www.PyleUSA.com
Cut the drywall.
Note: Always allow at least one-half
inch between a wall stud and the
speaker cutout, or the locking tabs
will not be able to swivel into place.
Connect the speaker wires to the
speaker.
Features:
• 6-112"High Quality Poly Carbon Cone
• 2-Way Water Resistant Construction Design
• 1"High Temperature Voice Coil
• 1/2"Neodymium Dome Tweeter
• 200 Watts Rated Peak Power
• Frequency Response: 85Hz-20K Hz
• 4 Ohm Impedance
• Sensitivity: 90dB
Installation
Visit Our Website
SCAN ME
PyleUSA.com
PLMR62
USER GUIDE
6-1/2” 2-Way Marine Speaker System
www.PyleUSA.com
Installation
Screw down each of the four Phillips
head screws. The locking tabs will
swivel into place and secure the unit
to the rear surface of the drywall.
Put in the strips of adhesive to secure
the grille.
Replace the metal grille.
Complete
California Prop 65 Warning
WARNING:
This product can expose you to chemicals, which is known to
the state of California to cause cancer birth defects and other
reproductive harm. Do not ingest.
For more info go to: www.P65warnings.ca.gov
Questions or Comments?
We are here to help!
Phone: 1.718.535.1800
PyleUSA.com/ContactUs
• Speaker Total Diameter: 7.09''
• Speaker Cut-Out Diameter: 5.31''
• Speaker Mounting Depth: 2.48''
RED +
BLACK -
