INSTRUCTION MANUAL
ICE MAKER
Model: ICM1225
THANK YOU FOR CHOOSING OUR ICE MAKER
PLEASE READ THE MANUAL CAREFULLY BEFORE OPERATING
IMPORTANT NOTICES
When using an electrical appliance, basic safety precautions should always be
followed to reduce the risk of fire, electric shock, and/or injury, including the
following:
1. Read all instructions before using.
2. Remove all packing material and carefully check your ice maker to ensure
it is in good condition and that there is no damage to the ice maker or
power cord and plug.
3. Before using the Ice maker for the first time, please wait 2 hours after
position
ing it, and keep the transparent lid open for at least 2hours
4. Pure water is not allowed to be used on this unit, spring water is
recommended.
5. Ensure the voltage is compliant with the voltage range stated on the rating
label, and ensure the earthing of the socket is in good condition.
6. If the supply cord is damaged, it must be replaced by the manufacturer or
its service agent or a similarly qualified person in order to avoid a hazard.
7. Do not upend this product or incline it ove
r a 45℃ angle.
8. To protect against risk of electric shock, do not pour water on cord, plug
and ventilation, immerse the appliance in water or any other liquid.
9. Unplug the appliance after using or before cleaning.
10. Keep the appliance 8cm from other objects to ensure the good heat
releasing.
11. Do not use the accessories which are not recommended by Manufacturer.
12. This appliance is not intended for use by persons (including children) with
reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the
appliance.
13. Do not use the appliance close by flames, hot plates or stoves.
14. Do not switch on the power button frequently (ensure 5min. interval at
least) to avoid the damage of compressor.
15. Metal sheet or other e
lectric objects are not allowed to be inserted into the
appliance to avoid fire and short circuit.
16. Do not use outdoors.
17. Never clean with scouring powders or hard implements.
18. Please keep the instruction manual.
19. Warning: Do not store explosive substances such as aerosol cans with a
flammable propellant in this appliance.
20. This appliance is intended to be used in household and similar applications
such as
– staff kitchen areas in shops, offices and other working environments;
– farm houses and by clients in hotel
s, motels and other residential type
environments;
– bed and breakfast type environments;
– catering and similar non-retail applications
21. When positioning the appliance, ensure the supply cord is not trapped or
damaged.
22. Do not locate multiple portable socket-outlets or portable power supplies at
the rear of the appliance
23. Children aged from 3 to 8 years are allowed to load and unload
refrigerating appliances.
24. The refrigerant and insulation blowing gas is f
lammable, when disposing of
the appliance, do so only at an authorized waste disposal centre. Do not
expose to flame.
This symbol indicates the refrigerant R600a and the
non-metallic materials of the appliance are flammable. It’s a warning
symbol. Warning: Risk of fire / flammable materials.
Warning; Risk of fire / flammable materials.
WARNING: When positioning the appliance, ensure the supply cord is not
trapped or damaged.
WARNING: Do not locate multiple portable socket-outlets or portable power
supplies at the rear of the appliance.
Children aged from 3 to 8 years are allowed to load and unload refrigerating
appliances.
To avoid contamination of food, please respect the following instructions:
– Opening the door for long periods can cause a significant increase of the
temperature in the compartments of the appliance.
– Clean regularly surfaces that can come in contact with food and accessible
drainage systems.
– Clean water tanks if they have not been used for 48 h; flush the water
system connected to a w
ater supply if water has not been drawn for 5 days.
– If the refrigerating appliance is left empty for long periods, switch off, defrost,
clean, dry, and leave the door open to prevent mould developing within the
appliance.
Regarding the information pertaining to the use of the appliance, thanks to
refer to the below paragraph of the manual.
SPECIFICATION
Model number：ICM1225
Daily ice output：12kg / 24 hours
Ice storage capacity：1.5L/650g
Refrigerant：R600a
Compression-type refrigeration:110V~ 60Hz
Water tank capacity：1.5 L
Voltage: 120V~
Frequency: 60Hz
Power consumption: 120 W
Max overall dimensions(W×D×H)：224X 308X283mm
N.W：7.75kg
G.W：8.60kg
DESCRIPTION
SN
Name
SN
Name
1
Transparent lid
9
Front housing
2
Micro switch support
10
Ice shovel
3 Water Tray 11 Top cover
4 Ice shovel board 12 Transparent cover
5 Ice basket 13 Evaporator
6 Water Reservoir 14 Motor Mount
7 Control panel 15 Back housing
8 Buttons 16 Air vent
FEATURE
Quick ice making
Prompt when the ice is full and water is insufficient
Bullet ice
9 pcs ice can be made in eight minutes
1. During transportation, do not tilt the machine more than 45 degrees, do not
reverse the machine. This may damage the compressor and the sealing
system.
2. Remove all packing materials, check the machine carefully and make sure
that the machine, power cord and plug are normal.
3. The machine should be on a level surface. To ensure sufficient ventilation,
the distance of the back of ice maker to the wall should be at least 150 mm, it
should be away from the oven, radiator or other
heat source.
4. Before using the machine for the first time, place the machine and leave the
transparent cover open for at least two hours.
5. Make sure that the home voltage is consistent with the voltage indicated by
the machine.
6. Distilled water is not allowed. Mineral water is recommended.
CONTROL PANEL OPERATION
ICE FULL: Ice full alarm
ADD WATER: Water shortage alarm
ICE MAKING: Ice making
1). Plug in the power, the "ICE MAKING " indicator flashes, and the machine
will start the deicing function. Press the power button, the "ICE MAKING"
indicator light is always on and then the ice block will be made automatically.
After the ice making is completed, the deicing will be carried out, and then the
ice shoveling function will be entered, and so on.
2). ADD WATER: wat
er shortage alarm
When the “ADD WATER” light turns red, it means that there is water shortage
in the water tank. You need to add water and press the power button to restart
the machine.
3) ICE FULL: Ice full alarm
When the ice reaches the maximum capacity of the ice storage container, the
"ICE FULL" light flashes, and the machine stops. At this time, the ice needs to
be poured out. When the ice position is lower than the full sensor position, the
machine will restart automatically.
4
) ICE MAKING: Ice making
When this light is always on, it means that the ice maker is making ice.
ICE FULLADD WATER
ICE MAKING
OPERATING INSTRUCTIONS
Step 1
Open the lid and take out the basket and add water to the reservoir.
Note: There is a maximum scale MAX in the reservoir. The water should not
exceed the MAX position. If the water exceeds the maximum scale MAX, you
need to open the bottom drain plug, release the excess water, and cover with
a transparent cover.
Step 2
Plug in the power and press the power button to start the machine.
When the ice basket is full, please take out the ice immediately, do not
let the
ice overflow the ice basket.
1. The three cycles used for the first time, the ice produced is small and
irregular.
2. When the ice basket is full, please take out the ice immediately, do not let
the ice overflow the ice basket
CLEANING & USE GUIDANCE
1. Clean the inner liner, ice collecting tray, water box, ice shovel and
evaporator frequently. When cleaning, unplug the unit and remove the ice
cubes. Use a diluted solution of water and vinegar to clean the inside and
the outside surface of the Ice maker. Do not spray Ice maker with
chemicals or diluted agents such as acids, gasoline or oil. Rinse
thoroughly before starting.
2. Keep ventilation openings in the appliance enclosure, or in the built-in
structure, clear of obstruction. Do not use mechanical devices or other
means to accelerate the defrosting process, other than those
recommended by the manufacturer.
3. Reuse the machine after being idled for a period of time, it may not have
enough water to pump for air retard, in this case, the water shortage
indicator “ADD WATER” will light up, repress power button to restart the
ice maker is okay.
4. To ensure the cleanness of ice, please change water for water reservoir
at least once one day. If do not use for a long time, please drain the water
out and clean it up.
5. If the compressor takes a strike action for s
hortage water, fully water or
interruption of power supply, it will delay for 3mins to start up after
restarted.
6. Always use fresh water before starting ice production either at initial
installation or after a long shut-off period.
TROUBLESHOOTING
1. Please note, if a power failure occurs due to disconnection of the power
cord, or the power button has been pushed off during an ice making cycle,
small ice chips may formed and lodge in the automatic shovel causing it to
jam. If this occurs, the ice chips may be removed by disconnecting the
power cord and gently pushing the shovel to the rear of the cabinet and
removing the ice chips, then restarting.
2. Please check if the water reservoir is flat when the ice sho
vel can not
remove the ice to ice basket. If not, please push the ice shovel gently by
finger, then press POWER button to restart.
PROBLEM POSSIBLE CAUSE SUGGESTED SOLUTIONS
The compressor
works abnormally
with a Buzzing
Noise
The voltage is lower
than
recommended
Stop the Ice maker and do not
restart until the voltage is
normal.
Water shortage
indicator
light is on
1.There is no water
2.The pump is full of
air
1.Add to some water until it
reaches MAX position
2.Press POWER button to
restart
Indicator lights on
display are not on
Blown fuse/ No power Replace fuse / Turn power on
The Ice made is too
large
and with pieces
sticking
together.
Ice of previous cycles
left in the water tray
Take out the ice under the
standby state
The ice making
process was
correct, but no ice
came out?
1. The compressor
has no refrigerant
2. Compressor
damaged
3. Fan motor
damaged
Call the service hotline
All indicators twinkle
simultaneously
Water tray is blocked
by ice cube
Unplug the powe
r to take out
the ice which blocking the tray,
then plug the power and press
the POWER button, the
machine will restart 3mins
later.
The machine has
been working, but
the water has been
warming
Solenoid broke down Replace the solenoid valve
When the ice is full,
the machine does
not display the ICE
FULL Icon
Ice full sensor
damaged
1. Replace the ice full sensor
2. Making ice indoor
3. Call the service hotline
1. If the power cord is damaged; it must be replaced by the manufacturer, its
service agent or a similarly qualified person in order to avoid a hazard.
2. Fill with potable water only.
3. It is normal for the compressor and condenser surface to reach
temperatures between 70°C and 90°C during operation and surrounding
areas may be very hot.
4. Due to fast freezing, ice cubes may appear “Cloudy”. This is air trapped
in the water and will not affect quality or taste of ice.
5. This appl
iance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities or lack of experience and
knowledge unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
6. Children should be supervised to ensure that they do not play with the
appliance.
7. Do not immerse in water.
Correct Disposal of this product
This marking indicates that this product should not be
disposed with other household wastes throughout the EU. To
prevent possible harm to the environment or human health
from uncontrolled waste disposal, recycle it responsibly to
promote the sustainable reuse of material resources. To return
your used device, please use the return and collection
systems or contact the retailer where the product was
purchased. They can take this product for environmentally
safe recyc
ling.
HOUSEHOLD USE ONLY
HONG KONG TOPCHEF APPLIANCE LIMITED
Room P, 4/f, Lladro Centre, 72 Hoi Yuen Road Kwun Tong Kowloon
support@ostba.cc
Made In China
