Dimmable Dual mounting magnifying
Work light 230V 45 SmD leD
Model no: Wl53/8D
thank you for purchasing a Sealey product. manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. Safety
1.1. eleCtriCal Safety.
uSe only the SuPPlieD Plug for ConneCting lamP to the PoWer SuPPly.
Warning! It is the user’s responsibility to read, understand and comply with the following electrical instructions:
You must ensure the risk of electric shock is minimised by the installation of appropriate safety devices.
An RCCB (Residual Current Circuit Breaker) should be incorporated in the main distribution board. We also recommend that an RCd
(Residual Current device) is used with all electrical products, particularly portable equipment which is plugged into an electrical
supply not protected by an RCCB.
You must also read and understand the following instructions concerning electrical safety.
1.1.1. TheElectricityAtWorkAct1989requiresallportableelectricalappliances,ifusedonbusinesspremises,tobetestedbyaqualied
electrician, using a Portable Appliance Tester (PAT), at least once a year.
1.1.2. The Health & Safety at Work Act 1974 makes owners of electrical appliances responsible for the safe condition of the appliance and
thesafetyoftheapplianceoperator.Ifinanydoubtaboutelectricalsafety,contactaqualiedelectrician.
1.1.3. You must ensure that you:
Inspect the charger plug, cable and connector for wear and damage to ensure items are safe before connecting to the mains power
supply.
1.1.4. If worn or damaged Do not use.
imPortant: Check that the voltage marked on the plug is the same as the lamp.
1.1.5. Uncoil the cable between charger and the lamp.
8 Do not pull the charger plug from the mains socket by the lead.
Warning! Do not use any other type of plug with this product, other than the supplied mains plug. Failure to observe this warning
couldresultininjuryandorreandwillinvalidatethewarranty.
8 Do not try to take the plug apart.
8 Do not use the plug to charge or power any other electrical item.
8 Do not get the plug wet, or use in wet, damp conditions (for indoor use only).
2. introDuCtion
Powerful 3 dioptre 85mm & 8 dioptre 22mm precision lens gives high quality magnifying capabilities. Features 45 SMd leds producing up to
550lumenstoilluminatetheobjectforimproveddetailedwork.Includesabuilt-intouchsensitivedimmerswitch.Extremelystrongandexible
neckallowingeaseofpositioning.FeaturesaG-clampbasetosecuretoaworkbenchortable.Alsoincludesasturdybasewhichthemagnier
cansitin.Idealforelectricalengineers,engraversandnedetailwork.SuppliedwithBSapprovedplug.
3. SPeCifiCation
Model no: ............................................................. Wl453/8d
leds: ........................................................................ 45 SMd
nett Weight: ................................................................ 1.08kg
Supply: ........................................................................... 230V
4. oPeration
4.1. Pleasechecktheboxforalltheparts.(g.1)
4.2. attaChing the ClamP
9 Make sure the light is unplugged while attaching it to the
table.
Fix the table clamp on a suitable table, the thickness required
≤44MM,puttheadaptor(g.1)ontothebottomofthelamp
arm and insert it into the table clamp, rotate the lamp arm
to the best position, connect the adapter and turn on
the electricity.
4.3. attaChing the baSe
9 Make sure the light is unplugged while attaching the base.
Remove the adaptor from the bottom of the lamp arm, then
Power Switch
Adaptor
Power Cable
And Plug
Table
Clamp
Lamp Arm
Base
g.1
Wl453/8d Issue 1 20/11/18
Original Language Version
© Jack Sealey limited
Refer to
instructions
insert the lamp arm into the corresponding hole in the base. Plug in the adapter and turn on
theelectricity.(g.2)
4.4. Dimmer SWitCh
4.4.1. Quicklytouchingthepowersymbolonthelamparmwillturnthelightonando.Onequick
touch,willturnthelighton,asecondquicktouch,willturnthelighto.
4.4.2. Touching and holding the power symbol, will dim the light. Touch and hold the power symbol
again and the light will become bright. The brightness will stop changing when you stop
touching the power symbol.
g.2
Sealey group, kempson Way, Suffolk business Park, bury St edmunds, Suffolk. iP32 7ar
01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk
enVironment ProteCtion
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
Weee regulationS
dispose of this product at the end of its working life in compliance with the eU directive on Waste electrical and electronic equipment
(Weee). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
important: no liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
