WOpet Brook Stainless Steel Drinking Fountain
INSTRUCTIONS
D30
【CONTENTS】
………………………………1
………………………………………………………………5
…………………………………………………………………9
………………………………………………………………………………10
……………………………………………………………………12
3URGXFWVSHFLǓFDWLRQVDQGDSSHDUDQFH
.H\IHDWXUHV
$VVHPEOHDQGXVH
………………………………………………………7
'LVDVVHPEOHDQGFOHDQ
,PSRUWDQWQRWHV
FAQ s
)&&ZDUQLQJV
………………………………………………………………………2
3OHDVHUHDGWKHVHLQVWUXFWLRQVFDUHIXOO\EHIRUHXVH
Thank you for choosing this WOpet intelligent product. In order to
guarantee your personal and material safety, please read these
instructions carefully before using our product. Under no circumstances
shall WOPET be liable to pay compensation or damages to any person
for any loss, injury, or damage, unless it's explicitly stipulated in law,
whatsoever occasioned by this product or as a result of not following
1
3URGXFWVSHFLǓFDWLRQVDQGDSSHDUDQFH
Water outlet mode: Spout jet / little flower fountain
Product dimensions: L288mm x W231mm x H94mm
Power supply: DC5V (Adapter for DC5V-1A or 2A is recommended)
Filter: Replaceable Carbon Filter
Product weight: 0.6 kg
Water storage capacity: 2.0 L (67 oz )
Consumed power: 1 W
Water outlet
Food-grade silicon
Drinking basin
304 stainless steel
Adapter (DC-5V-1A/2A)
In-line plug
USB Power Cord
Water storage basin
304 stainless steel
Filter cartridge
Built-in activated
carbon filter
Water pump
Burnout protection
Clamp wire stopper
Food-grade silicon
2
.H\IHDWXUHV
Little flower fountain type water outlet
(Natural and quiet)
For dogs to enjoy interesting and comfortable drinking.
3
Spout jet type water outlet
(fresh and oxygen-rich)
For kittens to enjoy fresh and oxygen-rich flowing water.
4
ŘȺ濦濼瀀瀃濿濸澳濴瀁濷澳濻濼濺濻激濸瀁濷澳濷濸瀆濼濺瀁澿澳瀆瀈濼瀇濴濵濿濸澳濹瀂瀅澳瀇濻濸澳瀊濴瀇濸瀅激濷瀅濼瀁濾濼瀁濺澳澳澳澳
habits of various pets.
řȺ濦瀃瀂瀈瀇澳濽濸瀇澳濴瀁濷澳濹瀂瀈瀁瀇濴濼瀁澳瀇瀌瀃濸澳瀊濴瀇濸瀅澳瀂瀈瀇濿濸瀇澳瀇瀂澳濶濴瀇濸瀅澳瀇瀂澳瀇濻濸
preferences and demands of different pets.
ŚȺ濧瀂瀇濴濿濿瀌澳濸瀁濶濿瀂瀆濸濷澳濷濸瀆濼濺瀁澳濼瀆澳瀆濴濹濸澳濴瀁濷澳瀆瀇濴濵濿濸澿澳濴瀁濷澳瀊濼濿濿澳濸濹濹濸濶瀇濼瀉濸濿瀌澳澳
prevent pets from overturning.
śȺ濙瀂瀂濷激濺瀅濴濷濸澳濹濼濿瀇濸瀅澳濴瀁濷澳濵瀈濼濿瀇激濼瀁澳濴瀁濷澳瀅濸瀃濿濴濶濸濴濵濿濸澳濴濶瀇濼瀉濴瀇濸濷澳濶濴瀅濵瀂瀁澳
filter element effectively filter impurities.
ŜȺ濦瀈瀃濸瀅激濸濴瀆瀌澳濷濼瀆瀀瀂瀈瀁瀇濼瀁濺澳濴瀁濷澳濶濿濸濴瀁濼瀁濺澳瀃瀅瀂瀉濼濷濸澳濶瀂瀀濹瀂瀅瀇濴濵濿濸澳
experiences for users.
ŝȺ濨濿瀇瀅濴激濿濴瀅濺濸澳瀇瀂瀃激濿濸瀉濸濿澳瀊濴瀇濸瀅澳濴瀅濸濴澳濼瀁濶瀅濸濴瀆濸瀆澳瀇濻濸澳瀊濴瀇濸瀅澳瀆瀇瀂瀅濴濺濸澳瀆瀂澳
continuing to work in occasional power outages.
ŞȺ濆濃濇澳瀆瀇濴濼瀁濿濸瀆瀆澳瀆瀇濸濸濿澳瀀濴濾濸瀆澳瀇濻濸澳瀃瀅瀂濷瀈濶瀇澳瀆濴濹濸澳濴瀁濷澳濷瀈瀅濴濵濿濸澳濴瀁濷澳濼瀇澳
conforms to the United States and EU safety standards.
şȺ濕瀅濴瀁濷澳瀁濸瀊澳瀊濴瀇濸瀅澳瀆瀇瀂瀅濴濺濸澳濴瀁濷澳濹濿瀂瀊澳瀆瀌瀆瀇濸瀀澳瀀濴濾濸澳濼瀇澳瀆瀈瀃濸瀅澳濶濿濸濴瀁澳
and rich in ozone, which improves water-drinking quality for
your pets.
1
2
3
4
5
6
7
8
5
$VVHPEOHDQGXVH
1
Open the top bowl by pulling the lifting handle as shown in
the picture.
2
Install the water pump at the location as shown in the picture.
3
Install the thread jamming slot as shown in the picture and
appropriately adjust the length of the water pump.
6
4
As shown in the picture, connect the DC connector.
5
Add appropriate water between “min” and “max”.
6
Install the top bowl.
7
Plug-in the adapter.
7
'LVDVVHPEOHDQGFOHDQ
Disassemble the fountain
1
Take out the drinking basin by pulling
the lifting handle as shown in the picture.
Take out the outlet for cleaning or replacing
according to the method shown in the picture.
Press to open the cover and take out the filter.
It is recommended to replace it once a week.
Take out the water pump to clean the
internal wall of the water storage basin.
a.
b.
c.
d.
1
2
3
4
8
Inlet cover
Filter
Cover
Pump
Rotor
Adjusting cover
Note:
Clean the internal wall of the water pump
2
Adjust the water flow rate
3
D30 stainless steel pet fountain has designed two modes for
different pets, the default installation of the product is spout
jet. Please switch to fountain type according to the method
shown in the picture b.
Take down the protective cover, adjusting cover and rotor successively.
1
In the pump, Max means increasing the water outlet, and Min deceasing.
1
The default setting is for Max flow.
2
Clean any foreign material inside it.
2
It is recommended to clean it once a week.
3
9
,PSRUWDQWQRWHV
1. Please add water immediately or stop using in the event that the
water level of the fountain is lower than the water pump.
2. Please keep the power adapter out of reach of pets so as to
prevent them from touching or chewing it.
3. Indoor use only. Please unplug the power line when cleaning,
and please note that the adapter cannot be cleaned and must
be kept away from water.
4. Cellphone adapters can be used (all DC5V are applicable).
5. Please keep the fountain away from socket and make sure the
adapter and socket are higher than the fountain to prevent
water damage.
6. For any questions, please contact the distributor or
manufacturer.
10
FAQs
Why is the noise of the water pump higher than before?
A: It is possible that the water level is too low, please add more water.
B: It is possible that there is foreign matter such as hair on the blades.
Please disassemble the water pump and have it cleaned.
Is it normal if the adapter heats up when the fountain is running
constantly?
A: It is normal for it to get slightly hot. It is within the safety range,
and will not cause any damage to the fountain.
How often should the fountain be cleaned?
A: It is recommended to clean it once or twice a week. Please do not
use detergent when cleaning, only use a cotton cloth with water.
11
Note: It's recommended to replace the filters every 2-4 weeks.
Is it safe for a water pump to operate on a long term basis and what
is its power consumption?
A: The fountain runs on a safe voltage, the same as a cellphone charger.
It is absolutely safe for people and pets.
B: The fountain is extremely power efficient. It will consume no more
than 1 Kilowatt-hour operating 24 hours every day in a month.
What is the fountain made of? What is the material of the filter?
A: The fountain is made of 304 food-grade stainless steel, which
conforms to United States and EU safety standards. The material
of the filter is Premium Activated Carbon.
12
)&&ZDUQLQJV
WARNING:
Changes or modifications to this unit not expressly approved.
Non-compliance could void the user's authority to operate
the equipment.
NOTE:
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
13
This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
Reorient or relocate the receiving antenna. ·Increase the distance
between the equipment and receiver.
Connect the equipment into an outlet on a different circuit from
that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Shielded interface cables must be used with the equipment in order
to comply with the limits for a digital device pursuant to Subpart B
of Part 15 of FCC Rules. Specifications and designs are subject to
change without any notice or obligation on the part of the
manufacturer.
A: The fountain is made of 304 food-grade stainless steel, which
conforms to United States and EU safety standards. The material
of the filter is Premium Activated Carbon.
