MANUAL MLR010567N
compact
glass kettle
HIGH QUALITY
BOROSILICATE GLASS
fast
boiling
MAX
1.5 L
1.0 L
MIN
0.5 L
IMPORTANT SAFETY INSTRUCTIONS | 3
EN
ultra kettle
manual
Before using the electrical appliance, the basic precautions below should
always be followed:
– Read all instructions and save them for future reference.
– Check that the voltage marked on the appliance rating plate matches your local
supply. For additional protection, we recommend the use of a power outlet with
a rated current of 13 amps. To avoid circuit overload, do not operate another
high wattage appliance on the same circuit.
– Do not use an extension cable, it may result in fire, electric shock,
and/or personal injury due to a tripping hazard.
– This appliance is intended for indoor household use only. Do not use this
appliance for any purpose other than its intended use. Any other use may
invalidate the warranty or may result in serious injury or harm.
– Do not touch the hot surface, the glass body will get hot during and after
heating the water. Always use the Handle for moving the Kettle.
– Do not use the appliance if the plug, the mains cord, the base, or the appliance
itself is damaged.
– Do not leave the appliance unattended when in use.
– Immediately unplug if the Kettle is not working correctly.
– This appliance is not intended for use by any individual (including children) with
reduced physical, sensory, or mental capabilities, or lack of experience
or knowledge, without proper supervision or instruction from an adult
or individual responsible for their safety and care.
– Children should be supervised to ensure that they do not play with the
appliance.
– To protect against fire, electrical shock, and personal injury, do not immerse the
appliance in water or any other liquids.
– Place the appliance on a flat surface. Do not hang the Power Cord over the
edge of a table or counter. Do not let the cord hang over the edge of a table or
counter, touch hot surfaces, or become knotted. Ensure the Power Cord does
not touch the hot surface of the appliance.
– Do not place it on or near a hot gas or electric burner, or on the top of another
electrical appliance, or near an open flame.
– Always turn appliance off at the power switch and remove the plug from outlet
before attempting to move the appliance when not in use, when no water is in
the Kettle, or when filling water.
– Remove the power plug from the wall outlet before cleaning or when not in use.
Allow the appliance to cool down completely before cleaning the appliance.
– Always grasp the power plug to remove it from the wall outlet.
Do not pull on the Power Cord itself.
– Do not try and repair on your own. If the plug is damaged, it must be replaced
by the manufacturer to avoid a hazard.
– Steam heat can cause burns. Use extra caution when opening the Lid
immediately after the water has boiled. The steam coming out of the Kettle
is very hot.
IMPORTANT SAFETY
INSTRUCTIONS
PARTS LIST | 54 | IMPORTANT SAFETY INSTRUCTIONS
EN
WARNING!
– Do not use this appliance within reach of a bath
or sink, or any vessel containing water or other liquids.
– Close the Lid until a click is heard so that steam is directed
away from the Handle.
– Do not press the “Lid Release” button to open the Lid while
the water is boiling.
– If the appliance is dropped in water, do not reach for it.
Switch it off at the outlet, then disconnect it from the electric outlet.
Drain the water before retrieving the appliance. Stop using the
appliance until it has been checked by a qualified service agent.
– To reduce the risk of fire or electrical shock, do not repair
the appliance by yourself. Do not remove the bottom of
the Body or the Power Base by yourself.
– Do not remove the Lid while the water is boiling.
– Position the Kettle to the rear of work surfaces to prevent the
Power Cord from hanging over the edge of a table or counter.
Water can remain hot for a considerable time after boiling
and can present a scald hazard.
CAUTION!
Ensure that the Kettle is switched off before removing it from
the Base. Do not fill Kettle beyond max fill line. If the Kettle is
overfilled, boiling water may eject from the Kettle and cause
scalding. Do not immerse the Kettle, or its plug, in water or any
other liquids. Do not wash the Kettle and its parts in a dishwasher;
wash the Kettle by hand with mild soap and water.
– Do not use the Kettle to heat anything other than water. Do not operate the
appliance without water.
– Do not fill the Kettle beyond the maximum level indication. Do not operate the
Kettle if the water is below the minimum level (usually 16.9 oz / 0.5 L).
– Do not fill the Kettle when positioned on the Power Base. Dry any water
on the bottom of the Body before placing the Kettle onto the Power Base.
– This Kettle is to be used with the supplied base only.
– We recommend cleaning the washable nylon filter periodically.
– Do not insert any object into the slots or holes of the Kettle.
– Do not touch the Power Base or bottom of the Kettle after use to avoid
scalding or burns.
– Do not remove the Lid during the heating cycle. Scalding may occur.
Never operate the appliance when the Lid is open or removed.
– Do not use the Kettle when you have wet hands or bare feet.
– The use of accessory attachments not recommended by the appliance
manufacturer may result in fire, electric shock or injury.
PARTS LIST
MAX
1.5 L
1.0 L
MIN
0.5 L
On/Off
Switch
Power
Base
Body
Handle
Lid Release
Button
Lid
6 | BEFORE FIRST USE
EN
1 With the power off, remove
the Kettle from its Power Base.
Automatic Switch-Off Protection
This Kettle is equipped with boil-dry protection. If it is accidentally switched
on without water in it, the Kettle will automatically switch off. The LED
indicator will turn off.
OPERATING INSTRUCTIONS
BEFORE FIRST USE
Water Capacity
– Minimum: 16.9 oz (0.5 L)
– Maximum: 50 oz (1.5 L)
2 To open the Lid, press the
“Lid Release” button (“Push”).
MAX
1.5 L
1.0 L
MIN
0.5 L
MAX
1.5 L
1.0 L
MIN
0.5 L
PUSH
PUSH
MAX
1.5 L
1.0 L
MIN
0.5 L
MAX
1.5 L
1.0 L
MIN
0.5 L
MAX
1.5 L
1.0 L
MIN
0.5 L
PUSH
PUSH
MAX
1.5 L
1.0 L
MIN
0.5 L
OPERATING INSTRUCTIONS | 7
3 Fill the Kettle with the desired
amount of fresh water throught
the open Lid.
MAX
1.5 L
1.0 L
MIN
0.5 L
MAX
1.5 L
1.0 L
MIN
0.5 L
PUSH
PUSH
MAX
1.5 L
1.0 L
MIN
0.5 L
4 Close the Lid by pressing down.
Place on the Power Base on
a flat, stable, heat-resistant surface
that is away from water splashes
and any heat source.
MAX
1.5 L
1.0 L
MIN
0.5 L
MAX
1.5 L
1.0 L
MIN
0.5 L
PUSH
PUSH
MAX
1.5 L
1.0 L
MIN
0.5 L
5 Insert the plug into the power
socket. Push the “On/Off” switch
on the Handle to “I” (On). The Kettle
will begin heating and blue LED
lights will illuminate.
6 The Kettle will automatically
switch off after the water has
boiled for a few seconds. The
switch will reset to “O” (Off) and
the blue LED lights will turn off.
MAX
1.5 L
1.0 L
MIN
0.5 L
MAX
1.5 L
1.0 L
MIN
0.5 L
PUSH
PUSH
MAX
1.5 L
1.0 L
MIN
0.5 L
MAX
1.5 L
1.0 L
MIN
0.5 L
MAX
1.5 L
1.0 L
MIN
0.5 L
PUSH
PUSH
MAX
1.5 L
1.0 L
MIN
0.5 L
7 When boiling finishes,
remove the Kettle from
its base. Carefully pour
your hot water.
MAX
1.5 L
1.0 L
MIN
0.5 L
MAX
1.5 L
1.0 L
MIN
0.5 L
PUSH
PUSH
MAX
1.5 L
1.0 L
MIN
0.5 L
IMPORTANT!
Check that the product is free of damage. Wash the Kettle. Fill the
Kettle with fresh water to the maximum level. Boil the water following
the instructions then pour out the water. Boil and discard the water
3–5 times to remove any dust or foreign matter prior to first use.
WARNING!
Never fill the Kettle while it is on the Power Base.
Do not use without water.
DESCALING INSTRUCTIONS | 98 | CLEANING INSTRUCTIONS
EN
1 Unplug the Kettle. 2 Allow it to cool down
before cleaning.
CLEANING INSTRUCTIONS
Cleaning the Kettle
MAX
1.5 L
1.0 L
MIN
0.5 L
MAX
1.5 L
1.0 L
MIN
0.5 L
MAX
1.5 L
1.0 L
MIN
0.5 L
3 Use a damp sponge to wipe
the interior and exterior.
DESCALING INSTRUCTIONS
Descale Using White Vinegar
1 Allow the Kettle to cool. With the
power off, remove the Kettle from
its Power Base.
2 Open the Lid with the “Lid Release”
button. Fill the Kettle with a solution
of 1.7 oz (50 ml) white vinegar and
1.7 oz (50 ml) clean water.
3 Leave the solution in the Kettle
for 1 hour without heating.
4 Empty the solution.
5 Fill the Kettle with clean water.
6 Boil, then discard the water.
Repeat one more time before
consuming boiled water.
7 If scale is still present in the Kettle,
repeat steps 1–6.
NOTE: Descale regularly.
We recommend at least once
a month or more frequently,
if you water is very hard.
Descale Using Citric Acid
1 Boil 16.9 oz (0.5 L) of water.
2 Add 25 g of citric acid in the Kettle.
Leave the solution in the Kettle for
15 minutes without heating.
3 Empty the solution and rinse the
Kettle with clean water.
4 Boil, then discard the water.
5 If scale is still present in the Kettle,
repeat steps 1–4.
WARNING!
Do not immerse the Kettle, its Power Base, the Power Cord or plug in
water. The electrical connections or the switch must not come into
contact with water.
WARNING!
– Always unplug the appliance from the power outlet and allow it
to cool down before cleaning.
– Do not use chemical, steel wool, or abrasive cleaner to clean
the appliance.
– The Kettle and its parts cannot be washed in a dishwasher.
– Never use a descaling method other than what is recommended here.
NOTE: Descaling is important because limescale can cause the Kettle
to work less efficiently. It also affects the taste and odor of your water.
What is limescale? It’s a chalky, hard white substance that can build up
inside kettles and is mainly composed of calcium carbonate (CaCO
3
).
This buildup often occurs in areas with hard water.
SPECIFICATIONS | 1110 | TROUBLESHOOTING
EN
Problem Possible Cause Solution
The Kettle does
not work or
stops before the
water comes to
a boil.
Does the outlet
work?
Unplug the cord then plug it back
again. If nothing happens, try
plugging a different appliance into
the same outlet to check if it works.
Is it the Power Cord?
Make sure the Cord is not damaged.
If there is damage to the Cord,
please contact Customer Service.
Has the Kettle been
switched on without
water?
Allow the Kettle to cool.
Fill it with water.
Is there an
accumulation of
scale?
Scale can cause the Kettle to enter
an overheat protection mode.
Allow the Kettle to cool.
Descale the Kettle (see Page 9).
Has the Kettle been
dropped or is there
damage to the
Power Cord or is the
plug or Power Base
damaged?
Please contact Customer Service.
Do not use the Kettle.
Cannot
power off
automatically, or
keeps boiling.
The top Lid was not
closed properly.
Close the top Lid properly and retry.
Failure of the steam
switch.
Remove the power connection.
Contact Customer Service and
do not use the Kettle.
TROUBLESHOOTING
If you do not find the cause of the problem listed here, please contact
Customer Service. Do not disassemble the Kettle or its safety devices.
SPECIFICATIONS
1-YEAR LIMITED WARRANTY
This product is warranted to be free from defects in material and workmanship
under normal use and service for one year from the date of the original purchase
with the receipt. The manufacturer’s obligation shall be limited to repairing
or replacing any part of the product that is defective. Such warranty shall not apply
to damages resulting from accidents, abuse, or misuse.
Model
Number
Rated Voltage Power Capacity
HHB1770 AC 110–120 V, 50/60 Hz 1250–1500 W 50 oz (1.5 L)
If there is any problem with MuellerLiving
Compact Glass Kettle, please contact
Customer Service.
MUELLERDIRECT.COM
SUPPORT@MUELLERDIRECT.COM
MUELLERDIRECT.COM
SUPPORT@MUELLERDIRECT.COM
MADE IN CHINA
happiness is homemade
HIGH QUALITY BOROSILICATE GLASS
compact glass kettle
