BJP18100 BALL JOINT PRESS APPLICATION CHART
©2017 Matco Tools. 1703203 All Rights Reserved Matco Tools
®
and their respective logos are trademarks
or registered trademarks of Matco Tools Corporation in the United States and in other countries.
Service. TruST. reSulTS
®
bjp18100
bALL jOINT pRESS
A
1.0 L
Pusher
A
1.5 L
Pusher
B
1.78 D
Installer Cup
C
2.0 D
Installer Cup
D
2.14 D
Installer Cup
E
2.22 D
Installer Cup
F
2.3 D
Receiver Cup
G
2.44 D
Receiver Cup
H
2.6 D
Receiver Cup
I
2.6 D
Receiver Cup
18100-7B
Cup Adapter
Open
18100-7A
Cup Adapter
Closed
Ford
2010-2016
250/350
Remove
LP UP UR LR
Install
UI LI UR LR
2017-2017
250/350
Remove
LP UP UR LR
Install
UI LI UR LR
2015-2017
450/550
Remove
LP UP UR LR
Install
LI UR LI LR
DODGE
2000-2013
2500/3500
Remove
UP LP UR LR
Install
UI LI UR LR
2014-2017
2500/3500
Remove
UP LP UR LR
Install
UI LI UR LR
GM
2007-2012 4500/5500
KODIAK/TOPKICK GMT
Remove
LP UR LR
Install
UI UR LI LR
U - Upper Joint
L - Lower Joint
P - Removal Pusher
I - Installer Pusher
R - Receiver Cup
