Questions, problems, missing parts?
Before returning to your retailer, call our customer service at 1-800-887-6326
Monday – Friday 9:00 a.m. – 5:00 p.m. CST
SKU Number: 343-4550
Solar Light
Model Number: SL23096
231128
REF. PARTS NAME
Includes (1) AA 1000 mAh(1.2V) Ni-MH rechargeable battery.
The lifetime for LEDs is estimated to be 100,000 hours.
LED
Screw
X4
Anchor
X2
Inner Base
X1
BBAA CC
PACKAGE CONTENTS
HARDWARE CONTENTS Note: Hardware not shown actual size.
A
B
C
A Solar Panel Unit
B Glass Shade
C Decorative Shade
Page 2 of 3
231128
Read all instructions before assembly. Failure to do so may result in faulty assembly
and potential injury.
ASSEMBLY AND BATTERY REPLACEMENT INSTRUCTIONS
ASSEMBLY
• Carefully remove your solar light from the box.
• Fix the inner base (CC) to the wood post with screws (AA),
then cover the decorative shade (C) onto the inner
base (CC), and then fix the decorative shade (C) and inner
base (CC) with screws (AA) from the side. (See Fig.1a)
If installed on cement post, anchors (BB) are required.
Mark the position of the two holes on the cement post where
the anchors (BB) will be placed, remove the inner base (CC)
from the cement post, and drill two holes on the target,
hammer the anchors (BB) into the holes of the cement post,
and then reattach the inner base (CC) to the cement post,
and secure the screws (AA) through the holes on the inner
base (CC). (See Fig.1b)
Note: 3" x 3" post and above size can be matched.
CLEANING AND MAINTENANCE: Please use a damp cloth to clean the solar panel. Do not use any chemical or
abrasive cleaner. It is important to ensure that no moisture enters into the solar light.
RECHARGEABLE BATTERY: The product contains (1) AA 1000 mAh(1.2V) Ni-MH rechargeable battery.
When the battery expires, it must be recycled or disposed of properly. Please contact your local waste disposal authority
for the correct procedure. Do not expose battery to fire.
FUNCTION: The built-in solar panels convert sunlight into electricity. The rechargeable battery stores the energy and
converts the power into light for use during the night. The overall performance and illumination hours of the solar light
are largely dependent on the geographic location, weather and temperature conditions. Stronger and longer exposure
to direct sunlight will maximize the stored energy in the battery and provide longer lighting hours.
LOCATION: It is important to select an outdoor location with full, direct sunlight where the solar panel can receive at
least 8 hours of sunlight each day. Shady areas will not enable batteries to be fully charged. This will reduce the lighting
hours at night. It is also important to avoid placing the solar light by light sources, such as street lights or porch lights,
which may cause the solar light to turn off automatically. The solar light is designated for outdoor usage and ideal for
night lighting of gardens, paths, etc.
Fig.2
3000K 5000K
OFF
OPERATIONAL INSTRUCTIONS (Fig.2)
• Rotate the solar panel unit (A) counterclockwise to remove
it from the decorative shade (C) before using the fixture.
• The switch be set at "OFF" as default. Customize the
correlated color temperature (3000K and 5000K) of the
fixture by moving the switch.
• After assembly, make sure the solar panel is exposed to
direct sunlight for 8 hours. The fixture will automatically
illuminate at dusk.
CHANGING BATTERIES (Fig.3)
• Rotate the solar panel unit (A) counterclockwise to remove
it from the decorative shade (C).
• Unscrew the four set screws, careful open the cover of solar panel unit (A) .
• Replace the old battery with a new battery making sure the polarity is correct.
• Restore the cover.
Fig.3
Battery
A
Fig.1a
Wood Post
AA
A
C
AA
CC
Cement
Post
AA
BB
A
C
AA
Fig.1b
Set Screw
Page 3 of 3
231128
If light does not work, please follow these troubleshooting steps:
Check the rechargeable battery and make sure that it is in contact to the metal plate and the polarity is correct. If the
battery is worn out, replace the battery with (1) AA 1000 mAh(1.2V) Ni-MH rechargeable battery.
Always keep the solar light distant from other night light sources, such as exterior lights. Reposition the light to avoid
close contact with other night light sources.
Make sure solar panel is clean and free of dirt and debris. If needed use a damp cloth to clean the solar panel. Do
not use any chemical or abrasive cleaner. It is important to ensure that no moisture enters into the solar light.
Questions, problems, missing parts?
Before returning to your retailer, call our customer service at 1-800-887-6326.
Monday – Friday 9:00 a.m. – 5:00 p.m. CST
TROUBLESHOOTING
ONE-YEAR LIMITED WARRANTY: If, during normal use, this PATRIOT LIGHTING lighting fixture breaks or fails due
to a defect in material workmanship within one (1) year from the date of original purchase, simply bring this lighting
fixture with the original sales receipt back to your nearest MENARDS retail store. At its discretion, PATRIOT
LIGHTING agrees to have the product or any defective part(s) repaired or replaced with the same or similar PATRIOT
LIGHTING product or part free of charge, within the stated warranty period, when returned by the original purchaser
with original sales receipt. This warranty; (1) excludes expendable parts including but not limited to light bulbs; (2)
does not cover damage that has resulted from abuse or misuse; and (3) does not cover any losses, labor, injuries to
persons/property or costs. This warranty does give you specific legal rights and you may have other rights, which vary
from state to state.
