57L WHEELED OIL/FLUID DRAIN & RECYCLING
CONTAINER
MODEL NO: DRP09.V2
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS &
CAUTIONS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO
SO MAY CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE
FOR FUTURE USE.
1. SAFETY
9 Replace damaged parts. Use recommended parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
9 Keep the drainer clean, dry and in good condition for best and safest performance.
9 Wear appropriate PPE. Protective clothing, gloves, eye protection and non-slip safety shoes are recommended.
9 If it is necessary to raise the vehicle, ensure that it is properly supported.
9 If the vehicle has been raised with a jack, axle stands must be put in place before working under the vehicle.
9 Remove the oil drainer and other tools and equipment from underneath the vehicle before lowering it again.
9 Use the drainer in a suitable work area.
9 Keep the work area clean, tidy, well-lit and free from unrelated materials.
9 The work area should have a at and level surface capable of supporting the weight of the drainer and it’s contents.
9 Ensure that the oor is not slippery and wear non-slip safety shoes.
9 Keep children and unauthorised persons away from the work area.
9 Dispose of waste liquids in accordance with local authority regulations.
8 DO NOT position the drainer in such a way that it becomes a hazard to others in the work area.
8 DO NOT use the drainer in wet or damp areas or where condensation is present.
8 DO NOT use the drainer near open ames or other sources of heat.
WARNING! If draining the oil whilst hot, take precautions to prevent against burns, particularly hands, wrists and arms.
WARNING! DO NOT allow uncontrolled discharge of uids which would pollute the environment.
2. INTRODUCTION
Ensures safe and clean collection, transportation and temporary storage of waste oil. Features heavy-duty construction with wheeled
undercarriage for easier transportation of full drainer. Stores flat or in upright position. Supplied with additional tap for alternative draining
method.
3. SPECIFICATION
Model No: ...................................................... DRP09.V2
Capacity: ...................................................................57L
Size (W x D x H): ...........................1000 x 615 x 220mm
4. OPERATION
REFER TO FIG.1
4.1. Ensure the container is at before receiving oil.
4.2. Open the lid and wing plugs.
4.3. Fill the container with up to 57L of oil.
NOTE: Keep the contain at when it is full of oil. Storing
the container upright when full may cause product
deformation.
4.4. Close the lid and wing plugs.
4.5. Open the drain valve or cap to drain the oil from the
container.
Refer to
instructions
Wear protective
gloves
Wear protective
clothing
Wear eye
protection
DRP09.V2 Issue 1 29/09/23Original Language Version
© Jack Sealey Limited
Wear safety
footwear
FIG.1
LID
CAP
WING PLUG
DRAIN VALVE
WING PLUG
DRP09.V2 Issue 1 29/09/23Original Language Version
© Jack Sealey Limited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When
the product becomes completely unserviceable and requires disposal, drain any uids (if applicable) into approved
containers and dispose of the product and uids according to local regulations.
REGISTER YOUR
PURCHASE HERE
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts
without prior notice. Please note that other versions of this product are available. If you require documentation for alternative versions, please
email or call our technical team on technical@sealey.co.uk or 01284 757505.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
