Technical Specications
•
Speaker Size: 12''
• Cone Material: High-Quality Polypropylene
• Construction: Water-Resistant Design
• Magnet Structure: 60 Oz
• Voice Coil: 2'' High-Temperature
• Peak Power Handling: 600 Watts
• Frequency Response: 20 Hz – 2.2 kHz
• Impedance: 4 Ohms
• Sensitivity: 95 dB
• Overall Diameter: 12.7''
• Mounting Depth: 5.25''
Mounting Instructions:
USER GUIDE
12'' Marine Subwoofer, 600 Watt
PLMRW12
Visit Our Website
SCAN ME
PyleUSA.com
Register Product
Thank you for choosing PyleUSA. By registering your product, you ensure that
you receive the full benets of our exclusive warranty and personalized
customer support. Complete the form to access expert support and to keep
your PyleUSA purchase in perfect condition.
1. Select a Suitable Location: Ensure the mounting
area is structurally sound and free from obstructions.
Avoid areas prone to excessive moisture or heat.
2. Cut the Mounting Hole: If installing into a panel,
cut a hole large enough to t the subwoofer’s
mounting depth (5.25'').
3. Connect the Wiring: Attach the positive (+) and
negative (-) terminals of the subwoofer to the
corresponding terminals on your amplier.
4. Secure the Subwoofer: Use the included mounting
screws to fasten the subwoofer into place.
Ensure a tight and secure t.
5. Test the Sound: Power on your audio system and
verify proper operation before nalizing the
installation.
Start Here
PyleUSA.com/pages/register
Model Number:
PLMRW12
www.PyleUSA.com
Questions or Comments?
We are here to help!
Phone: 1.718.535.1800
PyleUSA.com/ContactUs
California Prop 65 Warning
WARNING:
This product may expose you to chemicals, which is known to
the state of California to cause cancer, birth defects and other
reproductive harm. Do not ingest.
For more info go to: www.P65warnings.ca.gov
Vented and Bandpass Enclosures
Increased Bass Response & Enhanced Efficiency
Tunable enclosure for optimized performance.
Vented Enclosures
Vented enclosures, also known as "bass reex" or "ported enclosures,” utilize a tuned vent
(or "port") to capture the energy of the woofer's backwave, increasing bass response and
eciency. The tuning frequency can be altered by adjusting the vent’s size or length, allowing
users to modify bass output without changing the enclosure. Since the port supplies a portion
of the bass, it must vent into the vehicle's interior.
Guidelines for Vents:
• Vents can be any shape; cardboard tubes or PVC pipes work well.
Keep the port free of obstructions.
• Larger vents reduce duct noise, but require longer ducts to maintain tuning frequency.
• Keep vents at least one vent diameter from any wall and two vent diameters from the woofer.
• If space is limited, use PVC pipes with elbows to adjust duct length.
Bandpass Enclosures
Bandpass enclosures allow control over both low-end response and high-end cuto.
These enclosures oer:
• Increased eciency and lower distortion.
• Potential elimination of crossover electronics.
Bandpass designs, including 4th, 5th, and 6th order enclosures, vary in tuning and eciency.
The 4th order design has a sealed rear chamber and a vented front chamber, while 6th order
enclosures add a vented rear chamber for enhanced bass control.
Key Considerations for Bandpass Enclosures:
• All sound is delivered through a vent, which may aect sound quality.
• Complex design requires precise tuning and limited access to the woofer.
• Sealed and vented portions must be unobstructed for optimal performance.
• Subsonic lters can help prevent excessive cone movement and prolong speaker life.
Safety Precautions
•
Always disconnect the power source before installation or maintenance.
• Avoid exposing the subwoofer to extreme temperatures or direct water spray.
• Use only recommended accessories and mounting hardware.
• If you experience any issues with sound quality or performance, consult a professional
installer.
