OPERATION
DRYING
CHANGING THE PROGRAMME SEQUENCE
Before commissioning the tumble
dryer for the first time, make sure it has
been installed correctly. Connect it
correctly.
Please read the separate operating
instructions supplied with the appliance.
Risk of damage due to incorrect use
or operation.
This tumble dryer contains a refrigerant
that is flammable and explosive.
It is essential to read the separate
operating instructions.
Damage caused by switching the
appliance on too soon.
The heat pump can be damaged.
After setting up the tumble dryer, wait
for at least one hour before starting a
drying programme.
Switching on the tumble dryer
Turn the programme selector to a
programme.
The tumble dryer is switched on by
selecting a programme and switched off
by turning the programme selector to
theposition.
Operating the sensors
The , , and sensors control the
options located above them. The sensors
react to fingertip contact.
a
sensor (drying level)
For selecting the drying level.
b
PerfectDry indicator
For programmes with drying levels.
c
sensor (Gentletumble)
For temperature-sensitive fabrics with
the symbol.
d
sensor (Delay start or time)
– To activate Delay start: then
lights up.
– If Warm air/DryFresh is selected,
you can select the programme
duration. This programme cannot
be used with the Delay start
function.
e
Indicator lights
– Empty the condensed water
container
– Clean the fluff and plinth filters
f
sensor (Start/Add laundry)
– Touching the sensor starts the
selected programme. Start/Add
laundry will light up constantly in
the display.
– Once the programme has been
started, the sensor allows you
to add laundry.
g
Time display
The remaining programme running
time is displayed in hours and
minutes.
h
Optical interface
For service technicians.
i
Programme selector
The programme selector can be turned
clockwise and anti-clockwise.
Energy savings
There are various steps you can take to
avoid unnecessarily long drying times and
high energy consumption:
- Make sure your laundry is spun at the
maximum spin speed before drying.
- Load according to the optimum amount
of laundry recommended for the drying
programme. This will mean that the
energy consumption for the amount of
laundry is the most economical.
- Make sure the room temperature is not
too high.
If there are other heat producing
appliances in the room in which the
tumble dryer is located, make sure the
room is well ventilated and switch the
other appliances off if possible.
- Clean the fluff filters after every drying
cycle.
Preparing the laundry
Damage due to foreign objects which were not
removed from the laundry.
Foreign objects can melt, burn, or explode.
Remove foreign objects (e.g. detergent dispensing
balls, loose bra hangers, lighters and all objects) from
the laundry.
Fasten duvet covers and pillow cases to prevent small
items from being rolled up inside them.
Loading the tumble dryer
Do not overload the drum. Overloading can give a
disappointing drying result and cause unnecessary
wear and tear to the laundry. It can also cause more
creasing.
Loosen the laundry.
Open the tumble dryer door.
Check that the drum is empty.
Load the laundry in the drum.
Insert the fragrance flacon.
If you are drying without a
fragrance flacon, close the
socket. Push the tab on the
cover to the bottom (see arrow).
Shut the door with a gentle
swing.
Risk of damage to laundry.
When closing the door, make
sure that laundry does not get
trapped in the door opening.
1
Condensed water container
2
Door
3
Control panel
4
Plinth filter access panel
5
Cold air intake grille
1. Selecting a programme
Turn the programme selector.
- The interior drum lighting will come on.
- A suggested drying level may also light up brightly and
durations will appear.
2. Selecting programme settings
Selecting the drying level
Drying levels can be selected for certain programmes as
per the “Programme chart”.
Touch the sensor control.
Touch the sensor control repeatedly until you get to
the required drying level. Once selected, it will light up
brightly.
Selecting the programme duration
Applies only to Warm air/DryFresh.
Touch the sensor repeatedly until the required
programme duration lights up.
You can set the duration in 10-minute increments from
20 minutes to 2 hours.
Selecting Gentletumble
Sensitive textiles with care symbol , e.g.
made of acrylic, are dried gently.
Touch the sensor repeatedly until
Gentletumble lights up.
In some programmes, Gentle tumble is
switched on and cannot be deselected.
Selecting Delay start
With Delay start you can delay the start of
a programme. The start of the programme
can be delayed from 30 minutes up to a
maximum of 24 hours.
Touch the sensor repeatedly until the
required Delay start time lights up in
the time display.
The symbol lights up brightly and the
first 30minutes of the Delay start time
appear in the time display.
3. Starting the programme
Start/Add laundry flashes on and off in
the display.
Touch the sensor.
Start/add laundry lights up in the display
and the programme starts. When Delay
start is being used, the programme
duration will appear after the Delay start
time has elapsed.
Adding or removing laundry
You have forgotten an item of laundry, but
the programme has already started.
Touch the sensor.
* will light up in the time display.
Open the tumble dryer door.
Add or remove laundry.
Close the door.
Touch the sensor.
The programme will start.
*Exceptions
In some cases – for example, during the
cooling phase or the Proofingprogramme
– it is not possible to add laundry items.
does not light up in this case.
Cancelling the current programme
You cannot change to another programme
once a programme has started. This
prevents the appliance being operated
unintentionally.
If you adjust the programme selector, the
symbol will light up in the time display.
This indicator goes out when you select
the original programme.
Turn the programme selector to the
position.
The programme is cancelled. You can now
select a new programme.
At the end of the programme
End of programme: lights up and
Start/Add laundry goes out.
- 10minutes after the end of the
programme Start/Add laundry will begin
to flash slowly and the display will go
out.
- The tumble dryer switches off
automatically.
Do not open the tumble dryer door
before the end of the programme.
Open the door.
Remove the laundry.
Items left in the dryer could be damaged
by overdrying when the dryer is used the
next time.
Always remove all items from the drum.
If the dryer is switched on and the door is
opened, the drum lighting will come on.
The drum lighting will go out after a few
minutes to save energy.
Turn the programme selector to .
Clean the fluff filters.
Close the drum door.
Empty the condensed water container.
Emptying the condensed water
container
Empty the condensed water container
after every drying programme.
The indicator light will light up if the
maximum level of the condensed water
container is reached.
Open and close the door to deactivate
this message.
Pull out the
condensed water
container.
To prevent water running out, hold the
condensed water container by the front
panel and at the back to keep it in a
horizontal position.
Empty the
container.
Replace the
container in the
dryer.
Useful tip: You can use a fragrance
flacon to give your laundry a pleasant
fragrance.
Before using a fragrance flacon, please
read "Warning and Safety instructions -
Using a fragrance flacon (optional
accessory)" and "Fragrance flacon" in
the operating instructions.
Inserting a fragrance flacon
1. 2.
3. 4.
Marker must be in position .
5. 6.
Turn the outer ring clockwise a little.
Marker must be in position .
Setting the fragrance intensity
The further you
turn the outer
ring of the
fragrance flacon
clockwise, the
more intense the
fragrance.
Closing the fragrance flacon
Turn the outer
ring anti-
clockwise until
marker is in
position .
Removing the fragrance flacon
Turn the outer
ring until marker
is in position
.
Remove the fragrance flacon.
To prevent any fragrance running out of
the flacon, do not lay it down on any
surface.
Only store the fragrance flacon in its
original packaging.
Using for the first time Operation Drying End of the programme FragranceDos
fold here fold here fold here fold here fold here fold here
en-AU, NZ
M.-Nr. 12 708 710
T1
fold here fold here fold here fold here fold here fold here
PROGRAMME CHART
CLEANING AND CARE
PROBLEM SOLVING GUIDE
Programme overview Cleaning and care Problem solving guide
Programme Load (weight
of dry
laundry)
Items
Extra dry
Cupboard Dry
Hand iron+
Hand iron
Gentle tumble
ECO 8kg Cotton items such as those described under Cottons Cupboard Dry with
normal residual moisture.
— X — — —
Cottons 8 kg Towelling, jersey wear, T-shirts, underwear, baby clothes, workwear,
covers, jackets, bathrobes, and flannelette bed linen.
Do not use Extra dry for jersey fabrics (e.g. T-shirts, underwear, baby
clothes), as they have a tendency to shrink.
Select programme Cottons Extra dry for testing in accordance with AS/
NZS 2442.1 & AS/NZS 2442.2.
X X X X X
Minimum iron 4 kg Workwear, overalls, pullovers, dresses, trousers, leggings and table linen. — X X — X
Delicates 2.5 kg Shirts, blouses, lingerie, appliquéd garments. — X X — X
Woollens handcare 2 kg Pullovers, knitted jackets, socks, stockings. — — — — —
Shirts 2 kg Shirts and blouses. — X X — X
Express 4 kg Garments suitable for the Cottons programme. X X X X —
Denim 3 kg Denim garments, e.g., jackets, jeans, shirts, and skirts. — X X — X
Bed linen. 4 kg Bed linen X X X X —
Proofing 2.5 kg Microfibre fabric, skiwear, outerwear, fine close weave cotton garments
(poplin), tablecloths.
Risk of fire! Do not use proofing agents containing paraffin.
— X — — —
Pre-ironing 1 kg Cotton trousers, anoraks, shirts. — X X — X
Warm air/DryFresh 8kg - Warm air (for drying): thick and multi-layered jackets, pillows, sleeping
bags, blankets.
- DryFresh (for freshening up): all fabrics.
– Use DryFresh fragrance flacon.
– Reduce the load size.
– Select min. 60minutes.
— — — — X
X = Yes, – = No
Care symbols
Drying Ironing
Normal/Higher temperature Very hot
Reduced temperature (for delicate fabrics): select Gentle tumble Hot
Do not tumble dry Warm
— — Do not treat with heat
Fluff filters
Removing visible fluff
Clean the 2 fluff filters in the door opening
at the end of every programme.
Remove the fragrance flacon.
Pull the upper
fluff filter
forwards to
remove it.
Use your fingers
or a vacuum
cleaner to remove
the fluff from the
surface of the
filter.
Use your fingers
or a vacuum
cleaner to remove
the fluff from the
surface of the
filter.
Push the upper fluff filter back in until it
clicks into position.
Close the door.
Cleaning the fluff filters and air flow
openings thoroughly
If the drying duration has become longer
or the surface of the filters is visibly
compacted with fluff, you should carry
out the following cleaning procedure.
Pull the upper fluff filter forwards to
remove it.
Turn the yellow
dial on the lower
fluff filter in the
direction of the
arrow (until you
hear it click).
Hold the dial and
pull the fluff filter
forwards to
remove it.
Use a vacuum
cleaner with a
long crevice
nozzle attached
to remove any
visible fluff from
the upper air flow
openings.
Flush the fluff filters through with warm
running water.
Shake the fluff filters thoroughly and
then dry them carefully.
Ensure the filters are dry before replacing
them. Wet filters could cause
operational faults.
Refit all of the fluff filters and close the
door.
Plinth filter
Clean the plinth filter when the
programme duration is longer than usual
or whenever the indicator light comes
on.
Open and close the door to clear the
message.
Open the flap.
Pull the plinth
filter out by the
handle.
When the plinth filter is pulled out, the
right guide pin will slide out. The guide pin
prevents the flap from being closed
without the plinth filter in place.
Pull the handle
out of the plinth
filter.
Clean the plinth filter thoroughly under
running water.
Squeeze the plinth filter carefully
several times as you rinse it.
Rinse the plinth filter until all visible
residues have been removed.
Use a damp cloth
to remove any
fluff.
Refitting the plinth filter
Fit the plinth filter
back on the
handle the right
way round.
Push the plinth
filter in
completely.
Insert the right
guide pin at the
same time.
Close the panel.
Problem Possible cause and remedy
lights up after a
programme has been
cancelled.
The condensed water container is full or there is a kink in
the drain hose.
Open and close the door with the tumble dryer
switched on to clear the fault.
Empty the condensed water container.
Check the drain hose.
See “Cleaning and care” in the operating instructions.
lights up at the end of a
programme.
There is a build-up of fluff.
Open and close the door with the tumble dryer
switched on to clear the fault.
Clean the fluff filter.
Clean the plinth filter.
lights up and
flashes; the programme is
cancelled.
There is a very significant build-up of fluff.
Switch the tumble dryer off to deactivate the message.
Clean the fluff filter.
Clean the plinth filter.
lights up. The programme selector has been moved.
Select the original programme again. The time
remaining will appear in the display.
Bars flash in the display at
the end of a programme:
………
The laundry is cooled down at the end of the programme.
Either remove the laundry and spread it out to cool
down or leave it in the tumble dryer to cool down during
the cooling phase.
flashes/lights up
after the tumble dryer is
switched on and a
programme cannot be
selected.
Access via a code has been activated.
You must enter the correct PIN code to use the tumble
dryer. See “Programmable functions” in the operating
instructions.
Problem Possible cause and remedy
The display is dark and the
Start/Add laundry sensor
is flashing slowly.
This is not a fault, but a normal function.
Touch a sensor to switch on the indicators.
The dryer is switched off
at the end of the
programme.
The tumble dryer switches off automatically. This is not a
fault, but a normal function.
The laundry is not
sufficiently dry.
The load consisted of different types of fabric.
Finish drying using the Warm air/DryFresh programme.
Select a more suitable programme next time.
Items made of synthetic
fibres are charged with
static electricity after
drying.
Items made of synthetic fibre can become charged with
static electricity in the tumble dryer.
Static charge can be reduced by adding fabric softener
to the final rinse in the washing programme.
There is a build-up of fluff. Fluff is principally the result of friction when garments are
being worn and to some extent when they are being
washed. Tumble drying hardly causes any fluff to form.
Fluff is collected by the fluff filters and the plinth filter.
See “Cleaning and care” in the operating instructions.
There are operating noises
(whirring/humming).
This is not a fault.
The compressor (heat pump) is operating.
No action is required.
Quick Start Guide
Heat pump tumble dryer
These short instructions are not a substitute for the operating instructions supplied
with the appliance. Please read the operating instructions supplied with your tumble
dryer before using it for the first time and take note of the Warning and Safety
instructions, as well as the full descriptions on how to use your appliance.
en-AU, NZ
M.-Nr. 12 708 710 / 00
fold here fold here fold here fold here fold here fold here
