User Guide
Tapo Smart Wi-Fi Light Bulb
© 2023 TP-Link 1910013508 REV1.0.0
Contents
About This Guide ···················································· 1
Introduction ······························································· 2
Set Up Your Smart Bulb ······································· 3
Set Up via Matter ···················································· 5
Set Up via Matter Simple Setup ····················27
Basic Device Control ··········································31
Congure Your Smart Bulb ······························32
Smart Actions ·························································35
Share Your Smart Bulb ·······································37
Reset Your Smart Bulb ·······································38
Authentication ························································39
1
About This Guide
This guide provides a brief introduction to the Tapo Smart Wi-Fi Light Bulb and the Tapo app, as well as regulatory information.
Features available in Tapo may vary by model and software version. Tapo availability may also vary by region. All images, steps, and descriptions in this
guide are only examples and may not reect your actual Tapo experience.
Conventions
In this guide, the following convention is used:
Convention Description
Blue
Key information appears in teal, including management page text such as menus, items, buttons and so on.
Underline
Hyperlinks are in teal and underlined. You can click to redirect to a website.
Note:
Ignoring this type of note might result in a malfunction or damage to the device.
More Info
• Specications can be found on the product page at https://www.tapo.com.
• Our Technical Support and troubleshooting information can be found at https://www.tapo.com/support/.
• A Technical Community is provided for you to discuss our products at https://community.tp-link.com.
• Setup Video can be found at https://www.tp-link.com/support/setup-video/.
2
Introduction
The Tapo smart Wi-Fi light bulb is part of the Tapo smart home family of products, including plugs, switches, cameras and more. Smart Bulb lets you
easily control your lights via the Tapo app, no matter where you nd yourself. You can adjust brightness, set schedules and timers, and set an alarm that
wakes you naturally by simulating the sunrise. Group lights together to control your smart bulbs more easily.
Tapo L535 is Tapo's rst Matter-compatible high-lumen multicolor smart bulb that seamlessly integrates with certied smart home platforms, including
Apple Home, Amazon Alexa, Google Assistant, and Samsung SmartThings. No hub is required.
• Extra Bright Light - Brighten up your daily routine or activities with a 75W incandescent equivalent bulb.
• 16 Million Colors, Dimmable - With a wide range of colors and dimming capabilities, Tapo L535 oers endless lighting possibilities. Each color
displays vibrantly thanks to a high CRI.
• Matter Certied - Integrate Matter-certied Tapo devices with other Matter end products into your preferred ecosystem.
• Remote Control - Instantly turn the light on/o wherever you are through the Tapo app.
• Timer - Set a countdown timer to automatically turn the light on or o after a certain amount of time.
• Schedule - Use Schedules to set your light to automatically turn on and o.
• Preset for Convenience - Save and preset your favorite lightings for multiple scenarios.
• Away Mode - Set a period of time during which the light will be randomly turned on and o to make it look like you’re home.
• Sunrise and Sunset Mode - Automatically activate your bulb according to your time zone.
• Energy Saving - Reduces energy use by up to 87% without losing brightness compared to 75 W incandescent bulbs. Track real-time consumption
via the Tapo app.
• Restore Last Light State - The bulb automatically returns to its previous power-o state.
• Device Sharing - Invite your family members to manage the bulb together.
• Voice Control - Use Amazon Alexa, Google Assistant, and SmartThings to control your bulb with voice commands.
• No Hub Required - Connect to your existing Wi-Fi router.
3
Step 1. Download Tapo App
Get the Tapo app from the App Store or
Google Play, or by scanning the QR code
below.
Step 2. Log In
Open the app, and log in with your TP-Link ID. If you don't have an account, tap "Sign Up" to
create one rst.
Set Up Your Smart Bulb
Follow the steps below to get started with your new smart bulb.
4
Step 3. Add Your Smart Bulb
Tap the button in the app and select “Add Device”. Select "Lights" and then your model. Follow app instructions to set up your smart bulb,
and add it to your home network.
5
Set Up via Matter
This is a Matter-certied device. You can integrate it into any Matter ecosystem you prefer for easy control. As IoT manufacturers are working to
optimize the user experience of Matter setup, the setup process and user experience should improve over time. Take Alexa, Google, and Apple
ecosystems for example and the following shows you how to set up via Matter:
• Add to Alexa via Matter
• Add to Google via Matter
• Add to Apple via Matter
• Failed to Set Up via Matter?
Note:
1. The Matter setup code can only be used to add the device to the rst ecosystem. For the second commissioning, you will need to open the app of the rst
ecosystem to generate a new setup code. Please take a photo of the Matter setup code provided in the package as you will also need this code to set up if you do a
factory reset.
2. A Matter hub (i.e., controller) and smart home app of the same ecosystem are required.
More Information of Matter
• For matter setup guides for Alexa, Google and Apple, please refer to https://www.tp-link.com/support/faq/3564/
• For Matter setup troubleshooting, please refer to https://www.tp-link.com/support/faq/3574/
• For general questions and troubleshooting about Matter, please refer to https://www.tp-link.com/support/faq/3520/
• For the third-party setup video, please visit https://youtu.be/JS_7KmENSbo
• For Matter multi-admin setup and demo video, please visit https://youtu.be/C3t4kglK6tc
6
Before You Start
• Get a Matter Controller: This is needed to connect and manage Matter devices on your home network. For instance, Apple TV and HomePod are
examples of Matter controllers. For details, please refer to the Part 3. General Questions for TP-Link Matter-enabled Devices at https://www.tp-link.
com/support/faq/3520/
• Reset Your Device: It's important to start with a fresh device. Here's how:
- For most devices: Press and hold the 'Reset' button for 10 seconds.
- For smart bulbs: Turn the light switch o and on ve times, with a 2-second pause between each action.
• Connect to Wi-Fi: Connect your phone to the same Wi-Fi network as your Matter controller. Choose the 2.4 GHz network if 2.4 GHz and 5 GHz
networks are separate.
• Access Matter Setup Mode: This mode turns o 15 minutes after the device is powered up. To return to setup, simply turn your device o and then
back on.
• Locate Matter Setup Code: Look for a QR code or a numeric code on your device or in its packaging. Snap a picture of it for future reference.
• Regarding the Matter Code: The original Matter code can only be used for setup in one app (you can reuse it after a device reset). If you wish to set
it up in multiple apps, generate a new code using the rst app for all subsequent ones.
7
Add to Alexa via Matter
Before you start:
The pairing mode of your Matter-certied device will automatically turn o in 15 minutes. You can turn the pairing mode back on by powering o your
device, and then power it on.
Alexa will create the name according to the device type. Take L535E for example. The rst L535E paired with Alexa will be automatically named “First
Light.”
1. Check Compatibility (Click here for more information)
• Alexa app version: Update to the latest version
• Matter-supported Echo devices:
Device Version
Echo/Echo Dot 5th Gen: Echo Dot, Echo Dot (Gen 5 with Clock)
4th Gen: Echo, Echo Dot, Echo Dot (Gen 4 with Clock)
3rd Gen: Echo, Echo Dot, Echo Dot (Gen 3 with Clock)
Echo Show 3rd Gen: Echo Show 10, Echo Show 15
2nd Gen: Echo Show 8, Echo Show 5
1st Gen: Echo Show, Echo Show 8
Note: Please update the software of your Echo devices to a compatible version, such as v8289070468.
8
a. Launch the Alexa app and go to the Devices page.
b. Tap + and then tap Add Device to add a new device.
2. How to Set Up Your Matter Device
9
c. Choose Matter and then tap Next on the following pages. d. Tap Ye s on the conrming page.
10
e. Tap Scan QR Code and scan the QR Code.
Alternatively, you can tap Try Numeric Code Instead? to enter the numeric
setup code that comes along with your device.
f. Wait for your device to set up, then choose the Wi-Fi you want your
device to connect to and enter the corresponding Wi-Fi password.
11
g. Tap Done. Now you can nd your device on the Device list and use your
voice to control your device.
12
a. Launch your Alexa and go to the device Settings page.
b. Tap Other Assistants and Apps and then tap Add Another to create an
11-digit setup code.
3. How to Integrate Your Device into Another Ecosystem
As the setup code can only be used to add the device to the rst ecosystem, for the second commissioning, you need to open the app of the rst
ecosystem to generate a new setup code.
13
d. Launch the app of the second ecosystem. Follow the setup instruction
to enter the setup code and follow the app instructions to complete the
setup.
c. Copy the setup code.
14
Add to Google via Matter
1. Check Compatibility (Click here for more information)
• Google Home App: Update to the latest version
• Matter-supported Controller:
Device Version
Wi-Fi Routers Nest Wi-Fi Pro (Wi-Fi 6E)
Speakers Google Home, Google Home Mini, Nest Mini, Nest Audio
Displays Nest Hub (1st gen), Nest Hub (2nd gen), Nest Hub Max
Note: Please update the software/rmware of your controller devices to a compatible version, such as v1.56.324896 for Google Nest Hub (2nd gen).
Before you start:
The pairing mode of your Matter-certied device will automatically turn o in 15 minutes. You can turn the pairing mode back on by powering o your
device, and then power it on.
15
b. Choose Set up device and tap New Device to add a new device.a. Launch your Google Home App and tap +.
2. How to Set Up Your Matter Device
Note: The pairing mode of your Matter-certied device will automatically turn o in 15 minutes. You can turn the pairing mode back on by restarting your device.
16
c. Choose Matter and tap Yes on the conforming page. d. Scan the setup QR code on your device. If your device comes without
a QR code but a numeric code, you can tap Set up without QR code and
enter the numeric code.
17
f. Choose a location for your device and give it a name. Then you can nd
your device on the Device list and turn on/o your device on the Google
Home app or with Google assistants.
e. Tap Done when the device is connected.
18
a. Launch your Google Home app. Tap the gear button to go to the device
settings page.
b. Tap Linked Matter apps & services and then tap Link apps & services
to create an 11-digit setup code.
3. How to Integrate Your Device into Another Ecosystem
As the setup code can only be used to add the device to the rst ecosystem, for the second commissioning, you need to go to the app of the rst
ecosystem to generate a new setup code.
19
c. Tap Use pairing code.
If conditions permit, you can alternatively tap Share with QR code and you
should use the other mobile device to scan the newly-created pairing QR
code.
d. Tap Copy pairing code to copy the new code.
20
d. Launch the app of the second ecosystem. Follow the setup instruction
to enter the setup code and follow the app instructions to complete the
setup.
21
Add to Apple via Matter
1. Check Compatibility (Click here for more information)
• iOS system: Update to the latest version
• Matter-supported Controller: Home Pod, Home Pod mini, or Apple TV.
Note: Please update your iOS devices to iOS 16.2 or a later version. It is recommended to update your iOS to the latest version for better experience.
Before you start:
The pairing mode of your Matter-certied device will automatically turn o in 15 minutes. You can turn the pairing mode back on by powering o your
device, and then power it on.
22
b. Scan the setup QR code on your device.a. Launch your Home App. Tap + and then tap Add or Scan Accessory to
add a new device.
2. How to Set Up Your Matter Device
Note: The pairing mode of your Matter-certied device will automatically turn o in 15 minutes. You can turn the pairing mode back on by restarting your device.
23
d. Choose how your device will appear. Now you can check your device on
the Device list, turn on/o and dim your device on the Home app.
Here we use Tapo Plug as an example. The app page is subject to the actual display of
Apple Home.
c. Choose a location for your device and give it a name.
24
a. Launch your Home app and go to the Device Settings page. b. Scroll down, tap Turn On Pairing Mode and then Copy Code.
3. How to Integrate Your Device into Another Ecosystem
As the setup code can only be used to add the device to the rst ecosystem, for the second commissioning, you need to go to the app of the rst
ecosystem to generate a new setup code.
25
c. Launch the app of the second ecosystem. Follow the setup instruction
to enter the setup code and follow the app instructions to complete the
setup.
26
Failed to Set Up via Matter?
Refer to the following and you can resolve most setup issues.
1. Update Firmware: Make sure the rmware of your Matter hub and Smart Home app is updated to support Matter.
2. Restart: Try turning o and then turning back on your device and the controller. Restart your smartphone and clear the cache of the
smart home app.
3. Check IPv6: Ensure that IPv6 is activated on your router. Visit our FAQ for step-by-step guidance at https://www.tp-link.com/support/
faq/1525/
4. Enable Setup Mode: Restart your device to re-enter setup mode since Bluetooth should be turned o 15 minutes after the device is
powered up.
5. Regarding the Matter Code: The original Matter code can only be used for setup in one app (you can reuse it after a device reset). If you
wish to set it up in multiple apps, generate a new code using the rst app for all subsequent ones.
6. Stay on the Code-Generating Page: Do not close the pairing code-generating page in the multi-admin setup. Otherwise, this may
lead to exiting the setup mode. If you accidentally close the page after generating the pairing code before adding the device to another
ecosystem, you can try to reopen it. If the reopening fails, it is recommended to restart the device and try to generate the pairing code
again.
7. Factory Reset Your Device: If the LED is blue but the setup failed, try to factory reset the device. For most devices: Press and hold the
'Reset' button for 10 seconds. For smart bulbs: Turn the light switch o and on ve times, with a 1-second pause between each action.
8. If the Matter-enabled device has already been added to another ecosystem, you will need to get a new setup code for pairing according
to FAQ how to integrate your device into another ecosystem.
If the above steps did not help solve your problem, it’s recommended that you try to factory reset the Matter-enabled device or use
another smartphone to congure it. For more information, please refer to https://www.tp-link.com/support/faq/3574/
27
Set Up via Amazon Matter Simple Setup
What is Amazon Matter Simple Setup?
Amazon Matter Simple Setup can help connect and set up Tapo smart devices in fewer steps, without having to remember and re-enter your Wi-Fi
password on each device.
To use this feature, conrm the following:
● The device is purchased from Amazon and tick "Link to your Alexa account and to Tapo to simplify setup" during purchase.
● The new Tapo device supports MSS (short for Matter Simple Setup).
● You have an MSS enabled Alexa device or router.
● You have saved your Wi-Fi information to Amazon by using Alexa echo.
● Your Tapo device and router are on the same network as your Alexa echo.
LED Indications during Matter Simple Setup
LED Status
Solid white Ready for setup
Blinking white twice MSS setup in progress
Blinking white three times
MSS setup failed and you can manually
set up the bulb from the app manually
How to add the Tapo device manually:
Open the Tapo app, tap the + button on the page, select your device model, and follow the app instructions to complete setup.
28
1. Open the Amazon Alexa app. Then tap More and select Skills &
Games.
How to use Matter Simple Setup with Tapo devices
2. Enter Tapo in the search bar and choose Tapo.
29
3. Tap the ENABLE TO USE button.
4. Log in with your TP-Link ID that has bound to your Tapo device, and tap Authorize. After authorized
successfully, the message Tapo has been successfully linked will come up.
30
5. Power up your Tapo device and the setup will complete automatically in two minutes.
For setting up more Tapo devices, just power up and enjoy!
Done!
If this device displays on the Home page in the Tapo app, it indicates this device has been successfully associated with your Amazon account and
joined your Wi-Fi network automatically.
If this device does not display on the Home page in the Tapo app, try setting it up manually. (Tap the + button on the page, select your device model,
and then follow the app instructions to complete setup.)
31
Basic Device Control
After successfully setting up your smart bulb, you will see the home page of the Tapo app. Here you can view the status of all devices that you've added
and manage them. You can tap on the device to control and manage.
Home Page
You can turn on or o the bulb any time
anywhere and tap the bulb card to enter the
status page.
Device Status Page
You can adjust colors and temperature, enjoy
main features to control your device, and view its
runtime & energy usage.
Device Settings Page
You can edit the basic information, set Last On
State, enable gentle on/o, add a group, update
rmware and more.
32
Congure Your Smart Bulb
You can conure your smart bulb by adjust lighting settings and setting Themes, Presets, Auto White, Schedule, Timer, Away Mode and more.
Turn On/O
Tap the power button to turn the bulb on
or o.
Set Presets
With Presets, you can quickly apply your favourite
preset at one tap. To edit preset, just select one
and tap edit.
Enable Auto White
Tap A under “My Presets” to select a lighting
option (Auto Compensate or Auto Match) for
your bulb. And the bulb will follow the color and
brightness of the sun throughout the day.
33
Main Features
On the device status page, you can use the
Theme, Schedule, Timer, and Away Mode
features.
Set Theme
Tap Theme to apply theme to your bulb to t
your home atmosphere. You can custom shift
style, speed, and color cycle yourself.
Set Schedule
Tap Schedule to add a schedule for your bulb
to automatically turn on/o and adjust the
lighting settings to simplify your daily routine.
34
Set Timer
Tap Timer to set the timer and lighting settings,
then your bulb will automatically turn on with the
specic settings after the timer ends.
Set Away Mode
Tap Away to preset the Away Mode, set the start
and end time, then your bulb will be randomly
turned on/o during this period.
Check Runtime & Energy Usage
Slide up to check your bulb's Runtime and
Energy Usage today, past 7 days or past 30
days.
35
Option 1: Edit based on the featured actions
1. Go to the Smart Actions page and you will see the
Featured Actions (Shortcut or Automation).
2. Tap on a featured action. Tap EDIT to change the settings as needed and tap APPLY
to save changes.
Smart Actions
Smart Actions automate repetitive tasks, allowing you to blaze through tedium with utmost ease. Set everything up once and never have to worry about
it again. With Smart Actions, giving your home that level of intelligence is a snap. Shortcut lets you perform an action with a simple tap. Automation
allows you to automate tasks to be performed at a set time. e.g. The light will light on at sunset.
36
Option 2: Create your own smart actions
1. Go to Smart page. Tap + on the top right to add a simple
and smart action.
2. For Shorcuts: Tap + to add action like turning on the smart bulb.
For Automation: Tap + to add triggers (When) like the trigger time, and tap + to add
action (Then) like turning on the smart bulb.
37
Method 1
On the home page, long press the bulb card
and tap Share.
Method 2
Go to Device Status page, slide up and tap
Device Sharing.
Method 3
Go to Me page and tap Device Sharing
to view your shared devices and devices
shared from others.
Share Your Smart Bulb
You can invite your family members to manage your Tapo devices together by entering the TP-Link ID (email) you want to share the devices with.
38
Reset Your Smart Bulb
There are two types of reset available: a soft reset which resets the Wi-Fi settings only, and a factory reset that erases all of your custom settings and
restore them to factory defaults.
Soft Reset (without losing the conguration settings except Wi-Fi)
1. Turn the light switch controlling the smart bulb to the on position rst.
2. Switch it o and on 3 times, pausing for two seconds in between.
3. Wait for about 4 seconds and the smart bulb should blink 3 times, which indicates a successful soft reset.
Factory Reset (back to factory default settings)
Method 1
1. Turn the light switch controlling the smart bulb to the on position rst.
2. Switch it o and on 5 times, pausing for two seconds in between.
3. Wait for about 4 seconds and the smart bulb should blink 3 times, which indicates a successful soft reset.
Method 2
On the home page in Tapo app, long press the card and tap Remove.
Go to bulb's Settings page and tap REMOVE at the bottom.
OR
39
Authentication
FCC Compliance Information Statement
Product Name: Tapo Smart Wi-Fi Light Bulb, Multicolor
Model Number: Tapo L535E/TL135E
Responsible party:
TP-Link USA Corporation
Address: 10 Mauchly, Irvine, CA 92618
Website: http://www.tp-link.com/us/
Tel: +1 626 333 0234
Fax: +1 909 527 6804
E-mail: [email protected]om
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Increase the separation between the equipment and receiver.
• Reorient or relocate the receiving antenna.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/ TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
40
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired operation.
Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the
equipment.
Note: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications
could void the user’s authority to operate the equipment.
FCC RF Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This device and its antenna must not be
co-located or operating in conjunction with any other antenna or transmitter.
“To comply with FCC RF exposure compliance requirements, this grant is applicable to only Mobile Configurations. The antennas used for this
transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction
with any other antenna or transmitter.”
We, TP-Link USA Corporation, has determined that the equipment shown as above has been shown to comply with the applicable technical standards,
FCC part 15. There is no unauthorized change is made in the equipment and the equipment is properly maintained and operated.
Issue Date: 2023.9.11
41
CE Mark Warning
This is a class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take
adequate measures.
Operating Frequency
2400 MHz -2483.5 MHz (20dBm)
EU declaration of conformity
TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant provisions of directives 2014/53/EU,
2009/125/EC, 2011/65/EU, and (EU)2015/863.
The original EU declaration of conformity may be found at https://www.tapo.com/support/ce/
RF Exposure Information
This device meets the EU requirements (2014/53/EU Article 3.1a) on the limitation of exposure of the general public to electromagnetic fields by way
of health protection.
The device complies with RF specifications when the device used at 20 cm from your body.
Restricted to indoor use.
UK declaration of conformity
TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant provisions of the Radio Equipment
Regulations 2017.
The original UK declaration of conformity may be found at https://www.tapo.com/support/ukca/
Продукт сертифіковано згідно с правилами системи УкрСЕПРО на відповідність вимогам нормативних документів та вимогам,
42
що передбачені чинними законодавчими актами України.
Canadian Compliance Statement
This device complies with Industry Canada license-exempt RSSs. Operation is subject to the following two conditions:
1 ) This device may not cause interference, and
2 ) This device must accept any interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux
deux conditions suivantes :
1 ) l’appareil ne doit pas produire de brouillage;
2 ) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, meme si le brouillage est susceptible d’en compromettre le
fonctionnement.
Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated
with minimum distance 20cm between the radiator & your body.
Déclaration d’exposition aux radiations:
Cet équipement est conforme aux limites d’exposition aux rayonnements IC établies pour un environnement non contrôlé. Cet équipement doit être
installé et utilisé avec un minimum de 20 cm de distance entre la source de rayonnement et votre corps.
Industry Canada Statement
CAN ICES-3 (B)/NMB-3(B)
CAN ICES-005(B)/NMB-005(B)
NCC Notice
注意！
取得審驗證明之低功率射頻器材，非經核准，公司、商號或使用者均不得擅自變更頻率、加大功率或變更原設計之特性及功能。
43
低功率射頻器材之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停用，並改善至無干擾時方得繼續使用。
前述合法通信，指依電信管理法規定作業之無線電通信。
低功率射頻器材須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。
BSMI Notice
安全諮詢及注意事項
• 請使用原裝電源供應器或只能按照本產品注明的電源類型使用本產品。
• 清潔本產品之前請先拔掉電源線。請勿使用液體、噴霧清潔劑或濕布進行清潔。
• 注意防潮，請勿將水或其他液體潑灑到本產品上。
• 插槽與開口供通風使用，以確保本產品的操作可靠並防止過熱，請勿堵塞或覆蓋開口。
• 請勿將本產品置放於靠近熱源的地方。除非有正常的通風，否則不可放在密閉位置中。
• 不要私自拆開機殼或自行維修，如產品有故障請與原廠或代理商聯繫。
限用物質含有情況標示聲明書
設備名稱：Tapo Smart Wi-Fi Light Bulb, Multicolor
Equipment name
型號（型式）：Tapo L535E/Tapo L535B/TL135E
Type designation (Type)
單元
Unit
限用物質及其化學符號
Restricted substances and its chemical symbols
鉛
Lead
(Pb)
汞
Mercury
(Hg)
鎘
Cadmium
(Cd)
六價鉻
Hexavalent
chromium
(Cr
+6
)
多溴聯苯
Polybrominated
biphenyls
(PBB)
多溴二苯醚
Polybrominated diphenyl ethers
(PBDE)
PCB ○ ○ ○ ○ ○ ○
外殼 ○ ○ ○ ○ ○ ○
電源供應板 − ○ ○ ○ ○ ○
其他及其配件 − ○ ○ ○ ○ ○
44
備考1.〝超出0.1 wt %〞及〝超出0.01 wt %〞係指限用物質之百分比含量超出百分比含量基準值
Note 1：“Exceeding 0.1 wt %” and “exceeding 0.01 wt %” indicate that the percentage content of the restricted substance exceeds the reference
percentage value of presence condition.
備考2.〝○〞係指該項限用物質之百分比含量未超出百分比含量基準值。
Note 2：“○” indicates that the percentage content of the restricted substance does not exceed the percentage of reference value of presence.
備考3.〝−〞係指該項限用物質為排除項目。
Note 3：The “−” indicates that the restricted substance corresponds to the exemption.
Safety Information
• Keep the device away from water, fire, humidity or hot environments.
• Do not attempt to disassemble, repair, or modify the device.
• Do not use the device where wireless devices are not allowed.
• Only use the control provided with or specified by these instructions to control this device.
• For lamps with a weight significantly higher than that of the lamps for which they are a replacement, attention should be drawn to the fact that the
increased weight may reduce the mechanical stability of certain luminaires and lampholders and may impair contact making and lamp retention.
WARNING:
• RISK OF ELECTRIC SHOCK OR BURNS. Switch OFF the light switch controlling the bulb and WAIT for the bulb to cool down before attempting to
change it.
• Do not install the Smart Bulb with wet hands or when standing on wet or damp surfaces.
• Compatible with regular light switches. Not suitable for use with standard in-wall dimmers. Not compatible with photosensors, motion sensors, or
timers. Dimmable via the app only.
• NOT for use in totally enclosed or recessed luminaires. Suitable for damp locations.
• NOT FOR EMERGENCY LIGHTING.
• The increased weight may reduce the mechanical stability of certain luminaires and lampholders and may impair contact making and lamp retention.
• Please read and follow the above safety information when operating the device. We cannot guarantee that no accidents or damage will occur due
to improper use of the device. Please use this product with care and operate at your own risk.
• Operating Temperature: 0℃~40℃(32℉~104℉)
45
• Storage Temperature: -20℃~70℃(-4℉-158℉)
• Operating Humidity: 10%~90%RH, Non-condensing
• Storage Humidity: 10%~90%RH, Non-condensing
Explanation of the symbols on the product label
Symbols may vary from products
Symbol Explanation
Class II equipment
Class II equipment with functional earthing
Dimming not allowed
Lamp not suitable for use under moisture
Alternating current
DC voltage
Polarity of output terminals
Indoor use only
Dangerous voltage
Caution, risk of electric shock
46
Symbol Explanation
Energy efficiency Marking
Protective earth
Earth
Frame or chassis
Functional earthing
Caution, hot surface
Caution
Operator’s manual
Stand-by
“ON”/”OFF” (push-push)
Fuse
Fuse is used in neutral N
47
Symbol Explanation
RECYCLING
This product bears the selective sorting symbol for Waste electrical and electronic equipment (WEEE). This means
that this product must be handled pursuant to European directive 2012/19/EU in order to be recycled or dismantled to
minimize its impact on the environment.
User has the choice to give his product to a competent recycling organization or to the retailer when he buys a new
electrical or electronic equipment.
Caution, avoid listening at high volume levels for long periods
Disconnection, all power plugs
m Switch of mini-gap construction
µ
Switch of micro-gap construction (for US version)
Switch of micro-gap / micro-disconnection construction (for other versions except US)
ε Switch without contact gap (Semiconductor switching device)
