Diaphragm Pump
Instruction Manual
background
01
Diaphragm Pump
Have product questions? Need technical suppo?
Please feel free to contact us:
CustomerSe[email protected]
NEED HELP? CONTACT US!
This is the original instruction,Please read all manual instructions carefully
before operating.VEVOR resees clear interpretation of our user manual. The
appearance of the product shall be subject to the product you
received.Please forgive us that we won't inform you again if there is any
technology or software updates on our product.
NMDPA33-G33-45-110
background
02
PRODUCT SPECICATIONS
FEATURES
An incredible feature list, high-quality components, plus amazing
peormance. The three-chamber high-volume design, driven by a
heavy-duty motor produces ow rates of 3.3 GPM, capable of
self-priming up to 6 veical feet, and can run d, making it the
price-to-peormance leader. This pump also oers a variety of
An economical workhorse, the 33 Series is engineered for exibility.
The 3-chamber series are our Heavy-Duty water pump. It provides
high-volume water ow with reduced pump cycling, thanks to the
large three-chamber diaphragm. With the on- demand switch, 3.3
GPM, and 45 PSI, the 33 Series will meet your special requirements
with positive predictable peormance. The 33 Series can reduce ra
pid cycling and allow water to ow back from the outlet side to the i
nlet side of the pump. We also oer a variety of easy-connect tting
s and lters.
easy-connect ttings and lters.
·3 -chamber diaphragm pump
· Continuous duty
· Indust-standard mounting patten
· Run d capable for normal workloads
· Automatic: controlled by pressure switch
· Self priming
· Quiet Operation
· lgnition protected
Propey Specications
Rated Voltage
Rated Pressure
Max. Flow
Inlet/Outlet Diameter
Number of Chamber 3 PCS
110V
45 PSI
3 PCS
3.3 GPM
1/2" MNPT
background
APPLICATIONS
INSTALLATION
03
·Yacht/RV/caravan pressurized water system
·Sprayer xtures (vehicle-mounted sprayers electric sprayers)
·Cleaning machines Humidiers water purication,medical apparatus
·Food beverage lling & liquid transfer
·Solar water system
·Any other pressurization system
1.diaphragm pump with related accessories
2.(at least) pieces of exible, reinforced hose piping, with collapsing
strength of twice the inlet collapsing pressure(hose must be
minimum 1/2"ID)
3.stainless steel hose clamps and screws
4.screws to fasten the pump to the mounting suace
1 electrical cut o switch
1 fuse
1 screwdriver
1 strong cutting implement for tubing (if desired)Teon tape or sealant
1. The pump may be mounted in any position. If mounted veically,
the pump head should be in the down position to avoid leakage into
the motor casing in the event of a malfunction.
2. Secure the feet, but do not compress them. Over tightening the
securing screws may reduce their ability to dissipate noise and
vibration.
3.The inlet and outlet hoses must be 1/2" (13 mm) ID reinforced
hoses. The diameter of branch and individual supply lines from the
outlet should be no smaller than 3/8" (10 mm).
4. Plumb the system using high pressure (2 x pump rating), braided,
exible tubing to minimize vibration/noise.
5.Do not apply inlet pressure in excess of 30psi. In general, t to
avoid any inlet pressure completely.
6.Avoid any kinks or ttings which could ca use excessive restric-
tions.
7.Strainer should be attached to the inlet side.
8.The ttings must be secured to avoid leakage
9.Use clamps at both ends of the hose to prevent air leaks into the
water line.
Materials
Setup
background
04
10. If a check valve is installed in the plumbing, it must have a
cracking pressure of no more than 2 psi. 11. If applying a sealer or
plumbing tape, be careful to not over tighten, as they may be
sucked into
12. This pump should be wired on its own dedicated circuit. Connect
the positive lead (red) to the positive
terminal of your batte and the negative wire(black) to the
negative terminal of your batte.
13. In an easily accessible location, install a switch to control
electricity to the pump. Turn the pump o when
not used for extended periods or when the tank is empty.
14. The electrical circuit should be protected with an over-current
protection device(fuse) in the positive
lead. This pump requires a 15 amp fuse.
15. The pump circuit should not include any other electrical loads.
16. As the water supply pump is non-essential, reference the wire
Cha under the electrical information. Be
sure to have the correct wire sizing for the length of wire you are
using.
17.After installation, check the voltage at the pump motor. Voltage
should be checked when the pump is operating. Full voltage must
be available at the pump motor at times.
Notes
1. FIexible potable water hose or PEX tubing is recommended
instead of rigid piping at the pump. If you choose to use rigid piping,
provide a sho length of hose between the pipe and the pump to
avoid noise and vibration
2. We does not recommend the use of meta | ttings. When possible,
use the provided plastic ttings. 3.Do not adjust the bypass
personally without the help of technician.
4. Lack of sanitizing and maintenance is one of the main reasons for
the under peormance of the pump. Please do maintenance and
winterize the pump at appropriate times, especially before and after
a period of storage.
5. All 110 VAC pump motors and systems, MUST be ground per local
and state electrical codes.
background
ACCESSORIES
EXPLODED VIEWS
05
Item
Quantity
Hose Adapter
2
Filter
Hexagon Bolt
Sealing Tape
1
1
1
KEY Description Quantity
A
B
C
D
1
2
3
4
5
6
Pump Head Assembly
Valve Assembly
Diaphragm Assembly
Motor Assembly
Pressure Switch
Diaphragm of Pressure Switch
Pump Head
Diaphragm
Iron Feet
Motor
1
1
1
1
1
1
1
1
1
1
background
PRODUCT SIZE
TROUBLESHOOTING
06
•Check lines for kinks.
Plumbing lines or ttings may be too small.
Clean faucets and lters.
•Check tting tightness for air leaks.
PULSATING FLOW— PUMP CYCLES ON AND OFF
•Restricted in take or discharge line
• Air leak in intake line.
•Punctured pump diaphragm
•The initial amp supply is not enough to suciently sta the motor.
•Debris clogs in the valves
•Crack in the pump housing.
FAILURE TO PRIME BUT MOTOR OPERATES - NO
PUMP DISCHARGE
• Loose or improper wiring.
•The pump circuit has no power.
• Blown fuse.
•Failed pressure switch.
•Defective motor.
MOTOR FAILS TO TURN ON
• Punctured diaphragm.
•Discharge line leak
Defective pressure switch.
•Insucient voltage.
•Clogged valves in the pump head.
PUMP FAILS TO TURN OFF AFTER ALL FIXTURES ARE CLOSED
• Air leak at the pump intake.
•AccumuIation of debris inside pump or plumbing.
•Worn pump bearing (possibly accompanied by loud noise).
•Punctured diaphragm
•Defective motor.
LOW FLOW AND PRESSURE
background
Install the pump as the picture 1
CAUTION
FCC INFORMATION
07
• Check if the mounting feet are compressed too tightly.
•ls the mounting suace exible? If so, it may be adding noise.
•Check for loose head/screws.
•If the pump is plumbed with rigid pipe,then it may transmit noise
more easily.
This device complies with Pa 15 of the FCC Rules. Operation is
subject to the following two conditions:(1)This device may not cause
harmful inteerence, and (2)thisdevice must accept any inteerenc
ereceived , including inteerence that may cause undesired
operation.
This product is subject to the provision of European Directive
2012/19/EC. The symbol showing a wheelie bin crossed through
indicates that the product requires separate refuse collection in the
European Union. This applies to the product and all accessories
marked with this symbol. Products marked as such may not be
discarded with normal domestic waste, but must be taken to a
collection point for recycling electrical and electronic devices
Please do follow the instruction manual to install the product. Any
action outside what is recommended in this manual may bring
damage to the pump. Any inappropriate installation or operation
that causes the pump damage is not covered by warranty.
Defective motor.
TIPS:The range of pressure regulation is limited. Please operate
under the guidance of professional technicians, otherwise the
machine may not work normally
NOISY
background
08
*There are any minor changes to the numbers included in the user
manual without prior notice.
Manufacturer: Xiamen Newmao Pump Co., Ltd
Add2nd Pak of Zone Ⅲ, Floor 3, Main Building of Huaxin General
Facto;, No. 216, Huanzhu Road, Qiaoying Street, Jimei District,Xiamen
background
E-mail: CustomerSeice@vevor.com
