Brand:amzchef
Model:ZM1902B
120V~ 60Hz 200W
Instruction Manual
Slow Juicer
CONTENT
Chapter I. Precautions for Safe Use
Chapter II. Parts and Functions
Chapter III. Assembly and Disassembly Methods
Chapter IV. Methods of Operation
Chapter V. Ingredient Selection and Handling Tips
Chapter VI. Cleaning Guidelines and Maintenance
Chapter VII. Troubleshooting
Chapter VIII. Safety Indexes
Chapter IX. Warranty
1
4
5
8
8
9
10
11
12
www.iamzchef.com Email: [email protected] Whatsapp:+1（838）910 8317 Facebook: amzchefappliance
Chapter I. Precautions for Safe Use
All users of this appliance must read and understand these safety precau-
tions before operating.
SIGN SAMPLES
�. DO NOT PLUG IN OR UNPLUG WITH WET HANDS.
�.DO NOT USE WITH OTHER THAN RATED VOLTAGE.
�. IF THE SUPPLY CORD IS DAMAGED, IT MUST BE REPLACED BY
THE MANUFACTURER, ITS SERVICE OR SIMILARLY QUALIFIED
PERSONS IN ORDER TO AVOID A HAZARD.
�. NEVER ALTER THE APPLIANCE. ALSO DO NOT DISASSEMBLE
OR REPAIR BY YOURSELF. DO NOT INSERT FINGERS, FOREIGN
SUBSTANCES OR OBJECTS SUCH AS PINS INTO GAPS OR HOLES
IN THE BASE.
�. PLUG THE POWER CORD CORRECTLY AND PUSH IT TIGHT IN A
WALL SOCKET.
www.iamzchef.com Email: [email protected] Whatsapp:+1（838）910 8317 Facebook: amzchefappliance
1
��. IF THE MACHINE COMES TO A HALT DURING NORMAL
OPERATION, PRESS AND HOLD THE [R] BUTTON FOR � SECONDS
TO SWITCH TO REVERSE OPERATION. PRESS THE [ON] BUTTON TO
RESUME EXTRACTION AFTER REVERSING.
�. DO NOT MOISTEN THE BASE OR SPLASH WATER ON THE BASE.
�. WHEN THE POWER CORD, WIRE IS BROKEN OR DAMAGED OR
THE PLUG-IN. PART BECOMES LOOSE, DO NOT OPERATE IT.
�. ALWAYS USE AN OUTLET WITH A GROUND CONNECTION.
�. NEVER DISASSEMBLE ACCESSORIES DURING OPERATION OR
INSERT FINGERS, FOREIGN OBJECTS SUCH AS FORKS, SPOONS
ETC. INTO FEEDING TUBE OR JUICE OUTLET.
��. DO NOT OPERATE WITHOUT LOCKING THE HOPPER PROPERLY.
��. THIS APPLIANCE IS NOT INTENDED FOR USE BY PERSONS
(INCLUDING CHILDREN) WITH REDUCED PHYSICAL, SENSORY OR
MENTAL CAPABILITIES, OR LACK OF EXPERIENCE AND KNOWL -
EDGE, UNLESS THEY HAVE BEEN GIVEN SUPERVISION OR
INSTRUCTION CONCERNING USE OF THE APPLIANCE BY A
PERSON RESPONSIBLE FOR THEIR SAFETY.
��. IF A GAS LEAK IS DETECTED, DO NOT PLUG IN THE APPLI -
ANCE'S POWER CORD INTO A POWER OUTLET. IMMEDIATELY
VENTILATE THE ROOM BY OPENING A WINDOW, AND ALLOW TO
FULLY VENTILATE BEFORE PLUGGING IN THE APPLIANCE.
To be safe, always use an outlet with a ground connection, but never ground on
gas lines, plastic water pipes, telephone lines, etc. Failure to do so may result in
electric shock, fire or malfunction and explosion.
www.iamzchef.com Email: [email protected] Whatsapp:+1（838）910 8317 Facebook: amzchefappliance
2
1. Before use, please check if the power cord, the plug, the juice strainer, the spiral pusher and
any other part is damaged. If any of the said part is damaged, stop using the appliance and
contact our customer service department promptly. Do not dismantle and repair it by yourself,
otherwise dangers may happen.
2. It is necessary before connecting the power supply to ensure that the juicing body, the spiral
pusher, the juicing body cap and all other dismountable parts are properly installed.
3. Cut food ingredients into small blocks with sizes fitting the feed port of the juicing body.
Do not begin to process any vegetables or fruits with cores, hard seeds or thick skin or
shells until the cores, hard seeds or thick skin or shells are removed.
4. When feeding a food ingredient, do not make the pushing force too large but have it just
enough to cut thefood ingredient.
5. Dyeing of the juice strainer, the juicing body cap, the spiral pusher and other accessories after
juicing of some vegetables or fruits is normal and will neither affect food eating nor do harm to
health.
6. If the appliance has current limiting protection or its motor is locked and stops automatically
and cannot reverse automatically, switch off the power switch and put it on the "OFF" position,
then press the "R" button of the power switch to discharge the food ingredients in the
appliance and finally press the "ON" button of the power switch for normal use of the
appliance. If the motor is still locked, it is suggested to remove the food ingredients in the spiral
pusher before continue to use the appliance. This measure can protect the motor.
7. Do not dismantle the dismountable parts of the appliance immediately after use but after
both the motor and the spiral pusher have stopped and the power supply is disconnected.
8. Do not sterilize any accessories of the appliance with hot water with a temperature higher
than 50℃(122℉) or a dishwasher, otherwise they may heated, deformed and damaged.
The materials of all parts in contact with food ingredients should comply with food hygiene
certification and be clean, hygeian and reliable.
9. Do not clean the appliance with steel wool, abrasive cleaning agents or corrosive liquids (such
as gasoline or acetone).
10. The appliance is applicable to use by individuals or families only.
11. Switch off the appliance and disconnect the power supply before changing accessories,
assembling, disassembling, cleaning, or moving the appliance.
12. The hazardous operation may result in minor personal injury or equipment damage. Care
should be taken during the handling and cleaning of the auger.
www.iamzchef.com Email: [email protected] Whatsapp:+1（838）910 8317 Facebook: amzchefappliance
3
Chapter II. Parts and Functions
No.
Component
Name
Function Description
① Juicing Bowl
⑧ Food Pusher
One of the main parts of juicing, vegetables or fruits are
added from the feeding container at the top, while juice
and pulp are discharged by the filter.
② Anti-drip Cover To prevent any accidental spills or leaks while juicing.
③ Base
The main unit containing motor and other components,
providing power output.
④ Feeding Container Holding fruits and vegetables before processed.
⑤ Filter Separate juice and pulp.
⑥ Button
It controls the operating status of the juicer.
(on/off/reverse mode)
⑦ Juice Cup Collect the juice squeezed by the juicer.
⑪ Auger Used to extrude ingredients.
maximize the efficiency of juicing.
Push the ingredients to fully contact with the auger and
⑨ Cleaning brush For cleaning usage.
⑩ Pomace cup Collect the pulp separated by the extractor.
7
9
10
1
2
3
6
4
5
11
8
www.iamzchef.com Email: [email protected] Whatsapp:+1（838）910 8317 Facebook: amzchefappliance
4
Chapter III. Assembly and Disassembly Methods
�. Assembly Guide
Before using the product, clean the auger, juice cup, and
other accessories thoroughly.
�
�
�
�
�
�
Put the juice bowl onto the base as shown in the picture.
Install the auger into the juice bowl according to the
direction shown in the diagram, and confirm that the
auger is installed properly. Otherwise, the juicer cannot be
operated.
Install the feeding container into the juice bowl in the
direction shown in the picture, and rotate the feeding
container clockwise to confirm it is securely fastened to
the juice bowl.
After installing the juicer, place the juice cup and pomace
cup under the corresponding outlet of the juicer.
As picture, turn up the anti-drip cover.
www.iamzchef.com Email: [email protected] Whatsapp:+1（838）910 8317 Facebook: amzchefappliance
5
Plug the power cord, and then press the "ON" button. It
starts to work and can extract delicious vegetable and
fruit juice.
�
�
�
��
��
When squeezing juice, you can turn up the feeding cover,
and put some small and medium-sized apples or
tomatoes into the feeding container to avoid the trouble
of cutting.
During the juicing process, do not put any hard core or
hard food, such as peaches, plums, mangoes, or sugar-
cane. If the machine comes to a halt during normal
operation, hold and press the "R" button for � seconds to
loosen the auger and food, and then press the "ON"
button to continue the juicing.
During the juicing process, if there are fruit blocks or
grains sticking to the juicing body, use a food pusher to
push them in.
After squeezing the juice, cover the anti-drip cover to
prevent the juice from dripping onto the desktop. Then,
press the "OFF" button and unplug from the power
socket. Complete the juicing work and enjoy your
delicious juice.
www.iamzchef.com Email: [email protected] Whatsapp:+1（838）910 8317 Facebook: amzchefappliance
6
�. Disassembly Guide
�
�
�
�
Pull the juice bowl off from the base.
As shown in the picture, rotate the feeding container
counterclockwise and pull it off, then remove it from the
juice bowl.
Pull the auger off from the juice bowl.
After juicing , there will be pomace at the outlet of the
juice bowl. Turn up the silicone cover and anti-drip cover
before cleaning of the pomace.
After cleaning, remember to put the silicone cover and
anti-drip cover back in place, preventing juice from
flowing out.
www.iamzchef.com Email: [email protected] Whatsapp:+1（838）910 8317 Facebook: amzchefappliance
7
Chapter IV. Methods of Operation
Chapter V. Ingredient Selection and Handing Tips
3. Preparing ingredients for best results.
• Remove large stones from fruits, such as peaches, plums, mangoes and apricots to avoid damage
to the juicer.
• Please peal hard and thick skin from fruit first, such as citrus fruits, watermelon.
• Please remove the seeds first to avoid affecting the taste of the juice, such as oranges.
• Please cut the long fiber vegetable into small pieces (about 3cm) before putting it in. Such as
celery and wheatgrass.
• Please cut large pieces of food into small pieces before putting them in, such as carrots and
apples.
2. How to clean the ingredients?
• Rinse fruit or vegetables thoroughly with water or produce wash for fruits and vegetables.
1. How to choose ingredients?
• Please avoid foods that you are allergic to.
• Please avoid putting in frozen ingredients.
• Do not put ice cubes in.
• Please avoid putting hard food, such as nuts, coffee beans, sugar cane, etc.
• Please avoid putting meat.
• Please avoid putting cooked ingredients such as boiled potatoes and carrots.
“ON”
Power on
Power off
Reverse mastication (For solving ingredient clogging
problems)
“OFF”
“R”
4. How to increase the juice yield?
• Soft fruits (e.g. grapes and watermelon) are easy to stuck in the juicer, please reduce the feeding
speed. Or mix it properly with hard fruits before feeding.
• If you need to extract a large amount of juice, please repeat the steps of "cleaning-juicing-clean-
ing" to avoid pulp accumulating in the filter and blocking the mesh.
• Please cut the ingredients into small enough pieces.
• Do not press the food hard with the food pusher.
www.iamzchef.com Email: [email protected] Whatsapp:+1（838）910 8317 Facebook: amzchefappliance
8
Chapter VI. Cleaning Guidelines and Maintenance
Before cleaning, please make sure that the juicer is turned off
and the power is cut off.
Disassemble and separate the accessories of the juicer (please
refer to the "Disassembly Guide" section).
Note: When juicing soft fruits and vegetables (such as grapes, kiwi, tomato, etc.), due
to the high juice content, it is easy to cause the juice to stay in the drum. This is a
normal phenomenon. At this time, the feeding speed should be slowed down until the
juice flows out. If necessary, please disassemble and clean it in time.
�. Tips for cleaning
Please rinse all accessories and cups under running water and
wash them with soapy water.
Do not use a metal brush to clean, you can use the attached
cleaning brush to clean.
Please do not put all accessories and cups into the dishwash-
er.
Pomace on the metal filter of the juicer can be cleaned with a
cleaning brush.
www.iamzchef.com Email: [email protected] Whatsapp:+1（838）910 8317 Facebook: amzchefappliance
9
Chapter VII. Troubleshooting
Note: If the machine works continuously for a long time, it will automatically shut
down to protect the motor from overheating. Please note that this does not mean that
the machine is broken, but it means that it needs to take a rest. At this time, please turn
off the machine and wait for the machine to cool down for � hour before use it again.
Do not immerse the motor base in water or other liquids.
• After cleaning the accessories, let dry completely then assemble and place in a cool and dry
place.
• The machine needs to rest every 10 minutes to protect the motor.
• Please handle the ingredients correctly before putting them in (please refer to the "Preparing
ingredients for best results" section).
• When moving the juicer, always hold it by the base (and not the juicer accessories).
2. Tips for maintenance
Machine not working.
The power is not plugged in or the
power button is not pressed.
Machine damage.
The feeding container is not covered
correctly.
Secure the lid in place.
Connect the power and press the
power button.
Please contact the after-sales email:
Bad smell.
Machine stops working.
It is normal that it appeared in the
first few times of use, and there will
be no safety hazard.
It disappears after a few uses.
It has not occurred before, but it
suddenly occurs during a certain
use, which may be caused by
continuous use for a long time.
After 10 minutes of continuous use,
rest for 10 minutes before the next
start.
Fault Phenomenon Analysis of cause Fault Rresolution
Overheat protection due to continu-
ous use for a long time.
Shut down and wait 1 hour before
restarting the machine.
Food clogs in the juicer.
Restart the machine after disassem-
bling and cleaning the accessories.
www.iamzchef.com Email: [email protected] Whatsapp:+1（838）910 8317 Facebook: amzchefappliance
10
Chapter VIII. Safety Indexes
ZM1902B
120V
200W
60Hz
≤10 minutes
≥10 minutes
90-110 rpm
Model
Rated Voltage
Rated Power
Rated Frequency
Continuous Operating Time
Interval Time
Screw Running Speed
415mm
16.33inch
180mm
7.08inch
147mm
5.78inch
120mm
4.72inch
43mm
1.69inch
www.iamzchef.com Email: [email protected] Whatsapp:+1（838）910 8317 Facebook: amzchefappliance
11
