EN
Daily Reference Guide
1
THANK YOU FOR BUYING AHOTPOINT PRODUCT.
In order to receive amore complete assistance, please
register your appliance on: www.hotpoint.eu/register
PLEASE SCAN THE
QR CODE ON YOUR
APPLIANCE IN
ORDER TO HAVE
MORE DETAILED
INFORMATION
Before using the appliance carefully read Safety and Installation Instructions.
After installation, please remember to remove all transport protection parts from
the dishwasher.
APPLIANCE
PRODUCT DESCRIPTION
CONTROL PANEL
1. ON-OFF/Reset button
with indicator light
2. PREVIOUS program button
3. NEXT program button
4. FAVOURITE program button with indicator light
5. Salt reservoir empty indicator light
6. Rinse Aid reservoir empty indicator light
7. DESCALE indicator light
8. Closed Water Tap indicator light
9. Key lock indicator light
10. Program number and remaining time indicator
11. Display
12. 3D Zone Wash option button with indicator light
13. Half Load option button with indicator light/ Settings - 3 sec. press
14. Extra Dry Option button with indicator light/ Keylock - 3 sec. press
15. Delay option button with indicator light
16. START/Pause button with indicator light
The control panel of this dishwasher activates pushing by ON/OFF button.
For energy saving the control panel deactivates automatically after 10 minutes if no cycle has started.
W11617744 panel top 2022.12.05
W11617184 panel 10.01.2023
W11617170 button R 2022.11.03
W11617175 button L 2022.11.03
W11609979 display 2022.11.03
1 2 3 4
12 13
14
15
16
11
5 6 7 8 9 10
1. ActiveDry
2. Top rack
3. Foldable aps
4. Upper rack
5. Upper rack height adjuster
6. Upper sprayer arm
7. Lower rack
8. Cutlery basket
9. 3D Zone Wash
10. Lower sprayer arm
11. Filter Assembly
12. Salt reservoir
13. Detergent and Rinse Aid dispensers
14. Rating plate
15. Control panel
1
2
3
4
5
6
7
8
9
10
11
12
13
1414
15
EN
Daily Reference Guide
2
ADVICE REGARDING THE FIRST TIME USE
After installation, remove the stoppers from the racks and the retaining
elastic elements from the upper rack.
SETTING MENU
1. Switch on the appliance by pressing the ON-OFF button.
2. Hold the Settings (Half Load ) button for 3 seconds, until you hear
a beep and the display shows „SEt”.
3. After one second the rst available setting (letter „ ”) will be displayed.
4. Press PREVIOUS /NEXT to scroll through the list of available settings
(see table below), then press START/Pause to view and change the
value of the currently selected setting.
5. Press PREVIOUS /NEXT to change the value, then press START/Pause
to save the new value and return to the main menu.
6. To change another setting, repeat points 4 and 5.
7. Press ON-OFF or wait 30 seconds to exit the menu.
LETTER
SETTING
VALUES
(Default - in bold)*
Cycle Counter - number of washing cycles
carried out by the dishwasher.
Eg. 25 cycles: 25;
Eg. 13.947 cycles:
13_947
(scrolling
for 3 times)
Water Hardness Level
(see “SETTING THE WATER HARDNESS” and “WA-
TER HARDNESS TABLE”)
1 | 2 | 3 | 4 | 5
Rinse Aid Level
(see “ADJUSTING THE DOSAGE OF RINSE AID”)
0 | 1 | 2 | 3 | 4 | 5
ActiveDry (see “OPTIONS AND FUNCTIONS”)
“1” = On, “0” = O
1 | 0
Sound
“1” = On, “0” = O
1 | 0
Factory Settings - press START/Pause to re-
store to the factory default all the values of the
settings included in the settings menu.
-
*) The default value does not apply to the Cycle Counter.
FILLING THE SALT RESERVOIR
The use of salt prevents the formation of LIMESCALE on
the dishes and on the machine’s functional components.
The salt reservoir is located in the lower part of the dish-
washer (under the lower rack on the left side).
• It is mandatory that the salt reservoir never be empty.
• It is important to set the water hardness.
• Salt must be lled when the SALT REFILL indicator light on the control
panel is lit.
1. Remove the lower rack and unscrew the reservoir cap (anticlockwise).
2. Position the funnel (see gure) and ll the salt reservoir right up to its
edge (approximately 0,5 kg); it is not unusual for alittle water to leak out.
3. Only the rst time you do this: ll the salt reservoir with water.
4. Remove the funnel and wipe any salt residue away from the opening.
Make sure the cap is screwed on tightly so that no detergent can get into
the container during the wash program (this could damage the water sof-
tener beyond repair).
Whenever you need to add salt, it is mandatory to complete the pro-
cedure before the beginning of the washing cycle to avoid corrosion.
Residual saline solution or grains of salt can lead to corrosion, irrep-
arably damaging the stainless steel components.
The guarantee is not applicable if faults are caused by such circumstances.
If the salt container is not lled, the water softener and the heating
element may be damaged as a result of limescale accumulation.
Using of Salt is recommended with any type of dishwasher detergent.
SETTING THE WATER HARDNESS
To allow the water softener to work in a perfect way, it is essential that the
water hardness setting is based on the actual water hardness in your house.
This information can be obtained from your local water supplier. The facto-
ry setting is “3”. See „WATER HARDNESS TABLE”.
Water Hardness Table
Level
°dH
German degrees
°fH
French degrees
°Clark
English degrees
1 (Soft) 0 - 6 0 - 10 0 - 7
2 (Medium) 7 - 11 11 - 20 8 - 14
3 (Average) 12 - 16 21 - 29 15 - 20
4 (Hard) 17 - 34 30 - 60 21 - 42
5 (Very hard) 35 - 50 61 - 90 43 - 62
To change, follow instructions in section “SETTING MENU”.
Only use salt that has been specically designed for dishwashers.
After the salt has been poured into the machine, the SALT REFILL indicator
light switches o.
If the salt container is not lled, the water softener and the heating
element may be damaged as a result of limescale accumulation.
Using of Salt is recommended with any type of dishwasher detergent.
WATER SOFTENING SYSTEM
Water softener automatically reduces water hardness, consequently pre-
venting scale buildup on the heater, contributing also to better cleaning ef-
ciency. This system regenerates itself with salt, therefore it is required
to rell the salt container when empty.
The frequency of regeneration depends on the water hardness level setting
- regeneration takes place once per 4-6 Eco cycles with the water hardness
level set to 3. The regeneration process occurs at the beginning of the cycle
with additional fresh water.
• Single regeneration consumes ~3 L of water;
• Takes up to 5 additional minutes for the cycle;
• Consumes below 0.005kWh of energy.
A
B
FILLING THE RINSE AID DISPENSER
Rinse aid makes dish DRYING easier. The rinse aid dis-
penser Ashould be lled when the RINSE AID REFILL
indicator light in the control panel is lit.
1. Open the dispenser B by pressing and pulling up
the tab on the lid.
2. Pour in the rinse aid (max. 110 ml), making sure it
does not overow from the dispenser. If this hap-
pens, clean the spill immediately with adry cloth.
3. Press the lid down until you hear aclick to close it.
NEVER pour the rinse aid directly into the appli-
ance tub.
ADJUSTING THE DOSAGE OF RINSE AID
If you are not completely satised with the drying results, you can adjust
the quantity of rinse aid used.
To change, follow the instructions in the section “SETTING MENU”.
If the rinse aid level is set to ZERO, no rinse aid will be supplied. The LOW
RINSE AID indicator light will not be lit if you run out of rinse aid.
A maximum of 6 levels can be set according to the dishwasher model.
• If you see bluish streaks on the dishes, set a low number (0-3).
• If there are drops of water or limescale marks on the dishes, set a mid-
range number (4-5).
FILLING THE DETERGENT DISPENSER
Only use detergent which has been specically designed for dishwashers.
DO NOT USE washing up liquid.
Using excessive detergent may result in foam residues remaining in
the machine after the cycle has ended.
Usage of detergent not designed for dishwashers may cause malfunc-
tion or damage to the appliance.
To achieve the best washing and drying results, the combined use of
detergent, rinse aid liquid and rened salt is required.
We recommend using detergents that do not contain phosphates or
chlorine, as these products are harmful to the environment.
Good washing results also depend on the correct amount of detergent
being used.
Exceeding the stated amount does not result in a more eective wash
and increases environmental pollution.
25 ml
35 ml
The amount can be adjusted to the soil lev-
el. In the case of normally soiled items, use
approximately either 35g (powder deter-
gent) or 35ml (liquid detergent) and addi-
tional tea spoon of detergent directly in-
side the tub. If tablets are used, one tablet
will be enough.
If the crockery is only lightly soiled or if
it has been rinsed with water before be-
ing placed in the dishwasher, reduce the
amount of detergent used accordingly (minimum 25 g/ml) e.g. skip the
powder/gel putted inside the tub.
For good washing results also follow the instructions shown on the
detergent box.
For further questions please ask the detergent producers.
FIRST TIME USE
EN
Daily Reference Guide
3
1. CHECK WATER CONNECTION
Check that the dishwasher is connected to the water supply and that
the tap is open.
2. SWITCH ON THE DISHWASHER
Press the ON/OFF button.
3. LOAD THE RACKS (see LOADING THE RACKS).
4. FILL THE DETERGENT DISPENSER
5. CHOOSE THE PROGRAM AND CUSTOMISE THE CYCLE
Select the most appropriate program in accordance with the type of
crockery and its soiling level (see PROGRAMS DESCRIPTION) by pressing
the selected PREVIOUS/NEXT button.
Select the desired options (see OPTIONS AND FUNCTIONS).
Not all options are compatible with all programs.
6. START
Start the wash cycle by closing the door and pressing START/Pause
button (led is lit). When the program starts you hear a single beep.
7. END OF WASH CYCLE
The end of the wash cycle is indicated by sound and the display shows
END. Switch o the appliance by pressing the ON/OFF button and
opening the door.
Wait for a few minutes before removing the crockery - to avoid burns.
Unload the racks, beginning with the lower one.
The machine will switch o automatically during certain extended pe-
riods of inactivity, in order to minimise electricity consumption.
If the crockery is only lightly soiled or if it has been rinsed with water
before being placed in the dishwasher, reduce the amount of deter-
gent used accordingly.
MODIFYING A RUNNING PROGRAM
If a wrong program was selected, it is possible to change it, provided that it
has only just begun. RESET the machine: press and hold the ON/OFF but-
ton for more than 3. sec., and the machine will switch o. The dashboard
will show “0:01”. Wait until drain cycle ends (around 1 minute). Switch the
machine back on using the ON/OFF button and select the new wash cycle
and any desired options. Start the cycle by pressing the START/Pause button.
ADDING EXTRA CROCKERY
Without switching o the machine, open the door rst slightly to avoid
water splashing out (START/Pause led starts blinking) (Caution!: Hot
steam!) and place the crockery inside the dishwasher. Close the door and
press the START/Pause button, the cycle will resume from the point at
which it was interrupted.
ACCIDENTAL INTERRUPTIONS
If the door is opened during the wash cycle, or if there is a power cut, the
cycle stops. Close the door and ONLY IF YOU PRESS the START/Pause but-
ton the cycle will resume from the point at which it was interrupted.
TIPS
Before loading the baskets, remove all food residues from the crockery and
empty the glasses. You do not need to rinse beforehand under running
water. Arrange the crockery so that it is held in place rmly and does not
tip over; and arrange the containers with the openings facing downwards
and the concave/convex parts placed obliquely, thus allowing the water to
reach every surface and ow freely.
Warning: lids, handles, trays and frying pans should not prevent the spray-
er arms from rotating.
Place any small items in the cutlery basket.
Very soiled dishes and pans should be placed in the lower basket because
in this sector the water sprays are stronger and allow a higher washing per-
formance. After loading the appliance, make sure that the sprayer arms can
rotate freely.
UNSUITABLE CROCKERY
• Wooden crockery and cutlery.
• Delicately decorated glasses, artistic handicrafts and antique crockery.
Their decorations are not resistant.
• Parts in synthetic material which do not withstand high temperatures.
• Copper and tin crockery.
• Crockery soiled with ash, wax, lubricating grease or ink.
The colours of glass decorations and aluminium/silver pieces can change
and fade during the washing process. Some types of glass (e.g. crystal ob-
jects) can become opaque after a number of wash cycles too.
DAMAGE TO GLASS AND CROCKERY
• Only use glasses and porcelain guaranteed by the manufacturer as dish-
washer safe.
• Use a delicate detergent suitable for crockery
• Collect glasses and cutlery from the dishwasher as soon as the wash cy-
cle is over.
TIPS ON ENERGY SAVING
• When the household dishwasher is used according to the manufacturer’s
instructions, washing tableware in a dishwasher usually consumes
less energy and water than hand dishwashing.
• In order to maximize dishwasher eciency, it is recommended to in-
itiate the wash cycle once the dishwasher is fully loaded. Loading
the household dishwasher up to the capacity indicated by the manu-
facturer will contribute to energy and water savings. Information on
the correct loading of tableware can be found in the Loading chapter.
In case of partial loading, it is recommended to use a dedicated wash
options if available (Half load/ Zone Wash/ Multizone), lling up only
selected racks. Incorrect loading or overloading of the dishwasher may
increase resources usage (such as water, energy and time, as well as in-
crease noise level), reducing cleaning and drying performance.
• Manual pre-rinsing of tableware items leads to increased water and ener-
gy consumption and is not recommended.
HYGIENE
To avoid odour and sediment which can be accumulated in the dishwasher
please run a high-temperature program at least once a month. Use a
teaspoon of detergent and run it without loading to clean your appliance.
RESISTANCE TO FROST
If the appliance is placed in surroundings exposed to the risk of frost, it
must be drained completely. Turn o the water tap, remove the inlet and
outlet hoses, and let all the water drain away. Make sure that the water
softener is full of dissolved regeneration salt in the salt container, to
protect the appliance from temperatures of up to -20°C.
If the appliance was stored in frost conditions the appliance must remain at
an ambient temperature of min. 5°C for at least 24 hours before the rst run.
DAILY USE
ADVICE AND TIPS
D
C
To open the detergent dispenser use the
opening device C. Introduce the deter-
gent into the dry dispenser D only. Place
the amount of detergent for pre-wash-
ing directly inside the tub.
1. When measuring out the detergent refer
to the mentioned earlier information to
add the proper quantity. Inside the dis-
penser D, there are indications to help
the detergent dosing.
2. Remove detergent residues from the edges of the dispenser and close
the cover until it clicks.
3. Close the lid of the detergent dispenser by pulling it up until the closing
device is secured in place.
The detergent dispenser automatically opens up at the right time accord-
ing to the program.
Usage of detergent not designed for dishwashers may cause malfunc-
tion or damage to the appliance.
EN
Daily Reference Guide
4
PROGRAMS TABLE
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020.
Note for Test Laboratories:
For information on comparative EN testing conditions, please send an email to the following address: [email protected]
Pre-treatment of the dishes is not needed before any of the programs.
*) Door is opened before the programm has been ended. This is to improve the drying eciency. Wait until the time has reached 00:00 to unload the dishwasher
**) Not all options can be used simultaneously.
***) Values given for programs other than the program Eco are indicative only. The actual time may vary depending on many factors such as temperature and
pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and sensor cali-
bration. The sensor calibration can increase program duration by up to 20 min.
Program
Programs description
Drying phase
ActiveDry
*)
Available options
**)
Duration
of wash
program
(h: min)
***)
Water
consumption
(litres/cycle)
Energy
consumption
(kWh/cycle)
P1
Eco 50°- program is suitable to clean normally soiled table-
ware, that for this use, it is the most ecient program in terms
of its combined energy and water consumption, and that it is
used to assess compliance with the EU Ecodesign legislation.
5:10 9.9 0.55
P2
Auto Intensive 65° - Automatic program
for heavily soiled dishes and pans.
Senses the level of
soiling on the dish-
es and adjusts the
program according-
ly. When the sensor
is detecting the soil
level an animation
appears in the dis-
play and the cycle
duration is updated.
2:25 - 3:10 17.0- 25.0 1.30 - 1.70
P3
Auto Mixed 55° - Automatic program
for normally soiled dishes with dried
food residues.
1:20 - 3:20 7.5 - 20.5 0.75 - 1.20
P4
Auto Fast 50° - Automatic program for
normally and lightly soiled dishes. The
everyday cycle that ensures optimal
cleaning and drying performance in
shorter time.
1:00 - 1:50 8.0 - 16.0 0.70 - 1.10
P5
Rapid 45° - Program is recommended for limited amount of
lightly-soiled dishes with no dried food residues. Does not in-
clude the drying phase.
-
0:30 - 0:40 10.5 - 15.0 0.55 - 0.65
P6
Delicates 45° - Program for delicate items, which are more sensi-
tive to high temperatures, for example glasses and cups.
1:40 - 1:50 12.5 - 17.0 0.95 - 1.20
P7
Good Night 55° - Suitable for night-time operation of the
appliance. Ensures optimal cleaning and drying performance
with the lowest noise emission.
3:50 - 4:10 10.5 - 14.5 0.80 - 1.15
P8
Sanitizing 65° - Normally or heavily soiled crockery, with ad-
ditional antibacterial wash. Can be used to perform mainte-
nance of the dishwasher.
-
1:55 - 2:10 12.0 - 19.0 1.40 - 1.80
P9
Soak - Use to refresh crockery planned to be washed later. No
detergent is to be used with this program.
-
0:12 4.5 0.10
P10
Self-Clean 65° -
Program to be used to perform maintenance
of the dishwasher, to be carried out only when the dishwasher
is EMPTY using specic detergents designed for dishwasher
maintenance.
-
-
1:15 12.7 1.10
EXTRA DRY - The higher temperature during the final rinse and the
extended drying phase allow improved drying. The EXTRA DRY option
results in the lengthening of the wash cycle.
DELAY - The start of the program may be delayed for a period of time
between 0:30 and 24 hours.
1. Select the program and any desired options. Press the DELAY
button (repeatedly) to delay the start of the program. Adjustable from
0:30 to 24 hours. Once the 24 hours setting is reached, press the DELAY
another time to deactivate the DELAY function.
2. Close the door and press the START/Pause button. The timer will begin
counting down.
3. Once this time has elapsed, the indicator light switches o and the
program begins automatically.
The DELAY function cannot be set once a program has been started.
HALF LOAD - If there are not many dishes to be washed, HALF LOAD
is used to save water, electricity or time, depending on the selected
program. Remember to halve the amount of detergent.
OPTIONS can be selected/ deselected, after choosing the program, directly by pressing the corresponding button (if available - the indicator
lights up) (see CONTROL PANEL). If an option is not compatible with the selected program (see PROGRAMS TABLE), the corresponding LED ashes rap-
idly 3 times and beeps will sound. The option will not be enabled. An option can change time or water or energy consumption for the program.
OPTIONS AND FUNCTIONS
KEYLOCK - A long press (for 3 seconds) of EXTRA DRY button, will
activate the KEYLOCK function. The KEYLOCK function will block the control
panel except for the ON/OFF button. To deactivate the KEYLOCK, long press
again.
FAVOURITE - The FAVOURITE program may be saved and will be easily
accessible. Find the program using PREVIOUS/NEXT, and then press
the FAVOURITE program button for 3 seconds.
3D ZONE WASH - Thanks to the additional power jets this option pro-
vides up to 80% more water power, a more intensive and powerful wash
in the lower rack, in the specic bottom area. This option is recommend-
ed for washing pots and casseroles (Please refer to the 3D loading section).
EN
Daily Reference Guide
5
WATER TAP CLOSED – Alarm - Flashes when there is no inlet water or
water tap is closed .
ActiveDry -
It is aconvection drying system which automatically opens the
door during/after drying phase to ensure exceptional drying performance
every day. Door opens at the temperature that is safe to your kitchen furniture.
As additional steam protection, special designed protection foil is added
together with the dishwasher.
To see how to mount protection foil please refer to the INSTALLATION
GUIDE. This feature is active by default, but it is possible to deactivate it in
the “SETTINGS MENU” .
SENSING - When the sensor is detecting the soil level an
animation appears in the display (around 20 min.) and the cycle
duration is updated. SENSING is for the level of soiling on the
dishes and it is present for all cycles (excepting Eco) adjusting the program
accordingly .
DESCALE – Alarm - Limescale accumulation was detected on the
internal components of the appliance. Check if the Water Hardness
Setting is at the correct value and salt is present in the salt container
(see FIRST TIME USE), then use a descaling product (WPro brand is
recommended) with the Self-Clean program. After a successful descaling,
the icon will stop being displayed.
If the actions above are not performed, product performance will deteriorate.
DESCALE warning will start blinking and «dES» alarm will appear on the
display. If still no action is taken, the appliance will only allow a certain number
of cycles to be started (indicated during «dES» alarm display) and then will
be BLOCKED to prevent component damage, with only the Self-Clean
program available. Performing a full descaling will unblock the product.
In the case of extremely high amounts of limescale, descaling may have to
be performed twice to be ecient
.
CYCLE COUNTER - This feature shows the number of cycles the
dishwasher has performed.
For the number of cycles from 0-999, a xed number will be displayed.
Example for 25 cycles.
When the cycle number is higher than 1000, the number will scroll in
the display. The “_” represents the “
.
”, as for instance: 1.000 = 1_000,
13.947= 13_947 (the number will scroll for 3 times).
Example for
13.947 cycles:
After the cycle visualization, the display will return to visualize
„ ”
.
NOTE: The dishwasher may have already performed about 30 cycles.
This is due to the extended quality process carried out during
production. It guarantees higher product quality.
LOADING THE RACKS
CAPACITY: 15 standard place-settings
TOP RACK
The top rack pro-
vides a targeted
cleaning Wash Zone
for bowls, mugs,
even big plates and
cutlery that you’d
normally load in the
lower racks, making
extra space for the rest of the day’s dishes.
A separate arrangement of the cutlery makes
collection easier after washing and improves
washing and drying performance.
Knives and other utensils with sharp edges
must be positioned with the blades facing
downwards.
UPPER RACK
Load delicate and light dishes: glasses, cups,
saucers, low salad bowls.
The upper rack has tip-up supports which can
be used in a vertical position when arranging
tea/ dessert saucers or in a lower position to
load bowls and food containers.
(loading example for the upper rack)
ADJUSTING THE HEIGHT OF THE UPPER RACK
The height of the upper rack can be adjusted: a high posi-
tion to place bulky crockery in the lower basket and a low
position to make the most of the tip-up supports by cre-
ating more space upwards and avoiding collision with the
items loaded into the lower rack.
The upper rack is equipped with an Upper Rack height
adjuster (see gure), without pressing the levers, lift it up
by simply holding the rack sides, as soon as the rack is sta-
ble in its upper position. To restore to the lower position, press the levers A at
the sides of the rack and move the basket downwards.
We strongly recommend that you do not adjust the height of the rack
when it is loaded. NEVER raise or lower the basket on one side only.
FOLDABLE FLAPS WITH ADJUSTABLE POSITION
The side foldable aps can be folded or unfolded to optimize the
arrangement of crockery inside the rack. Wine glasses can be placed
safely in the foldable aps by inserting the stem of each glass into the
corresponding slots. In the case of the high position of the upper rack, aps
cannot remain in the vertical position.
Depending on the model:
• to unfold the ap there is needed to slide it
up and rotate or release it from the snaps and
pull it down.
• to fold the ap there is needed to rotate it and
slide the ap down or pull it up and attach the
ap to the snaps.
LOWER RACK
For pots, lids, plates, salad bowls, cutlery etc. Large plates and lids should ide-
ally be placed at the sides to avoid interferences with the spray arm.
The lower rack has tip-up supports which can be used in a vertical position
when arranging plates or in a horizontal position (lower) to load pans and
salad bowls easily.
(loading example for the lower rack)
3D ZONE WASH
3D Zone Wash uses additional water jets located
both: in the lower and upper part of the dishwasher
(marked with orange colour) to wash more inten-
sively heavily soiled items by increasing water cov-
erage on dishes.
Example: Load pots and casseroles facing the
lower part of 3D Zone Wash components and
activate the 3D Zone Wash option on the panel.
CUTLERY BASKET
It is tted with top grids for
improved cutlery arrange-
ment.
It must only be positioned at
the front of the lower rack.
Knives and other utensils
with sharp edges must be
placed in the cutlery basket
with the points facing downwards or they must be positioned horizon-
tally in the tip-up compartments on the upper rack.
EN
Daily Reference Guide
6
ATTENTION: Always unplug the appliance when cleaning it and when
performing maintenance work.Do not use ammable liquids to clean the
machine.
CLEANING THE DISHWASHER
Any marks on the inside of the appliance may be removed
using a cloth dampened with water and a little vinegar.
The external surfaces of the machine and the control pan-
el can be cleaned using a non-abrasive cloth which has
been dampened with water. Do not use solvents or abra-
sive products.
PREVENTING UNPLEASANT ODOURS
Always keep the door of the appliance ajar in order to avoid moisture from
forming and being trapped inside the machine. Clean the seals around the
door and detergent dispensers regularly using a damp sponge. This will
avoid food becoming trapped in the seals, which is the main cause behind
the formation of unpleasant odours.
CHEKING THE WATER SUPPLY HOSE
Check the inlet hose regularly for brittleness and cracks. If damaged, re-
place it by a new hose available through our After-Sales Service or your
specialist dealer. Depending on the hose type:
If the inlet hose has a transparent coating, periodically check if the colour
intensies locally. If yes, the hose may have a leak and should be replaced.
For water stop hoses: check the small safety valve inspection window (see
arrow). If it is red, the water stop function was triggered, and the hose must
be replaced by a new one. For unscrewing this hose, press the release but-
ton while unscrewing the hose.
CLEANING THE WATER INLET HOSE
If the water hoses are new or have not been used for an extended period of
time, let the water run to make sure it is clear and free of impurities before
performing the necessary connections. If this precaution is not taken, the
water inlet could become blocked and damage the dishwasher.
CLEANING THE FILTER ASSEMBLY
Regularly clean the lter assembly so that the lters do not clog and that
the waste water ows away correctly.
Using the dishwasher with clogged lters or foreign objects inside the l-
tration system or spray arms may cause unit malfunction resulting in loss of
performance, noisy work or higher resources usage.
The lter assembly consists of three lters which remove food residues
from the washing water and then recirculate the water.
The dishwasher must not be used without lters or if the lter is loose.
At least once per month or after every 30 cycles, check the lter assembly
and if necessary clean it thoroughly under running water, using a non-me-
tallic brush and following the instructions below:
1. Turn the cylindrical lter A in an anti-clockwise direction and pull it out
(Fig 1). It is important when reinstalling the lter that the two trian-
gles shown on the zoom meet.
2. Remove the cup lter B by exerting a slight pressure on the side aps
(Fig 2).
3. Slide out the stainless-steel plate lter C (Fig 3).
4. In case you nd foreign objects (such as broken glass, porcelain, bones,
fruit seeds etc.) please remove them carefully.
5. Inspect the trap and remove any food residues. NEVER REMOVE the
wash-cycle pump protection (shown by an arrow) (Fig 4).
CARE AND MAINTENANCE
2
1
4
3
A
A
B
C
After cleaning the lters, replace the lter assembly and x it in position cor-
rectly; this is essential for maintaining the ecient operation of the dishwasher.
CLEANING THE SPRAY ARMS
On occasions, food residue may
become encrusted onto the
spray arms and block the holes
used to spray the water. It is
therefore recommended that
you check the arms from time
to time and clean them with
asmall non-metallic brush.
To remove the upper spray you
must remove it together with
the manifold.
The lower spray arm may be removed by
pulling it upwards and rotating it an-
ti-clockwise. Mounting back the spray
arm is by pulling it down and rotating it
clockwise.
The ceiling spray arm may be removed
by pressing it up and then rotating it
anti-clockwise. Mounting back the spray
arm is by pulling it upwards and rotating
it clockwise.
EN
Daily Reference Guide
7
PROBLEMS POSSIBLE CAUSES SOLUTIONS
The salt
indicator is lit
Salt reservoir is almost empty.
Rell the reservoir with salt (for more information - see FILLING THE SALT RESERVOIR).
Check the water hardness setting if necessary (see WATER HARDNESS TABLE).
The salt
indicator is
blinking
Salt reservoir is empty.
Rell the reservoir with salt as soon as possible. Using the appliance without salt may
cause damage to its internal components.
The rinse aid
indicator is lit
or blinking
Rinse aid dispenser is empty. (After rell the
rinse aid indicator may remain lit for a short
time).
Rell the dispenser with rinse aid (for more information - see FILLING THE RINSE AID
DISPENSER).
Descale
indicator is lit
or blinking;"dES"
alarm is displayed.
Limescale is accumulating on internal com-
ponents of the appliance.
Descale the appliance immediately using the Self Clean program and a commercially
available descaling product (see OPTIONS AND FUNCTIONS). Rell the reservoir with
salt. Check the water hardness setting. If the appliance is not descaled, it will stop
functioning.
The dishwasher
won’t start or
does not respond
to commands.
The appliance has not been plugged in
properly.
Insert the plug into the socket.
Power outage.
For safety reasons, the dishwasher will not restart automatically when power returns.
Close the door and press START/Pause button.
The dishwasher door is not closed.
ActiveDry pin is not pulled in.
Vigorously push the door until you hear the “click”.
A cycle is interrupted by door opening for
more than 4 seconds.
Close the door within 4 sec. and press START/Pause button.
The control panel does not respond or
F6 E1 is displayed.
Switch o the appliance by pressing the ON-OFF/Reset button, switch it back on
after approximately one minute and restart the program. If the problem persists,
unplug the appliance for 1 minute, then plug it back in.
The dishwasher
won’t drain.
Display shows:
F7 E3 or F9 E1
The lter is clogged with food residues or
limescale
Clean the lter and descale the appliance (see CLEANING THE FILTER ASSEMBLY and
DESCALE INSTRUCTION).
The drain hose is kinked. Check the drain hose (see INSTALLATION INSTRUCTION).
The sink drain pipe is blocked. Clean the sink drain pipe.
The dishwasher
makes excessive
noise.
Dishes are rattling against each other. Position the crockery correctly (see LOADING THE RACKS).
An excessive amount of foam is present.
The detergent has not been measured out correctly or it is not suitable for use in the
dishwashers (see FILLING THE DETERGENT DISPENSER). Restart the current cycle by
switching OFF the dishwasher, then switch it on again, select a new program, close
the door and press START/Pause.
Crockery has not been arranged properly. Arrange the crockery correctly (see LOADING THE RACKS).
The lter is clogged with food residues or
limescale.
Clean the lter assembly (see CARE AND MAINTENANCE).
The dishes are not
clean.
Crockery has not been arranged properly. Arrange the crockery correctly (see LOADING THE RACKS).
Spray arms cannot rotate freely, being
hindered by the dishes.
Arrange the crockery correctly (see LOADING THE RACKS). Check that the upper rack is
in the correct position and adjust (lift up) if necessary.
The wash cycle is too gentle. Select an appropriate wash cycle (see PROGRAMS TABLE).
An excessive amount of foam is present.
The detergent has not been measured out correctly or it is not suitable for use in
dishwashers (see FILLING THE DETERGENT DISPENSER).
The cap on the rinse aid compartment has
not been closed correctly.
Make sure the cap of the rinse aid dispenser is closed.
The lter is clogged with food residues or
limescale.
Clean the lter and descale the appliance (see CLEANING THE FILTER ASSEMBLY).
The salt reservoir is empty. Fill the salt reservoir (see FILLING THE SALT RESERVOIR).
The dishwasher
does not ll the
water.
The display
shows: H2O and
is lit; acoustic
alarm sounds.
No water in the water supply or the tap is
closed.
Make sure there is water in the water supply and the water tap is open.
The water inlet hose is kinked.
Check the inlet hose (see INSTALLATION). Close the door and press START/Pause button.
The screen in the water inlet hose is
clogged; it is necessary to clean it.
Check and clean the screen in the water inlet hose.
Close the door and press START/Pause button.
The dishwasher
nishes the cycle
prematurely.
The display
shows: F8 E3
The lter is clogged with food residues or
limescale.
Clean the lter and descale the appliance (see CLEANING THE FILTER ASSEMBLY and
DESCALE INSTRUCTION).
Drain hose positioned too low or siphoning
into the home sewage system.
Check if the end of the drain hose is placed at the correct height (see INSTALLATION).
Check for siphoning into the home sewage system, and install a siphon breaker/air
admittance valve if necessary.
An excessive amount of foam is present.
The detergent has not been measured out correctly or it is not suitable for use in
dishwashers (see FILLING THE DETERGENT DISPENSER).
Air in the water supply. Check water supply for leaks or other issues letting air inside.
TROUBLESHOOTING
In case your dishwasher doesn’t work properly, check if the problem can be solved by going through the following list. For other errors or is-
sues please contact authorized After-sales Service whose contact details can be found in the warranty booklet. Spare parts will be available
for aperiod of either up to 7 or up to 10 years, according to the specic Regulation requirements.
EN
Daily Reference Guide
8
The dishes are not
dried well.
Rinse aid is not present or the dosage is too
low.
Make sure the rinse aid dispenser is lled (see FILLING THE RINSE AID DISPENSER).
Multifunctional tablets only will not provide as good drying eects as the actual use
of liquid rinse aid.
The dishes have been unloaded after the
door was opened automatically but before
the actual cycle end.
Make sure the cycle has ended before starting to unload the dishes (see DAILY USE).
For even better drying results, it is recommended to let the dishes sit inside the dish-
washer with the door open for additional 15 minutes after the cycle ends.
The dishes are sitting too at.
If you notice puddles of water inside cavities of cups, mugs or bowls, try loading the
dishes (especially in the upper rack) providing more inclination to let larger amounts
of water drip down before drying starts.
The selected cycle does not have the dry-
ing phase.
Please check in the PROGRAMS TABLE if the selected program is equipped in the
drying phase. A cycle without the drying phase may not deliver desired drying
eciency, so it is recommended to change cycle selection for the one that has the
drying phase.
The dishes are made of non-stick or plastic. Some water drops remaining on this type of material are normal.
Dishes and
glasses have blue
streaks
or bluish tinges.
Rinse aid dosage is excessive. Adjust the dosage to a lower setting.
Dishes and glass-
es are covered
with limescale or
a whitish lm.
The salt reservoir is empty.
Rell the reservoir with salt as soon as possible. Using the appliance without salt may
cause damage to its internal components.
The water hardness setting is too low. Increase the setting (see WATER HARDNESS TABLE).
The cap of the salt reservoir is not properly
closed.
Check and close the salt reservoir cap.
The rinse aid reservoir is empty or the rinse
aid dosage is insucient.
Rell the dispenser with rinse aid and check the dosage setting (for more information - see
FILLING THE RINSE AID DISPENSER).
The dishwasher
shows F8 E5
Valve is blocked or faulty. Close the water tap, if possible. Do not switch o the power supply. Call the service.
Detergent leaks.
Depends on the liquid detergent used and
can be emphasized in case of delay option
is activated.
Small leaks will not cause machine malfunction and can be avoided by changing
liquid detergent type or using tablets.
Policies, standard documentation, ordering of spare parts and additional product information can be found by:
• Using QR code on your product.
• Visiting our website docs.hotpoint.eu and parts-selfservice.europeanappliances.com
• Alternatively, contact our After-sales Service (See phone number in the warranty booklet). When contacting our After-sales
Service, please state the codes provided on your product’s identication plate.
The model information can be retrieved using the QR-Code reported in the energy label.
The label also includes the model identier that can be used to consult the portal of the registry at https://eprel.ec.europa.eu.
IEC 436
:
400020023983
04/2025 as - Xerox Fabriano
