USER’S GUIDE
3760/4220/6850/6860 SERIES
3
Safety Instructions
4
Product View
5-6
Assembly
6-9
Operations
10-15
Maintenance and Care
16-17
Troubleshooting
18
Consumer Services
19
Replacement Parts
20
Warranty
Lift-Off
®
REVOLUTION
™
2
Thank you for buying a BISSELL Lift-Off
®
Revolution
™
2
www.bissell.com 800.237.7691
We’re glad you purchased a BISSELL vacuum. Everything we know about floor
care went into the design and construction of this powerful, high-tech home
vacuuming system.
Your BISSELL vacuum is well made, and we back it with a limited one year
warranty. We also stand behind it with a knowledgeable, dedicated Consumer
Services Department, so, should you ever have a problem, you’ll receive fast,
considerate assistance.
My great-grandfather invented the floor sweeper in 1876. Today, BISSELL is a
global leader in the design, manufacture, and service of high quality homecare
products like your BISSELL Vacuum.
Thanks again, from all of us at BISSELL.
Mark J. Bissell
President and Chief Executive Officer
3
IMPORTANT SAFETY INSTRUCTIONS
When using an electrical
appliance, basic
precautions should be observed, including
the following:
READ All InSTRUCTIOnS
bEfORE USInG yOUR
UPRIGhT VACUUM.
Always connect to a polarized outlet (left slot is wider
than right). Unplug from outlet when not in use and
before conducting maintenance.
WARnInG: To reduce the
risk of fire, electric shock,
or injury:
■
Do not modify the polarized plug to fit a
non-polarized outlet or extension cord.
■
Do not leave vacuum cleaner unattended
when it is plugged in.
■
Unplug from outlet when not in use and
before servicing.
■
Do not use outdoors or on wet surfaces.
■
Do not allow children to operate vacuum
cleaner or use as a toy.
■
Close attention is necessary when used by or near
children.
■
Do not use for any purpose other than described in
this User’s Guide.
■
Use only manufacturer’s recommended
attachments.
■
Do not use with damaged cord or plug.
■
If appliance is not working as it should, has been
dropped, damaged, left outdoors, or dropped into
water, have it repaired at an authorized
service center.
■
Do not pull or carry by cord, use cord as a handle,
close a door on cord, or pull cord around sharp
edges or corners. Do not run appliance over cord.
Keep cord away from heated surfaces.
■
Do not unplug by pulling on cord. To unplug, grasp
the plug, not the cord.
■
Do not handle vacuum cleaner or plug with
wet hands.
■
Do not put any object into openings. Do not use with
any opening blocked; keep openings free of dust,
lint, hair, and anything that may reduce air flow.
■
Keep hair, loose clothing, fingers, and all parts of
body away from openings and moving parts.
■
Turn off all controls before plugging or unplugging
vacuum cleaner.
■
Use extra care when cleaning stairs.
■
Unplug before attaching the TurboBrush.
■
Do not pick up flammable materials (lighter fluid,
gasoline, kerosene, etc.) or use in the presence of
explosive liquids or vapors.
■
Do not pick up toxic material (chlorine bleach,
ammonia, drain cleaner, etc.).
■
Do not use vacuum cleaner in an enclosed space
filled with vapors given off by oil base paint, paint
thinner, some moth proofing substances,
flammable dust, or other explosive or toxic vapors.
■
Do not pick up hard or sharp objects such as
glass, nails, screws, coins, etc.
■
Do not pick up anything that is burning or smoking,
such as cigarettes, matches, or hot ashes.
■
Do not use without filters in place.
■
Use only on dry, indoor surfaces.
■
Keep appliance on a level surface.
SAVE ThESE
InSTRUCTIOnS fOR
fUTURE USE
ThIS APPlIAnCE hAS
A POlARIZED PlUG.
To reduce the risk of electric shock, this appliance has a
polarized plug (one blade is wider than the other). This plug
will fit in a polarized outlet only one way. If the plug does
not fit fully in the outlet, reverse the plug. If it still does not
fit, contact a qualified electrician to install a proper outlet.
Do not change the plug in any way.
This model is for household use only.
www.bissell.com 800.237.7691
4
www.bissell.com 800.237.7691
CAUTIOn:
Do not plug in your vacuum
cleaner until you are familiar
with all instructions and
operating procedures.
Product view
Crevice Tool
Handle
Quick Release
Cord Wrap
Handle Release
Pedal
Powerfoot
Stretch Hose
Power
Cord
Furniture
Protection
Guard
Height
Adjustment
Knob
Upper Tank
Dirt
Container
Pre-Motor
Filter
Lock ’n Seal
®
Lever
Headlight
Telescoping
Extension Wand
Upper Tank Knob
Cord Clip
HEPA Media
Post-Motor Filter
Hose Grip Base
Louvers/
Filter Frame
Upper Tank Filter
(Inside Louvers)
Dusting Brush/
Upholstery Tool
Comfort Grip
Hose Clip
Hose Grip
Brush On/Off
Switch
Release Button
Detachable Canister
Clean Filter
Indicator (Select
Models Only)
Twist n' Snap Hose
Connection
Dust Chamber
with Screens
Power Switch
5
www.bissell.com 800.237.7691
How to use this guide
Assembly
WARnInG:
Plastic film can be
dangerous. To avoid
danger of suffocation,
keep away from babies
and children.
This user’s guide has been designed to help you
get the utmost satisfaction from your bISSEll
vacuum. you’ll find assembly and operating
instructions, safety precautions, as well as
maintenance and troubleshooting instructions.
Please read this guide thoroughly before
assembling your vacuum cleaner.
Pay particular attention to the product diagram,
assembly instructions, and part names. locate
and organize all parts before assembly. following
this user’s guide will greatly enhance your ability
to get the most performance from your bISSEll
vacuum for many years.
The only tool you’ll need to assemble your
vacuum cleaner is a screwdriver.
Attach handle to vacuum
1. Locate the vacuum handle and remove the
screw packet taped to the base of the handle.
2. Stand the vacuum upright and slide the base of
the handle firmly into the grooves at the top of
the vacuum body.
3. Check to be sure the handle is fitted to the
vacuum body. If there is a gap in front, continue
to push firmly until the handle is flush.
4. Insert the two screws from the screw packet into the
existing holes. Tighten securely with a screwdriver.
Attach vacuum hose and tools
1. Position the Twist ‘n Snap Hose
™
assembly on
the vacuum and line up the tabs on the base of
the hose with the corresponding notches. Turn the
Twist ‘n Snap Hose to the right to lock into place.
2. Slide the end of the hose grip onto the hose grip
base. Place the hose into the hose clip.
nOTE: The powerfoot will not operate effectively
unless the hose is firmly attached to the base.
2.
4.
1.
2.
16
www.bissell.com 800.237.7691
Attach vacuum hose and tools continued
3. Snap the telescoping extension wand,
crevice tool, and combination tool into
storage clips as shown.
4. On board TurboBrush
®
(select models only)
The TurboBrush bracket slides onto the
hanger on the front of the handle. Attach
the bracket by aligning the slots with the
rectangular part on the hanger as shown
and pulling down until it is locked into place.
note: If you do not wish to store the Turbobrush
on your lift-Off vacuum, the bracket may be
hung on a wall for storage and the hanger may
be removed from the vacuum.
Place the TurboBrush in the bracket by aligning
the small holes near the brush roll with the
tabs at the bottom of the bracket and snap the
TurboBrush into place.
Power switch/brush switch
The power switch is located just below the handle
on the front of the detachable canister. Push the
rocker switch “On” (I) to vacuum, and “Off” (O)
when cleaning is complete.
The brush switch is located just below the
handle on the front of the detachable canister
next to the power switch. This switch turns the
rotating brush on and off. The brush switch
should be in the “On” (I) position for normal
carpet cleaning. you may want to turn the brush
switch “Off” (O) for bare floor cleaning or other
delicate surfaces.
note: your bISSEll lift-Off Revolution
vacuum is equipped with a special internal
switch that turns the rotating brush off
whenever the unit is in the Upright position.
Handle position
1. Upright- For storage and above floor clean-
ing with special tools.
2. normal Cleaning- Press handle release
pedal once. Use for most household floor
cleaning tasks.
Assembly
6
www.bissell.com 800.237.7691
Combination
Tool
Telescoping
Wand
Crevice Tool
TurboBrush
®
CAUTIOn:
before using your vacuum, make
sure that the Dirt Container and
Upper Tank are in locked position
and that all filters (Upper Tank,
Pre-Motor and Post-Motor) are
in place. Do not operate your
vacuum without these filters.
Operation
Tip:
Your vacuum features a Quick-Release
Cord Wrap. To remove the Power Cord
quickly and easily, rotate the Upper
Cord Wrap towards floor, and slip Power
Cord from Upper and Cord Wraps..
Brush
Power
3.
4.
2.
7
www.bissell.com 800.237.7691
Power height adjustment
The powerfoot on your vacuum can be
adjusted to clean several floor surfaces.
nOTE: for optimal cleaning performance,
adjust to the lowest practical setting. If
your cleaner is difficult to push, adjust to
the next higher setting.
1. Place handle in upright position.
2. Turn height adjustment knob to desired setting.
lowest Setting – For bare floors.
Medium Settings – For short and medium
pile carpets.
highest Setting – For plush pile carpet.
nOTE: you may also adjust the setting while
in the normal cleaning position.
Special tools
your vacuum is not only a powerful floor vacuum
cleaner, it’s also a versatile stairs and above floor
vacuum when you select one of the special tools.
note: The tools can be used with the
vacuum in the Upright Position or with the
Detachable Canister.
1. Detach the vacuum hose by grasping the
hose grip and lifting to separate from the
hose grip base.
2. Attach tools by firmly pushing onto vacuum
hose or telescoping extension wand.
Combination dusting brush/upholstery tool:
Two types of cleaning tools are included in one
attachment rotate for desired tool.
■ Use brush side to dust furniture, blinds, books,
lamps, shelves, and baseboards.
■ Use upholstery side for curtains, draperies,
cushions, fabrics.
Crevice tool:
Use in tight narrow spaces.
Telescoping extension wand:
Use with desired attachment for a longer reach. To
extend the wand, twist the collar to “Unlock” posi-
tion and push away from you. Twist the collar to the
“Lock” position to lock into place. To retract, twist to
unlock, pull toward you and twist to relock.
Stair cleaning tool (select models):
Use for stairs, area rugs, and other small carpeted
areas. This tool can also be used for bare floors.
note: The stair cleaning tool does not
store on board.
Operation
Tip:
Before cleaning under
low furniture, check
area first for objects
that might harm the
unit or block the
Vacuum Hose.
CAUTIOn:
Always place vacuum cleaner on
floor in its fully Upright Position
and make sure it is locked into
place before removing Canister
or when using tools. Placing the
lift-Off in its full Upright Position
automatically stops the
rotating brush.
7
1.
Special tools continued
Turbobrush
®
(select models):
Use rotating brush action for small areas such
as stairs and upholstery.
note: Press gently when using Turbobrush to
gain maximum cleaning. Too much pressure
could cause the brush to stop rotating.
Pet Turbobrush
®
(select models):
Use for removing dirt and pet hair from stairs,
upholstery, area rugs, and other small areas. Pull
towards you in a raking motion.
note: Pet Turbobrush is designed to remove pet
hair from upholstered or carpeted surfaces. It
should not be used on pets.
Deluxe bare floor tool (select models):
Use for bare floors. Swivel head turns to get
into tight spaces and fits under cabinets.
note: The deluxe bare floor tool does not store
on board.
All items may not be included with your model.
More tools are available; to order please refer
to page 19 .
Cleaning with the detachable canister
The detachable canister feature makes it
possible to easily take the powerful cleaning
action of your bISSEll lift-Off Revolution to
stairways, auto interiors, and other hard-to-
reach areas of your home.
before detaching the canister, your vacuum must
be in its fully upright position. you do not need to
turn off the power first.
1. Press the release button at the top of the
canister handle and lift the canister to remove.
2. Detach the vacuum hose from the hose grip
base at the back of the canister.
3. Attach the desired tool(s) to the hose grip at
the end of the Vacuum Hose.
4. When you’re done, remove the tool(s) and
reconnect the hose to the hose grip base.
5. Return the canister to the powerfoot by
aligning the “feet” on the front with the
bumps on the foot of the upright vacuum.
Push the canister toward the vacuum frame
until it “clicks” into place.
8
www.bissell.com 800.237.7691
Operation
Release
Button
nOTICE:
While vacuuming, certain
carpets and low humidity
conditions may generate small
static discharges. The discharges
are entirely harmless and are not
associated in any way with the
main power supply.
1.
16
www.bissell.com 800.237.7691
Buckle
Clean filter indicator
Select Models Only
The clean filter Indicator tells you when airflow
in the vacuum is reduced due to dirty filters or
a clog in the hose. The clean filter Indicator will
remain green until the airflow is reduced. At
that time, it begins to change to red. When it is
fully red, the airflow is significantly reduced or
blocked. follow the steps on page 11 to clean
your filters. All filters in the vacuum should be
cleaned or replaced when the clean filter
indicator turns red.
If the indicator remains red after all filters have
been cleaned, follow the steps on page 14 to
check for and clear clogs.
Shoulder strap
Select Models Only
The Shoulder Strap may be used while cleaning
with the Detachable Canister.
1. To attach the shoulder strap, wrap the Velcro
ends attached to the bottom of the strap
securely around the canister handle as shown.
To obtain maximum strength, overlap the loose
ends completely and press securely in place.
2. The plastic buckle must be positioned on top of
the canister handle as shown in the illustration.
3. The length of the strap may be adjusted as
required for comfort.
Power cord storage
When you are done using your vacuum, return it to
the Upright position and store the power cord.
1. Turn vacuum cleaner off (O).
2. Unplug power cord by grasping the polarized
plug (NOT the cord) and disconnect from outlet.
3. Loop power cord around cord wraps on side
of the canister.
4. Clip molded plug to power cord to secure.
Transporting Cleaner
1. To move your vacuum cleaner from room to room,
put the Handle in the Upright Position, tilt the
cleaner back on its rear wheels and push forward.
2. The cleaner can also be moved by using
the Carrying Handle on the Detachable
Canister.
Operation
9
CAUTIOn:
While the vacuum is in use, warm air
is emitted through the Post-Motor
filter on the back of the Canister.
The bottom of the Canister may
also become warm. When using the
shoulder strap, to avoid discomfort,
position the Canister so that these
parts are not directed towards or
touching your body.
CAUTIOn:
To reduce the risk of the shoulder
strap coming loose in operation
follow these instructions.
CAUTIOn:
Do not press the Release button
while using the Carrying handle to
transport the vacuum cleaner. The
Canister could detach causing
the rest of the vacuum to fall.
Carrying Handle
1. 2.
1.
2.
To maintain maximum cleaning performance, the
following maintenance steps must be performed:
1. Empty the dirt container when the dirt
reaches the “Full” line on the front.
2. Check the upper tank and pre-motor filters
at least once a month and clean and replace
as needed.
3. Replace the HEPA media post-motor filter
every six months.
nOTE: More frequent filter cleaning may be
necessary if you are vacuuming new carpet,
fine dust, or have allergy concerns.
follow the instructions on the following pages
to perform these simple maintenance steps.
Empty dirt container
The dirt container needs to be emptied when the
dirt reaches the “full” line on the front of the
container.
1. Unplug cleaner from electrical outlet.
2. Slide the Lock ‘n Seal Lever to the “Unlock”
position.
3. Grasp handle and pull the dirt container
straight out to remove from vacuum.
4. Empty dirt into garbage container.
5. Put the dirt container back in the vacuum
and slide the lever to the “Lock” position.
note: The screens may also be removed from
the side dust chambers when you empty
or clean the dirt container. The screens are
made to fit each dust chamber. If they do not
slide down completely, try in the opposite
dust chamber. The screens will also not fit if
there is debris in the track.
The dirt container and screens may be washed
in warm water with a mild detergent. Make
sure they are completely dry before replacing.
10
www.bissell.com 800.237.7691
Maintenance and care
Full Line
Lock
Position
Unlock
Position
Screen
Tip:
For maximum cleaning
performance, check and
clean or replace all filters
as suggested.
WARnInG:
To reduce the risk of electric
shock, turn Power Switch Off
and disconnect polarized plug
from electrical outlet before
performing maintenance or
troubleshooting checks.
11
www.bissell.com 800.237.7691
Maintenance and care
Cleaning the upper tank & filter
Unplug the cleaner from electrical outlet.
1. The upper tank filter can be reached by removing
the dirt container, reaching underneath the upper
tank and turning the rim of the filter frame to
unlock. Pull straight down to remove. Brush the
dirt off the louvers and upper tank filter.
2. The foam upper tank filter may be removed
and hand washed in cold water with mild
detergent. Rinse well then air dry thoroughly
before replacing.
3. The upper tank and louvers may also be
wiped clean with a damp cloth.
note: for easier access, the entire upper tank
may be removed by turning the knob on the
back of the cleaner to unlock and pulling the
entire tank straight out.
1. Unplug the cleaner from electrical outlet.
2. The Pre-Motor Filter protects the motor from
dirt particles. It is located in the slide out tray
underneath the Dirt Container. If the filter
becomes dirty, pull out the tray, lift out the fil-
ter and clean. This filter may be hand washed
in cold water with mild detergent. Rinse well
and air dry thoroughly before replacing.
3. The HEPA Media Post-Motor Filter assists in the
filtration process to return clean air to the
room. It is located behind the door on the back
of the cleaner. If the filter becomes dirty, open
the door, remove the filter and replace. The
HEPA Media Filter is not washable.
Upper
Tank
Knob
Cleaning the pre-motor and post-motor filter Maintenance
Pre-Motor Filter
WARnInG:
Do not operate cleaner
with damp or wet
filters or without all
filters in place.
HEPA Media
Post-Motor Filter
1.
2.
2.
3.
Maintenance and care
Check your vacuum cleaner’s rotating floor
brush and drive belt regularly for debris, wear or
damage. Debris can wrap around the brush and
hamper its ability to effectively clean your carpet.
1. Unplug cleaner from electrical outlet.
2. Remove detachable canister from vacuum cleaner
3. Recline handle and turn vacuum cleaner over
so bottom side is up.
4. Remove the six screws as shown with a Phillips
head screwdriver. Lift the brush cover off.
5. Lift the rotating floor brush to remove. Clean
strings, hair and other debris from the brush,
paying special attention to the brush ends.
6. Check air passageway for obstructions.
Remove any debris from this area.
7. Clean debris from the motor pulley and drive
belt areas.
8. Check drive belt carefully for wear, cuts or
stressed areas. If any damage is present,
discard old drive belt and replace.
9. Place one end of the new drive belt over motor
pulley and the other end over the brush in the
space between the bristles.
10. Pull the brush firmly to stretch the drive belt
and place ends of brush down into slots on
sides as shown. Turn brush several times by
hand to center the drive belt.
11. Reposition brush cover and screws. Tighten
screws securely.
Rotating brush and drive belt maintenance
Caution:
To reduce the risk of injury
from moving parts, turn
off vacuum cleaner and
disconnect Power Plug
from electrical outlet.
Air
Passageway
Motor
Pulley
12
www.bissell.com 800.237.7691
4.
10.
WARnInG:
To reduce the risk of electric
shock, turn Power Switch Off
and disconnect polarized plug
from electrical outlet before
performing maintenance or
troubleshooting checks.
Maintenance and care
Replace light bulb
1. Unplug cleaner from electrical outlet.
2. Remove detachable canister and recline
handle of vacuum.
3. Using a screwdriver, remove the one screw
as shown and lift off the lens.
4. Remove the bulb from the socket by grasping
bulb and pulling straight out. Install the new
bulb by pushing it gently into the socket until
the bulb snaps into place.
5. Reposition lens and secure with the one
screw.
TurboBrush maintenance
Select Models Only
The TurboBrush should be checked regu-
larly for clogs or debris wrapping around
the brush roll.
1. Unplug vacuum from electrical outlet.
2. If a clog is present or debris is visible, unscrew
the two screws on the back of the TurboBrush to
remove the faceplate and clear any obstructions.
3. To clean debris from the brush roll, remove the
screw located on the belt cover. Lift the belt
cover. Remove the brush roll from the drive belt
and clean debris.
4. Reposition the drive belt on the brush roll. Place
ends of brush roll in slots on sides as shown.
Reposition belt cover and secure with shorter
screw. Reposition faceplate and secure with two
longer screws. Several times by hand to center
the drive belt.
13
www.bissell.com 800.237.7691
3. 4.
Belt Cover
Maintenance and care
Cleaning clogs
low suction or poor pickup may be due to a clog
in the vacuum cleaner. If you notice a change in
the sound of the motor or a reduction in the
spinning action, check for clogs.
1. Unplug cleaner from electrical outlet.
2. Empty Dirt Container.
3. Check Upper Tank for build up or clogs.
4. Remove the Upper Tank and check the suc-
tion inlet for a clog.
5. Grasp the Hose Grip and lift to separate from
the suction opening. Check for a clog in the
Base or the Hose.
6. Release the Twist n' Snap hose from the
vacuum by turning to the left. Straighten the
hose and unclog with a long, narrow object.
7. If the clog persists, follow the instructions for
Checking the Rotating Brush on page 11 and
inspect the Air Passageway for obstructions.
Suction
Inlet
Air Passageway
Suction
Opening
4.
14
www.bissell.com 800.237.7691
Maintenance and care
Thermal protector
An internal thermal protector has been designed
into your cleaner to protect it from overheating.
When the thermal protector activates, the main
vacuum motor will stop operating. If this
happens, proceed as follows:
1. Turn the cleaner OFF (O) and unplug from
electrical outlet.
2. Check the Upper Tank area, Pre-Motor Filter
and Post-Motor Filter for dirt accumulation.
3. Refer to the "Clearing Clogs" section.
4. When the motor cools for approximately 30
minutes, the thermal protector automatically
resets and cleaning may continue. If the
thermal protector continues to activate after
following the above steps, your cleaner may
need servicing. Call BISSELL Consumer
Services, or visit the website.
note: The thermal protector controls the
main vacuum motor only, not the brush
motor. If the thermal protector activates,
the brush will continue to operate normally;
however, there will be no suction.
Caution:
To reduce the risk of
injury from moving
parts, turn off vacuum
cleaner and disconnect
Power Plug from
electrical outlet.
15
www.bissell.com 800.237.7691
WARnInG:
To reduce the risk of
electric shock, turn power
Off and disconnect
polarized plug from
electrical outlet before
performing maintenance
or troubleshooting.
Troubleshooting
Vacuum cleaner won’t run
Possible causes Remedies
1. Power cord not firmly plugged in 1. Check electrical plug
2. Blown fuse/tripped breaker 2. Check/replace fuse or reset breaker
3. Thermal protector activated 3. Allow cleaner to cool for 30 minutes,
see page 15
no power at rotating floor brush
Possible causes Remedies
1. Canister is not securely seated 1. Remove canister and replace, making sure
that it "clicks" into place
2. Brush switch turned to "OFF" 2. Make sure brush switch is in "ON" position
3. Vacuum is in upright position 3. Recline vacuum to operate brush
Vacuum cleaner won't pick up dirt
Possible causes Remedies
1. Incorrect height adjustment 1. Adjust powerfoot to correct height setting
2. Hose not attached to suction opening 2. Grasp hose grip and firmly push onto
the base
3. Crack or hole in hose 3. Check hose and repair if needed
4. Drive belt broken, worn or off motor pulley 4. Reposition or replace drive belt,
see page 12
5. Rotating floor brush bristles worn 5. Replace brush
6. Rotating floor brush jammed 6. Remove brush and clean debris from
brush ends
7. Clog in vacuum 7. Follow instructions for clearing clogs
on page 14
8. Dirt container full 8. Empty dirt container
9. Dirt container or upper tank not installed properly 9. Position correctly and lock into place
10. Filters are dirty 10. Check and clean or replace upper tank,
pre-motor and post-motor filters
Vacuum cleaner is difficult to push
Possible causes Remedies
1. Incorrect height adjustment 1. Adjust powerfoot to correct height setting
16
www.bissell.com 800.237.7691
Troubleshooting
Visible dirt escaping from cleaner
Possible causes Remedies
1. Dirt container full 8. Empty dirt container
2. Filter missing or installed incorrectly 2. Check upper tank, pre-motor and post-motor
filter for correct installation
3. Dirt container installed incorrectly 3. Pull out and re-insert dirt container correctly
Other maintenance or service not included in the manual should be performed by an
authorized service representative.
Thank you for selecting a bISSEll product.
If you should happen to need assistance during assembly or operation, call 1-800-237-7691.
Please do not return this product to the store.
for any questions or concerns, bISSEll is happy to be of service.
Contact us directly at 1-800-237-7691.
17
www.bissell.com 800.237.7691
BISSELL consumer service
For information about repairs or replacement parts, or questions about your warranty, call:
bISSEll Consumer Services
1-800-237-7691
Monday - Friday 8 a.m. — 10 p.m. ET
Saturday 9 a.m. — 8 p.m. ET
Or write:
BISSELL Homecare, Inc.
PO Box 3606
Grand Rapids, MI 49501
ATTN: Consumer Services
Or visit the BISSELL website - www.bissell.com
When contacting BISSELL, have model number of unit available.
Please record your Model Number: _______________Please record your Purchase Date: ______________
nOTE: Please keep your original sales receipt. It is your proof of warranty.
18
www.bissell.com 800.237.7691
You may purchase replacement parts from your retailer, by calling BISSELL Consumer Services or by
visiting our website. To locate a retailer near you, or to place an order using Visa, MasterCard, Discover or
American Express, call
bISSEll Consumer Services
1-800-237-7691
Monday - Friday 8 a.m. — 10 p.m. ET
Saturday 9 a.m. — 8 p.m. ET
Or visit our Website - www.bissell.com
Item Part no. Part name
1 3200 Style 8 Drive Belt (2-Pack)
2 203-1297 Standard Headlight Bulb (Select Models)
3 203-1063 Crevice Tool
4 203-1099 Dusting Brush/Upholstery Tool
5 203-6624 Stair Cleaning Tool (Select Models)
6 203-6625 Telescoping Extension Wand
7 203-2081 Deluxe Bare Floor Tool (Select Models)
8 203-1227 TurboBrush (Select Models)
9 203-2082 Bracket Assembly for TurboBrush (Select Models)
10 203-5542 Shoulder Strap (Select Models)
11 203-2073 Twist ‘n Snap Hose
12 203-2085 Brush Roll - Grey (other colors also available)
13 3093 Style 7/8 Upper Tank Filter/Pre-Motor Filter Set
14 3091 Style 8 HEPA Media Post-Motor Filter
Replacement parts – BISSELL Lift-Off Revolution series
1 2 3 4
7
5 6 7 8
9 10 11 12
13 14
19
www.bissell.com 800.237.7691
20
www.bissell.com 800.237.7691
Warranty
©2007 BISSELL Homecare, Inc
Grand Rapids, Michigan
All rights reserved. Printed in Korea
Part Number 603-5567
Rev 10/07
Visit our website at:
www.bissell.com
This warranty gives you specific legal rights, and you may also have other rights which may vary from state to state. If
you need additional instruction regarding this warranty or have questions regarding what it may cover, please contact
BISSELL Consumer Services by E-mail, telephone, or regular mail as described below.
limited One year Warranty
Subject to the *EXCEPTIONS AND EXCLUSIONS identified below, upon receipt of the product BISSELL
Homecare, Inc. will repair or replace (with new or remanufactured components or products), at BISSELL’s
option, free of charge from the date of purchase by the original purchaser, for one year any defective or
malfunctioning part.
See information below on "If your BISSELL product should require service".
This warranty applies to product used for personal, and not commercial or rental service. This warranty does not apply to fans
or routine maintenance components such as filters, belts, or brushes. Damage or malfunction caused by negligence, abuse,
neglect, unauthorized repair, or any other use not in accordance with the User's Guide is not covered.
If your bISSEll product should require service:
Contact bISSEll Consumer Services to locate a bISSEll Authorized Service Center in your area.
If you need information about repairs or replacement parts, or if you have questions about your
warranty,
contact bISSEll Consumer Services.
Website or E-mail: Or Call: Or write:
www.bissell.com bISSEll Consumer Services bISSEll homecare, Inc.
Use the “Customer Services” tab. 1-800-237-7691 PO box 3606
Monday - friday 8 a.m. - 10 p.m. ET Grand Rapids, MI 49501
Saturday 9 a.m. - 8 p.m. ET ATTn: Consumer Services
bISSEll hOMECARE, InC. IS nOT lIAblE fOR InCIDEnTAl OR COnSEQUEnTIAl DAMAGES Of
Any
nATURE ASSOCIATED WITh ThE USE Of ThIS PRODUCT. bISSEll’S lIAbIlITy WIll nOT EXCEED
ThE PURChASE PRICE Of ThE PRODUCT.
Some states do not allow the exclusion or limitation of incidental or consequential damages,
so the above limitation or exclusion may not apply to you.
*EXCEPTIOnS AnD EXClUSIOnS fROM ThE TERMS Of ThE lIMITED WARRAnTy
ThIS WARRAnTy IS EXClUSIVE AnD In lIEU Of Any OThER WARRAnTIES EIThER ORAl OR WRITTEn.
Any IMPlIED WARRAnTIES WhICh MAy ARISE by OPERATIOn Of lAW, InClUDInG ThE IMPlIED
WARRAnTIES Of MERChAnTAbIlITy AnD fITnESS fOR A PARTICUlAR PURPOSE, ARE lIMITED TO ThE
OnE yEAR DURATIOn fROM ThE DATE Of PURChASE AS DESCRIbED AbOVE.
Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may
not apply to you.
