USER GUIDE
Dual 6.5’’ Waterproof-Rated Marine
Speakers
PLMR652B - PLMR652W
www.PyleUSA.com2 www.PyleUSA.com 3
READ ALL INSTRUCTIONS CAREFULLY BEFORE USING THIS PRODUCT.
RETAIN THIS OWNER’S MANUAL FOR FUTURE REFERENCE.
Features:
• Includes (2) 6.5'' Coaxial Speakers
• Marine Grade Waterproof-Rated Construction
• Water-Resistant & Weatherproof Design
• Impressive Wide-Bass Response
• 2-Way Full Range Stereo Sound Reproduction
• Universal Standard OEM Replacement Size
• Hassle-Free Easy Access Speaker Terminals
• Reinforced Surround with Dense Speaker Cone
• Rugged Machined Basket & Grill with UV Resistant Housing
• Used For Car, Boat, O-Road & Marine Vehicle Applications
What’s in the Box:
• (2) 6.5’’ -inch Marine Speakers
• Cut-Out Template
• Mounting Screws
Sizes / Dimensions:
• Total Diameter: 6.9’’ -inches
• Cut-Out Diameter: 6.75’’ –inches
• Total Depth: 3.16” -inches
• Mounting Depth: 2.3’’ -inches
Technical Specs:
• Power Output: 600 Watt MAX (300 Watt RMS)
• Marine Grade Rating: IP-X4
• Speaker Composition: Polypropylene Cone, Butyl Rubber Surround
• Voice Coil: 1.0'', Aluminum (x2)
• Tweeters: 0.5'', Neodymium Dome (x2)
• Impedance: 4 Ohm
• Sensitivity: 90 dB
• Circuit Magnet: 20 oz.
• Frequency Response: 85Hz-20kHz
• Power Supply: DC 12V
• Single Speaker Weight: 1.344 lbs. (-Each Speaker)
FCC INFORMATION
WARNING: Changes or modications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This unit generates, uses, and can radiate radio frequency energy, and if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment o and on,
the user is encouraged to try and correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit dierent from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may
cause undesired operation.
California Prop 65 Warning
WARNING:
This product may expose you to chemicals, which is known to
the state of California to cause cancer, birth defects and other
reproductive harm. Do not ingest.
For more info go to: www.P65warnings.ca.gov
www.PyleUSA.com4 www.PyleUSA.com 5
Precautions
• Make sure the speakers are rmly installed before use.
• Do not go over the 600-watt power limit.
• Don’t press or hit the speaker cones or grills.
• Speakers are waterproof-rated, but do not fully submerge them in water.
• Turn o the power before connecting any wires.
• Use marine-grade wires and connectors for better performance.
• Match the + and - speaker wires correctly to avoid sound issues.
Cleaning
• Wipe the speakers with a soft, damp cloth.
• If used near saltwater, rinse gently with fresh water to remove salt.
• Do not use harsh cleaners or spray water directly into the speaker.
• Dry completely with a soft towel.
Maintenance
• Check the speakers and mounting parts often for any signs of damage or rust.
• Make sure all screws and wires are tight and secure.
• If needed, apply a waterproof sealant to protect against weather.
• Play music now and then to make sure everything sounds right.
Storage
• If you're not using the speakers for a while, store them in a dry, cool place.
• Cover or box them to protect from dust and damage.
• Unplug the speaker wires to avoid rust or corrosion.
Installation
LED INDICATOR
Other Ways to Connect
I. High-Level Input (Optional)
• Connect the speakers using speaker cables (not included) as shown in the
diagram.
• The speaker operates in a non-amplied passive state and receives signals
from radio sources.
II. Low-Level Input (Optional)
Connect the speakers to the radio using RCA cables (not included) as shown in
the diagram.
Note: Connection I is required for the Bluetooth feature between the Main
and Slave speakers. Connections II and III are optional.
Register Product
Thank you for choosing PyleUSA. By registering your product,
you ensure that you receive the full benets of our exclusive
warranty and personalized customer support. Complete the
form to access expert support and to keep your PyleUSA
purchase in perfect condition.
Start Here
Model Number:
PLMR652B
PyleUSA.com/pages/register
II
RADIO
I
III
Low level out
PLMR652B
Low level input
6.5” 2-Way Speaker
Status Master Slave
POWER ON
RCA LINE IN (RF was Connected)
BLUEGREEN
RED RED
