User Guide
Quality, Design and Innovation
home.liebherr.com/fridge-manuals
Contents
1 The appliance at a glance............................. 3
1.1 Delivered contents.............................................. 3
1.2 Overview of appliances and equipment.......... 3
1.3 SmartDevice......................................................... 3
1.4 Range of appliance use...................................... 4
1.5 Conformity............................................................ 4
1.6 Spare parts........................................................... 4
2 General safety instructions.......................... 4
3 Functionality of the Touch&Swipe display. 7
3.1 Navigation and symbol explanation................ 7
3.2 Menus.................................................................... 8
3.3 Sleep mode.......................................................... 8
4 Start-up......................................................... 8
4.1 Switching on appliance (first use)................... 8
5 Storage.......................................................... 9
5.1 Information regarding storage.......................... 9
5.2 Fridge compartment........................................... 9
5.3 EasyFresh............................................................ 9
5.4 Storage times...................................................... 9
6 Energy saving................................................ 10
7 Use................................................................. 10
7.1 Controls and displays......................................... 10
7.1.1 Status display...................................................10
7.1.2 Display symbols............................................... 10
7.2 Appliance functions............................................ 10
7.2.1 Notes on the appliance functions.................10
Switching appliance off and on....................10
WiFi.................................................................... 11
Temperature.....................................................12
Temperature unit.............................................12
SuperCool.........................................................13
PartyMode ....................................................... 13
HolidayMode.................................................... 14
SabbathMode...................................................14
EnergySaver ....................................................15
CleaningMode..................................................15
Display Brightness..........................................16
Door alarm........................................................16
Input lock..........................................................16
Language.......................................................... 17
Appliance information.................................... 17
Software............................................................17
Reminder.......................................................... 18
Demo mode......................................................18
Resetting to factory settings........................ 19
7.3 Messages.............................................................. 19
7.3.1 Overview of warnings......................................19
7.3.2 Ending warnings...............................................19
7.3.3 Overview of reminders....................................20
7.3.4 Ending reminders.............................................20
8 Equipment...................................................... 20
8.1 Door racks............................................................ 20
8.2 Drawers................................................................. 21
9 Maintenance.................................................. 22
9.1 FreshAir carbon filter.......................................... 22
9.2 Disassembling / assembling pull-out
systems................................................................. 22
9.4 Defrosting the appliance................................... 23
9.5 Cleaning the appliance...................................... 23
10 Customer support......................................... 24
10.1 Technical specifications.................................... 24
10.2 Operating noises................................................. 24
10.3 Technical faults................................................... 24
10.4 Customer Service................................................ 26
10.5 Rating plate.......................................................... 26
11 Decommissioning.......................................... 26
12 Disposal......................................................... 26
12.1 Preparing the appliance for disposal............... 26
12.2 Disposing of the appliance in an
environmentally friendly manner..................... 26
Congratulations on the purchase of your new appli‐
ance. With this purchase, you have chosen all the
advantages of the latest refrigeration technology, guar‐
anteeing you a high-quality appliance with a long life
span and high operating safety.
The equipment of your appliance gives you the highest
level of day-to-day ease of operation.
Together we are making an active contribution to the
conservation of our environment by purchasing this
appliance which is manufactured in an environmentally
friendly process with the use of recyclable materials.
We hope you enjoy your new appliance.
The manufacturer is constantly working to improve all
types and models. Therefore, please be aware that we
2 * Depending on model and options
reserve the right to make changes to the shape, equip‐
ment and technology.
Symbol Explanation
Read instructions
Please read the information in these
instructions carefully to understand all of
the benefits of your new appliance.
Additional information online
The digital manual with supplemental
information can be found online by scan‐
ning the QR code on the front page of this
manual or by entering the service number
at home.liebherr.com/fridge-manuals.
Check appliance
Check all parts for transport damage. If you
have any complaints, please contact your
agent or customer service.
Differences
These instructions apply to a range of
models, so there may be differences.
Sections that apply to certain models only
are indicated by an asterisk (*).
Instructions and results
Instructions are marked with a
.
Results are marked with a
.
Videos
Videos about the appliances are available
on the YouTube channel of Liebherr-Hausg‐
eräte.
Open-source licenses:
The appliance includes software components that
make use of open-source licenses. You can find
information on the open-source licenses to be used
here: home.liebherr.com/open-source-licenses
These operating instructions apply to:
UR
3750
UR 3650
1 The appliance at a glance
1.1 Delivered contents
Check all parts for transport damage. If you have any
complaints, please contact the retailer or customer
service. (see 10.4 Customer Service)
Delivery contains the following parts:
-
Integrated appliance
-
Equipment (depending on your model)
-
Installation parts (depending on your model)
-
User Guide
-
Installation Guide
-
Warranty documents
1.2 Overview of appliances and equip‐
ment
Fig. 1 Exemplary illustration of the front side
Equipment
(1)
Type plate (6) Operating elements
and temperature
display
(2) EasyFresh safe (7) Interior lighting
(3) Universal box (8) Shelf
(4) Adjustable feet (9) Defrost water drain
(5) Door racks (10)Fan with FreshAir acti‐
vated charcoal filter
Note
u
The shelves, drawers, and baskets are arranged for
optimal energy efficiency in the factory configura‐
tion. However, changes to the arrangement within
the given insertion options – for example the
arrangement of shelves in the fridge compartment –
have no effect on energy consumption.
1.3 SmartDevice
SmartDevice is the networking solution for your refrig‐
erator.
If your appliance is SmartDevice-enabled or compat‐
ible, you can quickly and easily connect your appliance
to your WiFi. With the SmartDevice app, you can
operate your appliance from a mobile device. Addi‐
tional functions and setting options are available in the
SmartDevice app.
The appliance at a glance
* Depending on model and options 3
SmartDevice-
enabled appli‐
ance:
Your appliance is capable of being
a SmartDevice. To be able to
connect your device to WiFi, you
need to download the SmartDevice
app.
More information
about SmartDe‐
vice:
smartdevice.liebherr.com
Downloading the
SmartDevice
app:
After installing and configuring the
SmartDevice app, you can connect
your appliance to the WiFi using
the SmartDevice app and the WiFi
appliance function (seeWiFi) .
1.4 Range of appliance use
Normal use
This appliance is intended to be used in
household and similar applications such as,
-
staff kitchen areas in shops, offices and
other working environments;
-
farm houses and by clients in hotels, motels
and other residential type environments;
-
bed and breakfast type environments;
-
catering and similar non-retail applications.
The appliance is not suitable for freezing food;
The appliance is suitable for integrated under
worktop use
All other types of uses are not permitted.
Foreseeable misuse
The following uses are specifically prohibited:
-
Storage and cooling of medication, blood
plasma, laboratory preparations or similar
substances and products in accordance
with the CMDCAS and FDA 510(k)
-
Use outdoors
-
Use in moist areas exposed to the rain
-
Use in areas at risk of explosion
Incorrect appliance use can cause damage to
the stored products or cause them to spoil.
Climate ratings
The appliance is set to operate within specific
ambient temperature limits according to its
climate rating The climate rating for your
appliance is printed on the rating plate
Note
u
To guarantee trouble-free operation, comply
with the indicated ambient temperatures.
Climate
rating
for ambient temperatures from
SN 10°C(50°F) to 32°C(90°F)
N 16°C(61°F) to 32°C(90°F)
ST 16°C(61°F) to 38°C(100°F)
T 16°C(61°F) to 43°C(109°F)
SN-ST 10°C(50°F) to 38°C(100°F)
SN-T 10°C(50°F) to 43°C(109°F)
1.5 Conformity
The refrigerant circuit has been tested for leaks. When
installed, the appliance complies with the applicable
safety regulations and with the corresponding direc‐
tives.
1.6 Spare parts
Spare parts for functional and storable parts of the
equipment are available for 15 years.
2 General safety instructions
Please keep these operating instructions in a
safe place so you can refer back to them at
any time.
If you pass the appliance on, please hand
these operating instructions to the new owner.
Read and follow these instructions. They
contain safety information which is important
for safe and problem-free installation and
operation. Always read and follow the safety
information.
Dangers for the user:
-
This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless
they have been given supervision or instruc‐
tion concerning use of the appliance by a
person responsible for their safety. Children
should be supervised to ensure that they do
General safety instructions
4 * Depending on model and options
not play with the appliance. Cleaning and
user maintenance must not be performed by
children unless they are supervised. Chil‐
dren between the ages of 3 and 8 may load
and unload the appliance. Children under
the age of 3 must be kept away from the
appliance unless they are constantly super‐
vised.
-
IMPORTANT: The power plug must be easily
accessible so that the appliance can be
disconnected from the mains quickly in an
emergency. It must not be behind the back
of the appliance.
-
The socket must be easily accessible so that
the appliance can be disconnected quickly
from the electricity in an emergency. It must
not be located in the area behind the appli‐
ance.
-
Always hold the appliance at the plug when
disconnecting it from the household power.
Do not pull on the cable.
-
Disconnect the power plug or fuse if there is
a malfunction.
-
Do not damage the power cable. Do not
operate the appliance with a faulty power
cable. If the supply cord is damaged, it must
be replaced by the manufacturer, its service
agent or similarly qualified persons in order
to avoid a hazard. For Plug and Play connec‐
tions, the change may be carried out by the
customer.
-
Repairs and work on the appliance may only
be carried out by Customer Service or other
specifically trained qualified personnel.
-
Only install, connect and dispose of the
appliance in accordance with the instruc‐
tions.
-
Only operate the appliance after it has been
installed.
Risk of fire:
-
The refrigerant contained within the appli‐
ance (specifications on the identification
plate) is environmentally friendly, but flam‐
mable. Leaking refrigerant can ignite.
•
WARNING: Do not damage the refrigerant
circuit.
•
Do not handle ignition sources inside the
appliance.
•
WARNING: Do not use electrical appli‐
ances inside the food storage compart‐
ments of the appliance, unless they are of
the type recommended by the manufac‐
turer (e.g. steam cleaning appliances,
heating appliances, ice cream makers).
•
If refrigerant leaks: Remove naked flames
or ignition sources located near the area
of the leak. Ventilate the room well.
Contact Customer Service.
-
Do not operate the appliance near explosive
gases.
-
Do not store or use gasoline or other flam‐
mable gases and liquids near the appliance.
-
Do not store explosive substances such as
aerosol cans with a flammable propellant in
this appliance. You can recognize such spray
cans by the printed list of contents or by a
flame symbol. Any leaking gases can be
ignited by electrical components.
-
Alcoholic beverages or other containers
holding alcohol must always be tightly
sealed for storage purposes. Any leaking
alcohol can be ignited by electrical compo‐
nents.
Risk of falling or toppling over:
-
WARNING: To avoid a hazard due to insta‐
bility of the appliance, it must be fixed in
accordance with the instructions.
-
Do not stand on the base, drawers, doors
etc. or use them as improper supports. This
applies in particular to children.
Danger of poisoning:
-
Do not consume spoiled food.
Danger of frostbite, feeling of numbness and
pain:
-
Avoid prolonged skin contact with cold
surfaces or chilled/frozen food or take
protective measures, e.g. wear gloves.
Risk of injury and damage:
-
Hot steam may cause injuries. Do not use
any electrical heating or steam cleaning
equipment, naked flames or defrosting
sprays for defrosting measures.
-
WARNING: Do not use mechanical devices
or other means to accelerate the defrosting
process, other than those recommended by
the manufacturer.
-
Do not remove ice using sharp objects.
General safety instructions
* Depending on model and options 5
-
WARNING: Keep clear of obstruction all
ventilation openings in the appliance enclo‐
sure or in the structure for building-in.
-
WARNING: Risk of child entrapment. Before
you throw away your old refrigerator or
freezer:
•
Take off the doors.
•
Leave the shelves in place so that children
may not easily climb inside.
Risk of crushing:
-
Do not hold onto the hinge when opening
and closing the door. Fingers may become
trapped.
California Proposition 65
-
WARNING: This product can expose you to
chemicals including Diisononyl Phthalate
(DINP), which is known to the State of Cali‐
fornia to cause cancer, and Di-isodecyl
Phthalate (DIDP), which is known to the
State of California to cause birth defects or
other reproductive harm. For more informa‐
tion, go to www.P65Warnings.ca.gov
FCC Warning
-
Changes or modifications not expressly
approved by the party responsible for
compliance could void the user’s authority
to operate the equipment.
FCC information
-
This appliance has been tested and found to
comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reason‐
able protection against harmful interference
from an installation in residential areas. This
appliance generates, uses and can radiate
radio-frequency energy and, if not installed
and used in accordance with the instruc‐
tions, may cause harmful interference to
radio communications. However, there is no
guarantee that interference will not occur in
a particular installation. If this appliance
does cause harmful interference to radio or
television reception, which can be deter‐
mined by switching the appliance on and
off, the user should try to correct the inter‐
ference by one or more of the following
measures:
•
Reorient or relocate the receiving antenna.
•
Increase the distance between the appli‐
ance and receiver.
•
Connect the appliance to an outlet on a
circuit different from that to which the
receiver is connected.
•
Consult the dealer or an experienced
radio/TV technician for help.
FCC Radio Frequency Exposure Statement
-
This appliance is found to comply with FCC
radio frequency (RF) exposure limits set for
an uncontrolled environment. This trans‐
mitter must not be set up or operated in
conjunction with another antenna or
another transmitter.
-
This appliance should be installed and oper‐
ated with a minimum space of
200 mm (7 7/8 in) between the antenna and
your body. The user must follow the specific
operating instructions to ensure compliance
with RF exposure.
IC information
-
This appliance has license-exempt transmit‐
ters/receivers, which comply with the
license-exempt Radio Standards Specifica‐
tion (RSS) of Innovation, Science and
Economic Development Canada. Operation
is subject to the following two conditions:
•
This appliance may not cause interfer‐
ence.
•
This device must accept any interference,
including interference that may cause
undesired operation of the device.
IC Radio Frequency Exposure Statement
-
This appliance meets the IC RSS-102 limits
for radiation exposure, which were defined
for an uncontrolled environment. This appli‐
ance should be installed and operated so
that there is a minimum space of
200 mm (7 7/8 in) between the antenna and
your body.
Symbols on the device:
The symbol may be located on the
compressor. It refers to the oil in the
compressor and refers to the following
danger: Can be fatal if swallowed or
inhaled. This notice only applies for
recycling. There is no danger during
normal operation.
General safety instructions
6 * Depending on model and options
WARNING: Risk of fire / flammable
materials. The symbol is located on the
compressor and indicates the danger
from flammable materials. Do not
remove the label.
This label or a similar one may be
located on the rear of the appliance.
This label indicates that there are
vacuum insulation panels (VIP) or perlite
panels in the door and/or housing. This
notice only applies for recycling. Do not
remove the label.
Observe the warning messages and other
detailed information in the other sections:
DANGER
Indicates an immediately
hazardous situation, which if
not avoided, will result in death
or serious injury.
WARNING Indicates a hazardous situa‐
tion, which if not avoided,
could result in death or serious
injury.
CAUTION Indicates a hazardous situa‐
tion, which if not avoided,
could result in minor or
moderate injury.
NOTICE Indicates a hazardous situa‐
tion, which if not avoided,
could result in damage to prop‐
erty.
Note Indicates useful advice and
tips.
3 Functionality of the
Touch&Swipe display
You operate your appliance using the Touch & Swipe
display. You select appliance functions in the
Touch & Swipe display (hereafter referred to as display)
by tapping them. If you do not perform any action on
the display for 10 seconds, the display either jumps
back to the higher-level menu or directly to the status
display.
3.1 Navigation and symbol explana‐
tion
In the illustrations, different symbols are used to navi‐
gate the display. The following table describes these
symbols.
Symbol
Description
Briefly touch the display:
Activates/deactivates function.
Confirms selection.
Opens submenu.
Touch the display for a specified
time (e.g. 3seconds):
Activates/deactivates function or
value.
Swipe left or right:
Navigate in the menu.
Briefly touch the Back symbol:
Jumps back one menu level.
Press and hold the Back symbol for
3seconds:
Jumps back to the status display.
Arrow with clock:
It takes more than 10 seconds for
the following message to appear in
the display.
Arrow with a time indication:
It takes the specified amount of
time until the following message
appears in the display.
“Open Settings menu” symbol:
Navigates to the Settings menu and
opens the settings menu.
If necessary: Navigate to the
desired function in the Settings
menu.
(see 3.2.1 Opening the Settings
menu)
“Open Advanced menu” symbol:
Navigates to the Advanced menu
and opens the advanced menu.
If necessary: Navigate to the
desired function in the Advanced
menu.
(see 3.2.2 Opening expanded menu)
No action for
10seconds
If you do not perform any action on
the display for 10 seconds, the
display either jumps back to the
higher-level menu or directly to the
status display.
Functionality of the Touch&Swipe display
* Depending on model and options 7
Symbol Description
Open door and
close it again.
If you open the door and immedi‐
ately close it again, the display
jumps directly back to the status
display.
Note: Illustrations of the display are shown in the English
version.
3.2 Menus
The appliance functions are distributed over various
menus:
Menu
Description
Main menu When you switch the appliance on,
you are automatically in the main
menu.
From here you can navigate to the
most important appliance functions,
to the Settings menu and to the
Advanced menu.
Settings menu
The Settings menu contains addi‐
tional appliance functions for
setting up your appliance.
Advanced
menu
The advanced menu contains
special appliance functions for
setting up your appliance. Access to
the Advanced menu is protected by
the numerical code 151.
3.2.1 Opening the Settings menu
Fig. 2 Example illustration
u
Carry out action steps according to the illustration.
w
Settings menu is open.
u
If necessary: Navigate to the desired function.
3.2.2 Opening expanded menu
Fig.3
Fig. 4 Example illustration, access with numerical code
151
u
Carry out action steps according to the illustration.
w
Expanded menu is open.
u
If necessary: Navigate to the desired function.
3.3 Sleep mode
If you do not touch the display for 1 minute, the display
switches to sleep mode. In sleep mode, the display
brightness is dimmed.
3.3.1 Ending sleep mode
u
Touch the display briefly with your finger.
w
Sleep mode is ended.
4 Start-up
4.1 Switching on appliance (first use)
Make sure that the following requirements are fulfilled:
q
The appliance is properly installed and connected
according to the installation instructions.
q
All adhesive strips, adhesive and protective films
and transport locks are removed from inside and on
the appliance.
q
All marketing leaflets are removed from the drawers.
q
You are familiar with the functionality of the
Touch & Swipe display. (see 3 Functionality of the
Touch&Swipe display)
Switch on the appliance using the Touch & Swipe
display.
u
If the display is in sleep mode: Briefly touch the
display.
u
Carry out action steps according to the illustration.
Start-up
8 * Depending on model and options
Fig. 5 Example illustration
w
Status display appears.
w
The appliance cools to the temperature set at the
factory.
w
The appliance starts in demo mode (status display
with DEMO appears): If the appliance starts in demo
mode, you can deactivate demo mode within the
next 5 minutes. (seeDemo mode)
More information:
-
Start the SmartDevice for the first time.
(see 1.3 SmartDevice) and (seeWiFi)
Note
The manufacturer recommends:
u
Stock with food: Wait for around 6 hours until the
set temperature is reached.
u
Observe the notes on storing food. (see 5.1 Informa‐
tion regarding storage)
Note
Accessories can be purchased from the Liebherr
Service Center. The address for your respective country
can be found on the back of the instructions.
5 Storage
5.1 Information regarding storage
WARNING
Danger of fire
u
Do not use electrical appliances inside the food
storage compartments of the appliance, unless they
are of the type recommended by the manufacturer.
Note
Insufficient ventilation results in an increase in energy
consumption and reduction of the refrigerating
performance
u
Always keep the air slots unobstructed.
Observe the following specifications for storage:
-
Keep the air vents on the fan free.
-
Package or cover foods that readily take on or give
off odors or taste in closed containers.
-
Package raw meat or fish in clean, closed
containers. This will prevent meat or fish from
touching or dripping onto other food.
-
Keep liquids in closed containers.
-
Leave space between goods to ensure good air
circulation.
-
Store food according to the instructions on the pack‐
aging.
-
Always observe the best-before date indicated on
the packaging.
Note
Failure to follow these guidelines can lead to food‐
stuffs spoiling.
5.2 Fridge compartment
5.2.1 Arranging your food properly
u
Upper area and door: Store butter, cheese, canned
food and tubes.
u
Store perishable food, such as pre-cooked meals,
fish, fresh meat and lunch meat, distributed on the
remaining shelves.
u
Universal box: Store small jars, tubes, chocolate,
eggs, packaged fruit and vegetables.
5.3 EasyFresh
EasyFresh is great for non-packaged foods, such as
fruit and vegetables.
The humidity in the compartment depends on the
moisture content of the chilled goods placed in it, and
also depends on how often the compartment is
opened. You can regulate the humidity level.
5.3.1 Arranging your food properly
u
Store unpackaged fruit and vegetables.
If the humidity is too high:
u
Regulate the humidity.
5.4 Storage times
The storage times given are guidelines
Food with a “use by” date must still be consumed by
the date indicated on the package
5.4.1 Fridge
The best-before date stated on the packaging applies.
Storage
* Depending on model and options 9
6 Energy saving
-
Always ensure good ventilation. Keep clear of
obstruction all ventilation openings in the appliance
enclosure or in the structure for building-in.
-
Never block air slits in the fan.
-
Do no install the appliance in an area with direct
sunlight, next to a heating unit or similar.
-
If you install the appliance directly next to an oven,
its energy consumption may increase slightly. This
depends on the service life and how often the oven
is used.
-
Energy consumption depends on installation condi‐
tions such as the ambient temperature
(see 1.4 Range of appliance use) . A warmer ambient
temperature can increase the energy consumption.
-
Avoid opening the appliance door for any longer then
necessary
-
The lower the temperature is set the higher the
energy consumption.
-
Only take food out for as long as necessary so that it
does not get too warm.
-
Insertion of warm foods: first let the food cool down
to room temperature.
-
For longer periods of absence, use HolidayMode
(seeHolidayMode) .
7 Use
7.1 Controls and displays
7.1.1 Status display
Fig. 6 Status display shows the actual temperature.
(1)
Fridge compartment
temperature display
7.1.2 Display symbols
The display symbols provide information about the
current appliance status.
Symbol
Appliance status
Standby
The appliance or temperature
zone is turned off.
Flashing number
Appliance is working. Tempera‐
ture flashes until the set
temperature is reached.
Symbol Appliance status
Flashing symbol
Appliance is working. Setting is
made.
7.2 Appliance functions
7.2.1 Notes on the appliance functions
The appliance functions are set at the factory so that
your appliance is fully functional.
Before you alter, activate or deactivate the appliance
functions, make sure that the following requirements
are met:
q
You have read and understood the descriptions of
how the display works. (see 3 Functionality of the
Touch&Swipe display)
q
You have familiarized yourself with the operating
and display elements of your appliance.
Switching appliance off and on
This function switches the entire appliance on and off.
Switching off the appliance
If you switch off the appliance, the settings that were
made before remain stored.
Make sure that the following requirements are fulfilled:
q
Handling instructions (see 11 Decommissioning)
have been completed.
Fig.7
Fig.8
u
Carry out action steps according to the illustration.
w
Appliance is switched off.
w
Standby symbol appears in the display.
w
Display turns black.
Switching on the appliance
If the display is in sleep mode:
Energy saving
10 * Depending on model and options
u
Briefly touch the display.
Fig. 9 Example illustration
u
Carry out action steps according to the illustration.
If the appliance starts in demo mode:
u
Deactivate demo mode. (see Deactivating demo
mode)
w
Appliance is switched on.
w
Previously made settings are re-established.
w
The appliance cools to the set target temperature.
WiFi
Use this function to connect your appliance to WiFi.
You can then operate it via the SmartDevice app on a
mobile device. You can also use this function to
disconnect or reset the WiFi connection.
More information on the SmartDevice: (see 1.3 Smart‐
Device)
Note
The SmartDevice function is not available in the
following countries: Russia, Belarus, Kazakhstan.
Establishing the WiFi connection for the first time
Make sure that the following requirements are fulfilled:
q
You have installed the SmartDevice app (see
apps.home.liebherr.com).
q
Registration in the SmartDevice app is completed.
Fig. 10
Fig.11
u
Carry out action steps according to the illustration.
w
Connection is established.
Disconnecting from the WiFi
Fig.12
Fig.13
u
Carry out action steps according to the illustration.
w
There is no connection.
Resetting the WiFi connection
Fig. 14
Use
* Depending on model and options 11
Fig. 15
u
Carry out action steps according to the illustration.
w
WiFi connection and other WiFi settings are reset to
factory settings.
Showing information about the WiFi connection
Fig. 16
Fig.17
u
Carry out action steps according to the illustration.
Temperature
Use this function to set the temperature.
The temperature depends on the following factors:
-
How often the door is opened
-
How long the door is open
-
The room temperature of the installation site
-
Type, temperature and amount of food
Temperature zone
Factory-set
temperature
Recommended
setting
Fridge section
5°C(41°F) 4°C(39°F)
Setting the temperature
Fig. 18 Example illustration
u
Carry out action steps according to the illustration.
w
Temperature is set.
Temperature unit
Use this function to set the temperature unit. You can
set the temperature unit in either degrees Celsius or
degrees Fahrenheit.
Setting the temperature unit
Fig. 19
Fig. 20 Example illustration: Switching between
degrees Celsius or degrees Fahrenheit.
u
Carry out action steps according to the illustration.
w
Temperature unit is set.
Use
12 * Depending on model and options
SuperCool
This function activates or deactivates SuperCool. If you
activate SuperCool the appliance increases the cooling
capacity. This allows you to achieve lower cooling
temperatures. You can activate SuperCool if you want
to quickly cool large volumes of food.
If the function is active, the appliance operates at a
higher output. As a result, the operating noise of the
appliance may be temporarily louder, while energy
consumption increases.
Activating SuperCool
Time for activating the function:
-
If you want to store fresh food in the fridge section:
Activate the function when storing food.
Fig.21
Fig.22
u
Carry out action steps according to the illustration.
-or-
u
Activating with the SmartDevice app.
w
SuperCool is activated.
w
Temperature display turns blue.
Deactivating SuperCool
SuperCool is automatically deactivated after 18 hours.
However, you can also manually deactivate SuperCool
at any time:
Fig.23
Fig. 24
u
Carry out action steps according to the illustration.
-or-
u
Deactivating with the SmartDevice app.
w
SuperCool is deactivated.
w
Appliance continues to run in normal operation.
w
The appliance first cools to the set temperature.
PartyMode
This function activates and deactivates PartyMode.
PartyMode activates different functions that are useful
for a party.
PartyMode activates the following functions:
-
SuperCool (seeSuperCool)
You can set all listed functions individually and flexibly.
By deactivating PartyMode all changes are discarded.
If the function is active, the appliance operates at a
higher output. As a result, the operating noise of the
appliance may be temporarily louder, while energy
consumption increases.
Activating PartyMode
Fig.25
Fig. 26
u
Carry out action steps according to the illustration.
w
PartyMode and the corresponding functions are acti‐
vated.
w
Temperature display turns blue.
w
The current temperature flashes until the target
temperature is reached.
Deactivating PartyMode
PartyMode is automatically deactivated after 24 hours.
However, you can also manually deactivate PartyMode
at any time:
Fig.27
Fig.28
u
Carry out action steps according to the illustration.
Use
* Depending on model and options 13
w
PartyMode is deactivated.
w
The appliance first cools to the set temperature: The
current temperature flashes until the target temper‐
ature is reached.
HolidayMode
Use this function to activate or deactivate Holiday‐
Mode. If you activate HolidayMode the fridge section is
set to 15 °C (59 °F). This helps you save energy if you
are away for a longer period of time and avoid bad
smells and mold formation.
Appliance status with active HolidayMode
Fridge section cools to 15°C(59°F).
PartyMode is deactivated.
SuperCool is deactivated.
PowerCool is deactivated.
Activating HolidayMode
u
Empty the fridge section completely.
Fig.29
Fig.30
u
Carry out action steps according to the illustration.
w
HolidayMode is activated.
w
Temperature display turns blue and shows the Holi‐
dayMode symbol.
Deactivating HolidayMode
Fig.31
Fig.32
u
Carry out action steps according to the illustration.
w
HolidayMode is deactivated.
w
The appliance first cools to the set temperature.
SabbathMode
This function activates and deactivates SabbathMode.
If you activate this function, some electronic functions
are switched off. Your appliance thereby meets the reli‐
gious requirements of Jewish holidays such as the
Sabbath and complies with STAR-K Kosher certifica‐
tion.
Appliance status with active SabbathMode
The status display continuously shows SabbathMode.
All functions in the display except the Deactivating
SabbathMode function are disabled.
Active functions remain active.
The display remains bright when you close the door.
The interior lighting is deactivated.
Memories are not listed. The set time interval is
stopped.
Memories and warnings are not displayed.
There is no door alarm.
There is no temperature alarm.
After a power failure, the device returns to
SabbathMode.
Appliance status
Note
This appliance has certification from the “Institute for
Science and Halacha”. (www.machonhalacha.co.il)
You can find a list of STAR-K-certified appliances at
www.star-k.org/appliances.
Activating SabbathMode
WARNING
Danger of poisoning from spoiled food!
If you have SabbathMode activated and a power failure
occurs, no message appears in the status display
about the power failure. Once the power is restored,
the appliance continues to operate in SabbathMode.
The power failure may mean that food spoils and the
consumption of this food could lead to food poisoning.
After a power failure:
u
Do not consume food that has been frozen and
thawed.
Fig.33
Use
14 * Depending on model and options
Fig.34
u
Carry out action steps according to the illustration.
w
SabbathMode is activated.
w
Status display continuously shows SabbathMode.
Deactivating SabbathMode
SabbathMode is automatically deactivated after
80 hours. However, you can also manually deactivate
SabbathMode at any time:
Fig.35
u
Carry out action steps according to the illustration.
w
SabbathMode is deactivated.
EnergySaver
Use this function to activate or deactivate energy
saving mode. If you activate energy saving mode,
energy consumption drops and the temperature in the
appliance increases. Food remains fresh, but shelf life
is reduced.
Temperature
zone
Recommended
setting
(see Setting the
temperature)
Temperature
while Ener‐
gySaver is active
Fridge
section
4°C(39°F) 7°C(45°F)
Temperatures
Activating EnergySaver
Fig.36
Fig.37
u
Carry out action steps according to the illustration.
w
Energy saving mode is activated.
Deactivating EnergySaver
Fig.38
Fig. 39
u
Carry out action steps according to the illustration.
w
Energy saving mode is deactivated.
CleaningMode
This function activates and deactivates CleaningMode.
CleaningMode enables you to comfortably clean the
appliance.
This setting relates to the fridge compartment.
Application:
-
Clean the fridge compartment. (see 9.5 Cleaning the
appliance)
Appliance status with active CleaningMode
The status display continuously shows CleaningMode.
The fridge section is switched off.
The interior lighting is activated.
Reminders and warnings are not displayed. No signal
tone is sounded.
Appliance status
Activating CleaningMode
Fig.40
Fig. 41
u
Carry out action steps according to the illustration.
w
CleaningMode is activated.
w
Status display continuously shows CleaningMode.
Deactivating CleaningMode
CleaningMode is automatically deactivated after
60 minutes. However, you can also manually deactivate
CleaningMode at any time:
Use
* Depending on model and options 15
Fig. 42
u
Carry out action steps according to the illustration.
w
CleaningMode is deactivated.
w
The appliance first cools to the set temperature.
Display Brightness
Use this function to set the brightness of the display
gradually.
You can set the following brightness levels:
-
40%
-
60%
-
80%
-
100% (default setting)
Setting the brightness
Fig.43
Fig. 44 Example illustration: Switching from 80 % to 60%.
u
Carry out action steps according to the illustration.
w
Brightness is set.
Door alarm
Use this function to activate or deactivate the door
alarm. The door alarm sounds if the door is open for
too long. The door alarm is activated upon delivery. You
can set how long to door can remain open until the
door alarm sounds.
You can set the following values:
-
1 minute
-
2 minutes
-
3 minutes
-
Off
Setting the door alarm
Fig.45
Fig. 46 Example illustration: Changing the door alarm from
1 minute to 3 minutes.
u
Carry out action steps according to the illustration.
w
Door alarm is set.
Deactivating door alarm
Fig.48
Fig. 49
u
Carry out action steps according to the illustration.
w
Door alarm is deactivated.
Input lock
This function activates and deactivates the input lock.
The input lock prevents the appliance from being oper‐
ated accidentally, e. g. by children.
Application:
-
Prevent unintentional changes of functions.
-
Prevent switching off of the appliance.
-
Prevent unintentional temperature setting.
Activating the input lock
If you activate the input lock, you can continue to navi‐
gate in the menus, however you cannot select or
modify other functions.
Use
16 * Depending on model and options
Fig.50
Fig.51
u
Carry out action steps according to the illustration.
w
Input lock is activated.
Deactivating the input lock
Fig.52
Fig.53
u
Carry out action steps according to the illustration.
w
Input lock is deactivated.
Language
Use this function to set the display language.
You can set the following languages:
-
German
-
English
-
French
-
Spanish
-
Italian
-
Dutch
-
Czech
-
Polish
-
Portuguese
-
Bulgarian
-
Russian
-
Chinese
Setting the language
Fig.54
Fig. 55 Example illustration depending on the language and
temperature
u
Carry out action steps according to the illustration.
w
Language is set.
w
Display jumps back to the status display.
Appliance information
Use this function to display the model name, index,
serial number and service number of your appliance.
You will need the appliance information when you
contact customer service. (see 10.4 Customer Service)
You also use this function to open the expanded menu.
(see3 Functionality of the Touch&Swipe display)
Display appliance information
Fig.56
Fig.57
u
Carry out action steps according to the illustration.
w
Display shows the appliance information.
Software
Use this function to display the software version of
your appliance.
Display software version
Fig.58
Use
* Depending on model and options 17
Fig. 59
u
Carry out action steps according to the illustration.
w
Display indicates the software version.
Reminder
Use this function to activate or deactivate reminder.
This function is activated upon delivery.
The following reminders will then appear if the func‐
tion is activated:
-
Replace the FreshAir activated charcoal filter
(see Replace FreshAir activated charcoal filter)
Activating reminder
Fig.60
Fig.61
u
Carry out action steps according to the illustration.
w
Reminder is activated.
Deactivating reminder
Fig. 62
Fig.63
u
Carry out action steps according to the illustration.
w
Reminder is deactivated.
Demo mode
Demo mode is a special feature for dealers who want
to demonstrate appliance features. If you activate
demo mode, all refrigeration functions are deactivated.
If you switch on your appliance and “Demo” appears in
the status display, then demo mode is already acti‐
vated.
If you activate and then deactivate demo mode, the
appliance will be reset to factory defaults. (see Reset‐
ting to factory settings)
Activating demo mode
Fig.64
Fig.65
u
Carry out action steps according to the illustration.
w
Demo mode is activated.
w
Appliance is switched off.
u
Switch on the appliance. (see4.1 Switching on appli‐
ance (first use))
w
“DEMO” appears in the status display.
Deactivating demo mode
Fig.66
Use
18 * Depending on model and options
Fig. 67
u
Carry out action steps according to the illustration.
w
Demo mode is deactivated.
w
Appliance is switched off.
u
Switch on the appliance. (see4.1 Switching on appli‐
ance (first use))
w
Appliance is reset to factory settings.
Resetting to factory settings
Use this function to reset all settings to factory
settings. All settings you have made so far are reset to
their original settings.
Performing a reset
Fig.68
Fig. 69
u
Carry out action steps according to the illustration.
w
Appliance is reset.
w
Appliance is switched off.
u
Restart the appliance. (see 4.1 Switching on appli‐
ance (first use))
7.3 Messages
There are two categories of messages:
Category Meaning
Warning Warnings are displayed if there is a door
alarm or a malfunction.
You can easily end warnings yourself. For
any major malfunction, you must contact
Customer Service. (see 10.4 Customer
Service)
Reminder Reminders remind you of general
processes. You can perform these
processes and end the message doing so.
7.3.1 Overview of warnings
The appliance’s behavior in the event of a warning:
-
Warning appears in the display in red.
-
Alarm sounds in increasing volume.
-
For some warnings the interior lighting pulses.
Message
Cause Ending the
message
Door alarm
The message appears if
the door is open for too
long.
Carry out
action steps
(see Door
alarm) .
Error
This message appears if
there is an appliance
error. An appliance
module indicates an
error.
Carry out
action steps
(see Error) .
WLAN error
This message appears if
the appliance could not
be connected to the
WLAN. (see Establishing
the WiFi connection for
the first time)
Carry out
action steps
(see WLAN
error) .
7.3.2 Ending warnings
Door alarm
Fig. 70 Example illustration
u
Carry out action steps according to the illustration.
Use
* Depending on model and options 19
-or-
u
Close the door.
w
Display skips to status display.
You can set how long to door may remain open until
the door alarm sounds. (see Setting the door alarm)
Error
Fig. 71 Example illustration
u
Briefly touch the display.
w
Error code is displayed.
u
Make a note of the error code.
u
Briefly touch the display.
w
Display skips to status display.
u
Contact Customer Service. (see 10.4 Customer
Service)
WLAN error
u
Check the WLAN connection.
u
Connect the appliance to the WLAN again.
(seeWiFi)
7.3.3 Overview of reminders
The appliance’s behavior in the event of a reminders:
-
Reminder appears in the display in yellow.
-
Alarm tone sounds.
-
For some reminders the interior lighting pulses.
Message
Cause Ending the
message
Replace the Fres‐
hAir activated
charcoal filter
This message
appears if you
have to replace
the activated
charcoal filter.
Carry out action
steps
(see Replace
FreshAir acti‐
vated charcoal
filter) .
7.3.4 Ending reminders
Replace FreshAir activated charcoal filter
Liebherr recommends: Replace the FreshAir activated
charcoal filter every 6 months.
Note
FreshAir activated charcoal filters can be purchased
from the Liebherr Service Center. The address for your
respective country can be found on the back of the
instructions.
Fig. 72 Example illustration
u
Briefly touch the display.
w
Display shows information about the reminder.
u
Briefly touch the display.
u
Replace activated charcoal filter. (see 9.1 FreshAir
carbon filter)
w
The activated charcoal filter ensures optimum air
quality in the refrigerator.
w
Reminder appears again after 6 months.
If you no longer want to keep this reminder, you can
deactivate the reminder. (see Deactivating reminder)
8 Equipment
8.1 Door racks
Door racks are suitable for storing beverages and food.
You can move door racks for use as individually needed
and disassemble them for cleaning. However, Liebherr
recommends using the door racks in the position they
are in when delivered from the plant.
Fig. 73 Example illustration of the door racks
(1)
Shelf
The following table shows examples of what you can
store in each door rack. Here, make sure that you do
not exceed the maximum loading weight for the door.
Door racks
Food
Door racks (see Fig.73) Butter, cheese, canned food,
tubes
Equipment
20 * Depending on model and options
8.1.1 Removing the door rack
Fig. 74 Example illustration
u
Move the door rack up.
u
Move the door rack to the front.
8.1.2 Inserting the door rack
Fig. 75 Example illustration
u
Insert the door rack.
u
Press the door rack down.
8.1.3 Disassembling the door rack
You can disassemble some of the door racks if you
want to clean the door rack or if you’d like to insert or
remove replacement parts.
Disassembling the door rack
Make sure that the following requirements are fulfilled:
q
Door rack is removed. (see 8.1.1 Removing the door
rack)
Fig. 76 Door racks with shelf
u
Remove the shelf Fig. 76(1).
8.1.4 Assembling the door rack
Assembling the door rack
Fig. 77 Door racks with shelf
u
Push the shelf Fig.77(1) into the side cutouts.
8.2 Drawers
You can remove the drawers for cleaning.
The way to remove/insert the drawers varies
depending on the pull-out system. Your appliance can
contain a variety of pull-out systems.
Note
Insufficient ventilation results in an increase in energy
consumption and reduction of the refrigerating
performance.
u
Never obstruct the vents on the interior rear wall!
8.2.1 Drawer on appliance base or glass
shelf
The drawer runs directly on the appliance base or on a
glass shelf. There are no rails.
When you remove the drawers, you can use the glass
shelves below them as storage shelves.
Removing drawer
Fig.78
u
Remove drawer as shown in the diagram.
Inserting drawer
Equipment
* Depending on model and options 21
Fig.79
u
Insert drawer as shown in the diagram.
The lid ensures constant levels of humidity.
The lid is located directly on the drawer and can be
covered by shelves or additional drawers.
8.3.1 Reducing humidity in the drawer
Fig.80
u
Pull out the drawer Fig.80(1).
u
Grip the handle recess Fig. 80 (2) on the lid while
pulling the lid forward at the same time.
w
When the drawer is closed, there is a small gap
between the lid and the drawer.
8.3.2 Increasing humidity in the drawer
Fig.81
u
Pull out the drawer Fig.81(1).
u
Grip the handle recess Fig. 81 (2) on the lid while
pulling the lid backward at the same time.
w
When the drawer is closed, the lid closes tightly with
the drawer.
9 Maintenance
9.1 FreshAir carbon filter
The FreshAir carbon filter is located in the compart‐
ment above the fan.
It guarantees the best air quality.
q
Change the carbon filter every 6 months.
When the reminder is set, a message on the display
prompts you to change it.
q
You can dispose of the carbon filter with the regular
household waste.
Note
FreshAir activated charcoal filters can be purchased
from the Liebherr Service Center. The address for your
respective country can be found on the back of the
instructions.
9.1.1 Removing the FreshAir carbon filter
Fig.82
u
Pull out the compartment Fig.82(1).
u
Remove the carbon filter Fig.82(2).
9.1.2 Inserting the FreshAir carbon filter
Fig.83
u
Insert the carbon filter as shown in the diagram
Fig.83(1).
w
The carbon filter clicks into place.
If the carbon filter is pointing downwards:
u
Push the compartment in Fig.83(2).
w
The carbon filter is now ready for use.
9.2 Disassembling / assembling pull-
out systems
9.2.1 Notes on disassembly
You can disassemble some of the pull-out systems for
cleaning. Your appliance can contain a variety of pull-
out systems.
Maintenance
22 * Depending on model and options
The following pull-out systems can be disassembled or
cannot be disassembled:
Pull-out system can be disassembled/
cannot be disassembled
Drawer on appliance base or
glass shelf
cannot be disassembled
You can remove the lid for cleaning.
9.3.1 Removing the lid
Make sure that the following requirements are fulfilled:
q
The shelf directly above the drawer has been
removed.
q
The compartment directly below the lid has been
removed. (see8.2 Drawers)
Fig.84
u
Push the lid backward.
u
Lift up the lid forward.
u
Remove the front lid by lifting it up at an angle.
9.3.2 Inserting the lid
If the lettering THIS SIDE UP is on top:
u
Insert the rear bracket retainers in the corresponding
rear openings.
u
Push the lid backward.
u
Lower the lid at the front and latch the front bracket
retainers in the openings.
u
Bring the lid to the desired position.
9.4 Defrosting the appliance
WARNING
Appliance incorrectly defrosted!
Injuries and damage.
u
Do not use mechanical devices or other means to
accelerate the defrosting process, other than those
recommended by the manufacturer.
u
Do not use any electrical heating or steam cleaning
equipment, naked flames or defrosting sprays.
u
Do not remove ice with sharp objects.
Defrosting is performed automatically. The water from
the thawing process runs out via the drain opening and
is evaporated.
Water droplets or a thin layer of frost or ice can form
on the rear wall; this is a completely normal part of the
appliance’s function. You do not have to remove them.
A frost or ice layer may form briefly due to the energy-
optimized control of the appliance.
u
Clean the drain hole regularly. (see 9.5 Cleaning the
appliance)
9.5 Cleaning the appliance
9.5.1 Preparation
WARNING
Danger of electric shock.
u
Unplug refrigerator or disconnect power.
WARNING
Danger of fire
u
Do not damage the refrigerant circuit.
u
Empty appliance.
u
Pull out the power plug.
-or-
u
Activate CleaningMode. (seeCleaningMode)
9.5.2 Cleaning the interior
NOTICE
Improper cleaning!
Damage to the appliance.
u
Only use soft cleaning cloths and ph-neutral all-
purpose cleaners.
u
Do not use steel wool or sponges that scour or
scratch.
u
Do not use caustic or abrasive cleaning materials or
those containing sand, chloride, or acids.
u
Plastic surfaces: clean by hand with a soft clean
cloth, lukewarm water and a little detergent.
u
Metal surfaces: clean by hand with a soft clean
cloth, lukewarm water and a little detergent.
u
Drain hole: remove any deposits with a thin item
such as a cotton bud.
Maintenance
* Depending on model and options 23
9.5.3 Cleaning the equipment
NOTICE
Improper cleaning!
Damage to the appliance.
u
Only use soft cleaning cloths and ph-neutral all-
purpose cleaners.
u
Do not use steel wool or sponges that scour or
scratch.
u
Do not use caustic or abrasive cleaning materials or
those containing sand, chloride, or acids.
Clean with a soft, clean cloth, lukewarm water and a
little washing up liquid:
- Drawer
Clean in the dishwasher up to 60°C(140°F):
- Door racks
- Shelf
- Split shelf
- Holder for the split shelf
u
Disassemble the equipment: see the relevant
section.
u
Clean the equipment.
9.5.4 After cleaning
u
Wipe dry the appliance and items of equipment
u
Connect and switch on the appliance.
When the temperature is sufficiently cold
u
Place the food inside.
u
Repeat cleaning regularly.
10 Customer support
10.1 Technical specifications
Temperature zone
Cool: 2°C(34°F) to 9°C(46°F)
For appliances with a WiFi connection:
Frequency specification
Frequency band 2.4GHz
Maximum radi‐
ated power
< 100 mW
Purpose of the
wireless equip‐
ment
Integration in the local WiFi
network for data communication
10.2 Operating noises
The appliance makes noises while in operation.
-
At less cooling output the appliance saves energy
but takes longer to cool items. The volume is lower.
-
At a higher cooling output the food cools more
quickly. The volume is higher.
Examples:
•
Activated functions (see 7.2Appliance functions)
•
Running fan
•
Freshly sorted food
•
High ambient temperature
•
Door opened for long periods
Noise
Possible cause Type of noise
Bubbling and
splashing
Coolant is
flowing into the
cooling circuit.
Normal noise
Spitting and
hissing
Coolant is
spraying into the
cooling circuit.
Normal noise
Humming The appliance
cools. The
volume depends
on the cooling
output.
Normal noise
Whirring and
murmuring
The fan is
running.
Normal oper‐
ating noise
Clicking Components are
being switched
on and off.
Normal
switching noise
Rattling or
humming
Valves are
active.
Normal
switching noise
Noise Possible
cause
Type of
noise
How to
resolve
Vibration Unsuitable
installation
Error noise Check
installation.
Set up the
appliance.
Clattering Equipment,
Objects
inside the
appliance
Error noise Secure
equipment
parts.
Leave a gap
between
items.
10.3 Technical faults
Your appliance is designed and manufactured for reli‐
able operation and a long service life. If a malfunction
nonetheless occurs during operation, please check
whether the malfunction is due to an operating error. In
Customer support
24 * Depending on model and options
this case, you will have to be charged for the costs
incurred, even during the warranty period.
You may be able to rectify the following faults yourself.
10.3.1 Appliance function
Defect Cause Remedy
The appliance
does not work.
The appliance is not switched on.
u
Switch on the appliance.
The power plug is not properly
inserted in the wall socket.
u
Check the power plug.
The powerfuse in the wall socket
is not OK.
u
Check the fuse.
Power failure.
u
Keep the appliance closed.
The IEC socket is not correctly
plugged into the appliance.
u
Check the IEC socket.
The temperature
is not cold
enough
This means that the door of the
appliance is not closed properly
u
Close the appliance door
Insufficient ventilation
u
Clear and clean the ventilation grille.
The ambient temperature is too
high
u
Problem solution: (see1.4 Range of appliance use)
The appliance was opened too
frequently or for too long
u
Wait to see if the required temperature corrects
itself. If not, contact Customer Service.
(see 10.4 Customer Service)
The temperature is incorrectly set
u
Set to a colder temperature and check after 24
hours.
The appliance is too near to a heat
source (stove, heater etc).
u
Change location of appliance or the heat source.
The appliance was not properly
installed in the recess.
u
Make sure the appliance was installed correctly
and the door closes properly.
The door seal is
defective or
should be
replaced for
other reasons.
The door seal is interchangeable.
You can replace it without the use
of any special tools.
u
Contact Customer Service. (see 10.4 Customer
Service)
The appliance is
iced up or
condensation is
building.
The door seal may have slipped
out of its groove.
u
Check the door seal is well placed in the groove.
10.3.2 Equipment
Defect Cause Remedy
The interior light
does not turn on.
The appliance is not switched on.
u
Switch on the appliance.
The door was open for more than
15 minutes.
u
If the door is open, the interior lighting switches
off automatically after about 15 minutes.
The LED interior light is faulty or
the lid is damaged.
u
Contact Customer Service. (see 10.4 Customer
Service)
Customer support
* Depending on model and options 25
10.4 Customer Service
First check whether you can rectify the fault yourself
(see 10 Customer support) . If you cannot rectify the
problem, contact Customer Service.
You can find the address in the enclosed brochure
“Liebherr-Service” or at home.liebherr.com/service.
WARNING
Unprofessional repair!
Injuries.
u
A damaged power cable may only be replaced by the
manufacturer, the manufacturer’s Customer Service
or a similarly qualified person.
u
For appliances with plug and play connection cables,
the change can be made by the customer.
10.4.1 Contacting Customer Service
Make sure that the following appliance information is
available:
q
Appliance name (model and index)
q
Service no. (service)
q
Serial no. (S no.)
u
Call up the appliance information via the display.
(see Appliance information)
-or-
u
Refer to the type plate for appliance information.
(see 10.5 Rating plate)
u
Take note of the appliance information.
u
Notify customer service: Report errors and the appli‐
ance information.
w
This will help us give you fast and accurate support.
u
Follow further instructions from Customer Service.
10.5 Rating plate
The type plate is on the bottom on the inside of the
appliance.
Fig.85
(1)
Appliance name (3) Serial no.
(2) Service no.
u
Information from the nameplate.
11 Decommissioning
u
Empty appliance.
u
Switch off appliance. (see Switching appliance off
and on)
u
Pull the power plug from the outlet.
u
If necessary, remove the IEC socket: Pull the IEC
socket out of the appliance plug while turning it to
the left and right at the same time.
u
Clean appliance. (see 9.5Cleaning the appliance)
u
Leave the door open to prevent unpleasant odors.
12 Disposal
12.1 Preparing the appliance for
disposal
WARNING
Risk of child entrapment!
Before you throw away your old refrigerator or freezer:
u
Take off the doors.
u
Leave the shelves in place so that children may not
easily climb inside.
Liebherr uses batteries in some of its appli‐
ances. You should remove these before
disposal of the old appliance for environ‐
mental reasons. If your appliance contains
batteries, a corresponding notice is
attached to the appliance.
Lamps If you can remove the lamps yourself
without destroying them, also remove these
before disposal.
u
Take the appliance out of operation.
u
If possible: Remove lamps without destroying them.
12.2 Disposing of the appliance in an
environmentally friendly manner
The appliance still contains
valuable materials and must
be collected separately from
unsorted municipal waste so
it can be recycled.
Decommissioning
26 * Depending on model and options
Dispose of batteries sepa‐
rately from the old appliance.
Certain batteries should NOT
go in household garbage or
recycling bins. Waste
batteries can always be recy‐
cled or taken to household
hazardous waste collection
points. To prevent fires from
lithium-ion batteries, tape
battery terminals and/or
place batteries in separate
plastic bags and never put
these batteries in household
garbage or recycling bins.
Lamps
Dispose of removed lamps via
the respective collection
systems.
For USA: Check the Responsible Appli‐
ance Disposal (RAD) program
to find a RAD partner near
you.
For Canada: Follow your local guidance
about recycling and disposal
capabilities near you.
WARNING
Leaking refrigerant and oil!
Fire. The refrigerant contained within the appliance is
environmentally friendly, but flammable. The oil
contained within the appliance is flammable. Escaping
refrigerant and oil can ignite if they are of high enough
concentration and are exposed to an external heat
source.
u
Do not damage the pipelines of the coolant circuit
and the compressor.
u
Observe the notes on appliance transport.
u
Transport the appliance away without damaging it.
u
Dispose of batteries, lamps, and the appliance
according to the above specifications.
Disposal
* Depending on model and options 27
home.liebherr.com/fridge-manuals
Under-worktop refrigerator
Issue date:20250127
Part number index: 7083753-00
For Service in the U.S.: Liebherr Service Center
Toll Free: 1-866-LIEBHER or 1-866-543-2437
Service-appliances.us@liebherr.com
PlusOne Solutions, Inc.
3501 Quadrangle Blvd, Suite 120
Orlando, FL 32817
For Service in Canada: Liebherr Service Center
Toll Free: 1-888-LIEBHER or 1-888-543-2437
www.euro-parts.ca
EURO-PARTS CANADA
39822 Belgrave Road, Belgrave, Ontario, N0G 1E0
Phone: (519) 357-3320 | Fax: (519) 357-1326
