6 SMD LED DIMMABLE RECHARGEABLE
DUAL MOUNTING MAGNIFYING WORKLIGHT
MODEL NO: WL63/8D
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
9 Inspect the cable and connector for wear and damage to ensure items are safe before connecting to the power supply. If worn or
damaged DO NOT use.
9 Ensure the lamp is fully charged before initial use.
8 DO NOT charge in damp conditions.
8 DO NOT turn the lamp on when it is being charged.
8 DO NOT shine directly into your, another person’s or an animal’s eyes.
8 DO NOT allow children to use the lamp.
8 DO NOT handle or move the lamp whilst it is being charged.
8 DO NOT use the lamp if you suspect that the battery or the lamp casing is damaged.
8 DO NOT leave battery in a discharged state, recharge battery immediately. Before storage, fully recharge the battery, subsequently
recharge the battery at least once every six months of non-use.
8 DO NOT attempt to open, disassemble, modify or service the battery pack.
8 DO NOT crush, puncture, short external contacts or dispose of in re or water.
8 DO NOT expose to temperatures above 40°C (104°F).
2. INTRODUCTION
Powerful three dioptre 109mm & eight dioptre 24mm precision lens gives high quality magnifying capabilities. Features six SMD LEDs
producing up to 60 lumens to illuminate the object for improved detailed work. Built-in touch sensitive dimmer switch. Magnifier can
detach from its sturdy base and spring clamp to a work bench up to 45mm thick. Ideal for electrical engineers, engravers and fine
detail work. Rechargeable 3.7V 400mAh lithium cell battery. Supplied with micro USB cable.
3. SPECIFICATION
4. OPERATION
4.1. CHARGING:
4.1.1. Connect the micro-USB lead to the socket on the side of the base of the lamp (g.1). Plug into USB power supply and turn on.
4.1.2. While lamp is charging there is a red LED shining through the desk clamp surface just above the touch sensitive switch.
4.2. Direct the lens away from your eyes before switching on.
4.3. Lightly tap the touch pad switch on the base to turn the lamp on. Lightly tap the touch pad switch again to turn o.
4.4. To modify the lamp output, press and hold the touch pad switch to dim or increase the light output.
4.5. The lamp may be either desk mounted or attached to any desk/bench edge up to 45mm thick by exposing the clamp after removing
the base plate.
WL63-8D Issue 2 (3) 20/09/23
Original Language Version
© Jack Sealey Limited
Refer to
instruction
manual
Model no: WL63/8D
LED Type: SMD
Supply: 5V-1A
Original Language Version
© Jack Sealey Limited
WL63-8D Issue 2 (3) 20/09/23
fig.
1
fig.
2
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic
Equipment (WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact
your local solid waste authority for recycling information.
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts
without prior notice.
IMPORTANT: No Liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which is required for any claim.
