Installation
Display
Before
1.To prevent damage to the door seal, ensure that the door is fully open before pulling out the
shelves to add or remove bottles.
2.For easier access to the contents of the shelves, slide the shelf out approximately one third of the
way.The shelves are, however, fitted with a stop to prevent the bottles falling out.
3. To remove or reposition the shelves, the side with the limiter will be facing the inside of the box,
one side of the shelf will be on the shelf strip, incline the shelf as indicated in the diagram more than
45°, then push or pull as required.
Shelf frame
Shelf
Limit
Shelves
This unit is designed for freestanding or built in installation but indoor use only.
The installation distance make sure to leave min.15mm space for back, 5mm space for each side
and top.
Installation
Display
31 Bottles
8
5
5
5
①
②
②
4
4
②
③
④
① ②
③ ④
