
switching on and off during
use or switching off before
boiling.
l
the kettle may take longer to
boil.
l
the flat element may be
damaged.
Please note: Failure to descale
your kettle may invalidate your
guarantee.
l
When limescale starts to build
up on the heating element, buy
a suitable descaler and descale
your kettle. After descaling, boil
with fresh water several times
and discard. Clean any descaler
off the kettle - it can damage
the parts.
l
Some regions of the country
have chalky water. This makes
boiled water look cloudy and
leaves a deposit on the side of
the kettle. This is normal but
can be removed with regular
cleaning.
l
Alternatively, to reduce
limescale build up, use filtered
water to fill your kettle.
English
6
Service and customer care
If you experience any problems with the operation of the kettle,
before calling for assistance refer to the troubleshooting guide or
visit www.kenwoodworld.com.
UK
If you need help with:
l
using your kettle
l
servicing or repairs (in or out of guarantee)
Z call Kenwood Customer Care on 0345 222 0458. Have your model
number ready (e.g. TYPE ZJP04 or TYPE ZJP05) and date code
(5 digit code e.g. 21T04) ready. They are located on the underside
of your kettle and powerbase.
l
spares and attachments
Z call 0844 557 3653.
Other countries
l
If you experience any problems with the operation of
your appliance, before requesting assistance refer to the
“Troubleshooting guide” section in the manual or visit
www.kenwoodworld.com.
l
Please note that your product is covered by a warranty, which
complies with all legal provisions concerning any existing warranty
and consumer rights in the country where the product was
purchased.
l
If your Kenwood product malfunctions or you find any defects,
please send it or bring it to an authorised KENWOOD Service
Centre. To find up to date details of your nearest authorised
KENWOOD Service centre visit www.kenwoodworld.com or the
website specific to your Country.
l
Made in China.
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE
PRODUCT IN ACCORDANCE WITH THE EUROPEAN DIRECTIVE ON
WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT (WEEE)
At the end of its working life, the product must not be disposed of as
urban waste.
It must be taken to a special local authority differentiated waste
collection centre or to a dealer providing this service.
Guarantee (UK only)
If your kettle goes wrong
within one year from the date
you bought it, we will repair
or replace it free of charge
provided:
l
you have not misused,
neglected or damaged it;
l
it has not been modified (unless
by Kenwood);
l
it is not second-hand;
l
it has not been used
commercially;
l
you have not fitted a plug
incorrectly; and
English
7 8
Problem Cause Solution
Kettle not operating. No Power. Check kettle is plugged in.
Kettle unplugged. Check kettle is correctly
located to the powerbase.
Kettle not switching Kettle overfilled. Check water level is not
off automatically after above the Max level.
boiling/Long switch
off time. Lid not closed. Check lid is closed
correctly.
Water splashing out Filter not fitted in Always use the filter and
of spout area. spout area. do not overfill above the
Max level.
Kettle switching on Limescale/mineral Check that the element is
and off during use or build up on element free from scale.
switching off before affecting operation. Refer to “descaling”
water boiled. section under care and
cleaning.
Kettle stopped Boil dry protection Switch off and remove
working during operated due to from the powerbase.
operation. insufficient water in Allow to cool down
the kettle. before refilling.
When the kettle has
cooled down the switch
will reset itself.
Check the water level is
above the minimum level.
If none of the above solve the problem see “Service & Customer Care”.
Troubleshooting guide
l
you supply your receipt to
show when you bought it.
This guarantee does not affect
your statutory rights.
Children and burns
or scalds
Advice from the British Burn
Association
Every year, 30,000 children go
to hospital with burns. What
might be a minor burn for an
adult could horrifically injure -
or even kill - a child.
take these precautions
l
Keep hot drinks out of
children’s reach.
l
Do not drink while holding your
baby. If you’re passing someone
a drink, make sure a child isn’t
underneath.
l
Keep your kettle, and its cord,
well back from the worktop
edge so that children can’t grab
them.
l
Keep children away from the
kitchen work area.
l
For baby’s bath, run the cold
water first, then add the
hot. Mix well and test the
temperature with your elbow
before you put baby in.
l
Teach children about hot things.
Run cold water over a burn
immediately, then get medical
help. Do not stop to remove
clothing.
English
7 8
œ∞Oq «ß∑JAU· «_îDU¡ Ë≈Åö•NU
«∞LAJKW «∞º∂V«∞L∫∑Lq «∞∫q
«∞Gö¥W ô ¢FLq. ô ¢u§b ©UÆW. ¢QØbÍ ±s ¢uÅOq «∞Gö¥W °LBb¸
«∞∑OU¸ «∞JNd°w.
«∞Gö¥W ±HBu∞W ´s ±Bb¸ ¢QØbÍ ±s Ë{l «∞Gö¥W ´Kv ÆU´b…
«∞∑OU¸ «∞JNd°w. «∞DUÆW °Dd¥IW Å∫O∫W.
«∞Gö¥W ô ¢∑uÆn ¢KIUzOUÎ °Fb «∞Gö¥W ±F∂Q… ≠u‚ ßF∑NU ¢QØbÍ ±s √Ê ±º∑uÈ «∞LU¡ ô ¥∑πUË“
¨KOUÊ «∞LU¡. «∞IBuÈ. ´ö±W «∞∫b «_ÆBv.
≈¥IU· «∞∑AGOq °Fb ≠∑d… ©u¥KW.
¢∑MU£d «∞LOUÁ îU¸Ã ≠∑∫W ∞r ¥∑r ¢dØOV «∞Ld®` ≠w ¢QØbÍ ±s «ß∑ªb«Â «∞Ld®` œ«zLU
«∞BV. ≠∑∫W «∞BV. Ëô ¢∑πUË“Í «∞ºFW «∞IBuÈ ∞∑F∂µW
«∞Gö¥W °U∞LU¡.
¨ö¥W «∞LOU… ¢FLq Ë¢∑uÆn ´s ≥MU„ ¢dßO∂U‹ §Od¥W ´Kv ¢QØbÍ ±s îKu ßD` «∞∑ºªOs ±s
«∞FLq √£MU¡ «∞∑AGOq, √Ë ßD` «∞∑ºªOs ¢R£d ´Kv «∞∑dßO∂U‹ «∞πOd¥W.
¢∑uÆn ´s «∞FLq Æ∂q ¨KOUÊ «_œ«¡. ¸«§Fw ≠Id… “≈“«∞W «∞∑dßO∂U‹
«∞LOUÁ. «∞πOd¥W” {Ls ƺr «∞FMU¥W
Ë«∞∑MEOn.
¢uÆHX «∞Gö¥W ´s «∞FLq √£MU¡ ¢r ¢AGOq Ë™OHW «∞∫LU¥W {b √ËÆHw ¢AGOq «∞Gö¥W Ë√“¥KONU ´s
«∞∑AGOq. «∞∑AGOq °bËÊ ±U¡ ≤∑OπW ´b ÆU´b… «∞DUÆW.
˧uœ ØLOW ØU≠OW ±s «∞LU¡ ≠w «¢dØONU ∞∑∂dœ Æ∂q ≈´Uœ… ¢F∂µ∑NU ±d…
«∞Gö¥W. √îdÈ °U∞LU¡.
´Mb±U ¢∂dœ «∞Gö¥W, ßOFOb «∞LH∑UÕ
¢FOOs ≤Hºt –«¢OUÎ.
¢QØbÍ ±s ¢F∂µW «∞Gö¥W °U∞LU¡ ≠u‚
´ö±W «∞∫b «_œ≤v ∞Lº∑uÈ «∞LU¡.
≈Ê ∞r ¢∑r •q «∞LAJKW «∞∑w ¢u«§NOMNU ±s îö‰ «∞ªDu«‹ «∞ºU°IW, ≠Hw ≥cÁ «∞∫U∞W ¸«§Fw ƺr
“«∞BOU≤W ˸´U¥W «∞FLö¡”.
لوفقم ريغ يولعلا ءاطغلا
.حيحص لكشب
لكشب يولعلا ءاطغلا لفق نم يدكأت
.حيحص
١٣
English
9 10
ري ،ةدعاسا بلطل لاصتا لبق ،زاها ليغشتب ةقلعتم ةشم ةيأ ةهجاوم ةلاح
l
بيولا عقوم ةرايز وأ ليلدلا »اهلحو تكشا فاشتكا ليلد« مسق ةعجارم
.www.kenwoodworld.com
ةينوناقلا محا ةف عم قفاوتي نضلا اذه ،نضب لوم كزاهج نأب ةظحا ري
l
.ام جتنا ءا لا دلبلا كلساو نضلا قوق ةقلعتاو ا لومعا
وأ هلاسرإ ف ،بويع يأ دوجو ةلاح وأ لمعلا نع Kenwood جتنم لطعت ةلاح
l
لوح ةثد تامولعم ع لوصحلل .KENWOOD نم دعم ةمدخ زكرم إ هراضحإ
بيولا عقوم ةرايز ري ،KENWOOD نم دعم ةمدخ زكرم برقأ
.كدلبل صصخا بيولا عقوم وأ ،www.kenwoodworld.com
«∞BOU≤W Ë«∞FMU¥W °U∞FLö¡
داا تاجوتل قفو جتنا نم صلختلل ةحيحصلا ةيفيكلا وه ةماه تامولعم
ةينوكلاو ةيئابرهكلا تادعا تايافنب ةقلعتا وروا
)WEEE(
l ÅMl ≠w «∞BOs.
≠w ≤NU¥W «∞FLd «∞∑AGOKw ∞KπNU“, ¥πV ´b «∞∑ªKh ±s «∞πNU“ ≠w ≤HU¥U‹ «∞LMU©o «∞∫Cd¥W.
°q ¥πV √îcÁ ≈∞v ±dØe ¢πLOl îU’ °πNW ±∫KOW ±∑ªBBW ≠w «∞∑ªKh ±s ≥cÁ «∞MHU¥U‹ √Ë
≈∞v ¢U§d ¥Ib ≥cÁ «∞ªb±W.
١٢
English
9 10
l ≈–«Ë«§N∑p±BU´V≠w¢AGOq
Ë≈¥IU·«∞Gö¥W√£MU¡«ôß∑ªb«Â√Ë
≠w≈¥IU·«∞∑AGOqÆ∂q«∞GKw;≠∑QØb
√Ê«∞FMBd«∞LºD`îU‰±s«∞πOd-
¸«§l“≈“«∞W«∞πOd”.
l «∞Gö¥W °NU ±d®` ô•∑πU“ «∞Lu«œ «∞πOd¥W.
l ≈–« ´∏d‹ ´Kv ≤IU◊ ±s «∞LU¡ ¢∫X «∞Gö¥W;
≠ö ¢IKo ≠Nc« ¢J∏n Ë•ºV.
«∞∫LU¥W±s«∞GKw´Kv«∞πU·
l ´Mb ¢AGOq «∞πNU“ Ë°t ÆKOq ±s «∞LU¡; ≠SÊ
–∞p ¥RœÍ ≈∞v ¢uÆHt ´s «∞FLq ¢KIUzOÎU. √ËÆn
´Lq «∞πNU“; £r ≠Jt ±s «∞IU´b… Ë«¢dØt ¥∂dœ
Æ∂q ≈´Uœ… «∞Lq¡. °Fb √Ê ¥∂dœ; ¥FOb «∞LH∑UÕ
{∂j ≤Hºt.
«∞FMU¥W Ë«∞∑MEOn
l Æ∂q «∞∑MEOn; «≠Bq «∞πNU“ Ë«¢dØt ¥∂dœ.
«∞πe¡«∞ªU¸§wË«∞IU´b…
«∞πe¡«∞b«îKw
l
±º` °∂OJd°u≤U‹ «∞Buœ« ´Kv ÆDFW ±s
«∞ILU‘ ¸©∂W. «®DHw §Ob«Î.
l •∑v Ë≈Ê ØU≤X «∞Gö¥W ¢∫∑uÍ ´Kv
±d®`; ≈ô √≤t ¥πV ¢MEOn «∞πe¡ «∞b«îKw
(Ë«∞Ld®`) °U≤∑EUÂ.
«∞Ld®`
3 ≈±U °U∞ADn ¢∫X «∞BM∂u¸ √Ë «ß∑ªb«Â
≠d®U… ∞OMW.
√Ë ´Mb ≈“«∞W «∞πOd ±s «∞Gö¥W; √œîq
«∞Ld®` ≠ONU √¥CÎU. «®Dn §ObΫ.
≈“«∞W«∞πOd
l ¢FLq «ù“«∞W «∞b˸¥W ∞KπOd ±s «∞FMBd
«∞LºD` ´Kv ¢∫ºOs √œ«¡ «∞Gö¥W. ≈–« ∞r
¥∑r ≈“«∞W «∞πOd ±s «∞Gö¥W °U≤∑EUÂ; ≠SÊ
¢d«Ør «∞πOd Æb ¥RœÍ ≈∞v ±U ¥Kw:
l ±u«§NW ±AUØq ≠w ¢AGOq Ë≈≤NU¡ ¢AGOq
«∞Gö¥W √£MU¡ «ôß∑ªb«Â √Ë ≈≤NU¡ ¢AGOKNU
Æ∂q «∞GKw.
l Æb ¢º∑Gd‚ «∞Gö¥W ËÆ∑ÎU √©u‰ ∞Jw ¢GKw.
l Æb ¥∑Kn «∞FMBd «∞LºD`.
¥d§v
«ô≤∑∂UÁ: «ùîHU‚ ≠w ≈“«∞W «∞πOd ±s
«∞Gö¥W Æb ¥∂Dq «∞CLUÊ.
l ´Mb±U ¥∂b√ «∞πOd ≠w «∞∑d«Ør ´Kv ´MBd
«∞∑ºªOs; «®∑dÍ ±e¥q §Od ±MUß∂ÎU
Ë¢ªKh ±s «∞πOd «∞Lu§uœ ≠w «∞Gö¥W.
°Fb ≈“«∞W «∞πOd; «¨ºq ±U¡ ≤EOHÎU ´b… ±d«‹
Ë¢ªKh ±Mt. ≤En Øq °IU¥U ±e¥q «∞πOd _≤t
Æb ¥∑Kn «∞LJu≤U‹.
l °Fi «∞LMU©o ≠w «∞bË∞W ±Uƒ≥U §OdÍ. «_±d
«∞cÍ ¥πFq «∞LU¡ «∞LGKw ¥∂bË ±FJdΫ Ë¥∑d„
¬£U¸Î« ´Kv §U≤V «∞Gö¥W. Ë≥c« «_±d ´UœÍ;
Ë∞Js ¥LJs ≈“«∞∑t °U∞∑MEOn «∞LM∑Er.
l √Ë ¥LJs ∞∑IKOq ¢d«Ør «∞πOd; «ß∑ªb«Â «∞LU¡
«∞Ld®` ∞∑F∂µW «∞Gö¥W.
.فيفجتلا ةبطر شا ةعطقب حسم
l
إ يدؤت فوس – ةطش داوم دختست
.كيتسبلاو دعا حطسلا شدخ
.
(B)
جراخلل هيباو را كبشم ف ٢
ءزا عضو لخ نم را دبتسا 4
هيتبث بصلا ةقطنم رل اما
.
(C)
هعضوم
.يولعلا ءاطغلا يحتفا ١
(B)+(C)
١١
English
11
يبرهكلا رايتلا ردصمب ليصوتلا لبق
ىلع ةحضوملا تافصاوملا عم كيدل يبرهكلا رايتلا تافصاوم قباطت نم يدكأت
l
.زاهجلل يلفسلا بناجلا
يبرهكلا رهصنملاو سبقملا – ماه
:يلاتلاك يه يبرهكلا كلسلا يف ةدوجوملا كسا ناوللا
l
يضرا = رفصأ طخب رضخأ
لداعتم = قرزأ
ةيح ءابرهك = ينب
بجيف ،رهصملا اذه لطعتو بكر
ُ
م رهصم هب كزاهج يف دوزملا سباقلا ناك اذإ
l
.ةيريبما ريدقت سفنب هل لثامم رهصمب هلادبتسا
امهلادبتسا بجيف ،يبرهكلا كلسلا وأ سبقملا لادبتسا ىلإ ةجاحلا ةلاح يف
l
.Kenwood ىدل دمتعم صصختم ةنايص زكرم لبق نم امهبيكرتو
.يضرأ فرطب زاهجلا اذه ليصوت بجي :ريذحت
l
:ةظحم
ةداعإ بجي ،،اهب ةديدجلا كسا بيكرت ةداع ةلباقلا ريغ سباقملا ىلإ ةبسنلاب
l
،يبرهكلا رهصنملا ءاطغ دقف ةلاح يف .هلادبتسا دنع يبرهكلا رهصنملا ءاطغ تيبثت
رهصنملا ءاطغ ديدحت متي .ليدب ىلع لوصحلا متي نأ إ سبقملا مادختسا مدع بجي
صصختم ةنايص زكرم نم ليدب ىلع لوصحلا نكميو نوللا بسح حيحصلا يبرهكلا
.)ةمدخلا مسق ةعجارم ىجري( Kenwood ىدل دمتعم
ىلع هريمدت بجيف ،هب ةديدجلا كسا بيكرت ةداع لباق ريغ سبقم عطق مت اذإ
l
،سبقملا جرخم يف دصق ريغ نع ديدمتلا ةداع لباق ريغ سباق لاخدإ مت اذإ .روفلا
.ةيئابرهك ةمدص ثودح رطخ أشني دق دقف
ماسجاو داوملاب ةقلعتملا 2004/1935 يبوروا داحتا تاميظنت عم زاهجلا اذه قفاوتي l
.ةمعطا عم ةسمتملا
Æ∂q«ôß∑ªb«Â∞KLd…«_Ë∞v
1 ∞Hw √Í ©u‰ “«zb ≠w «∞ºKp «∞JNd°w •u‰
«∞Iu”
g
«∞Lu§uœ ≠w «∞πU≤V «∞ºHKw
∞IU´b… «∞DUÆW.
2 «±Kµw «∞Gö¥W •∑v ±º∑uÈ «∞Fö±W “
XAM”
(«∞∫b «_ÆBv) £r «¨Kw «∞LU¡ ËÅ∂Ot
°FOb«Î.
«∞b∞Oq
ôß∑ªb«Â «∞πNU“
l
≈–« ØMX ¢IOLOs ≠w ±MDIW °NU ±U¡ ´ºd,
≠MMB∫p °Uß∑ªb«Â ±OUÁ ±d®∫W ∞K∫HUÿ
´Kv ±ENd ËØHU¡… ¨ö¥W «∞LOUÁ.
l «Æ∑Bb: ô ¢Gq ±U¡ √Ø∏d ±LU ¢∫∑UÃ.
l «ß∑ªb ±U¡ ≤IOÎU ∞∑∫ºOs §uœ…
«∞LAdË°U‹.
l √≠d⁄ «∞Gö¥W °Fb Øq «ß∑ªb«Â.
3 Åq «∞JNd°U¡ £r ®Gq «∞πNU“.
4 ßu· ¢GKw «∞Gö¥W Ë¢∑uÆn ¢KIUzOÎU ù´Uœ…
«∞GKw; «≤∑Ed °Cl £u«Ê; ¥πV ≈´Uœ… {∂j
±H∑UÕ «∞∑AGOq «ù¥IU·.
±ö•EW-ù¥IU·´LKOW«∞GKOUÊ,
¢QØbͱs¢u§Ot«∞LH∑UÕ≈∞v±u{l
≈¥IU·«∞∑AGOqÆ∂q«ù“«∞W´sÆU´b…
«∞DUÆW.
.تارم ٣ ةوطخلا هذه يررك
بصلا ةحتف
بق يولع ءاطغ
يولعلا ءاطغلا ريرحت رز
دوزم )فاقيإ/ليغشت( On/Off حاتفم
يئوض رشؤمب
ءاملا ىوتسم سايقم
a
b
c
d
e
f
g
h
ÆU´b… ©UÆW 063 œ¸§W
∞n «∞ºKp
«∞Ld®`
d
.لفس هيلع طغضلاب يولعلا ءاطغلا يقلغأ ٢
مدع ةلاح يف يراج ءامب ةيغلا يفطشا l
نيموي ةدمل اهمادختسا
ءاضي ذئدنع
.
ةقاطلا ليغشت ءوض
يولعلا ءاطغلا حتف قيرط نع ةيغلا يئبع ١
نيب ءاملا ىوتسم نوكي نأ بجي .
(A)
)ىصقا دحلا( "MAX" نيتمعلا
ىلع )يللم 500( )ىندا دحلا( "MIN"و
.ءاملا ىوتسم سايقم
١0
English
12
نوكي ثيحب نةيغلا ةئبعت لبق يولعلا ءاطغلا يليزأ
l
.يئرم ءاملا ىوتسم سايقم
.ءاملا نايلغ ءانثأ يولعلا ءاطغلا يحتفت :ريذحت
l
باسنت دقف – يولعلا ءاطغلا حتف دنع رذحلا يخوت
l
.يلغملا ءاملا نم تارطقلا ضعب
l
¢QØbÍ ±s ≈•JU ¨Ko «∞GDU¡ «∞FKuÍ Æ∂q ¢AGOq
«∞Gö¥W.
l
¢QØbÍ ±s ≈¥IU· ¢AGOq «∞Gö¥W Æ∂q ≈“«∞∑NU ´s ÆU´b…
«∞DUÆW √Ë «∞BV.
l
√“¥Kw «∞Gö¥W ´s ÆU´b… «∞DUÆW Æ∂q «∞∑F∂µW √Ë «∞BV.
l
¥∫c¸ Ë{l «∞Gö¥W °U∞Id» ±s √Ë ´Kv ßD` ±uÆb
ßUîs √Ë ®FKW «∞LuÆb «∞GU“Í
l
≥cÁ «∞Gö¥W ôß∑ªb«±U‹ ¨Kw «∞LU¡ ≠Ij.
l
Æb ¥RœÍ ßu¡ «ß∑ªb«Â «∞πNU“ ≈∞v •bËÀ ≈ÅU°U‹
l
¥LJs ∞ú©HU‰ «∞c¥s ¢∑d«ËÕ √´LU¸≥r ±s 8 ßMu«‹
˱U ≠u‚ «ß∑ªb«Â Ë¢MEOn ËÅOU≤W «∞πNU“ Ë≠IUÎ
∞∑FKOLU‹ «ôß∑ªb«Â, ®d¥DW √Ê ¥∑r «ù®d«·
´KONr ±s Æ∂q ®ªh ±ºµu‰ ´s ßö±∑Nr ˱M∫Nr
¢FKOLU‹ °AQÊ «ß∑ªb«Â «∞πNU“ Ë≈œ¸«ØNr ∞KLªU©d
«∞LMDu¥W ´Kv «ß∑ªb«±t.
l
«_®ªU’ –ËÍ «∞Ib¸«‹ «∞πºb¥W √Ë «∞∫ºOW
√Ë «∞FIKOW «∞LMªHCW ˱Ls ∞OºX ∞b¥Nr ±Fd≠W
°Uß∑ªb«Â «∞πNU“ ¥πV «ù®d«· ´KONr √Ë ±M∫Nr
«∞∑FKOLU‹ «∞ªUÅW °Uß∑ªb«Â «∞πNU“ °Dd¥IW ¬±MW
±l ≈œ¸«„ «∞LªU©d «∞∑w ¢MDuÍ ´Kv «ß∑ªb«Â
«∞πNU“.
l
¥M∂Gw ´Kv «_©HU‰ ´b «∞F∂Y °U∞πNU“, ØLU ¥πV
«ô•∑HUÿ °U∞πNU“ Ë«∞ºKp «∞JNd°w °FOb«Î ´s ±∑MUˉ
«_©HU‰ ±Ls ≥r œËÊ 8 ßMu«‹ ±s «∞FLd”.
l
«ß∑ªb±w «∞πNU“ ≠Ij ≠w «ôß∑ªb«±U‹ «∞LMe∞OW
«∞LªBh ∞NU. ∞s ¢∑∫Lq ®dØW doowneK √¥W ±ºµu∞OW
≠w •U∞W «ß∑ªb«Â «∞πNU“ °Dd¥IW ¨Od Å∫O∫W √Ë ´bÂ
«ô±∑∏U‰ ∞K∑FKOLU‹ «∞LcØu¸….
٩
English
13
«∞ºö±W
l
«Ædzw «∞∑FKOLU‹ «∞∑U∞OW Ë«•∑HEw °NU ≠w «∞L∑MUˉ
∞öß∑ªb«±U‹ «∞Lº∑I∂KOW «∞Ld§FOW.
l
√“¥Kw ±Ju≤U‹ «∞∑GKOn Ë√¥W ±KBIU‹.
l
¥∫c¸ «ß∑ªb«Â «∞πNU“ ≠w •U∞W ¢KHt. ¥πV ≠∫h
«∞πNU“ √Ë ≈Åö•t: ¸«§Fw ƺr “«∞BOU≤W ˸´U¥W
«∞FLö¡”.
l
«ß∑ªb±w «∞Ld®` œ«zLUΠ˥∫c¸ ¢πUË“ «∞ºFW «∞IBuÈ
∞K∑F∂µW - ≠Ib ¥∑MU£d «∞LU¡ «∞LGKw ≈∞v «∞ªU¸Ã.
l
¢πM∂w «∞∑Fd÷ ∞K∂ªU¸ «∞ªU¸Ã ±s ±MDIW «∞BV √£MU¡
ÅV «∞LU¡ «∞LGKw √Ë «∞∂ªU¸ «∞ªU¸Ã ±s «∞GDU¡ «∞FKuÍ
√Ë ±MDIW «∞BV √£MU¡ ≈´Uœ… ¢F∂µW «∞Gö¥W.
l
¥∫c¸ ¢d„ «∞ºKp «∞JNd°w ±∑b∞OUÎ ≠w •U∞W ˧uœ ©Hq
≠Ib ¥M∑e´t.
l
«≠BKwœ«zLUΫ∞Gö¥W´s±Bb¸«∞∑OU¸«∞JNd°w
≠w•U∞W´b«ß∑ªb«±NU.
l
¥∫c¸ Ë{l «∞Gö¥W √Ë ÆU´b… «∞DUÆW √Ë «∞ºKp «∞JNd°w
√Ë «∞IU°f «∞JNd°w ≠w √Í ßUzq.
l
¢M∂Ot: ô ¢AGKw «∞Gö¥W ´Kv ßD` ±Uzq.
l
«ß∑ªb±w ≠Ij ÆU´b… «∞DUÆW «∞LeËœ… ±l «∞πNU“ Ë¥πV
«∞∫HUÿ ´Kv ≤EU≠∑NU ˧HU≠NU.
´d°w
Æ∂q«∞Id«¡…,«∞d§U¡ÆKV«∞BH∫W«_Ë∞v∞Fd÷«∞Bu¸
٨
ءانثأ ةيغلل دعا مسا ني :رذا وت
l
.ليغشتلا
ةرارحلاب ظافتحل ةضرع نيخستلا رصنع حطس
l
.مادختسا دعب
ةيأ ثودح بنجتلو ةمسلاب ةقلعتم بابس
l
،سباقلا وأ يبرهكلا كلسلا فلت ةلاح يف ،رطاخم
ةمدخ زكرم وأ
Kenwood ةطساوب هلادبتسا بجي
.Kenwood لبق نم دمتعم
باكسنا يأ ثودح بنجتل رذحلا يخوت :ريذحت
l
وأ ةئبعتلا وأ فيظنتلا ءانثأ يبرهكلا لصوملا ىلع
.بصلا
English
