A5P | 01
3500341
Please read all instructions carefully before use and
retain for future reference.
CAUTION Do not immerse in water.
Protect your eyes.
Protect your ears.
Protect your hands.
Wear a dust mask.
Protective clothing must be worn
Do not use in wet conditions.
CAUTION Sharp edges.
Manufactured and sold under licence
A5P | 01
Please read all instructions carefully before use and retain
for future reference.
INTENDED USE Only operate the power tool/machine
for its intended purpose and within the parameters spec-
ied in this manual.
This power tool/machine is for domestic use only. This
power tool/machine is not intended for use by persons
with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless supervised or
given appropriate instruction concerning the product’s
use by a person responsible for their safety.
GENERAL PRECAUTION Do not allow to be used as a
toy. Children should be supervised to ensure they do not
play with the power tool/machine.
If the power tool/machine is not functioning properly,
has been dropped, damaged, left outdoors, or immersed
in liquid, do not use, contact DOMU Brands Customer
Services.
Do not use the power tool/machine if any parts appear to
be faulty, missing or damaged.
Ensure all parts are securely attached before use.
RISK OF PERSONAL INJURY Avoid body contact with
earthed or grounded surfaces such as pipes,radiators,
ranges and refrigerators. There is an increased risk of
electric shock if your
body is earthed or grounded.
Prevent unintentional starting. Ensure the switch is in the
o position before connecting to the power source and/
or battery pack, picking up or carrying the tool. Carrying
power tools with your nger on the switch, or energising
power tools that are switched on, invites accidents.
Do not operate power tools in explosive atmospheres
such as in the presence of ammable liquids, gases or
dust. Power tools create sparks which may ignite the
dust or fumes.
Always wear eye protection. Any power tool can throw
foreign objects into your eyes and cause permanent
eye damage. Always wear safety goggles (not glasses)
that comply with ANSI safety standard Z87.1. Every day
glasses have only impact resistant lenses.
Do not expose power tools to rain or wet conditions.
Water entering the power tools will increase the risk of
electric shock.
Stay alert, watch what you are doing and use common
sense when operating a power tool/machine. Do not use
a power tool/machine while you are tired or under the
inuence of drugs, alcohol or medication. A moment of
inattention while operating power tool/machine may re-
sult in serious personal injury.
Use personal protective equipment. Always wear eye
protection. Protective equipment such as dust mask,
non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce
personal injuries.
Prevent unintentional starting. Ensure the switch is in the
o-position before connecting to power source and/or
battery pack, picking up or carrying the tool.
Carrying power tool/machine with your nger on the
switch or energizing power tool/machine that have the
switch on invites accidents.
Remove any adjusting key or spanner before turning the
power tool/machine on. A spanner or a key left attached
to a rotating part of the power tool/machine may result in
personal injury.
Do not overreach. Keep proper footing and balance at
all times. This enables better control of the power tool/
machine in unexpected situations.
Dress appropriately. Do not wear loose clothing or jew-
ellery.
Keep your hair, clothing and gloves away from moving
parts. Loose clothes, jewellery or long hair can be caught
in moving parts.
If devices are provided for the connection of dust extrac-
tion and collection facilities, ensure these are connected
and properly used. Use of dust collection can reduce
dust-related hazards.
WORK AREA SAFETY Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
Do not operate power tool/machine in explosive atmos-
pheres, such as in the presence of ammable liquids,
gases or dust.
Power tool/machine create sparks which may ignite the
dust or fumes.
Keep children and bystanders away while operating a
power tool/machine. Distractions can cause you to lose
control.
GENERAL POWER TOOL USE AND CARE Do not force
the power tool/machine. Use the correct power tool/ma-
chine for your application. The correct power tool/ma-
chine will do the job better and safer at the rate for which
it was designed.
Do not use the power tool/machine if the switch does not
turn it on and o. Any power tool/machine that cannot
be controlled with the switch is dangerous and must be
repaired.
Disconnect the plug from the power source and/or the
battery pack from the power tool/machine before making
any adjustments, changing accessories, or storing pow-
er tool/machine tools. Such preventive safety measures
reduce the risk of starting the power tool/machine ac-
cidentally.
Store idle power tool/machine out of the reach of children
and do not allow persons unfamiliar with the power tool/
machine or these instructions to operate the power tool/
machine.
Power tool/machines are dangerous in the hands of un-
trained users.
Maintain power tool/machines. Check for misalignment
or binding of moving parts, breakage of parts and any
other condition that may aect the power tool/machines
operation. If damaged, have the power tool/machines re-
paired before use. Many accidents are caused by poorly
maintained power tool/machines.
Keep cutting tools sharp and clean.
Properly maintained cutting tools with sharp cutting edg-
es are less likely to bind and are easier to control.
Use the power tool/machine accessories and tool bits in
accordance with these instructions, take into account the
working conditions and the work to be performed.
Use of the power tool/machine for operations dierent
from those intended could result in a hazardous situation.
CLEANING & MAINTENANCE Never soak or immerse
electrical components and or a component that has a
plug attached.
Disconnect the plug from the power source before mak-
ing any adjustments, changing accessories, or storing.
Such preventive safety measures reduce the risk of start-
ing the power tool accidentally.
Ensure the motor has fully stopped before cleaning,
clearing a blockage, checking, or carrying out any main-
tenance on the tool.
Maintain your power tool. Check for misalignment or
binding of moving parts, breakage of parts and any oth-
er condition that may aect the power tool’s operation.
If damaged, have the power tool repaired by a qualied
repair person before use. Many accidents are caused by
poorly maintained power tools.
Keep cutting tools sharp and clean. Properly maintained
cutting tools with sharp cutting edges are less likely to
bind and are easier to control.
Regularly check external nuts and xings to ensure vibra-
tion caused by normal use has not begun to loosen them.
Store idle power tools out of reach of children and do
A5P | 01
not allow persons unfamiliar with the power tool or these
instructions to operate the Breaker.
Locate the power tool out of reach of children, in a dry,
locked unit.
Make sure that the cord is located so that it will not be
stepped on, tripped over, or otherwise subjected to dam-
age or stress.
Remove the plug from the mains socket / battery (where
applicable) before carrying out any adjustment or main-
tenance.
Always store the power tool/machine in a dry place.
If the power cord is damaged, it must be replaced by a
qualied service technician.
Keep the ventilation slots and motor housing as free of
dirt and dust as possible (where applicable).
Clean the power tool/machine by rubbing it with a clean
cloth and blow it clean using low-pressure compressed
air is recommended.
Ensure you have all the pieces listed. If you are missing
any components, contact our customer services
department at
[email protected] DO NOT proceed with assembly
if any components are missing.
LAWNMOWERS
Do not expose the Lawnmower to rain or wet conditions.
Water entering the Lawnmower will increase the risk of
electric shock.
Always check the area to be worked on for wire and other
debris that could cause potential damage to the Lawn-
mower and injury to the operator.
Always wear substantial footwear and long trousers
whilst operating the Lawnmower.
Never operate the Lawnmower without the Grass Catch-
er in place, unless otherwise specied in this manual.
Keep children, pets and bystanders away whilst operat-
ing the Lawnmower. Distractions can cause you to lose
control. Switch on the motor carefully according to in-
structions and with feet well away from the blade.
Do not start the Lawnmower whilst standing in front of
the discharge opening. Keep clear of the discharge open-
ing at all times. Do not use the Lawnmower if the switch
does not turn it on and o. Any garden tool that cannot
be controlled with the switch is dangerous and must be
repaired. Do not tilt the Lawnmower when switching on
the motor, except for if the machine has to be tilted for
starting. In this case, do not tilt it more than absolutely
necessary and lift only the part which is away from the
operator. Always keep your arms and legs a safe distance
from the cutting mechanism, particularly after turning the
appliance on.
Do not put hands or feet near or under rotating parts.
Keep hair, loose clothing, ngers, and all parts of body
away from openings and moving parts.
Walk, never run.
Do not overreach. Keep proper footing and balance at all
times. Always be sure of your footing on slopes.
Always mow across the face of slopes, never up or down.
Do not mow excessively steep slopes.
Exercise extreme caution when changing direction on
slopes. Use extreme caution when reversing or pulling
the Lawnmower towards you.
Do not transport the Lawnmower whilst the power source
is running. If the Lawnmower has to be tilted when trans-
porting it between areas, stop the blade before attempt-
ing to move it. The same applies when crossing surfaces
other than grass. If a foreign body or other debris ac-
cidentally become entangled in the Lawnmower, stop it
immediately. Disconnect from the mains and do not use
again until cleared.
If the Lawnmower makes any unusual sounds or starts to
vibrate abnormally, stop it immediately. Disconnect from
the mains and investigate the cause. Inspect for damage,
tighten any loose parts and have any damaged parts re-
paired or replaced.
BATTERY WARNINGS (INCLUDING BUTTON CELLS,
AA BATTERYS, LITHIUM PACKS)
WARNING The use, and particularly abuse of portable
sealed secondary lithium cells and batteries may result in
the creation of hazards and may cause harm.
Do not dismantle, open or shred secondary cells or
batteries.
Keep batteries out of the reach of children.
NOTE the battery pack is not fully charged out of the box.
Secondary cells and batteries need to be charged before
use, always refer to the cell or battery manufacturer’s in-
structions and use the correct charging procedure.
Recharge only with the charger specied by the manu-
facturer. A charger that is suitable for one type of battery
pack may create a risk of re when used with another
battery pack.
Use the appliance/power tool/machines only with specif-
ically designated battery packs. Use of any other battery
packs may create a risk of injury and re.
First read the safety instructions and then follow the
charging notes and procedures.
Incorrect reassembly may result in a risk of electric shock
or re.
Protect the battery and charger against water and mois-
ture. Always keep cells and batteries clean and dry.
Wipe the cell or battery terminals with a clean dry cloth if
they become dirty.
Protect the battery from heat and re. Place the charger in
a position away from any heat source and avoid storage
in direct sunlight.
Do not maintain secondary cells and batteries on charge
when not in use.
After extended periods of storage, it may be necessary to
charge and discharge the cells or batteries several times
to obtain maximum performance.
Do not short-circuit a cell or battery.
Do not store cells or batteries haphazardly in a box or
drawer where they may short-circuit each other or be
short-circuited by conductive materials. When the battery
pack is not in use, keep it away from other metal objects
such as paper clips, coins, keys, nails, screws or other
small metal objects that can make a connection from one
terminal to another. Short-circuiting the battery terminals
together may result in burns or a re.
Do not expose cells or batteries to mechanical shock.
Never attempt to open the battery pack for any reason or
if the plastic housing of the battery pack breaks or cracks,
immediately discontinue use and do not recharge.
When possible, remove the battery from the appliance/
power tool/machine when not in use.
Do not leave a battery on prolonged charge when not in
use or stored for extended periods of time as this may
cause damage to the battery.
To facilitate cooling of the battery pack after use, avoid
placing the charger or battery pack in a warm environ-
ment such as a metal shed or an uninsulated trailer.
To reduce the risk of electric shock, unplug the charger
from the outlet before attempting any cleaning. Removing
the battery pack will not reduce this risk.
In the event of a cell leaking, do not allow the liquid to
come into contact with the skin or eyes. If contact has
been made, wash the aected area with copious amounts
of water and seek medical advice.
Seek medical advice immediately if a cell or battery has
been swallowed.
Always observe the polarity marks (+) and (-) on the cell,
battery and equipment and ensure correct use.
Retain the original cell and battery literature for future
reference
When disposing of secondary cells or batterie, keep cells
or batteries of dierent electrochemical systems separate
from each other.
Do not use any cell or battery which is not designed for
use with the equipment.
Do not mix any cells of dierent manufacturers, capacity,
size or type within a device.
Always purchase the battery recommended by the
device manufacturer for the equipment.
A5P | 01
ADDITIONAL SAFETY INFORMATION FOR BATTERY
CHARGERS.
This appliance should not be used by children and/or
persons with reduced physical, sensory or mental ca-
pabilities or lack of experience and knowledge. Children
shall not play with the appliance.
Do not place any object on top of the charger or place
the charger on a soft surface that may result in excessive
internal heat.
Do not attempt to disassemble the charger. Take it to
an electrician or tool repairer when service or repair is
required.
Appliances/power tools/machines with Lithium-ion bat-
teries shall only be charged with the specically designed
Lithium-ion battery charger purchased with this tool. Do
not attempt to charge the battery with any charger other
than the one supplied as this is potentially dangerous.
Before using the charger, read all instructions, labels and
cautionary markings on the charger.
The charger is not intended to be used for any purpose
other than charging the battery pack for this tool. Any
other use may result in risk of re or electric shock. Do
not attempt to use the charger on any other voltage or
rating than those stated on the rating plate.
Do not use the charger for any purpose other than that for
which it is intended.
Do not use the charger to charge any device other than
the appliance/power tool/machine it was sold with.
Do not use an extension cord unless absolutely neces-
sary. The use of an improper extension cord could result
in re or electric shock.
Never attempt to connect two chargers together.
Use the battery charger indoors only.
Make sure that the charger cable is positioned where it
will not be stepped on, tripped over or otherwise subject-
ed to damage or stress. Keep the cord away from operat-
ing appliance/power tool/machine.
1. Upper Handle
2. Lower Handle support
3. Locking Levers x2
4. Collection Basket with Handle
5. Handle Release Button
6. Carry Handle
7. Battery Compartment
8. Cutting Height Adjustment Lever
9. Switch Box
10. Start Key
11. 40V Battery
12. Battery Charger Indicator
13. Battery Charger
Do not operate the charger in a cabinet or other enclo-
sure unless ventilation is adequate.
Do not place any object onto the charger or allow any
object to rest on the charger.
Never place the appliance/power tool/machine or charg-
er near or over a heat source such as radiator or heater.
WARNING Never charge your Lithium-ion battery below
or above temperatures recommended as this may result
in re or permanent damage to the battery.
The most suitable temperatures to charge the battery are
between 20°C/68°F and 25°C/77°F.
WARNING Do not allow water or any other liquid to come
into contact with the charger as this may result in electric
shock. Do not position the tool or battery charger near
water. Take care not to spill liquid of any kind on the tool
or charger.
DANGER Do not use the charger if it has been subjected
to a heavy knock, dropped, or otherwise damaged in any
way. Take the charger to an authorised service centre for
it to be checked and repaired.
Do not attempt to disassemble the charger by opening
or removing covers.
To reduce risk of damage to the electric plug and cord,
pull by the plug rather than the cord when disconnecting
the charger.
TECHNICAL SPECIFICATION
Battery Rating: 40V MAX 4000mAh
Charger Input: 220V-240V 50/60Hz, 100W
Charger Output: 42V 2.0Ah
CONTENT LIST / LISTE DE CONTENU/ INHALTSANGABE /
LISTA DE CONTENIDO / ELENCO DEI CONTENUTI / LISTA DE CONTENIDO
A5P | 01
COMPONENTS / COMPOSANTS / KOMPONENTEN / COMPONENTES / COMPONENTI /COMPONENTE
7
8
6
2
12
5
3
4
3
1
9
10
11
13
A5P | 01
ASSEMBLY / ASSEMBLÉE / VERSAMMLUNG / MONTAJE / MONTAGGIO / EL MONTAJE
Red LED
Green LED
LED Status
Green Flickering Ready to charge
Solid Red Charging
Solid Green Fully Charged
Solid Green and Red Battery/Charger is
faulty.
60mins
100%
75%
25%
0%
11
12
A5P | 01
ASSEMBLY / ASSEMBLÉE / VERSAMMLUNG / MONTAJE / MONTAGGIO / EL MONTAJE
2
5
3
A5P | 01
ASSEMBLY / ASSEMBLÉE / VERSAMMLUNG / MONTAJE / MONTAGGIO / EL MONTAJE
OPERATION / OPÉRATION / DIE ANWENDUNG / OPERACIÓN / FUNZIONAMENTO / FUNCIONAMIENTO
1 2
3
4 5
55mm
45mm
35mm
25mm
Transport
65mm
A5P | 01
OPERATION / OPÉRATION / DIE ANWENDUNG / OPERACIÓN / FUNZIONAMENTO / FUNCIONAMIENTO
Allowing the grass cuttings to lay on the surface of the
lawn can be benecial and act as a natural food.
Remove the Collection Basket and t the mulching
attachment into its location as show, this will deect the
clippings downwards.
Set mower to the highest cutting height when mowing
on uneven ground or in tall weeds.
NOTE: Release the switch to turn the mower o when
crossing any gravelled area (stones can be thrown by
the blade).
For eective mulching, do not cut wet grass, because it
tends to stick to the underside of the deck, preventing
proper mulching of grass clippings. New or thick grass
may require a narrower cut.
The ground speed should be adjusted to the condition
of the lawn.
If the grass is longer than 4" (10 cm), mow the lawn
twice in order to reduce the grass height to a maximum
of 3 ¼” (8.3 cm).
Walk at a steady pace. Overlap the cutting rows. Do not
let the grass get too tall. If the grass gets too long, start
at the highest cutting position and work down to the
desired cutting height.
OPERATION / OPÉRATION / DIE ANWENDUNG / OPERACIÓN / FUNZIONAMENTO / FUNCIONAMIENTO
A
B
10
9
A5P | 01
OPERATION / OPÉRATION / DIE ANWENDUNG / OPERACIÓN / FUNZIONAMENTO / FUNCIONAMIENTO
OPERATION / OPÉRATION / DIE ANWENDUNG / OPERACIÓN / FUNZIONAMENTO / FUNCIONAMIENTO
Protect your hands.
While wearing gloves, wedge a block of wood between
the blade and the mower deck in order to prevent the
blade from turning when the nut is being removed.
Using a 12mm wrench or socket, loosen the blade nut
and remove the blade.
Turn the nut anticlockwise to loosen it and clockwise to
tighten, remove the blade.
To re-install the blade, position the blade with the cutting
edges toward the ground making sure that the 2 holes
locate with the 2 protrusions on the plastic insulator
section.
Assemble the blade nut and the insulator section as
shown below. Using a 12mm socket or wrench, turn the
blade nut clockwise to secure the blade.
A5P | 01
DISPOSAL INFORMATION Please recycle where
acilities exist. Check with your local authority for
recycling advice.
CUSTOMER SERVICE If you are having diculty using
this product and require support, please contact
WARRANTY To register your product and nd out if you
qualify for a free extended warranty please go to
www.vonhaus.com/warranty. Please retain a proof of
purchase receipt or statement as proof of the purchase
date. The warranty only applies if the product is used
solely in the manner indicated in the warnings page of
this manual, and all other instructions have been followed
accurately. Any abuse of the product or the manner in
which it is used will invalidate the warranty. Returned
goods will not be accepted unless re-packaged in its
original packaging and accompanied by a relevant and
completed returns form. This does not aect your stat-
utory rights. No rights are given under this warranty to a
person acquiring the appliance second-hand or for com-
mercial or communal use.
COPYRIGHT All material in this instruction manual are
copyrighted by DOMU Brands.Any unauthorised use
may violate worldwide copyright, trademark, and other
laws.
THANK YOU
Thank you for purchasing your product/appliance.
Should you require further assistance with your pur-
chase, you can contact us at
VonHaus is a registered trademark of DOMU Brands
Ltd. Made in China for DOMU Brands. M24 2RW.
C
