Microwave oven with built in Air Fryer
Quick start guide
R-26CAF-B
EN – 3EN – 2
EN
CONTROL PANEL
1. DIGITAL DISPLAY – Cooking time, power, indicators and clock time are
displayed.
2. MICROWAVE POWER – Press to select microwave power level.
3. CONVECTION – Press to select convection temperature.
4. GRILL – Press to set grill cooking program.
5. MICROWAVE+GRILL – Press to set microwave and grill combination
cooking program.
6. MICROWAVE+CONVECTION – Press to select convection combination
cooking.
7. AIR FRY – Press to use Air Fry function.
8. 10 SECONDS, 1 MINUTE, 10 MINUTES – Use to set time of cooking or
the clock.
9. DOWN
– Press to set food weight or servings.
10. TEMPERATURE/TIME – Press to toggle between Temperature and Time
setting.
11. UP
– Press to set food weight or servings.
12. AUTO MENU key – Press to select auto cooking menus.
13. DEFROST – Press to select defrost function.
14. SET CLOCK – Use to set clock time. Use to set timer function.
15. STOP – Press once to temporarily stop cooking, or twice to cancel cooking
altogether.
16. START/+30s – Press to start the oven and to increment cooking in 30
second intervals.
Symbol
Description Microwave Grill Air Fry Convection Temperature Time
Supplied accessories:
1. Frying Basket
2. Baking Tray
• The Grill Racks and Baking Tray are designed for
use when using the grill and convection modes
only. DO NOT use any metal accessories when
using the microwave function.
SETTING THE CLOCK
Your oven has a 24 hour clock mode.
1. Open and close the oven door, then press the SET CLOCK button
once and the display will ash 00:00.
2. Press the time buttons to enter the current time. Hours are set using the 10min button and enter the minutes by
the 1min and 10s buttons.
3. Press the SET CLOCK button
to nish setting the clock.
OPERATING THE OVEN
1. Prepare and place food in a suitable container, position container directly onto the middle of the turntable. Use
the either of the supplied grill racks when grilling or the baking tray when in the convection only mode. Close the
door.
2. To microwave, press the MICROWAVE button to select the desired power level.
For grill press the GRILL button to select the grill function.
For CONVECTION or AIR FRY, press the CONVECTION or AIR FRY button repeatedly to set the temperature, then
press the START/+30s button to set the temperature.
3. Enter the time by pressing the 10min, 1min and 10s buttons and press the START/+30s button.
4. When Cooking/defrosting is complete a signal will sound. The oven lamp will turn o and the turntable stops
rotating. Open the oven door, remove the container carefully. Leave food to stand as required.
8
2
3
5
6
11
14
16
12
15
9
1
4
7
10
13
8
9
1 2
EN – 4EN – 3
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO MICROWAVE ENERGY
1. Do not attempt to operate this oven with the door open as this can result in harmful exposure to microwave
energy. It is important not to defeat or tamper with the safety interlocks.
2. Do not insert anything between the oven front face and the door or allow debris or cleaner residue to accumulate
on sealing surfaces.
3. Do not operate the oven if it is damaged. It is very important that the oven door closes properly and that there is
no damage to the door, hinges, latches or door seals and sealing surfaces.
4. Do not attempt to repair or adjust the oven.
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
To avoid the danger of re. The microwave oven should
not be left unattended during operation. Power levels
that are too high, or cooking times that are too long, may
overheat foods resulting in a re.
This oven is designed to be used on a countertop only. It is not
designed to be built into a kitchen unit. Do not place the oven
in a cabinet. The electrical outlet must be readily accessible so
that the unit can be unplugged easily in an emergency.
The AC power supply must be 230 V, 50 Hz, with a minimum
10 A distribution line fuse, or a minimum 10 A distribution
circuit breaker. A separate circuit serving only this appliance
should be provided.
Do not place the oven in areas where heat is generated. For
example, close to a conventional oven. Do not install the oven
in an area of high humidity or where moisture may collect. Do
not store or use the oven outdoors.
If smoke is observed, switch o or unplug the oven and
keep the door closed in order to sti e any ames.
As part of our ongoing commitment to reduce paper usage, we have not included
a full User Manual with this product. Should you wish to obtain the full User
Manual, it is available online free of charge. Simply scan the QR code with your
mobile device or visit https://www.sharpconsumer.com/support/ where you can
search for your model and simply download the manual.
EN – 5EN – 4
EN
Metallic containers for food and beverages are not
allowed during microwave modes.
Use only microwave-safe containers and utensils when in
microwave modes. Utensils should be checked to ensure
that they are suitable for use in microwave ovens.
When heating food in plastic or paper containers, keep an
eye on the oven due to the possibility of ignition.
Clean the waveguide cover and the oven cavity. These
must be dry and free from grease. Built up grease may
overheat and begin to smoke or catch re.
Do not place ammable materials near the oven or ventilation
openings. Do not block the ventilation openings.
Remove all metallic seals, wire twists, etc., from food and food
packages. Arcing on metallic surfaces may cause a re.
Do not use the microwave oven to heat oil for deep frying. The
temperature cannot be controlled and the oil may catch re.
To make popcorn, use only special microwave popcorn makers.
Do not store food or any other items inside the oven.
Check the settings after you start the oven to ensure the oven
is operating as desired.
Do not leave the oven unattended while it is operating.
To avoid overheating and re, special care must be taken when
cooking or reheating foods with a high sugar or fat content,
for example, Sausage rolls, Pies or Christmas pudding. See the
corresponding hints in the user manual.
To avoid the possibility of injury. WARNING:
Do not operate the oven if it is damaged or malfunctioning.
Check the following before use:
a) Make sure the door closes properly and ensure it is not
misaligned or warped.
b) Check to make sure the hinges and safety door latches are
EN – 6EN – 5
not broken or loose.
c) Ensure that the door seals and sealing surfaces have not
been damaged.
d) Make sure inside the oven cavity or on the door are no
dents.
e) Ensure that the power supply cord and plug are not
damaged.
If the door or door seals are damaged, the oven must not be
operated until it has been repaired by a competent person.
Never adjust, repair or modify the oven yourself. It is
hazardous for anyone other than a competent person to
carry out any service or repair operation which involves
the removal of a cover which gives protection against
exposure to microwave energy.
Do not operate the oven with the door open or alter the door
safety latches in any way. Do not operate the oven if there is an
object between the door seals and sealing surfaces.
Do not allow grease or dirt to build up on the door seals
and adjacent parts. Clean the oven at regular intervals and
remove any food deposits.
Follow the instructions for “Care and Cleaning" in the full
version of the User Manual. Failure to maintain the oven
in a clean condition could lead to a deterioration of the
surface that could adversely a ect the life of the appliance
and possibly result in a hazardous situation.
Do not use harsh abrasive cleaners or sharp metal scrapers to
clean the oven door glass, since they can scratch the surface,
which may result in shattering of the glass.
The appliance shall not cleaned with a steam cleaner.
Individuals with PACEMAKERS should check with their doctor or
the manufacturer of the pacemaker for precautions regarding
EN – 7EN – 6
EN
microwave ovens.
To avoid the possibility of electric shock.
• Under no circumstances should you remove the outer
cabinet.
• Never spill or insert any objects into the door lock openings
or ventilation openings. In the event of a spill, turn o and
unplug the oven immediately, and call an authorised SHARP
service agent.
• Do not immerse the power supply cord or plug in water or
any other liquid.
• Do not let the power supply cord hang over the edge of a
table or work surface.
• Keep the power supply cord away from heated surfaces,
including the rear of the oven.
• Do not attempt to replace the oven lamp yourself or allow
anyone who is not an electrician authorised by SHARP to do
so. If the oven lamp fails, please consult your dealer or an
authorised SHARP service agent.
• If the power supply cord is damaged, it must be replaced by
an authorised SHARP service agent.
To avoid the possibility of explosion and sudden boiling:
WARNING: Liquids and other foods must not be heated
in sealed containers since they are liable to explode.
Microwave heating of beverages can result in delayed
eruptive boiling; therefore, care must be taken when
handling the container.
Never use sealed containers. Remove seals and lids before use.
Sealed containers can explode due to a build-up of pressure
even after the oven has been turned o . Take care when
microwaving liquids. Use a wide mouthed container to allow
bubbles to escape.
Never heat liquids in narrow necked containers such as
EN – 8EN – 7
baby bottles, as this may result in the contents erupting
from the container when heated and cause burns.
To prevent sudden eruption of boiling liquid and possible
scalding:
1. Do not use excessive amount of time.
2. Stir liquid prior to heating/reheating.
3. It is advisable to insert a glass rod or similar utensil (not
metal) into the liquid whilst reheating.
4. Let liquid stand for at least 20 seconds in the oven at the
end of cooking time to prevent delayed eruptive boiling.
Do not cook eggs in their shells, and whole hard-boiled
eggs should not be heated in microwave ovens since they
may explode even after microwave cooking has ended.
To cook or reheat eggs which have not been scrambled or
mixed, pierce the yolks and the whites. Shell and slice hard
boiled eggs before reheating them in the microwave oven.
Pierce the skin of such foods as potatoes, sausages and fruit
before cooking, or they may explode.
To avoid the possibility of burns:
WARNING: The appliance and its accessible parts become
hot during use. Care should be taken to avoid touching
heating elements. Children less than 8 years of age shall
be kept away unless continuously supervised.
The contents of feeding bottles and baby food jars must
be stirred or shaken and the temperature checked before
consumption, in order to avoid burns. Use pot holders
or oven gloves when removing food from the oven to
prevent burns.
• During use the appliance becomes hot. Care should be
taken to avoid touching heating elements inside the oven.
EN – 9EN – 8
EN
• Always open containers, popcorn makers, oven cooking
bags, etc., away from the face and hands to avoid steam
burns and eruption of boiling. To avoid burns, always test
food temperature and stir before serving and pay special
attention to the temperature of food and drink given to
babies, children or the elderly. Accessible parts may become
hot during use. Young children should be kept away.
• Temperature of the container is not a true indication of the
temperature of the food or drink; always check the food
temperature.
• Always stand back from the oven door when opening it to
avoid burns from escaping steam and heat.
• Slice stu ed baked foods after heating to release steam and
avoid burns.
• Keep children away from the door to prevent them burning
themselves.
To avoid misuse by children:
WARNING: Only allow children aged from 8 years and
above to use the oven without supervision when adequate
instructions have been given so that the child is able to
use the oven in a safe way and understands the hazards of
improper use.
When the appliance is operated in ANY mode which
generates direct heat (mode applicable to model),
children should only use the oven under adult supervision
due to the temperature generated.
This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
Children should be supervised to ensure that they do not
EN – 10EN – 9
play with the appliance. Cleaning by children should be
monitored.
Models with Electronic touch panel are enabled with a
child lock mode.
Do not lean or swing on the oven door. Do not play with the
oven or use it as a toy.
Children should be taught all important safety instructions:
use of pot holders, careful removal of food coverings - paying
special attention to packaging (e.g., self-heating materials)
designed to make food crisp, as they may be extra hot.
Other warnings
Never modify the oven in any way.
Do not move the oven while it is in operation.
This appliance is intended to be used in household. This oven
is only for home food preparation and may only be used for
cooking food and beverages. Drying of food or clothing and
heating of warming pads, slippers, sponges, damp cloth and
similar may lead to risk of injury, ignition or re. It is not suitable
for commercial or laboratory use.
To promote trouble-free use of your oven and avoid
damage.
Never operate the oven when it is empty. When using a
browning dish or self-heating material, always place a heat-
resistant insulator such as a porcelain plate under it to prevent
damage to the oven base due to heat stress. The preheating
time speci ed in the dish’s instructions must not be exceeded.
Do not use metal utensils, which re ect microwaves and may
cause electrical arcing. Do not put cans in the oven.
To prevent the turntable or base of the oven breaking:
a) Before cleaning with water, leave to cool.
EN – 11EN – 10
EN
b) Do not put hot foods or hot utensils on a cold turntable/
oven base.
c) Do not pace cold foods or cold utensils on a hot turntable/
oven base.
Do not place anything on the outer cabinet during operation.
NOTE:
Do not use plastic containers for microwaving if the oven is still
hot from using grill, convection or a combination mode (oven
model dependant) because they may melt.
Plastic containers must not be used during above modes unless
the container manufacturer says they are suitable.
If you are unsure how to connect your oven, please consult an
authorised, quali ed electrician.
Neither the manufacturer nor the dealer can accept any liability
for damage to the oven or personal injury resulting from failure
to observe the correct electrical connection procedure.
Water vapour or drops may occasionally form on the oven walls
or around the door seals and sealing surfaces. This is a normal
occurrence and is not an indication of microwave leakage or a
malfunction.
This appliance is intended for use in household and similar
applications such as; Kitchen areas reserved for sta in
stores, o ces and other professional environments / Farms
/ Use by clients of hotels, motels and other residential type
environments / Bed and breakfast type environments.
This symbol means that the surfaces are liable to get
hot during use.
EN – 12EN – 11
INSTALLATION
1. Remove all packing materials from the inside of the oven cavity and remove any protective lm found on the
microwave oven cabinet surface.
2. Check the oven carefully for any signs of damage.
3. Place the oven on a secure, level surface, strong enough to take the oven weight, plus the heaviest item likely to
be cooked in the oven. Do not place the oven in a cabinet.
4. Select a level surface that provide enough open space for the intake and/or outlet vents. See picture on the rst
page. The rear surface of appliance can be placed against a wall.
• The appliance must not be installed behind a decorative door in order to avoid overheating.
• The minimum installation height is 85 cm.
• A minimum space of 20 cm is required between the sides of the microwave oven and any adjacent walls or objects.
• Leave a minimum space of 30 cm above the oven.
• Do not remove the feet from the bottom of the oven.
• Blocking the intake and/or outlet openings can damage the oven.
• Place the oven as far away from radios and TV as possible. Operation of microwave oven may cause interference to
your radio or TV reception.
20 cm
30 cm
85 cm
10 cm
20 cm
5. Securely connect the plug of the oven to a standard earthed (grounded) household electrical outlet.
WARNING:
Do not place the oven where heat, moisture or high humidity are generated, (for example, near or above a
conventional oven) or near combustible materials (for example, curtains) .
Do not block or obstruct air vent openings.
Do not place objects on top of the oven.
Do not touch the exterior of the microwave oven during or shortly after operation as it will be hot.
