Vacuum cleaner
Operating instructions
en-AU/NZ
M.-Nr. 12 963 210
HS22
Contents
2
Warning and Safety instructions ............................................................................... 4
Sustainability and environmental protection.......................................................... 9
Guide to the appliance................................................................................................. 10
Familiarisation................................................................................................................ 12
Accessories included ....................................................................................................
12
3D4U ...............................................................................................................................
12
Network connection ......................................................................................................
12
Symbols in the display...................................................................................................
13
How the vacuum cleaner bag change indicator works .............................................
13
Function of the exhaust filter change indicator..........................................................
13
Motor protection filter ...................................................................................................
13
Commissioning.............................................................................................................. 14
Attaching the suction hose ..........................................................................................
14
Removing the suction hose .........................................................................................
14
Connecting the suction hose to the handle ..............................................................
14
Connecting the handle to the suction tube ...............................................................
14
Connecting the suction tube to the adjustable floorhead .......................................
15
Activating the network function ...................................................................................
15
Operation........................................................................................................................ 16
Adjusting the telescopic tube ......................................................................................
16
Adjusting the floorhead ................................................................................................
16
Vacuuming staircases ...................................................................................................
17
Unwinding the mains cable ..........................................................................................
17
Rewinding the mains cable ..........................................................................................
17
Switching on and off .....................................................................................................
18
Update ........................................................................................................................
18
Regulating the suction power.......................................................................................
18
Foot switches..................................................................................................................
18
Interim suction power levels.........................................................................................
18
Removing accessories ..................................................................................................
19
Adjusting the 2-in-1 upholstery and crevice nozzle...................................................
19
Using the dusting brush integrated in the Comfort handle2.0 (depending on
the model) ......................................................................................................................
20
Park system for pauses during vacuuming ................................................................
20
Park system for storage ................................................................................................
21
Cleaning and care ......................................................................................................... 21
Purchasing accessories.................................................................................................
22
Vacuum cleaner bag change indicator ........................................................................
22
Removing the vacuum cleaner bag .............................................................................
22
Inserting the vacuum cleaner bag ...............................................................................
23
When the exhaust filter change indicator lights up...................................................
23
Contents
3
Replacing the AirClean Plus 50, Silence AirClean 50, Active AirClean 50 and
HEPA AirClean 50 exhaust filters ...............................................................................
24
Replacing one type of exhaust filter with another ....................................................
24
Cleaning the motor protection filter ...........................................................................
25
Replacing the thread lifters ..........................................................................................
25
Cleaning the vacuum cleaner and accessories..........................................................
26
Troubleshooting............................................................................................................. 27
Technical data................................................................................................................ 28
Copyright and licences ..................................................................................................
28
Electrical connection AU, NZ .......................................................................................
28
Service............................................................................................................................. 29
Contact in case of malfunction ....................................................................................
29
Warranty ..........................................................................................................................
29
Optional accessories.................................................................................................... 29
Warning and Safety instructions
4
This vacuum cleaner conforms to current safety requirements. In-
appropriate use can lead to personal injury and damage to prop-
erty.
Please read the operating instructions before using the vacuum
cleaner for the first time. They contain important information on the
safety, use, cleaning and care of the vacuum cleaner. This will pre-
vent both personal injury and damage to the appliance.
In accordance with standard IEC60335-1, Miele expressly and
strongly advises that you read and follow the instructions in the
“Commissioning” section as well as the warning and safety notes.
Miele cannot be held liable for injury or damage caused by non-
compliance with these instructions.
Keep these operating instructions in a safe place and pass them on
to any future owner.
Always disconnect the vacuum cleaner from the power supply
when you have finished using it, before changing any accessories
and before performing cleaning, care and troubleshooting. Remove
the plug from the socket.
Warning and Safety instructions
5
Correct application
This vacuum cleaner is intended for cleaning flooring in domestic
households and similar residential environments. This vacuum
cleaner is not suitable for use on construction sites.
This vacuum cleaner can be used for all normal cleaning of carpets,
rugs and robust hard flooring.
This vacuum cleaner is not intended for outdoor use.
This vacuum cleaner is intended for use at altitudes of up to
4000m above sea level.
The vacuum cleaner must only be used to vacuum dry floor sur-
faces. Do not vacuum people or animals. Any other types of use,
modifications or alterations are not permitted.
The vacuum cleaner can only be used by people (including chil-
dren) with reduced physical, sensory, or mental capabilities, or lack of
experience or knowledge, if they are supervised whilst using it or
have been shown how to use it in a safe way and understand and re-
cognise the consequences of incorrect operation.
Safety with children
Danger of suffocation. Packaging, e.g. plastic wrappings, must be
kept out of the reach of babies and children. Whilst playing, children
could become entangled in packaging or pull it over their head and
suffocate.
Children under 8 years of age must be kept away from the vacuum
cleaner unless they are constantly supervised.
Children aged 8 and older may only use the vacuum cleaner
without supervision if they have been shown how to use it in a safe
manner. Children must be able to understand and recognise the pos-
sible dangers caused by incorrect operation.
Children must not be allowed to clean or maintain the vacuum
cleaner unsupervised.
Please supervise children in the vicinity of the vacuum cleaner and
do not let them play with it.
Warning and Safety instructions
6
Technical safety
Check both the vacuum cleaner and all accessories supplied with
it for any visible signs of damage before use. Do not use a damaged
vacuum cleaner or damaged accessory.
Compare the connection data on the data plate of the vacuum
cleaner (mains voltage and frequency) with that of the mains electri-
city supply. This data must match exactly. Without modifications, the
vacuum cleaner is suitable for 50Hz or 60Hz.
The mains electrical outlet must be fitted with an appropriate cir-
cuit breaker.
Temporary or permanent operation with a self-sufficient or non-
mains synchronous energy supply system (e.g. isolated networks,
back-up systems) is possible. A requirement for the operation is that
the energy supply system complies with all current local and national
requirements that apply to stand-alone, solar and/or battery systems.
The protective measures provided in the domestic installation and in
this Miele product must also be assured in their function and opera-
tion in isolated operation or in non-mains synchronous operation, or
replaced with equivalent measures in the installation.
While the vacuum cleaner is under warranty, repairs should only be
undertaken by a Miele authorised service technician. Otherwise the
warranty will be invalidated.
Do not use the vacuum cleaner if the cable is damaged. If the
cable is damaged it must be replaced together with a complete cable
rewind. For safety reasons this must only be done by Miele Service or
a Miele authorised service technician.
Do not pull or carry the vacuum cleaner by the cable, and be care-
ful not to damage the cable when withdrawing the plug from the
socket. Keep the cable away from sharp edges and do not let it get
squashed, for example, under a door. Avoid running the vacuum
cleaner over the cable. This could damage the cable, plug or socket.
The appliance must not be used if any of these have suffered dam-
age.
Repairs should only be carried out by a Miele authorised service
technician. Repairs and other work by unqualified persons can cause
considerable danger to users.
Warning and Safety instructions
7
Correct use
Do not use the vacuum cleaner without the vacuum cleaner bag,
motor protection filter and exhaust filter in place.
It is not possible to close the dust compartment lid if the vacuum
cleaner bag is not inserted. Do not force it.
Before closing the dust compartment lid, always make sure that
the vacuum cleaner bag has been inserted far enough and has clearly
clicked into position.
Do not vacuum up anything which has been burning or is still glow-
ing e.g. cigarettes, ashes or coal, whether glowing or apparently ex-
tinguished.
Do not use the vacuum cleaner to vacuum toner dust. Toner, such
as that used in printers and photocopiers, can conduct electricity.
Do not use the vacuum cleaner to vacuum up any water, liquid or
damp dirt. Wait until any freshly cleaned or shampooed rugs or car-
pets are completely dry before attempting to vacuum.
Do not vacuum up any inflammable or combustible liquids or
gases and do not vacuum in areas where such substances are stored.
Do not vacuum at head height and do not let the suction get any-
where near a person's head.
Warning and Safety instructions
8
Cleaning
Do not let the vacuum cleaner get wet. Clean only with a dry cloth
or slightly damp cloth when disconnected from the mains supply.
Accessories and spare parts
It is not advisable to vacuum directly with the handle, i.e. without
an accessory attached as the rim could get damaged and you could
hurt yourself on sharp edges.
Only use vacuum cleaner bags, filters and original accessories
bearing the Miele logo on the packaging. The manufacturer cannot
otherwise guarantee the safety of the product.
Miele can only guarantee the safety of the appliance when genuine
Miele replacement parts are used. Faulty components must only be
replaced with genuine Miele replacement parts.
Miele will guarantee to supply functional spare parts for a min-
imum of 10years and up to 15years following the discontinuation of
your vacuum cleaner.
Transport
The packaging material protects the vacuum cleaner from trans-
port damage. We recommend you keep the packaging for transport
purposes.
Sustainability and environmental protection
9
Disposing of the packaging ma-
terial
The packaging material is used for hand-
ling and protects the appliance from
transport damage. The packaging ma-
terial used is selected from materials
which are environmentally friendly for
disposal and can generally be recycled.
Recycling the packaging material re-
duces the use of raw materials. Use ma-
terial-specific collection points for valu-
able materials and take advantage of re-
turn options.
We recommend you keep the packaging
material for transport purposes.
Disposing of the vacuum
cleaner bags and filters
Vacuum cleaner bags and filters are
made from environmentally friendly ma-
terials. You can dispose of the filters
with normal household waste. You can
also dispose of the vacuum cleaner bag
with normal household waste, providing
it contains general household dust only.
Disposing of your old appliance
Electrical and electronic appliances con-
tain many valuable materials. They also
contain certain materials, compounds
and components which were essential
for their correct functioning and safety.
These could be hazardous to human
health and to the environment if dis-
posed of with household waste or if
handled incorrectly. Please do not,
therefore, dispose of your old appliance
with household waste.
Instead, please make use of officially
designated collection and disposal
points to dispose of and recycle elec-
trical and electronic appliances in your
local community, with your dealer or
with Miele, free of charge. By law, you
are solely responsible for deleting any
personal data from the old appliance
prior to disposal (depending on coun-
try). You are legally obliged to remove
any old batteries which are not securely
enclosed by the appliance and to re-
move any lamps without destroying
them, where this is possible. These
must be taken to a suitable collection
point where they can be handed in free
of charge. Please ensure that your old
appliance poses no risk to children while
being stored for disposal.
Guide to the appliance
10
A
Guide to the appliance
11
a
Suction hose
b
Dust compartment lid release button
c
Hose connector
d
Park system for pauses during vacuuming
e
Mains cable with plug
f
Accessories compartment for 2-in-1 upholstery and crevice nozzle
g
Control field
h
Park system for storage (underside of the vacuum cleaner)
i
Original Miele exhaust filter*
j
Vacuum cleaner bag holder
k
Original Miele vacuum cleaner bag
l
Carrying handle
m
Floorhead*
n
Release buttons
o
Telescopic tube
p
Telescopic tube release mechanism
q
Dusting brush
r
Comfort handle 2.0
t
+/- foot switches for setting the suction power
u
Optical interface for the Customer Service Department
v
Display
w
On/Off foot switch
x
WiFi signal status
y
Exhaust filter change indicator
z
Vacuum cleaner bag change indicator
{
Foot switch for automatic cable rewind
|
Selected power level
}
Symbol for selected power level
~
Vacuum cleaner bag change indicator
* These features depend on the model and may vary or may not be available on
your vacuum cleaner.
12
Familiarisation
This vacuum cleaner can be used for
daily cleaning of carpets, rugs and ro-
bust hard floors.
Miele offers a range of suitable ac-
cessories for many special applica-
tions (see “Optional accessories”).
Accessories included
Dusting brush
For vacuuming scratch-resistant
surfaces, e.g. keyboards or vacu-
uming up crumbs.
2-in-1 upholstery and crevice
nozzle
For cleaning in folds, crevices and
corners as well as for vacuuming
upholstered furniture, mattresses,
cushions, curtains, etc.
3D4U
With 3D4U, Miele offers free accessor-
ies to download for your 3D printer
(www.miele.com, Service, 3D4U).
Network connection
The vacuum cleaner is equipped with an
integrated WiFi module. The WiFi mod-
ule makes it possible to connect to your
home network and to use the Miele app
on a mobile device.
Networking the vacuum cleaner allows
you to do the following, among other
things:
- Access status information
- Order more vacuum cleaner bags for
your vacuum cleaner
- Access information about accessories
based on your usage behaviour
- Keep the vacuum cleaner up to date
with the latest Miele developments
via software updates
Availability of the WiFi connection
The WiFi connection shares a frequency
range with other appliances (including
microwave ovens and remote control
toys). This can give rise to sporadic or
even complete connection failures.
Therefore, the availability of featured
functions cannot be guaranteed.
13
Symbols in the display
Symbols are shown on the display to in-
dicate the type of use the power levels
are suitable for.
Curtains, fabric
Upholstery, cushions
A
Automatic adjustment of the
suction power to the surface
Cut pile carpets, rugs and
runners
Hard floors and heavily
soiled carpets and rugs
Manual selection of interim
suction power levels
Saved interim suction power
level
Other symbols for operation and func-
tion:
- Reduces the suction power
+ Increases the suction power
On/Off
Automatic cable rewind
How the vacuum cleaner bag change
indicator works
The vacuum cleaner bag change indic-
ator is set for normal household dust.
This generally contains a mixture of
dust, hair, threads, carpet fluff, grit, etc.
However, if the vacuum cleaner has
been used to vacuum up fine dust, such
as drilling dust, sand, plaster dust or
flour, the pores of the vacuum cleaner
bag will become blocked very quickly.
The indicator will indicate that the va-
cuum cleaner bag is “full” even when it
is not. The vacuum cleaner bag must be
replaced if this is the case.
If, on the other hand, you vacuum up a
significant amount of hair, carpet lint,
etc., the vacuum cleaner bag will be full
to bursting before the indicator reacts.
Function of the exhaust filter change
indicator
The exhaust filter change indicator lights
up after approximately 50hours of op-
eration, which is equivalent to about a
year of average use. Change the exhaust
filter when the indicator on the vacuum
cleaner lights up. The level of soiling of
the motor protection filter should also
be checked at this point.
Each time you replace the exhaust filter
and – if necessary – clean the motor
protection filter, you must reset the in-
dicator. Please refer to the “When the
exhaust filter change indicator lights up”
section in “Cleaning and care”.
Motor protection filter
Your vacuum cleaner is equipped with a
Lifetime motor protection filter as
standard. It will last for the entire ser-
vice life of the vacuum cleaner and does
not need to be replaced.
14
Commissioning
Attaching the suction hose
Insert the hose connector into the
suction opening on the vacuum
cleaner until it clicks into position. To
do this, line up the guides on the two
pieces.
Removing the suction hose
Press the release buttons at the side
of the hose connector, and lift the
hose from the suction opening.
Connecting the suction hose to the
handle
Fit the suction hose connector into
the handle until it clicks into position.
Connecting the handle to the suction
tube
Insert the handle into the suction
tube until it clicks into position. To do
this, line up the guides on the two
pieces.
To detach the handle from the suction
tube, press the release button and
pull the handle out of the suction
tube, twisting it slightly as you do so.
15
Connecting the suction tube to the ad-
justable floorhead
Push the suction tube into the floor-
head and turn it clockwise or anti-
clockwise until it clicks into position.
To separate the suction tube from the
floorhead, press the release button
and pull the suction tube away from
the floorhead, twisting it slightly as
you do so.
Activating the network function
Your vacuum cleaner is equipped with
an integrated WiFi module.
Connecting your vacuum cleaner to your
WiFi network will increase energy con-
sumption.
Make sure that you have sufficient
signal strength for your WiFi network
where the vacuum cleaner will be
used.
To set up this feature, you will need:
1. A WiFi network
2. Miele app
3. A Miele user account. You can create
a user account via the Mieleapp.
Scan the QR code to download the
Miele app (if you do not have it yet).
Open the Miele app and set up a user
account.
To start networking, scan the QR
code again and follow the user navig-
ation instructions in the Miele app.
The vacuum cleaner fan is switched off
for the duration of the connection at-
tempt. The vacuum cleaner display in-
dicates that the connection has been
established successfully.
You can also exit connection mode
early without having established a con-
nection. To do this, switch the vacuum
cleaner off and on again using the On/
Off foot switch.
16
Operation
Adjusting the telescopic tube
One part of the telescopic tube is
packed inside the other, and it can be
adjusted to suit your height for comfort-
able vacuuming.
Grasp the release mechanism and ad-
just the telescopic tube to the re-
quired length.
Adjusting the floorhead
Depending on the model, your vacuum
cleaner will be fitted as standard with
one of the floorheads illustrated.
Please observe the flooring manufac-
turer’s cleaning and care instructions.
Clean hard flooring which is not sus-
ceptible to scratching, as well as floor-
ing with gaps or deep crevices in it, with
the brush protruding:
Press the foot switch.
Vacuum carpets and rugs with the brush
retracted:
Press the foot switch.
17
Vacuuming staircases
Risk of injury caused by falling
vacuum cleaner.
You or others may be injured if the
vacuum cleaner should fall from the
stairs.
When vacuuming stairs, it is best to
start at the bottom of the stairs and
move upwards.
The adjustable floorhead can also be
used for vacuuming the stairs.
Unwinding the mains cable
Pull the mains cable out to the re-
quired length.
Insert the power plug into the socket.
Risk of damage due to overheat-
ing.
The mains cable may overheat after a
long period of use.
If vacuuming for longer than
30minutes, the cable must be pulled
out all the way.
Rewinding the mains cable
Remove the plug from the socket.
Step briefly on the cable rewind foot
switch.
The cable will then retract itself fully into
the vacuum cleaner.
You can interrupt the cable rewind at
any point.
Give the cable a short pull while re-
winding.
18
Switching on and off
Press the On/Off foot switch .
Update
Miele will provide you with updates
at irregular intervals. This will update the
software in your vacuum cleaner and
ensure that it is in line with the latest
Miele developments.
After switching on the vacuum cleaner,
you will be informed if there is an up-
date available.
To start installing the update, press
the + foot switch.
A progress bar will show you the status
of the installation.
To postpone the installation of the up-
date, press the - foot switch.
The next time you switch on the vacuum
cleaner, you will be prompted to install
the update again.
Regulating the suction power
The suction power can be regulated to
suit the type of flooring being cleaned.
Reducing the suction power reduces the
amount of effort required to manoeuvre
the floorhead.
The selected power level is shown as a
symbol and via an orange power indic-
ator in the vacuum cleaner display, see
the “Symbols in the display” section in
“Familiarisation”.
Foot switches
The first time the vacuum cleaner is
switched on, the highest power level
will be selected automatically.
After that, the vacuum cleaner will
switch on at the power level which was
used previously.
Press the + foot switch to select a
higher suction power level.
Press the - foot switch to select a
lower suction power level.
Interim suction power levels
You can deviate from the preset power
levels and customise the suction
power of your vacuum cleaner to meet
your individual requirements.
To do this, proceed as follows:
Press and hold the + or - button.
The display shows the symbol for
manual selection of interim suction
power levels.
19
Press and hold the + or - button until
the desired suction power is reached.
Release the button.
Wait 5seconds and do not touch the
controls; the interim suction power set-
ting will be saved to the next highest or
lowest power level. A tick appears to
confirm that the setting has been saved.
The symbol for the saved interim suc-
tion power level is displayed.
The next time the vacuum cleaner is
used it will switch on with the saved in-
terim suction power level. This setting
will be deleted if you then select one of
the standard 4 power levels.
Removing accessories
Press the release button on the ac-
cessories compartment.
The accessories compartment will then
open.
Remove the combined upholstery and
crevice nozzle.
Press down firmly on the accessories
compartment lid to close it.
Adjusting the 2-in-1 upholstery and
crevice nozzle
Your vacuum cleaner is equipped with a
combined upholstery and crevice nozzle
as standard.
Crevice nozzle
Once removed from the accessories
compartment, the 2-in-1 upholstery and
crevice nozzle is suitable for cleaning in
folds, crevices or corners.
Upholstery nozzle
Press the release button of the 2-in-1
upholstery and crevice nozzle and
swivel the upholstery nozzle over the
guide until it clearly engages in posi-
tion.
When you have finished cleaning,
press the release button and swivel
the upholstery nozzle back into its ori-
ginal position. Swivel the 2-in-1 uphol-
stery and crevice nozzle until the re-
lease button clearly engages in posi-
tion.
20
Using the dusting brush integrated in
the Comfort handle2.0
Press the release button on the dust-
ing brush and push the brush out until
it clearly engages in position.
Press the release button and turn the
dusting brush to the side.
Push the dusting brush down over the
guide until it releases from the handle.
Push the dusting brush onto the suc-
tion tube until it clicks into place.
When you have finished dusting
Press the release button and pull the
dusting brush off the suction tube.
Push the dusting brush back onto the
Comfort handle2.0 until it clicks into
place.
Push the dusting brush to its original
position so the handle can be pushed
back into the suction tube.
Park system for pauses during vacu-
uming
The park system allows you to conveni-
ently park the suction tube and floor-
head during pauses.
Risk of injury caused by vacuum
cleaner falling over.
Do not use the park system if the va-
cuum cleaner is on a sloping surface,
e.g. a ramp.
21
Slot the floorhead into the park sys-
tem on the vacuum cleaner.
Park system for storage
Risk of electric shock from mains
voltage.
The mains voltage is applied to the
vacuum cleaner even if it is switched
off.
Always disconnect the vacuum
cleaner from the power supply when
you have finished using it. Remove
the plug from the socket.
Stand the vacuum cleaner upright.
Retract the telescopic tube fully.
Slot the floorhead downwards into
the parking attachment on the under-
side of the vacuum cleaner.
Cleaning and care
Risk of electric shock from mains
voltage.
The mains voltage is applied to the
appliance even if it is switched off.
Before cleaning and care, switch the
appliance off at the wall socket and
unplug it.
The Miele filter system consists of 3 ac-
cessories:
- Original Miele vacuum cleaner bag
(modelTU)
- Original Miele exhaust filter
- Motor protection filter
The vacuum cleaner bag and exhaust fil-
ter will need to be replaced from time to
time to ensure that your vacuum cleaner
performs efficiently.
We recommend using only genuine
Miele accessories bearing the Miele
logo on the packaging. Only these will
guarantee the optimum suction power
of your vacuum cleaner and the best
possible cleaning results.
Vacuum cleaner bags with the Miele
logo on the packaging are not made
from paper or paper-based materials,
nor do they have a cardboard collar.
This is why Miele dustbags are partic-
ularly long-lasting and reliable.
Please note that faults and damage
caused by use of accessories which do
not bear the Miele logo on the pack-
aging are not covered by the vacuum
cleaner warranty.
22
Purchasing accessories
You can order genuine Miele accessor-
ies from the Miele online shop, Miele
Customer Service or your Miele dealer.
You can identify genuine Miele ac-
cessories by the Miele logo on the pack-
aging.
Every packet of original Miele vacuum
cleaner bags contains 4vacuum cleaner
bags and one AirClean exhaust filter.
Original Miele multipacks contain 16va-
cuum cleaner bags and 4AirClean ex-
haust filters.
For information on purchasing genuine
Miele exhaust filters, see the sales
designations in “Optional accessories”
– “Filters”.
Vacuum cleaner bag change indicator
Replace the vacuum cleaner bag when
indicated on the vacuum cleaner dis-
play.
Blocked pores reduce the suction
power of the vacuum cleaner.
Dispose of vacuum cleaner bags when
they are full. Do not attempt to re-use
vacuum cleaner bags.
Removing the vacuum cleaner bag
Press the release buttons at the side
of the hose connector and pull the
hose out of the suction opening.
Press the release button in the re-
cessed grip for the dust compartment
lid and raise the lid as far as it will go.
Lift the vacuum cleaner bag holder
with one hand.
Pull out the vacuum cleaner bag with
the other hand using the grip.
The turquoise catch element will lift up.
The turquoise catch element prevents
the dust compartment lid from closing
when there is no vacuum cleaner bag
inserted.
Do not force it.
23
Inserting the vacuum cleaner bag
Lift the vacuum cleaner bag holder
with one hand.
With the other hand, insert the new
vacuum cleaner bag into the raised
vacuum cleaner bag holder as far as it
will go. Leave the vacuum cleaner bag
folded up when you take it out of the
packet.
Make sure that the collar of the va-
cuum cleaner bag is fully inserted into
the guide on both sides (see magnified
image).
The turquoise catch element closes and
clicks into position.
Close the dust compartment lid se-
curely, making sure it clicks into posi-
tion. Take care not to trap the vacuum
cleaner bag when doing so.
Insert the hose connector into the
suction opening on the vacuum
cleaner until it clicks into position. To
do this, line up the guides on the two
pieces.
When the exhaust filter change indic-
ator lights up
Replace the exhaust filter when indic-
ated on the vacuum cleaner display. The
level of soiling of the motor protection
filter should also be checked at this
point, see “Cleaning the motor protec-
tion filter”.
You must reset the indicator each time
you replace the exhaust filter. The va-
cuum cleaner must be switched on to
do this.
Press and hold the + button.
A countdown is displayed and the va-
cuum cleaner fan is switched off.
The indicator will light up green to show
it has been reset successfully. The indic-
ator will then go out and reset to zero.
The indicator can only be reset when
indicating that it is time to change
the exhaust filter. It cannot be reset
at other times.
24
Replacing the AirClean Plus 50, Si-
lence AirClean 50, Active AirClean 50
and HEPA AirClean 50 exhaust filters
Do not use more than one exhaust
filter at a time.
Open the dust compartment lid.
1
2
2
If you wish to fit an AirClean exhaust
filter, see “Replacing one type of ex-
haust filter with another”.
Pull the exhaust filter forwards and re-
move it upwards.
2
1
2
Insert the new exhaust filter down-
wards, making sure it goes in properly,
then press it backwards on both sides
until it clicks into place.
Damage due to contamination in
the dust compartment.
Large quantities of dust may get into
the dust compartment and damage
components if the vacuum cleaner
bag has not clicked into position.
Before closing the dust compartment
lid, always make sure that the va-
cuum cleaner bag has been inserted
and the catch element is closed.
Close the dust compartment lid se-
curely, making sure it clicks into posi-
tion. Take care not to trap the vacuum
cleaner bag when doing so.
Replacing one type of exhaust filter
with another
Do not use more than one exhaust
filter at a time.
Depending on the model, your vacuum
cleaner will be fitted as standard with
one of the following exhaust filters:
b – e
a
a AirClean
b AirClean Plus 50 (light blue)
c Silence AirClean 50 (grey)
d Active AirClean 50 (black)
e HEPA AirClean 50 (white)
25
When changing the filter, please note
If you wish to replace exhaust filter b, c,
d or e with filter a, it is essential that
you also fit the filter grille, see the “Fil-
ter” section in “Optional accessories”.
1
2
Cleaning the motor protection filter
Open the dust compartment lid.
Remove the vacuum cleaner bag.
1
2
2
Release the motor protection filter
forwards and remove it upwards from
the dust compartment.
Risk of damage caused by incor-
rect cleaning.
The motor protection filter can be-
come damaged and be less effective
as a result.
Do not clean the motor protection fil-
ter with water. Do not use pointed or
sharp-edged objects to clean the fil-
ter.
Clean the motor protection filter with
a dry dust cloth or dust brush.
Place the hinges of the motor protec-
tion filter carefully into the hinge re-
cesses in the dust compartment and
lock the motor protection filter so it
clicks into place.
Insert the vacuum cleaner bag into
the holder until the catch element is
firmly closed.
Close the dust compartment lid se-
curely, making sure it clicks into posi-
tion. Take care not to trap the vacuum
cleaner bag when doing so.
Replacing the thread lifters
(not possible for models with FlexTeQ/
AllFloor floorheads)
Replace the thread lifters if the pile has
worn down.
26
Lever the thread lifters from the slots.
To do so use a suitable tool, e.g. a flat-
head screwdriver.
Fit new thread lifters.
Replacement parts are available from
your Miele dealer or from the Miele
Spare Parts Dept.
Cleaning the vacuum cleaner and ac-
cessories
Risk of electric shock from mains
voltage.
The mains voltage is applied to the
vacuum cleaner even if it is switched
off.
Before cleaning, switch the appliance
off at the wall socket and unplug it.
Risk of electric shock from mains
voltage.
If moisture gets into the vacuum
cleaner, there is a risk of electric
shock.
Do not let the vacuum cleaner get
wet.
- Vacuum textile surfaces using a va-
cuum cleaner on the lowest power
level with the dusting brush fitted.
- The vacuum cleaner and all plastic ac-
cessories should be cleaned with a
commercially available cleaner suit-
able for plastic.
Static charge can cause a build-up of
dust on the plastic parts of the vacuum
cleaner. This should be removed using a
soft, dry cloth.
Damage due to unsuitable clean-
ing agents.
All surfaces are susceptible to
scratching. Contact with unsuitable
cleaning agents can alter or discolour
the external surfaces.
Do not use abrasive cleaning agents,
glass cleaning agents, all-purpose
cleaners or oil-based care products.
Cleaning the dust compartment
The dust compartment can, if neces-
sary, be cleaned using a dry duster,
brush or, if available, a second vacuum
cleaner to vacuum the dust out.
Also clean the underside of the dust
compartment lid.
27
Troubleshooting
Many malfunctions and faults that can occur in daily operation can be easily
remedied. You can save time and money in many cases, as you do not need to call
the Miele Customer Service Department.
Information to help you remedy faults yourself can be found at www.miele.com/
service.
The following tables are designed to help you to find the cause of a malfunction or a
fault and to resolve it.
Risk of electric shock from mains voltage.
The mains voltage is applied to the appliance even if it is switched off.
Before dealing with any problems, switch the appliance off at the wall socket
and unplug it.
Problem Cause and remedy
The vacuum cleaner
switches off automatic-
ally.
A temperature limiter switches the vacuum cleaner off
automatically if it gets too hot.
This can occur if, for instance, large objects block the
suction tube or when the vacuum cleaner bag is full or
contains particles of fine dust. A heavily soiled motor
protection filter or exhaust filter can also be the cause
of overheating.
Switch the vacuum cleaner off immediately using
the On/Off foot switch . Switch off at the wall
socket and unplug it.
After removing the cause, wait for approximately 20–
30minutes to allow the vacuum cleaner to cool down.
It can then be switched on again.
28
Technical data
Bluetooth
Frequency range 2.40–2.4835GHz
Maximum transmission power <10mW
WiFi
Frequency range 2.40–2.4835GHz
Maximum transmission power <100mW
Electricity consumption in standby mode
with WiFi activated 0,95W
with WiFi deactivated 0,95W
Copyright and licences
For the purpose of operating and controlling the vacuum cleaner, Miele uses propri-
etary or third-party software that is not covered by open source licensing terms.
This software/these software components are protected by copyright. The copy-
rights held by Miele and third parties must be respected.
In addition, the vacuum cleaner contains software components which are distrib-
uted under open source licensing terms. The open source components contained in
the appliance along with the corresponding copyright notices, copies of the licens-
ing terms valid at the time, and any further information can be accessed locally by
IP via a web browser (http://<IP address>/Licenses). The liability and warranty ar-
rangements for the open source licences displayed in this location only apply in re-
lation to the respective rights holders.
Electrical connection AU, NZ
All work must be carried out by a suitably qualified and competent person in strict
accordance with national and local safety regulations. The voltage and rated load
are given on the data plate located underneath the vacuum cleaner. Please ensure
that these match the household mains supply. The appliance is supplied with a
cable and moulded plug ready for connection to a 230V/50Hz AC single phase
supply.
Test Marks Electrical safety
RCM Mark
Electrically suppressed
according to AS/NZS CISPR 14.1
29
Service
Information to help you rectify faults
yourself and about Miele spare parts
can be found at www.miele.com/ser-
vice.
Contact in case of malfunction
In the event of any faults which you can-
not remedy yourself, please contact
your Miele Dealer or Miele Service.
Contact information for Miele Service
can be found at the end of this docu-
ment.
Please note that telephone calls may be
monitored and recorded for training pur-
poses and that a call-out charge will be
applied to service visits where the prob-
lem could have been resolved as de-
scribed in this booklet.
Warranty
For information on the appliance war-
ranty specific to your country please
contact Miele. See end of this docu-
ment for contact details.
In the UK, your appliance warranty is
valid for 2 years from the date of pur-
chase. However, you must activate your
cover by calling 0330 160 6640 or re-
gistering online at www.miele.co.uk.
Optional accessories
Please observe the flooring manufac-
turer’s cleaning and care instructions.
Please note that faults and damage
caused by use of accessories which
do not bear the Miele logo on the
packaging are not covered by the va-
cuum cleaner warranty.
These and many other products can be
ordered from the Miele online shop, the
Miele Customer Service Department or
your Miele dealer.
Certain models are supplied with one or
more of the following accessories as
standard.
Floorheads / brushes
(only available in selected countries)
AllFloor (SBDAF) floorhead
Flat floorhead for cleaning underneath
very low furniture. It is also quiet, light
and stands out due to its very good
pick-up of coarse dirt.
TurboTeQ Turbobrush (STB 305-3)
This brush is ideal for cleaning cut pile
carpet.
Parquet Twister floorbrush with swivel
action (SBB 300-3)
With natural bristles for vacuuming
smooth hard floors and small gaps.
Parquet Twister XL floorbrush with
swivel action (SBB 400-3)
With natural bristles for quickly vacuum-
ing smooth hard floors and small gaps.
30
Other accessories
(only available in selected countries)
Turbo Mini hand turbobrush (STB 101)
For vacuuming upholstery, mattresses
or car seats, etc.
Universal brush (SUB 20)
For dusting books, shelves, etc.
Radiator brush (SHB 30)
For dusting radiators, narrow shelves
and crevices.
Mattress nozzle (SMD 10)
For vacuuming upholstery, mattresses,
cushions, curtains, covers etc.
Crevice nozzle, 300mm (SFD 10)
Extra long crevice nozzle for cleaning in
folds, crevices and corners.
Crevice nozzle, 560mm (SFD 20)
Flexible crevice nozzle for vacuuming
hard to reach places.
XL upholstery nozzle (SPD20)
Wide upholstery nozzle for cleaning up-
holstery, mattresses and cushions.
Filters
AirClean Plus 50 exhaust filter
(SF-AP 50)
Effective filtration for particularly clean
room air.
Exhaust filter Silence AirClean 50
(SF-SA 50)
For a significant reduction in noise
whilst vacuuming.
Active AirClean 50 exhaust filter
(SF-AA 50)
For a significant reduction of unpleasant
odours. Ideal for households with pets
or smokers.
HEPA AirClean 50 exhaust filter
(SF-HA 50)
Effectively filters fine dust and allergens.
Ideal for people allergic to house dust.
Filter grille
This is required if you wish to replace an
AirClean Plus 50, Silence AirClean
50,Active AirClean 50or HEPA
AirClean 50 filter with an AirClean filter.
Miele Australia Pty. Ltd.
Miele New Zealand Limited
Miele Global Headquarters
Germany
Miele & Cie. KG
Carl-Miele-Straße 29
33332 Gütersloh
Federal Republic of Germany
IRD 98 463 631
8 College Hill
Freemans Bay, Auckland 1011
ACN 005 635 398
ABN 96 005 635 398
Level 4, 141 Camberwell Road
Hawthorn East, VIC 3123
0800 464 353 (0800 4 MIELE)
www.miele.co.nz
1300 464 353 (1300 4 MIELE)
www.miele.com.au
SUMF0 - 2425
M.-Nr. 12 963 210 / 01
