MODEL # SRFP12402
FIRE PIT
1
Before retu rning to your retaile r, call our customer
service depa rtment at 1-888-909-3888, 7:30 a.m. - 4:30 p.m., PST, Monday - Friday.
or email to [email protected]
ATTACH YOUR RECEIPT HERE
Serial Number
Purchase Date
Questions, problems, missing parts?
1A
B
C
D
E
D
2
Screen
1
(shown actual size)
M6 Flange Nut
(Preassembled to M6
Ring Screw (AA))
Qty. 1
M6 x 15 mm Bolt
Qty. 6
M6 Ring Screw
Qty. 1
DD
M6 x 10 mm Bolt
Qty. 8
Estimated Assembly Time : 10 minutes
Tools required for assembly (not included) : Philli
ps screwdriver
Before assembling product, make sure all parts are present. Compare parts with package contents
list and hardware contents list. If any part is missing or damaged, do not attempt to assemble
the product.
SAFETY INFORMATION
WARNING:
CAUTION: Assemble the fire pit on a non-abrasive surface.
FOR OUTDOOR USE ONLY.
Do not use the fire pit indoors. Carbon monoxide fumes, due to lack of ventilation, can cause
death.
Do not use gasoline or kerosene to start fires in the fire pit. Keep all flammable liquids away from
the fire pit.
This unit is designed to burn charcoal and untreated wood only. Fill the bottom of the bowl with
sand until the surface of sand is 0.2 inches below the crossbar.
Do not use under or on combustible structures/surfaces including wooden decks.
Use protective
gloves and long-handled tools with this fire pit.
Dispose of packaging materials properly.
Keep children away from
hot fire pit.
Fire pit remains very hot for a period of time after using.
Be sure fire pit is cool before attempting to move it.
Do not burn more than 1.6 lbs. of charcoal or 3 lbs. of untreated wood at one time.
The handles of the tools may become hot during and after use. The fire pit should be placed no
closer than 24 in. from walls during use.
PREPARATION
3
Please read and understand this entire manual before attempting to assemble, operate or install
the product.
CALIFORNIA PROPOSITION 65 WARNING
Fuels used in wood or charcoal burning appliances, and the products of combustion of such fuels,
contain chemicals known to the State of California to cause cancer and birth defects or other
reproductive harm.
This product can expose you to chemicals including carbon monoxide and carbon black, which are
known to the State of California to cause cancer and birth defects or other reproductive harm. For
more information go to www.P65Warnings.ca.gov
x 8
M6 x 10 mm Bolt
1. Attach
screws
4
2
2. Attached legs (D) to fire bowl (C) with M6x15
screws.
x 6
CC
M6x15 screws
DD
B
C
CC
D
DD
DD
ASSEMBLY INSTRUCTIONS
3
4
3.
Remove M6 flange nut (BB) from M6 ring
screw (AA). Attach M6 ring screw (AA) to the
top of the screen (A) with M6 flange nut (BB).
Hardware Used
x 1
AA
M6 Ring Screw
x 1
BB
M6 Flange Nut
4. Place screen (A) and fire ring (B) and fire
hook(E) on top of fire bowl (C).
BB
AA
A
A
B
C
D
5
CARE AND MAINTENANCE
Inspecting
Inspect this fire pit on a regular basis to ensure product safety and longer product life.
DO NOT attempt to inspect this outdoor fire pit until the fire is COMPLETELY out and cooled down.
Check handles to make sure they are secure.
Check components for any signs of damage or rust.
If any component is damaged, do not operate until repairs are made.
Cleaning
Clean this outdoor fire pit on a regular basis to promote safer use and longer product life.
Note: After repeated use, the finish may discolor slightly.
DO NOT attempt to clean this outdoor fire pit until the fire is COMPLETELY out and cooled down.
DO NOT use oven cleaner or abrasive cleaners as they will damage this product.
DO NOT clean any part of this outdoor fire pit in a self-cleaning oven as it may damage this finish.
Wipe exterior surfaces with a mild dishwashing detergent or baking soda.
For stubborn surfaces, use a citrus-based degreaser and a nylon scrubbing brush.
Rinse clean with water.
Remove built-up creosote from components with a chimney cleaning product.
Storage
DO NOT move or store this outdoor fire pit until the fire is COMPLETELY out and cooled down.
Once the fire is out, coals are cold and outdoor fire pit is cool to touch, remove ashes
and properly dispose.
Store assembled in a location away from children and pets.
Note: If you do not use, store this outdoor fire pit in a dry location to maximize product life.
ONE-YEAR LIMITED WARRANTY
The item has been manufactured under the highest standards of quality and workmanship.
We warrant to the original consumer/purchaser that all aspects of this product will be free of
defects in material and workmanship for one (1) year from the date of purchase. A replacement
for any defective part will be supplied free of charge for installation by the consumer. Defects or
damage caused by the use of other than genuine parts are not covered by this warranty.
This warranty shall be effective from the date of purchase as shown in the purchaser’s receipt.
For warranty service, call 1-888-909-3888, 7:30 a.m. - 4:30 p.m., PST, Monday - Friday.
This warranty is valid for the original consumer/purchaser only and excludes industrial,
commercial or business use of the product, product damage due to shipment or failure which
results from alteration, product abuse, or product misuse, whether performed by a contractor,
service company, or consumer. We will not be responsible for labor charges and/or damage
incurred in installation, repair or replacement, nor for incidental or consequential damage.
This warranty gives you specific rights, and you may also have other rights that vary from state
to state.
6
Multiple Use
7
Option 1 - Use as fire pit
Option 2 - Use as fire ring
Option 3 - Use as fire pit
