Model Number:
GENERAL SPECIFICATIONS
Nominal Diameter:
Rated Lmpedance:
Operating Bandwidth:
Power Handling Capacity:
Sensitivity (1W/M):
Voice Coil Diameter:
THIELE-SMALL PARAMRTERS
Resonance Frequency Fs: 36.6 HZ
DC Resistance Re: 3.4ohm
Mechanical Q Factor Qms: 3.2313
Electrical Q Factor
Qes: 0.502
Total Q Factor
Qts: 0.4345
Equivalent Cas air load Vas: 33.97 L
Surface Area of Cone Sd: 0.0216 m2
Efficiency Bandwidth Product EBP 52.9
Voice Coil Over Hang
X-max
5.5 mm
PHYSICAL INFORMATION
Basket:
Magnet Type:
Cone Material:
Surround:
Molded ABS Plastic Basket
24 OZ
PP Cone
Rubber
88 dB(+-3dB)
1.5 inch
8 inch
4 ohms
40-1.8k hz(-3dB)
200 Watts
SPEAKER SPECIFICATIONS
PLMRW8
Dust Cap:
Damper:
-
44
-
2.0
-
-
-
-
NA
Small
Fb Tuning Frequency of Vented Enclosure,Hz
Suggested enclosure parameters
Sealed
PP
cloth
Sealed Box
0.74
-
Enclosure Frequency,Hz
Vented
Large
Small
Large
-
59
NA
0.74
NA
Vented Box
Enclosure volume,cu.ft.
Vent length,inches
Vent diameter,inches
-
4.1
-
-
-
-
-
44
F3 Systems 3dB Down Piont(Sealed),Hz
