DOOR HANDLE INSTALLATION
The door handle comes detached due to packaging
restrictions.lt can be easily attached following the
instructions.
-Fix the two screws (1) to the door.
-Insert the two fixed screws into the two holes on the metal
handle(2).
-Fasten the two screws (3) to the bottom of the handle.
1
1
2
3
3
Setting of Fridge and Freezer Drawer
5 Upper drawer:
L1 indicates an open circuit of temperature
sensor for the upper drawer, and H1
indicates a short circuit of temperature
sensor for the upper drawer.
L2 indicates an open circuit of defrosting
temperature sensor for the upper drawer,
H2 indicates a short circuit of defrosting
temperature sensor in for the upper drawer
Lower drawer:
L1 indicates an open circuit of temperature
sensor for the lower drawer, and H1
indicates a short circuit of temperature
sensor for the lower drawer.
L2 indicates an open circuit of defrosting
temperature sensor for the lower drawer,
H2 indicates a short circuit of defrosting
temperature sensor in for the lower drawer
E9 indicates a communication failure
between the display board and power
board.
6 Each time the button is pressed, the
buzzer will beep once.
7 After the door has been open for 1
minute, the buzzer will beep until the door is
closed or any button is pressed.
temperature of the lower draw will flash,
allowing to set the temperature of the lower
draw. Press longer time to switch between
F/C;
3 Temperature up button: When the
temperature display LED flashes, press
once to increase the temperature by 1
degree, and the temperature range can not
cycle. Long press the up button and the
setting temperature goes up automatically.
4 Temperature down button: When the
temperature display LED flashes, press
once to decrease the temperature by 1
degree, and the temperature range can not
cycle. Long press the up button and the
setting temperature goes down automatical-
ly.
1 Power button: Press for 6 seconds to turn
off when the controller is on, press once
shortly to turn on when the controller is off.
2 Function button: Press once, the LED of
the temperature of the upper draw will flash,
allowing to set the temperature of the upper
draw. Press again, the LED of the
