2
3
4
5
1
MILWAUKEE TOOL
l
www.milwaukeetool.com
13135 W. LISBON RD., BROOKFIELD, WI 53005
Drwg. 2
FIG. PART NO. DESCRIPTION OF PART NO. REQ.
1 --------------- No Brim Safety Helmet (Non-vented Shown) (1)
2 48-73-1093 Helmet Top Liner (Accessory) (1)
3 48-73-1092 Helmet Sweat Band (Accessory) (1)
4 50-73-1067 Helmet Chin Strap Assembly (Accessory) (1)
5 48-73-1098 Helmet Suspension Assembly (Accessory) (1)
6 48-73-1087 F.R. Safety Helmet Chin Strap (Accessory) (Not Shown) (1)
BULLETIN NO.
PN0009308
SERVICE PARTS LIST
CATALOG NO.
REVISED BULLETIN
SPECIFY CATALOG NO. AND SERIAL NO. WHEN ORDERING PARTS
BOLT™ Safety Helmet - No Brim
DATE
Oct. 2025
48-73-1300 No Brim Safety Helmet Vented White
48-73-1301 No Brim Safety Helmet Unvented White
48-73-1302 No Brim Safety Helmet Vented Yellow
48-73-1303 No Brim Safety Helmet Unvented Yellow
48-73-1304 No Brim Safety Helmet Vented Blue
48-73-1305 No Brim Safety Helmet Unvented Blue
48-73-1306 No Brim Safety Helmet Vented Green
48-73-1307 No Brim Safety Helmet Unvented Green
48-73-1308 No Brim Safety Helmet Vented Red
48-73-1309 No Brim Safety Helmet Unvented Red
48-73-1310 No Brim Safety Helmet Vented Black
48-73-1311 No Brim Safety Helmet Unvented Black
48-73-1312 No Brim Safety Helmet Vented Orange
48-73-1313 No Brim Safety Helmet Unvented Orange
48-73-1334 No Brim Safety Helmet Vented Gray
48-73-1335 No Brim Safety Helmet Unvented Gray
BOLT™ SAFETY HELMET - FRONT BRIM SEE PAGE 2
BOLT™ SAFETY HELMET - FULL BRIM SEE PAGE 3
2
3
4
5
1
CATALOG NO.
BOLT™ Safety Helmet - Front Brim
48-73-1320 Front Brim Safety Helmet Vented White
48-73-1321 Front Brim Safety Helmet Unvented White
48-73-1322 Front Brim Safety Helmet Vented Yellow
48-73-1323 Front Brim Safety Helmet Unvented Yellow
48-73-1324 Front Brim Safety Helmet Vented Blue
48-73-1325 Front Brim Safety Helmet Unvented Blue
48-73-1326 Front Brim Safety Helmet Vented Green
48-73-1327 Front Brim Safety Helmet Unvented Green
48-73-1328 Front Brim Safety Helmet Vented Red
48-73-1329 Front Brim Safety Helmet Unvented Red
48-73-1330 Front Brim Safety Helmet Vented Black
48-73-1331 Front Brim Safety Helmet Unvented Black
48-73-1332 Front Brim Safety Helmet Vented Orange
48-73-1333 Front Brim Safety Helmet Unvented Orange
48-73-1336 Front Brim Safety Helmet Vented Gray
48-73-1337 Front Brim Safety Helmet Unvented Gray
FIG. PART NO. DESCRIPTION OF PART NO. REQ.
1 --------------- Front Brim Safety Helmet (Vented Shown) (1)
2 48-73-1093 Helmet Top Liner (Accessory) (1)
3 48-73-1092 Helmet Sweat Band (Accessory) (1)
4 50-73-1067 Helmet Chin Strap Assembly (Accessory) (1)
5 48-73-1098 Helmet Suspension Assembly (Accessory) (1)
6 48-73-1087 F.R. Safety Helmet Chin Strap (Accessory) (Not Shown) (1)
4
3
5
1
CATALOG NO.
BOLT™ Safety Helmet - Full Brim
48-73-1650 Full Brim Safety Helmet Vented White
48-73-1651 Full Brim Safety Helmet Unvented White
48-73-1652 Full Brim Safety Helmet Vented Yellow
48-73-1653 Full Brim Safety Helmet Unvented Yellow
48-73-1654 Full Brim Safety Helmet Vented Blue
48-73-1655 Full Brim Safety Helmet Unvented Blue
48-73-1656 Full Brim Safety Helmet Vented Hi Viz Green
48-73-1657 Full Brim Safety Helmet Unvented Hi Viz Green
48-73-1658 Full Brim Safety Helmet Vented Red
48-73-1659 Full Brim Safety Helmet Unvented Red
48-73-1660 Full Brim Safety Helmet Vented Black
48-73-1661 Full Brim Safety Helmet Unvented Black
48-73-1662 Full Brim Safety Helmet Vented Safety Orange
48-73-1663 Full Brim Safety Helmet Unvented Safety Orange
48-73-1664 Full Brim Safety Helmet Vented Gray
48-73-1665 Full Brim Safety Helmet Unvented Gray
48-73-1688 Full Brim Safety Helmet Vented Orange
48-73-1689 Full Brim Safety Helmet Unvented Orange
48-73-1690 Full Brim Safety Helmet Vented Green
48-73-1691 Full Brim Safety Helmet Unvented Green
48-73-1692 Full Brim Safety Helmet Vented Light Gray
48-73-1693 Full Brim Safety Helmet Unvented Light Gray
48-73-1694 Full Brim Safety Helmet Vented Forest Green
48-73-1695 Full Brim Safety Helmet Unvented Forest Green
FIG. PART NO. DESCRIPTION OF PART NO. REQ.
1 --------------- Full Brim Safety Helmet (Unvented) (1)
2 --------------- Full Brim Safety Helmet (Vented) (1)
3 48-73-1081 Bolt Full Brim Helmet Sweat Band (Accessory) (1)
4 50-73-1067 Helmet Chin Strap Assembly (Accessory) (1)
48-73-1087 F.R. 4PT Chin Strap Assembly (Accessory) (Not Shown) (1)
5 48-73-1099 Helmet Suspension Assembly (Accessory) (1)
2
