* Product picture is for reference only.
Model: FDUP43CBS / FDUP49CBS / FDUP55CBS / FDUP65CBS
FDUF43CBS / FDUF49CBS / FDUF55CBS / FDUF65CBS
Furrion Aurora™ TV Series
User Manual
2
Welcome
Thank you and congratulations for purchasing this Furrion product. Before operating your new
product, please read these instructions carefully. This user manual contains information for safe
use, installation and maintenance of the product.
Please keep this user manual in a safe place for future reference. This will ensure safe use and
reduce the risk of injury. Be sure to pass on this manual to new owners of this product.
The manufacturer does not accept responsibility for any damages due to not observing these
instructions.
Supplier’s Declaration of Conformity
47 CFR § 2.1077 Compliance Information
Unique Identifier
Trade Name: Furrion
Model No.: FDUP43CBS, FDUP49CBS, FDUP55CBS, FDUP65CBS,
FDUF43CBS, FDUF49CBS, FDUF55CBS, FDUF65CBS
Furrion Aurora™ TV Series
User Manual
Responsible Party – U.S. Contact Information
Furrion Innovation Center & Institute of Technology
52567 Independence Ct., Elkhart, IN 46514, USA
Toll free:
1-800-789-3341; Email: [email protected]
FCC Compliance Statement
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2)this device must accept any interference received,
including interference that may cause undesired operation.
3
Contents
Welcome ................................................................................................. 2
Contents .................................................................................................3
Safety Warnings ....................................................................................4
Important Safety Instructions ......................................................................................................... 4
Control Panel .........................................................................................................................................8
Function Overview ................................................................................8
Rear Panel ............................................................................................................................................... 9
Connection ........................................................................................................................................... 10
Remote Control................................................................................................................................... 12
Programming Other Manufacturers’ Universal Remote Control Devices ................ 13
Before Operation................................................................................. 14
What’s in the Box ................................................................................................................................ 14
Prepare your Remote Control ...................................................................................................... 14
Choose a Proper Location for your TV .....................................................................................15
Cable Management ...........................................................................................................................15
Mount on Wall .......................................................................................................................................17
Getting Started ....................................................................................19
TV Settings .......................................................................................... 20
Setup Settings .................................................................................................................................... 20
Picture Settings ..................................................................................................................................23
Audio Settings .....................................................................................................................................24
Time Settings ...................................................................................................................................... 26
Lock Settings .......................................................................................................................................27
Channel Settings ............................................................................................................................... 30
USB Operation ..................................................................................... 31
Troubleshooting ..................................................................................32
Specifications .................................................................................... 33
Care and Clean ................................................................................... 36
4
Safety Warnings
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE COVER
(OR BACK). NOUSER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
WARNING: TO REDUCE THE RISK OF FIRE
OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPARATUS TO RAIN OR MOISTURE.
This ‘bolt of lightning’ indicates
uninsulated material within your unit
which may cause an electric shock.
For the safety of everyone in your
household, please do not remove product
covering.
The ‘exclamation mark’ calls attention
to features within the enclosed
literature to prevent operating and
maintenance problems.
Important Safety
Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Clean only with dry cloth.
6. Do not block any ventilation openings. Install
in accordance with the manufacturer’s
instructions.
7. Do not install near any heat sources such
as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
8. Do not mount this TV near a motor or
transformer where strong magnetism is
generated. Images on the television will
become distorted and the colour irregular.
9. Do not defeat the safety purpose of the
polarized or grounding-type plug. Apolarized
plug has two blades with one wider than the
other. A grounding type plug has two blades
and a third grounding prong. The wide blade
or the third prong are provided for your safety.
When the provided plug does not fit into your
outlet, consult an electrician for replacement
of the obsolete outlet.
10. Protect the power cord from being walked on
or pinched, particularly at plugs, convenience
receptacles, and the point where they exit
from the apparatus.
11. Only use attachments/accessories specified
by the manufacturer.
12. Do not place the product on an unstable cart,
stand, tripod, table, or anywhere the unit is not
permanently installed. Placing the product
on an unstable place can cause the product
to fall, resulting in potential serious personal
injuries, as well as damage to the product.
13. Use only with a cart, stand, tripod, bracket or
table specified by the
manufacturer or sold with the
apparatus. When a cart is used,
use caution when moving the cart/
apparatus to avoid injury from
tip-over.
14. Unplug this apparatus during lightning storms
or when unused for long periods of time.
15. Do not touch this apparatus or antenna during
a thunder or lightning storm.
16. Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way,
such as if the power-supply cord or plug is
damaged, liquid has been spilled or objects
have fallen into the apparatus, or when
the apparatus has been exposed to rain or
moisture, does not operate normally, or has
been dropped.
17. Naked flame sources such as lit candles,
should not be placed on apparatus.
18. Do not overload wall outlets, extension cords,
or integral convenience receptacles as this
can result in a risk of fire or electric shock.
19. The power cord must be routed properly to
prevent people from stepping on it, or objects
from resting on it. Check the cords at the
plugs and product.
5
Safety Warnings
20. Never push objects of any kind into this
product through openings as they may touch
short-out parts or dangerous voltage points
that could result in a fire or electric shock.
21. If an outside antenna is connected to the
television equipment, be sure the antenna
system is grounded so as to provide some
protection against voltage surges and built
up static charges. Section 810 of the National
Electrical Code provides information with
respect to proper grounding of the mast and
supporting structure, grounding of the lead-in
wire to an antenna discharge unit, size of
grounding conductors, location of antenna
discharge unit, connection to grounding
electrodes, and requirements for the
grounding electrodes.
22. An outside antenna system should not be
located in the vicinity of overhead power
lines or other electrical light or power circuits,
or where it can fall into such power lines or
circuits. When installing an outside antenna
system, extreme care should be taken to keep
from touching such power lines or circuits as
contact with them might be fatal.
NEC-NATIONAL
ELECTRICAL
CODE S2898A
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H))
GROUND CLAMPS
GROUND CLAMP
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
EXAMPLE OF ANTENNA GROUNDING AS PER
THE NATIONAL ELECTRICAL CODE
ANTENNA
LEAD IN WIRE
GROUNDING
CONDUCTORS (NEC
SECTION 810-21)
ELECTRIC SERVICE
EQUIPMENT
23. NOTE TO CABLE/TV INSTALLER: This
reminder is provided to call the CATV system
installer’s attention to Article 820-40 of the
National Electric Code (U.S.A.). The code
provides guidelines for proper grounding and,
in particular, specifies that the cable ground
shall be connected to the grounding system of
the building, as close to the point of the cable
entry as practical.
24. When replacement parts are required, be sure
the service technician uses replacement parts
specified by the manufacturer or those that
have the same characteristics as the original
part. Unauthorized substitutions may result in
fire, electric shock or other hazards.
25. Upon completion of any service or repairs to
this unit, ask the service technician to perform
safety checks to determine that the unit is in
proper operating condition.
26. When you connect the product to other
equipment, turn off the power and unplug
from the wall outlet. Failure to do so may
cause an electric shock and serious personal
injury. Read the owner’s manual of the
other equipment carefully and follow the
instructions when making any connections.
27. The socket-outlet must be installed near the
unit and easily accessible.
28. Where the mains plug is used as the
disconnect device, the disconnect device
shall remain readily operable.
29. Never remove the back cover of the TV as
this can expose you to very high voltages
and other hazards. If the TV does not
operate properly, unplug the TV and call
your authorized dealer or service center.
Adjust only those controls that are covered
in the instructions, as improper changes or
modifications not expressly approved by
Furrion could void the user’s warranty.
30. Do not submerge this TV in water or pressure
wash it. It is not designed to be submerged
in water, withstand pressure washers,
high-pressure water jets, or hurricane-type
weather.
31. Cleaning : With your TV turned off, gently
wipe the surface of the display panel with a
damp (with water) microfiber, cotton or flannel
cloth. (Do not use tissues, rags, sponges or
paper towels because they may damage the
screen and leave lint pieces behind). Remove
any dirt and salt deposits from the unit, being
careful to rinse the cloth frequently to avoid
scratching the TV or screen surface. Avoid
using harsh chemicals, abrasives, or solvents
when cleaning any surface on the unit.
6
Safety Warnings
32. The operation temperature for the unit is
-20°C (-4°F) to +43°C (+109.4°F). The storage
temperature is -33°C (-27.4°F) to +58°C
(+136.4°F). Protect the TV from damage
by the extreme temperature. This is not a
commercialTV.
33. Batteries (battery pack or batteries installed)
shall not be exposed to excessive heat such
as sunshine, fire or the like.
34. The apparatus should be connected to a
mains socket outlet with a protective earthing
connection.
35. To prevent injury, this apparatus must be
securely attached to the wall in accordance
with the installation instructions.
HOW TO HANDLE THE LED PANEL
● Do not press hard or jolt the LED panel. It may
cause the LED panel glass to break and injury
may occur.
● If the LED panel is broken, make absolutely
sure that you do not touch the liquid in the
panel. This may cause skin inflammation.
● If the liquid gets in your mouth, immediately
rinse and consult with your doctor. Also, if the
liquid gets in your eyes or touches your skin,
consult your doctor after rinsing for at least 15
minutes in clean water.
Possible Adverse Effects on LED Panel: If
a fixed image displays on the TV screen for a
long period of time, it may cause a permanent
disfigurement on the screen with image burn-in or
ghosting. This type of damage is NOT COVERED
BY THE WARRANTY.
● Avoid displaying a static picture or a picture
with static elements (black bars, black
borders, logos, etc.) on the TV screen for
more than two hours at a time. Make sure you
change the image on your screen periodically.
● If the aspect ratio of the TV is set to 4:3 for
a long period of time, image burn may occur
on the letterboxed area of the screen. Make
sure you change the size of the picture
occasionally.
The following symptoms are not signs
of malfunction but technical limitation.
Therefore we disclaim any responsibility for
these symptoms.
● LED panels are manufactured using an
extremely high level of precision technology,
however sometimes parts of the screen may
be missing picture elements or have luminous
spots. This is not a sign of a malfunction.
● Do not install the LED panel near electronic
equipment that produces electromagnetic
waves. Some equipment placed too close to
LED may cause interference.
● Effect on infrared devices – There may be
interference while using infrared devices such
as infrared cordless headphones.
COMPLIANCE
FCC Statement
Note: This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment generates,
uses and can radiate radio frequency energy and,
if not installed and used in accordance with the
instructions, may cause harmful interference to
radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference
to radio or television reception, which can be
determined by turning the equipment off and
on, the user is encouraged to try to correct the
interference by one or more of the following
measures:
● Reorient or relocate the receiving antenna.
● Increase the separation between the
equipment and receiver.
● Connect the equipment into an outlet on a
circuit different from that to which the receiver
is connected.
● Consult the dealer or an experienced radio/TV
technician for help.
WARNING: Changes or modifications to this unit
not expressly approved by the party responsible
for compliance could void the user’s authority to
operate this equipment under FCCRules.
7
Safety Warnings
This device complies with part 15 of the FCC
Rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful
interference.
2. This device must accept any interference
received, including interference that may
cause undesired operation.
POWER SOURCE
This TV is designed to operate on 100~240 volt
50/60 Hz, AC current. Connect the power cord
to a GFCI protected AC outlet with an “in-use”
waterproof cover.
Warning: TV and GFCI receptacle must be
installed away from any water source in a safety
distance. Be sure to check local electrical codes
and comply with their local standards.
To reduce the risk of fire or electric shock, do not
expose this apparatus to rain or moisture.
CARE OF THE ENVIRONMENT
Disposal of your old product and battery
Your product is designed and
manufactured with high quality materials
and components, which can be recycled
and reused.
● Never dispose of your product with other
household waste. Please familiarize yourself
with the local rules on the separate collection
of electrical and electronic products and
batteries.
● The correct disposal of these products helps
prevent potentially negative consequences on
the environment and human health.
● Your product contains batteries which cannot
be disposed of with normal household waste.
The battery must be recycled or disposed of
properly. Contact your local waste management
oce for information on battery recycling or
disposal.
All registered and unregistered trademarks are
property of their respective owners.
CAUTION: Changes or modifications not
expressly approved by the party responsible for
compliance could void the user’s authority to
operate the equipment.
SAFETY PRECAUTIONS
WARNING: Never place a television set in an
unstable location. A television set may fall,
causing serious personal injury or death. Many
injuries, particularly to children, can be avoided by
taking simple precautions such as:
– Using cabinets or stands recommended by
the manufacturer of the television set.
– Only using furniture that can safely support
the television set.
– Ensuring the television set is not overhanging
the edge of the supporting furniture.
– Not placing the television set on tall furniture
(for example, cupboards or bookcases)
without anchoring both the furniture and the
television set to a suitable support.
– Not placing the television set on cloth or other
materials that may be located between the
television set and supporting furniture.
– Educating children about the dangers of
climbing on furniture to reach the television
set or its controls.
If your existing television set is being retained
and relocated, the same considerations as above
should be applied.
NOTES WHEN MOUNTING THE TV ON THE
WALL
IMPORTANT: The TV must be installed away
from any water source in a safe distance.
If the unit is to be mounted on the wall, contact the
retailer where you purchased the TV for advice,
and have the equipment professionally installed.
Incomplete or improper installation may cause
injury to you, and/or damage to the TV. Please
refer to the VESA mounting pattern to ensure the
correct VESA mounting is used for the TV.
CAUTION: To prevent personal injury and/or
damage to the TV or personal property, use at
least two people to install or move the TV.
8
Function Overview
Control Panel
POWER
VOL- VOL+
CH- CH+ MENU SOURCE
1
4
2
5
3
6
7
* Please note that the button layout of the
controls may vary from model to model.
Item Button Function
1
SOURCE
Select the input source
2
MENU
Enter the main menu
3
CH+
Skip to the next channel
4
CH-
Skip to the previous
channel
5
VOL+
Increase volume
6
VOL-
Decrease volume
7
POWER
Switch the TV on/off
9
Function Overview
Rear Panel
* The configuration of the connection ports
may vary from model to model.
USB IN
DC 5V 1A
2
3
4
7
6
5
8910
1
No. I/O port Description
1
AUDIO
OUT
(L-R)
Connect to the AUDIO IN ports of an
audio device.
2
IR Ext
Connect with an IR extender.
Note: Please purchase an IR
extender with the spec as below:
3.5 mini plug/Tip-VCC 5V/Center-
Data/Lower-Ground; With 30ft
range from remote control to IR
receiver; Operating voltage 3.3~5v
and supported by 38Khz bandwidth.
3
USB IN
USB Port: view pictures and listen to
MP3s via a compatible USB stick.
4
RF IN
Connect to the ANTENNA, CABLE
or CABLE BOX.
No. I/O port Description
5
HDMI
3 IN
(MHL/
CEC)
Connect to the HDMI OUT port of a
DVD Player, Games Console, Cable
Box or other HDMI device.
MHL (Mobile High-Definition Link)
You can connect an MHL-enabled
device, such as certain models of
smart phones & tablets, and view
the device’s screen on the TV.
Connecting an MHL-enabled device
to the HDMI3 input requires a special
MHL cable (not included).
CEC (Consumer Electronics Control)
When connected to the CEC
compatible Furrion Entertainment
Systems or other CEC Compatible
devices, the TV links with the system
to give extra functionality.
ARC (Audio Return Channel)
When connected with a HDMI 1.4
cable to an ARC compatible audio
system, the TV links with the device
to give extra audio functionality.
6
HDMI
2 IN
(CEC)
7
HDMI
1 IN
(ARC/
CEC)
8
Y/Pb/Pr
Connect to the COMPONENT
VIDEO OUT ports of a DVD Player,
Cable Box or other compatible
devices.
9
VIDEO IN
Connect to the COMPOSITE
VIDEO/AUDIO OUT ports of a
DVD Player, Cable Box or other
compatible devices.
AUDIO
IN
(L-R)
10
COAX
OUT
Connect to the COAXIAL AUDIO IN
port of an audio device.
10
Function Overview
Connection
Your Furrion Aurora™ TV offers multiple connection options. Please consult the manual of DVD
player, Games Console or other devices to ensure proper connection and use.
You can choose one or more of the connections below to operate.
Note: All external devices and cables shown in the diagram are for reference only and not
included in the package.
A
HDMI 1,
HDMI 2, or
HDMI 3
OR
B
L (Red)
R (White)
VIDEO (Yellow)
AUDIO
C
11
Function Overview
Connection
R (White)
Y (Red)
Pb (Blue)
Pr (Green)
AUDIO
VIDEO
L (Red)
D
R (Red)
L (White)
OR
Furrion model No.:
FSBNN30MSS-BL
(sold separately)
E
F
IR extender
G
12
Function Overview
Remote Control
1
3
5
6
8
9
10
11
13
15
17
19
21
28
26
24
32
34
36
37
38
39
41
43
30
2
4
7
12
14
16
18
20
22
27
25
23
29
31
33
40
42
35
No. Button Function
1
Turn the TV on/off
2
SLEEP
Set time for the TV to turn off
3
INFO
Display information about the
current input source
4
FREEZE
Freeze current picture
5
MENU
Enter the main menu
6
/ / / Navigate in a menu
7
OK
Confirm the selection
8
RETURN
Return to the previous menu
9
NUMBER
BUTTONS
Enter numbers or select channels
10
-
Insert the dash for selecting
digital channels directly (For
example, channel 28-2 would be
selected by the button sequence
2 8 - 2.)
11
Fast backward
12
Start or pause the playback
13
Skip to the beginning of the
previous chapter/track/photo.
14
Stop playback
15
USB
Switch the source to USB
16
TV
Switch the source to TV
17
Power on/off or switch to
standby.
18
SOURCE
Select the input source
19
MUSIC
Select the preset EQ mode
MUSIC.
13
Function Overview
No. Button Function
20
MOVIE
Select the preset EQ mode
MOVIE.
21
Skip to the previous track for
Bluetooth or USB playback.
22
Start or pause Bluetooth or USB
playback.
23
Skip to the next track for
Bluetooth or USB playback.
24
Decrease volume
25
SPORT
Select the preset EQ mode
SPORT.
26
Increase volume
27
Press it briefly to enter Bluetooth
pairing mode;
Press and hold it for 3 seconds
to unpair the connected device,
then launch paring with a new
device.
* BT Name: Furrion SB 2.1
28
Mute or un-mute the Soundbar
audio.
29
HDMI
Switch the source to HDMI
30
AV
Switch the source to AV
Remote Control
Programming Other Manufacturers’ Universal Remote
Control Devices
When programming a local cable universal remote control or control system, you may find
that Furrion may not be on the list of TV manufacturers. If that is the case, your Furrion Aurora
Outdoor TV supports LG’s universal remote code. Commonly used cable provider remote codes
are:
● Dish Network- 545
● DirectTV- 12731
● Xfinity- 10178 / 11265 / 12731
● Frontier- 210
No. Button Function
31
Skip to the beginning of the next
chapter/track/photo.
32
CC
Select Closed Caption: ON/OFF/
CC On Mute
33
Fast forward
34
P.MODE
Select picture mode
35
Toggle between the current and
previous channels
36
CH
/
Channel Up/Down
37
VOL +/-
Increase/Decrease the volume
38
EXIT
Exit the current menu
39
Select an input source for the
Soundbar: AUX / RCA/ COAX
/ BT.
40
GUIDE
Open the current digital channel
information guide (antenna only).
41
FAV
Add the channel to favorite list
42
CH.LIST
Display the channel list
43
Mute or unmute the audio
14
Before Operation
What’s in the Box
Thanks for purchasing this Furrion Aurora™ TV. This manual will help you set up and begin using
your TV. First, check the contents of your box with the parts checklist below:
● TV
● Weather proof remote with button battery (x1) and tool to open battery cover (x1)
● Wall mount screws (x4)
● Screw adaptors (x4)
● RCA cable
● Printing materials
Now you can get started!
Prepare your Remote Control
BATTERY INSTALLATION
1. Open the battery cover with the tool supplied with the remote control.
2. Install the supplied button battery CR2025.
3. Close the battery cover.
OP EN
CLO SE
OP EN
CLO SE
OP EN
CLO SE
BATTERY PRECAUTIONS
These precautions should be followed when using battery in this device:
● Use only the size and type of battery specified.
● Danger of explosion if batteries are incorrectly replaced.
● If the device is not to be used for a long period of time, remove the battery to prevent
damage or injury from possible battery leakage.
● The batteries should not be exposed to excessive heat due to sunlight, fire or other heat
sources.
WARNING: This product contains a button battery on the remote control.
15
Before Operation
● Do not ingest the battery contained within
the remote control supplied with the unit
as this battery represents a chemical burn
hazard.
● If the button battery is swallowed, it can
cause severe internal burns in just 2
hours and can lead to death. If you think
batteries might have been swallowed or
placed inside any part of the body, seek
immediate medical attention.
● Keep new and used batteries away from
children. If the battery compartment does
not close securely, stop using the product
and keep it away from children.
Choose a Proper Location
for your TV
Important: The TV must be installed away
from any water source in a safety distance.
For best viewing we recommend you install it
in a shaded environment.
● Avoid to install the TV where the screen is
facing direct sunlight. The ideal location
is in one place where the TV is shaded
by structures, or under a patio cover or
gazebo.
● If the sun shines directly on the screen
for long periods of time, dark areas may
appear on the screen. This is a normal
reaction for the LED panel, and will not
cause damage to the screen. Either turn
the screen away from the sun, or shade
the TV, and the dark areas will soon
disappear.
Note: DO NOT use the TV if ambient
air temperature exceeds the operating
temperature limits.
Cable Management
WARNING: Do not connect the power source
before making connections.
1. Open the cable access door in the rear
panel by loosing the thumb screws.
(Figure 1)
2. Connect the cables and lead all
connecting cables downwards through
the duct at the bottom of the cable access
door.
3. Leave a drip loop when cables enter the
compartment. This will prevent water
from dripping down the cord and possibly
entering the door area.
4. Close the door and tighten the thumb
screws for the best waterproof effect.
(Figure 2)
USB IN
DC 5V 1A
Figure 1
16
Before Operation
Cables
Drip Loop
Thumb Screws x 3
Cable Access Door
Figure 2
Tip: If a TV streaming stick is connected and stays inside the rear cable compartment, the RF/
Wifi signal will be reduced when passing through the closed cable door.
Connect the Power Cord
Connect the power cord to a GFCI protected AC outlet with an “in-use” waterproof cover.
Caution:
● Do not connect power cord during cable connecting and TV installation.
GFCI
PROTECTED
OUTLET
GFCI
PROTECTED
OUTLET
WARNING: TV and GFCI receptacle must be installed away from any water source in a safety
distance. Be sure to check local electrical codes and comply with their local standards.
17
Before Operation
POWER SOURCE
NOTE: Please make sure to insert the cord securely at both the TV and the wall outlet.
WARNING:
● DO NOT USE WITH A VOLTAGE OTHER THAN THE POWER VOLTAGE SPECIFIED. DOING
SO MAY CAUSE FIRE, ELECTRIC SHOCK, OR DAMAGE.
● DO NOT PLUG/UNPLUG THE POWER ADAPTER WHEN YOUR HANDS ARE WET. DOING
SO MAY CAUSE ELECTRIC SHOCK.
CAUTION:
● WHEN THIS UNIT IS NOT BEING USED FOR EXTENDED PERIODS OF TIME(E.G., AWAY
ON A TRIP), BE SURE TO UNPLUG IT FROM THE OUTLET.
Mount on Wall
You are recommended to install the TV in an area shaded by trees, landscape and/or
structures, or under a patio cover or gazebo.
FULL SHADE (Covered gazebos, patios, porches)
TV designed for fully shade outdoor spaces.
(Model: FDUF43CBS / FDUF49CBS / FDUF55CBS / FDUF65CBS)
PARTIAL SUN (Pergolas, partially covered decks)
TV designed for partial sun exposure and brighter outdoor spaces.
(Model: FDUP43CBS / FDUP49CBS / FDUP55CBS / FDUP65CBS)
18
Before Operation
IMPORTANT: Connect all cables to the rear panel prior to mounting TV on wall. The cable
access door in rear panel will be obstructed once the TV is mounted.
● Follow the installation guide supplied with the Wall-Mount Bracket (purchased separately)
when installing the TV.
● Choose an appropriate location and refer to VESA pattern for mounting.
● Recommend you to contact a professional for installation and use at least two people to
move or install the TV.
Wall
Adaptor
M6 Screws
19
Getting Started
The Setup Wizard window appears only the
first time you turn on the TV. It will assist you
to configure the TV and scan for available
channels.
IMPORTANT: Make sure the antenna or
cable connection is made.
1. Press POWER button on the TV control
panel or
button on the remote control
to switch on the TV. The Setup Wizard
window appears on the screen.
NOTE: It may take a few seconds before
the Setup Wizard window appears on the
screen.
2. Use / / / to navigate and select
your desired settings.
Setup Wizard
Air/Cable Air
Cable System Auto
Auto Scan
Menu Language English
Move
Select
Exit
MENU
Setup Wizard
Menu
Language
Use
or to highlight Menu
Language, then press or to select
English, French or Spanish.
Air/Cable
Use
or to highlight Air/Cable,
then press or to select Air or
Cable.
Cable
System
Use
or to highlight Cable
System, then press
or to select
Auto, STD, IRC or HRC.
NOTE: Only adjustable when “Air/
Cable” is set as “Cable” mode.
Auto Scan
Use
or to highlight Auto Scan,
then press OK or to start scanning all
the channels available in your area.
NOTE: You may press MENU at any time to
exit the menu.
20
TV Settings
Setup Settings
1. Press MENU button, the setup window will appear on the screen.
2. Use or to highlight Setup mode.
3. Use or to highlight the item you would like to reset, then press or to select the
settings.
4. Press MENU to return to the previous menu or press EXIT at any time to exit the setting.
Setup Menu
Menu
Language
Select the menu
language
Press
or to select English, Français, Español or Deutsch.
Transparency
Control the menu
transparency
Press
or to select Off /On.
Zoom Mode
Set the picture
proportion
Press
or to select Zoom, Normal, Cinema or Wide.
* The selection for Zoom Mode may vary from model to model.
Noise
Reduction
Reduce the
roughness of the
Press
or to select Off, Weak, Middle or Strong.
21
TV Settings
Setup Menu
Closed
Caption
Set the Closed
Caption features.
CC Mode
Press
or to select Off, On or CC On Mute.
Basic
Selection
Press
or to select CC1, CC2, CC3, CC4, Text 1, Text 2,
Text 3 or Text 4 .
Advanced
Press
or to select Service1, Service 2, Service 3,
Service 4, Service 5 or Service 6.
Option
Press
or
to enter the
sub menu to
customize text
fonts, colors,
opacity.
Mode
Press
or to select Default or
Custom.
Font Style
Press
or to select Default, Font
0, Font 1, Font 2, Font 3, Font 4,
Font 5, Font 6 or Font 7.
Font Size
Press
or to select Default,
Normal, Large or Small.
Font Edge Style
Press
or to select Default, None,
Raised, Depressed, Uniform, Left
Shadow or Right Shadow.
Font Edge Color
Press
or to select Default,
Black, Red, Green, Blue, Yellow,
Magenta or Cyan.
FG Color
Press
or to select Default,
White, Red, Green, Blue, Yellow,
Magenta or Cyan.
BG Color
Press
or to select Default, Cyan,
Magenta, Yellow, Blue, Green, Red
or Black.
FG Opacity
Press
or to select Default,
Solid, Flashing, Translucent or
Transparency.
BG Opacity
Press
or to select Default,
Solid, Flashing, Translucent or
Transparency.
DLC
Adjust the picture
contrast.
Press
or to select Off or On.
22
TV Settings
Setup Menu
HDMI CEC
Press
to enter
sub-menu, then
press or to
select Off /On for
HDMI CEC.
When selecting
On, the sub-menu
in the right column
will be available to
set up.
Auto Standby
Press
or to select Off /On.
In On mode, TV will shut down when there is no signal for
several minutes.
Auto TV on
Press
or to select Off /On.
In On mode, TV will automatically turn on when the connected
CEC device is turned on.
HDMI ARC
Press
or to select Off /On.
Set the HDMI ARC On if you want to enable the ARC function
with a connected 5.1/7.1 Home Theater System.
Device control
Press
or to select Off /On.
In On mode, it allows a connected CEC device to be
controlled by TV remote control.
Device list
Press
to display a list of HDMI CEC devices currently
connected to the TV.
EDID Switch
Select the EDID
version.
Press
or to select Auto, EDID 1.4 or EDID 2.0.
Restore
Default
Reset to factory
default settings.
Press
or to select Yes or No.
NOTE: HDMI CEC function is only available when connecting with a CEC device.
23
TV Settings
Picture Settings
1. Press MENU button, the setup window will appear on the screen.
2. Use
or to highlight Picture mode.
3. Use or to highlight the item you would like to reset, then press or to select the settings.
4. Press MENU to return to the previous menu or press EXIT at any time to exit the setting.
Picture Menu
Picture Mode
Select the display mode
Press
or to select User / Standard / Dynamic / Mild.
Contrast
Control the contrast level of the
Press
or to increase or decrease contrast intensity.
* Only adjustable after set “Picture Mode” as “User” mode
Brightness
Control the brightness level of the
Press
or to increase or decrease the overall brightness.
* Only adjustable after set “Picture Mode” as “User” mode
Color
Control the color level of the picture
Press
or to increase or decrease the color intensity.
* Only adjustable after set “Picture Mode” as “User” mode
Tint
Control picture tint
Press
or to adjust colors toward green or reddish tint.
* Only adjustable under NTSC signal
Sharpness
Control the sharpness of the picture
Press
or to soften or enhance edges in the picture.
* Only adjustable after set “Picture Mode” as “User” mode
Color Temp
Select the color mode
Press
or to select Medium / Warm / Cool.
Backlight
Control the backlight
Press
or to increase or decrease the backlight.
Blue Screen
If this is set as On, the screen changes
to blue when no signal input.
Press
or to set as On or Off.
Advanced
Setting
Press
to enter sub-menu to set the
features in right column.
Aspect Ratio
Press
or to select Wide /
Normal/Cinema/ Zoom.
Noise Reduction
Press
or to select Off /
Weak/ Middle / Strong.
Dynamic Contrast
Press
or to set as On or Off.
HDMI mode
Press
or to set as Video.
Auto Brightness
Press
or to set as On or Off.
HDR Select the HDR mode
Press
or to select Middle, Strong or Weak setting.
24
TV Settings
Audio Settings
1. Press MENU button, the setup window will appear on the screen.
2. Use or to highlight Audio mode.
3. Use or to highlight the item you would like to reset, then press or to select the
settings.
4. Press MENU to return to the previous menu or press EXIT at any time to exit the settings.
For DTV mode For ATV mode
25
TV Settings
Audio Menu
Sound Mode
Select the sound mode
Press
or to select Standard / Music / Movie / Sport / User
mode.
Standard: Optimizes a balanced sound in all environments.
Music: Preserves the original sound clear and dynamic like that on a
concert.
Movie: Enhances treble and bass for a rich surround sound
experience.
Sport: Reproduces a realistic sound like that in a stadium.
User: Customizes audio setting.
Bass
Control the bass level
Press
or to increase or decrease low frequency intensity.
Treble
Control the treble level
Press
or to increase or decrease high frequency intensity.
Balance
Control the balance level
Press
or to adjust the desired level between 0~100.
Surround
Control the surround effect
Press
or to set as On or Off.
AVC
(Auto Volume Control)
Control the maximum power
output
Press
or to set as On or Off.
SPDIF Type
Select the SPDIF sound mode
Press
or to select Off / RAW / PCM.
Audio
Languages
Select the menu language
Press
or to select English / French / Spanish.
* Only available on DTV channel
Accessibility
Control
the Voice
Guide
functions
Voice Guide
Voice Guide
Press
, or Enter to enter sub menu settings.
Then press or to set as On or Off. When the
Voice Guide is On, the OSD will read out via voice
once you operate the TV.
Volume
Press
or to select Weak / Middle / Strong to
change the volume.
* Only available after Voice Guide is set as On mode
Speed
Press
or to select Weak / Middle / Strong to
change the voice speed.
* Only available after Voice Guide is set as On mode
Pitch
Press
or to select Weak / Middle / Strong to
change the voice pitch.
* Only available after Voice Guide is set as On mode.
Video
Description
Press
or to set as On or Off. When setting as On, the video
description function is enabled and the video commentary text will
appear.
26
TV Settings
Time Settings
1. Press MENU button, the setup window will
appear on the screen.
2. Use or to highlight Time mode.
3. Use or to highlight the item you
would like to reset, then press or to
select the settings.
4. Press MENU to return to the previous
menu or press EXIT at any time to exit the
setting.
Time Menu
Sleep Timer
Set the countdown time
before TV automatically
shutdown
Press
or to select Off, 5Min, 10Min, 15Min, 30Min, 45Min, 60Min,
90Min, 120Min, 180Min or 240Min.
Time Zone
Set the time zone
Press
or to select Pacific, Alaska, Hawaii, Atlantic, Eastern,
Central or Mountain
Daylight
Saving Time
Turn on/off daylight
saving time
Press
or to set as On or Off.
* Only adjustable on DTV channel
Time Format
Select the time display
format
Press
or to set as 12-hour or 24-hour.
* Only adjustable on DTV channel
Auto Clock
Set automatic time
Press
or to set as On or Off.
* Only adjustable on DTV channel
Clock
When Auto Clock is set as Off, you can set the time manually.
Clock and Date are automatically set on the first time when the tuner receives a broadcast channel.
* Only adjustable on DTV channel
27
TV Setting
Lock Settings
1. Press MENU button, the setup window will appear on the screen.
2. Use
or to highlight Lock mode.
3. Use or to highlight “Enter Password” and input “0000” to enter the sub menu.
4. Use or to highlight the item you would like to reset, then press or to select the
settings.
5. Press MENU to return to the previous menu or press EXIT at any time to exit the setting.
28
TV Setting
Lock Menu
Enter
Password
Input the password to access the Lock
menu.
Use the Number Buttons (0~9) to enter the password, the
Lock menu will appear.
* Default password is 0000.
* If you forgot the password, use 8888 to enter any locked
menu.
Set
Password
Change the user password.
Set Password
Use Number buttons (0-9) to enter a
new password.
Confirm
Password
Repeat the password to confirm.
System
Lock
Change the parental controls.
Press
or to set as On or Off.
US
Set up parental locks based on US
rating system.
* Only available when System Lock is
set as On mode.
TV
Press
to enter the TV Ratings menu and
use / / / to select your TV rating
preference.(refer to the following tables of
Age and Genre)
MPAA
Press
/ buttons to select your movie rating
preference based on US Rating System.
Canada
Set up parental locks based on
Canadian rating system.
* Only available when System Lock is
set as On mode
Canada
English
Use
/ buttons to select your ratings
preference based on Canadian Rating
System (English).
Canada French
Use
/ buttons to select your ratings
preference based on Canadian Rating
System(French).
RRT Setting
Not adjustable by user.
Reset RRT
Restore to default RRT settings.
Press OK or
to enter the sub menu, then press or to
select Yes or No.
Clear Lock
Restore to default V-chip settings and
clear the lock setting.
Press OK or
to enter the sub menu, then press or to
select Yes or No.
29
TV Settings
Age
T V-Y
All Children
T V-Y 7
Suitable for 7 years old or above
TV-G
General Audience
TV-PG
Parental Guidance
TV-14
Suitable for 14 years old or above
TV-MA
Suitable for 17 years old or above
US Rating System
N/A
All Ages
G
General Audience
PG
Parental Guidance
PG-13
Parental Guidance below 13 years
R
Parental Guidance below 17 years
NC-17
Suitable for 17 years old or above
X
Adults Only
Genre
ALL
All
FV
Fantasy Violence
V
Violence
S
Sex
L
Language
D
Dialogue
Canadian Rating System (English)
E
Exempt from the ratings (All ages)
C
Suitable for children age of 0–7 years
C8+
Suitable for children age over 8 years
G
General Audience
PG
Parental Guidance
14+
Suitable for viewers age over 14 years
18+
Suitable for adults over 18 years
Canadian Rating System (French)
E
Exempt from the ratings (All ages)
G
General Audience
8 ans+
Suitable for children ages over 8 years
13 ans+
Suitable for children ages over 13 years
16 ans+
Suitable for viewers ages over 16 years
18 ans+
Suitable for adults over 18 years
30
TV Settings
Channel Settings
1. Press MENU button, the setup window will appear on the screen.
2. Use or to highlight Channel mode.
3. Use or to highlight the item you would like to reset, then press or to select the
settings.
4. Press OK to confirm your selections or settings and enter the sub menus.
5. Press MENU to return to the previous menu or press EXIT at any time to exit the setting.
Note: For Cable or Satellite users with a set-top box, there is no need to run channel Auto Scan.
Connect your cable or satellite set top box to one of the available inputs on the TV for viewing.
Channel Menu
Air/Cable
Set the reception type.
Press
or to select Air or Cable.
● Select Air when TV is connected to an indoor / outdoor antenna.
● Select Cable if you subscribe to a pay television service WITHOUT a set top
box.
Auto Scan
Press
or OK to enter
sub menu.
Cable System
Press
or to select Auto, STD, IRC or HRC.
(Only available when you select Cable as the reception type.)
Start to Scan
Press
or OK to start scanning available channels..
Favorite
Add or delete a channel in
the favorite list.
Press
or to select a channel, then press or OK to add or delete the
channel in the favorite list.
Show/Hide
Show or hide available
channels already in
memory.
Press
or to select a channel, then press or OK to show or hide the
channel.
Channel No.
Select a channel number
to be labeled
Press
or to select a channel.
DTV Signal
Dynamically display the DTV signal status.
31
USB Operation
1. After connecting a flash drive, press SOURCE button and select MEDIA. Press OK or to
enter.
2. Use or to select Photo or Music. Press OK or to enter.
3. Use or to navigate the files or folders on the USB drive.
4. Press MENU to return to the previous menu or press EXIT at any time to exit the setting.
Playback of music is via this music player,
which gives playback controls and information
on the file.
The music player plays MP3 audio format
files.
When viewing photos, you can use this photo
viewer tool to control slide show, play music
and show file information.
The photo viewer displays .jpg photo format
files.
32
Troubleshooting
Problem Solution/Issue
TV does not
operate
● Make sure the power cord is plugged in.
● Try another AC outlet.
● Power is off, check fuse or circuit breaker.
● Unplug unit for an hour, then plug it back in.
Normal
picture, but
no sound
● Check the volume settings.
● Sound muted? Press MUTE button.
● Try another channel.
● Check audio cable connections.
The remote
control does
not work
● Make sure the remote control is in range with no obstructions.
● Check the batteries.
● Correct operating mode set: TV, VCR etc.
Poor sound or
no sound
● Station or Cable TV experiencing problems, tune to another station.
● Check sound adjustments (Volume or Mute).
● Check for sources of possible interference.
Poor picture
or no picture
● Station or Cable TV experiencing problems, tune to another station.
● Make sure channels are set into memory.
● Check antenna or Cable TV connections, adjust antenna.
● Check for sources of possible interference.
● Check picture control adjustments.
Poor TV
reception
● Ensure the antenna amplifier is turned on for Antenna TV.
● Adjust the antenna position to a stronger signal receiving angle.
● Check if the Antenna connection is tight to the TV.
● Check if there is power supplied to the Antenna distribution box.
● Check if your incoming cable is connected to the correct cable / antenna
wall connection inside the RV.
● Ensure the internal RV coax jump cable is connected to the correct port.
Poor Cable /
Satellite TV
Reception
● Ensure antenna amp is turned off for cable signal.
● Check if incoming cable is connected correctly to RV.
● Ensure cable splitter box has power.
● Check if the incoming cable is connected to the correct cable / Satellite
wall connection inside your RV.
● Ensure the internal RV coax jump cable is connected to the correct port.
● Ensure Dish has no obstruction.
TV shuts off
● Sleep Timer is set.
● Power interrupted.
Black and
white image
from the
connected AV
device
● Check video connections on both the TV and connected AV device.
Ensure the colors match between the connectors and sockets: green(Y),
blue (Pb/Cb) and red (Pr/Cr) for component connection, and yellow
(VIDEO) for composite connection.
● Ensure all video cables are connected firmly.
33
Specifications
MODEL, DIMENSION & RESOLUTION
TV Model
Dimension without Stand
(L x H x W)
Max Resolution
FDUP43CBS
39 7 /8” x 23 7 /8 ” x 3 3 /4 ”
(1013 x 605 x 96 mm)
3840 x 2160@ 60Hz UHD
FDUF43CBS
FDUP49CBS
44 11/16” x 26 13/16” x 3 7/8 ”
(1135 x 680 x 98 mm)
FDUF49CBS
FDUP55CBS
50 3 /16” x 29 3 /4 ” x 4 3 /16”
(1274 x 756 x 105 mm)
FDUF55CBS
FDUP65CBS
59 1 /16” x 34 7 /8” x 3 7 /8 ’’
(1499 x 885 x 97 mm)
FDUF65CBS
INPUT & OUTPUT CONNECTIONS
Model
L-AUDIO
OUT-R
IR Ext
Coaxial
Out
L-AUDIO IN-R
Component
Video in
Component
YP
b
P
r
Video in
HDMI
in
RF in USB
FDUP43CBS
FDUP49CBS
FDUP55CBS
FDUP65CBS
FDUF43CBS
FDUF49CBS
FDUF55CBS
FDUF65CBS
1 x Left
(White)
1 x Right
(Red)
1 1
1 x Left (White)
1 x Right (Red)
1 x Green
3 1 2
1 x Blue
1 x Red
W
H
L
34
Specifications
16"
406.5 mm
815∕16"
226.5 mm
77∕8"
200 mm
71∕4"
178.5 mm
161∕16"
406.5 mm
77∕8"
200 mm
FDUP43CBS, FDUF43CBS
187∕16"
467.5 mm
67∕16"
164 mm
153∕4"
400 mm
49∕16"
116 mm
187∕16"
467.5 mm
77∕8"
200 mm
FDUP49CBS, FDUF49CBS
VESA MOUNTING PATTERN
Model Width mm Height mm Screw Size Quantity
FDUP43CBS
200 200
M6 * 15mm 4
FDUF43CBS
200 200
FDUP49CBS
200 400
FDUF49CBS
200 400
35
Specifications
171∕4"
437 mm
8"
203 mm
153∕4"
400 mm
6"
153 mm
171∕4"
437 mm
153∕4"
400 mm
FDUP55CBS, FDUF55CBS
215∕8"
549.5 mm
115∕16"
288 mm
153∕4"
400 mm
73∕4"
197 mm
215∕8"
549.5 mm
153∕4"
400 mm
FDUP65CBS, FDUF65CBS
VESA MOUNTING PATTERN
Model Width mm Height mm Screw Size Quantity
FDUP55CBS
400 400
M6 * 15mm 4
FDUF55CBS
400 400
FDUP65CBS
400 400
FDUF65CBS
400 400
36
Care and Clean
TV Cleaning
Remove any dirt and salt deposits from the unit, being careful to rinse the cloth frequently to
avoid scratching the TV or screen surface. Avoid using harsh chemicals, abrasives, or solvents
when cleaning any surface on the unit.
● If there is snow or ice on the TV surface, use a soft brush and towel to remove snow and
ice from the unit.
● Cleaning the LED panel: With your TV turned off, gently wipe the surface of the display
panel with a damp (with water) microfiber, cotton or flannel cloth. (Do not use tissues,
rags, sponges or paper towels because they may damage the screen and leave lint pieces
behind). If the LED panel is very dirty, you can mix equal parts of isopropyl alcohol and
distilled water in a clean spray bottle, spray the mixture onto the cloth (do not spray the
solution directly on the panel) and gently clean the panel.
● When the TV is not in use, keep it covered with the Furrion Weatherproof TV Cover.
The fitted cover is designed to protect the LED panel from the harmful UV rays from direct
sunlight, the ingress of water, and keeps wind-blown objects from scratching the surface of
the TV. To order a Furrion Weatherproof TV Cover, you can contact the authorized dealer
or buy from Furrion website.
IM-FHA00085 V1.0
Furrion Innovation Center & Institute of Technology
● 52567 Independence Ct., Elkhart, IN 46514, USA ● Toll free:1-800-789-3341
● Email: [email protected]
©2007-2021 Furrion Ltd. Furrion® and the Furrion logo are trademarks licensed for use
by Furrion Ltd. and registered in the U.S. and other countries.
For Patent Info: www.furrion.com/pages/patents
FURRION.COM
