Printing a Mounting Template
Notice
It is not recommended that you print a mounting template on your own. Use the template that came in the product box.
If you do print the template, you must follow these instructions for printing a mounting template precisely. To print large templates,
you need large enough paper and printer. Failure to have the correct sized paper and printer, or a failure to follow these instructions,
may result in an incorrectly sized template and therefore an incorrect cutout (too large or too small) on the mounting surface of your
boat.
1
Select File > Print.
➋
➌
➍
➎
➊
2
Select None for Page Scaling ➊.
3
Ensure the check mark is next to Auto-Rotate and Center ➋.
4
Drag the arrow ➌ to the right, to view page 2 in the window below.
4
Verify that the paper size is larger than the template ➍.
In this example, the paper is not larger than the template.
5
If the paper size is not large enough, select Properties ➎ and select a Page Size that is larger than the template.
Notice
Fusion is not responsible for any damages or expenses resulting from a miscut mounting surface arising from a failure to follow
these instructions.
MS-NRX300
April 2016 Printed in Taiwan 190-02022-04_0A
Max. Ø
