USE AND CARE GUIDE
Microwave Oven
THANK YOU
products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Vissani
Item# 1010954456
Model# VSCMWE11S2W2102
Questions, problems, missing parts? Before returning to the store,
call VISSANI Customer Serive
8 a.m -8 p.m., EST, Monday-Friday, 8 a.m.-6 p.m., EST, Saturday
1-855-847-7264
HOMEDEPOT.COM
Table of Contents
Table of
Contents
...................................................................
Safety Information........................................................ 2
Precautions to Avoid Possible Exposure
to Excessive Microwave Energy.................................. 2
California Proposition 65 Warning.............................. 2
General Warning ....................................................... 2
Grounding Instructions............................................... 4
Installation Guide........................................................ 5
Product Diagram......................................................... 5
Control Panel.............................................................. 6
Operation Instructions................................................ 7
How Does The Safety Lock Functions................ 7
Deactivating And Reactivating Electromagnetic
Safety Lock................................................................ 7
Setting the Clock .................................................8
Timer.................................................................... 8
+30 Sec Function................................................ 8
Microwave Cooking............................................. 8
Weight Defrost .................................................... 9
Time Defrost........................................................ 9
Auto Cook............................................................ 9
Express Cook......................................................10
Multi-stage Cooking............................................10
Child Lock...........................................................10
Cleaning And Care ............................................ 11
Product Warranty .............................................. 12
Button Adhesion Protection............................... 10
2
2
HOMEDEPOT.COM Please contact 1-855-847-7264
for further assistance
□
Do not attempt to operate this oven with the
door open since open-door operation can result in
harmful exposure to microwave energy. It is
important not to defeat or tamper with the safety
interlocks.
Do not place any object between the oven front
face and the door or allow soil or cleaner residue
to accumulate on sealing surfaces.
Do not operate the oven if it is damaged. It is
very important that the oven door close properly
and that there is no damage to the
a) Door (including any dents),
b) Hinges and latches (broken or loosened),
c) Door seals and sealing surfaces.
The oven should not be adjusted or repaired by
anyone except qualified service personnel.
CALIFORNIA PROPOSITION 65 WARNING
General Warning
To reduce the risk of burns, electric shock,
fire, injury to persons or exposure to
excessive microwave energy:
□
Read all instructions before using the
appliance.
□
Read and follow the specific "PRECAUTIONS TO
AVOID POSSIBLE EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY" on page 2.
This appliance must be grounded. Connect only to
properly grounded outlet. See "GROUNDING
INSTRUCTIONS " on page 4.
□
Do not operate the oven when empty.
Install or locate this appliance only in accordance
with the provided installation instructions.
□
Some products such as whole eggs and sealed
containers -for example, closed glass jars- are
able to explode and should not be heated in this
oven.
□
Use this appliance only for its intended use as
described in this manual. Do not use corrosive
chemicals or vapors in this appliance. This type of
oven is specifically designed to heat, cook, or dry
food. It is not designed for industrial or laboratory
use.
□
As with any applianc
□
Hot contents can cause severe burns. Do not allow
children to use the microwave. Use caution when
removing hot items.
e, close supervision is
necessary when used by children.
WARNING:
Precautions to Avoid Possible Exposure to
Excessive Microwave Energy
WARNING:
Cancer and Reproductive
Harm-WWW.P65Warnings.ca.gov.
Safety Information
□
□
□
To reduce the risk of fire in the oven
cavity:
1. Do not overheat the liquid. Carefully attend to
the appliance when paper, plastic, or other
combustible materials are placed inside the oven
to facilitate cooking.
2. Remove wire twist-ties from paper or plastic
bags before placing bag in oven.
3. If materials inside the oven should ignite, keep
oven door closed, turn oven off using the circuit
breaker panel, and call emergency services.
□
Do not use the cavity for storage purposes. Do
not leave paper products, cooking utensils or food in
the cavity when not in use.
□
Liquids, such as water, coffee, or tea are able to
be overheated beyond the boiling point without
appearing to be boiling due to surface tension of the
liquid. Visible bubbling or boiling when the container
is removed from the microwave oven is not always
present. This could result in very hot liquids
suddenly boiling over when a spoon or other utensil
is inserted into the liquid.
□
To reduce the risk of injury to person:
1. Do not overheat the liquid.
2. Stir the liquid both before and halfway through
heating it.
3. Do not use straight-sided containers with
narrow necks.
4. After heating, allow the container to stand in the
microwave oven for a short time before removing the
container.
5. Use extreme care when inserting a spoon or
other utensil into the container.
□
Do not heat oil or fat for deep-frying. It is
difficult to control the temperature of oil in
microwave oven.
□
Do not cover or block any openings on the
appliance.
□
Do not operate this appliance if it has a
damaged cord or a plug, if it is not working properly
or if it has been damaged or dropped.
□
Do not immerse cord or plug in water. Keep
cord away from heated surface. Do not let cord hang
over edge of table or counter.
□
This appliance should be serviced only by
qualified service personnel.Contact nearest
authorized service facility for examination,
repair, or adjustment.
3
HOMEDEPOT.COM Please contact 1-855-847-7264
for further assistance
Safety Information (Continued)
□
Oversized food or oversized metal utensils
should not be inserted in a
microwave/toaster oven as they may create
a fire or risk of electric shock.
□
When cleaning surfaces of door and oven
that comes together on closing the door, use
only mild, non-abrasive soaps, or detergents
applied with a sponge or soft cloth.
□
Do not store or use this appliance
outdoors. Do not use this product near water,
for example, near a kitchen sink, in a wet
basement, near a swimming pool, or similar
locations.
□
Do not clean with metal scouring pads.
Pieces can burn off the pad and touch
electrical parts involving a risk of electric
shock.
□
Do not use paper products when appliance
is operated in the toaster mode.
□
Do not store any materials, other than
manufacturer’s recommended accessories,
in this oven when not in use.
□
Do not cover turntables, pans or any other
part of the oven with metal foil. This will
cause overheating of the oven.
□
This device complies with Part 18 of the
FCC Rules. This equipment has been tested
and found to comply with the limits for a
Consumer ISM equipment, pursuant to Part
18 of the FCC Rules. These limits are
designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses
and can radiate radio frequency energy and,
if not installed and used in accordance with
the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that
interference will not occur in a particular
installation.
Please note that changes or modifications of
this product is not expressly approved by the
party responsible for compliance could void
the user's authority to operate the
equipment.
Distributed by HOME DEPOT
2455 PACES FERRY ROAD
ATLANTA, GA 30339
4
HOMEDEPOT.COM Please contact 1-855-847-7264
for further assistance
CAUTION:
Changes or modifications not
approved by the party responsible for
compliance could void the user's authority
to operate the product.
This equipment generates, uses and can
radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that
interference will not occur in a particular
installation.
If this equipment does cause harmful interference to
radio or television reception, which can be determined
by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or
more of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and
receiver.
3. Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
4. Consult the dealer or an experienced radio/TV
technician for help.
This appliance must be grounded. In the event of an
electrical short circuit, grounding reduces risk of
electric shock by providing an escape wire for the
electric current. This appliance is equipped with a
cord having a grounding wire with a grounding plug.
The plug must be plugged into an outlet that is
properly installed and grounded.
Consult a qualified electrician or serviceman if the
grounding instructions are not completely
understood, or if doubt exists as to whether the
appliance is properly grounded. If it is necessary to
use an extension cord, use only a 3-wire extension
cord that has a 3-blade grounding plug and a 3-slot
receptacle that will accept the plug on the appliance.
The marked rating of the extension cord shall be
equal to or greater than the electrical rating of the
appliance.
Electrical Requirements
The electrical requirements are a 120 volt 60
Hz, AC only, 20 amp. It is recommended that a
separate circuit serving only the oven be
provided. The oven is equipped with a 3-prong
grounding plug. It must be plugged into a wall
outlet properly installed and ground.
Power Cord
□
A short power supply cord is provided to
reduce the risks resulting from becoming
entangled in or tripping over a longer cord.
□
Longer cord sets or extension cords are
available and may be used if care is exercised
in their use.
□
If long cord or extension cord is used:
a) The marked electrical rating of the cord set
or extension cord should be at least as great
as the electrical rating of the appliance.
b) The extension cord must be a grounding-type
3-wire cord, and the longer cord should be
arranged so that it will not drape over the
countertop or tabletop where it can be pulled
on by children or tripped over accidentally.
IMPORTANT
:
Important Grounding Instructions
Safety Information (Continued)
3-Pronged Plug
Ground Plug
3-Prong Receptacle
Make sure that all the packing materials are
removed from the inside of the door.
This microwave oven must be placed on a flat,
stable surface.
For correct operation, the oven must have
sufficient airflow. Allow minimum 8 in. (20.32cm)
of free space necessary above the top surface of
the oven and 2 in. (5.08cm) at both sides. Do not
cover or block any openings on the appliance. Do
not remove feet.
Only use the appliance on a countertop over 3 ft.
(91.6cm) above the floor.
Do not place the oven where heat, moisture, or
high humidity is generated, or near combustible
materials.
8 inch
2 inch
2 inch
Make sure that the power cord is undamaged
and does not run under the oven or over any
hot or sharp surface.
The socket must be readily accessible so the
microwave oven can be easily unplugged in an
emergency.
Part No.
1
2
3
4
5
6
7
Description
Quantity
Safety Interlock System
Observation Window
Roller Ring
Plastic Shaft
Control Panel
Wave Guide Cover
Glass Turntable
1
1
1
1
1
1
1
NOTE: Hardware not shown to actual size.
5
HOMEDEPOT.COM Please contact 1-855-847-7264
for further assistance
Installation
Control Panel Operation
AUTO COOK
Use to set the auto cook programs
(See Page 8).
TIMER
The TIMER function can be used
alone, even in the process of
cooking.
POWER LEVEL
Use to set microwave power
levels.
CLOCK
Press to set the clock function.
TIME DEFROST
Press to set defrosting time.
TIME COOK
Use for multi-stage cooking. It
enables cooking at multiple
power/time settings.
WEIGHT DEFROST
Touch to set the weight of the
food to be defrosted.
Number Pad 1-6
Express cooking, press 1-6 to
automatically begin cooking
between 1 and 6 minute
increments.
STOP/CLEAR/LOCK
Press to clear all previous settings
before cooking starts.
Press once to pause current
cooking program or press twice to
cancel the program.
Or press and hold 3 seconds for
child lock.
START/+30 SEC
Press to start a cooking program.
It is also used to set quick start
function or to increase cooking
time during cooking.
6
HOMEDEPOT.COM Please contact 1-855-847-7264
for further assistance
Note:
Please remove the protective
film on the control panel before
the first time you use the
microwave.
Operation Instruction
1. Deactivating And Reactivating
Electromagnetic Safety Lock
2. How Does The Safety Lock Functions
7
HOMEDEPOT.COM Please contact 1-855-847-7264
for further assistance
NOTE:
a) In standby mode:
The oven door can be opened and closed normally.
b) During cooking:
• Locking during cooking cannot directly open the
door.
• Press number button "0" once to unlock the
electromagnetic lock and pause cooking work. If
the door does not opened within 10 seconds, the
electromagnetic lock will automatically lock. If the
door is not opened for 30 minutes, the electromag-
netic lock will unlock automatically.
• Press STOP/CLEAR button once to pause cooking
and unlock the electromagnetic lock. If the door is
not opened for 10 seconds, the electromagnetic
lock will lock automatically. If the door is not
opened for 30 minutes, the electromagnetic lock
will unlock automatically.
• Press number button "0" once, then open the
door, the electromagnetic lock does not need to be
locked again until the next cooking.
c) Cooking ends state:
• After the cooking ends, the buzzer will emit four
beeps of "DE -" and the display will show "End". At
the same time, the display will switch to "Loc"
every 5 seconds.
• Press number button "0" once to unlock the
electromagnetic lock. If the door does not opened
within 10 seconds, the electromagnetic lock will
automatically lock. If the door does not opened
within 30 minutes, the electromagnetic lock will
unlock automatically.
• Press number button "0" once and open the door,
and the electromagnetic lock does not need to be
locked again until the next cooking.
• Press STOP/CLEAR button once to unlock the
electromagnetic lock, and the display shows clock
time. If the door is not opened for 10 seconds, the
electromagnetic lock will automatically lock, which
can be set normally. During setting, if the setting is
not completed for 30 seconds, the display will show
"Loc". Open the door once or after 30 minutes, the
display will show clock time and the system will
return to standby mode.
• If setting the electromagnetic lock is not
completed within 10 seconds, the setting
is unsuccessful and the system returns
standby mode.
• The initial state is in the enabling state,
and the electromagnetic lock setting
status will not be changed when power
on again after power outage.
• When the electromagnetic lock
function is deactivating, the door can be
opened and closed normally.
To reactivate the electromagnetic lock function
after deactivating: While in standby mode and the
electromagnetic lock has been deactivated, press
and hold number button “0” for 2 seconds, the
display will show ”Uloc”, then press “7” then “9”,
the display will show “Loc”
To deactivate the electromagnetic lock function:
While in standby mode and the electromagnetic lock
is active, press and hold number button “0” for 2
seconds, the display will show ”Loc”, then press “7”
then “9”, the display will show “ULoc” The
microwave will remain in deactivated until it is
reactivated even with a power loss
Operation Instruction (Continued)
8
HOMEDEPOT.COM Please contact 1-855-847-7264
for further assistance
4. Setting The Kitchen Timer
In standby state or during cooking, touch TIMER
pad to set kitchen timer.
Example: How to set 30 minutes timer.
1. Touch TIMER pad once.
2. Use the number pads to enter time. The longest
time is 99 minutes 99 seconds.
3. Touch START/+ 30 SEC pad to start.
NOTE:
The TIMER function can be used in any cooking
process. You can check the countdown time by
pressing TIMER pad, but if STOP/CLEAR pad is
pressed when the display shows the time, the
function is cancelled.
3. Setting The Clock
This is 12 and 24 hour clock, and you can select
which by pressing CLOCK pad. During cooking, the
current time can be seen by touching CLOCK pad.
EXAMPLE: How to set the oven clock time at 8:30.
1) In standby mode, touch CLOCK pad once to select
12 hour clock.
2) Use the number pads to enter the time (touch
number pads 8,3,0 in order to enter 8:30).
3) Press START/+30SEC to confirm.
5. Start/ Add 30 SEC
1) Touch once and cooking will start at full power
level immediately for 30 seconds. Touching this
button repeatedly will add 30 seconds each time.
2) During the time cook and time defrost, you can
add 30 seconds for each push.
This function will not work for auto cooking menus
and defrost program.
6. Cooking Program
1) Touch the TIME COOK pad.
2) Touch the number pad to enter desired cooking
time.
The maximum number that can be entered is 99
min. 99 sec.
3) Touch the POWER LEVEL pad.
4) Use the number pads to enter the power level
as shown in the table below.
5) Touch START/+30 SEC pad to start.
Power Level Chart:
Power Level Display
100%
PL10
90%
PL-9
80% PL-8
70%
PL-7
60%
PL-6
50%
PL-5
40% PL-4
30% PL-3
20% PL-2
10% PL-1
DisplayPower Level
NOTE:
You can check the power level by
pressing Power Level pad during
cooking.
NOTE:
• If the electromagnetic lock function is in disabled mode, pressing number button "0" in the
above state will result in an invalid sound.
• In electromagnetic start mode, when the door is closed and press the "0" button once, the
electromagnetic lock action once.
Operation (Continued)
7. Setting Time Defrost
1) Touch the TIME DEFROST pad.
2) Enter desired defrosting time by touching the
correct number pads. The longest time you can set
is 99 min. 99 sec.
3) Touch the START/+30 SEC pad to start.
8. Setting Weight Defrost
1) In standby mode, touch the WEIGHT DEFROST
pad to defrost food by weight.
2) Enter food weight using the number pad, and
touch START/+30 SEC pad to start.
Weight Range is 4~64oz.
9. AUTO Cooking Program
For the following foods or cooking operation, you do not need to input cooking power and time. It is
sufficient to indicate the type of food that you want to cook as well as the weight or servings of this
food.
1. In standby mode, press the corresponding menu button once.
2. Press the button repeatedly to enter food weight or servings.
3. The oven starts cooking automatically 3 seconds later.
9
HOMEDEPOT.COM Please contact 1-855-847-7264
for further assistance
Auto Program Food Chart
Time
1 Pot (8oz/serving)
2 Pot
6 oz
2-pc
4:00
2:00
7:00
2:20
1:20
0:40
POTATO
Weight/Serving
Menu
POPCORN
PIZZA
3.5oz
BEVERAGE
1-pc (200ml/serving)
3-pc
3:20
2:20
3:20
2:50
9 oz
18 oz
9:00
5:00
21 oz
18 oz
14 oz
11 oz
7 oz
28 oz
25 oz
1:20
4:20
3:50
1:50
11 oz
1:10
16 oz 1:40
NOTE:
During defrosting program, the system will
pause and countdown time will stop to
remind user to turn food over, and then touch
STAR
During defrosting, you can add defrosting time
by pressing START/+30 SEC button, each
press to add 30 seconds.
T/+30SEC pad to resume.
NOTE:
During defrosting program, the system will
pause and sound beeps to remind user to
turn food over, and then touch
START/+30SEC pad to resume.
REHEAT
Frozen
Dinner
10
HOMEDEPOT.COM Please contact 1-855-847-7264
for further assistance
10. Express Cook
Cooking will start immediately after touching the
number pad (1-6). For example. if you want to set the
express cooking time to 6 minutes.
1) Touch the 6 pad.
2) 6:00 minutes displays.
3) Cooking automatically starts and runs for 6
minutes.
Touch Number Pad
Time Minutes
1 Minute
2 Minutes
1
4
3
2
6
5
6 Minutes
5 Minutes
4 Minutes
3 Minutes
11. Multi-stages Cooking
12. Child Lock
The child lock prevents unsupervised operation by
children.
To set, in standby mode, press and hold STOP/CLEAR
for 3 seconds. "Loc" is indicated on the display.
To cancel, press and hold STOP/CLEAR for 3 seconds.
"Loc" indication disappears.
13. Button Adhesion Protection
Operation (Continued)
Your oven can be programmed up to 3 automatic
cooking sequences. It can be composed of time
defrost with one or two microwave cooking
program, or composed of two microwave cooking
sequence.
A. Time defrost with one or two-stage microwave
cooking programs:
1. Open the door and place the food into the oven,
close it.
2. Press TIME DEFROST button once.
3. Use number buttons to set defrosting time.
not press START button.
5. Input the second microwave cooking program.
NOTE: Step 5 is not necessary if you just need one
microwave cooking program.
B. Two-stage microwave cooking programs:
Some recipes require different stages of cooking at
different temperatures.
not press START. button.
2. Input the second microwave cooking program.
3. Press START to start.
In any state, if any button on the control panel is
adhesion for 60 seconds, the program stops working
immediately, the display shows "FAIL" and the
system will sound beep. If the button is adhesion all
the time, beep will sound every one minute. Any
button is invalid at this time. After troubleshooting,
press STOP/CLEAR button to return standby mode.
Care and Cleaning
11
HOMEDEPOT.COM Please contact 1-855-847-7264
for further assistance
1. Turn off the oven and unplug the power cord from the wall when cleaning.
2. Keep the inside of the oven clean. When food splatters or spilled liquids adhere to oven walls, wipe
with a damp cloth. Mild detergents may be used if the oven gets very dirty. Avoid using spray or other
harsh cleaners. They may stain, streak or dull the door surface.
3.The outside of the oven should be cleaned with a damp cloth. To prevent damage to the operating
parts inside the oven, water should not be allowed to seep into the ventilation openings.
4. Wipe the door and window on both sides, the door seals and adjacent parts frequently with a damp
cloth to remove any spills or spatters. Do not use abrasive cleaner.
5. Do not allow the control panel to become wet. Clean with a soft, damp cloth. When cleaning the
control panel, leave oven door open to prevent oven from accidentally turning on.
6. If steam accumulates inside or around the outside of the oven door, wipe with a soft cloth. This may
occur when the microwave oven is operated under high humidity condition. This is normal.
7. It is occasionally necessary to remove the glass tray for cleaning. Wash the tray in warm sudsy
water or in a dishwasher.
8. The roller ring and oven floor should be cleaned regularly to avoid excessive noise. Simply wipe the
bottom surface of the oven with mild detergent. The roller ring may be washed in mild, soapy water or
in a dishwasher. When removing the roller ring, be sure to replace it in the proper position.
9. Remove odors from your
oven by combining a cup of water with the juice and skin of one lemon in
a microwaveable bowl. Microwave for 5 minutes. Wipe thoroughly and dry with a soft cloth.
10. If the light bulb burns out, please contact customer service to have it replaced.
11. The oven should be cleaned regularly and any food deposits should be removed. Failure to
maintain the oven in a clean condition could lead to deterioration of surface that could adversely
affect the life of the unit and could possibly result in a hazardous situation.
12. Please do not dispose of this appliance into the municipal waste bin; it should be disposed to the
particular disposal center provided by the municipalities.
Warranty
12
HOMEDEPOT.COM Please contact 1-855-847-7264
for further assistance
This warranty applies to microwave ovens under the brand name Vissani sold by The Home Depot,
in the U.S (“Vissani Products”). This warranty is in lieu of any other warranty and expressly applies
to the individual product only. Vissani products are warranted to be free from any defects in
material and workmanship resulting from noncompliance with the legal standards for one year
from the date of the consumers’ first purchase. In addition, the magnetrons (parts only) of Vissani
Products are warranted to be free from defects in material and workmanship for a period of eight
years from the date of the consumers’ first purchase. Nevertheless, the consumer is responsible
for all labor and transportation expenses related to the diagnosis and replacement of the
magnetron after the initial one-year warranty expires. In the event the unit requires replacement
or refund under the terms of this warranty, the consumer is responsible for all transportation
expenses to return the unit to our factory prior to receiving a replacement unit or refund.
Please save your receipt as proof of purchase is required to make a warranty claim. If a covered
defect occurs during the one-year warranty period, we agree, at our own discretion, to repair,
replace, or pay the consumer the reasonable cost of repairing or replacing the defective item. The
warranty can not be transferred through resale, including the resale through a 3rd party
unauthorized retailer and is only bestowed upon the original consumer who purchases from an
authorized retailer. This warranty does not cover, and excludes, damage or defects caused by:
Consumer misuse Abuse Neglect including the failure to clean and/or provide adequate regular
maintenance as outlined in the user manual, Commercial use, Subjecting the product to any
voltage outside the specified range, Loss of parts,The affixing of any attachments not provided
with the product, Loss or damage caused by acts of God, including but not limited to fire,
explosion, smoke, water escape, changes that are not reasonably foreseeable in the level of
underground water table, glass breakage, windstorm, hail, lightning,
falling trees, aircraft, vehicles,
flood, and earthquakes. Use in a manner not intended and outlined in the user manual. Failure of
the consumer to take timely action to minimize loss or damage or failure of the consumer to give
us timely notice of the defect.
Any subsequent damages caused by the above listed exclusions will not be covered and any
claims determined to meet the above exclusions will be denied. All liability is limited to the
purchase price and does not include any: Retail offered extended warranties, Tax, Other charges
(including postage to send required materials), Incidental and/or consequential damages
associated with the product in question. Every implied warranty, including any statutory warranty
of merchantability or fitness for a particular purpose is disclaimed except to the extent prohibited
by law, in which case such warranty is limited to the duration of this written warranty. This
warranty gives you specific legal rights. You may have other legal rights that vary depending on
where you live. Some states do not allow limitations on implied warranties or special, incidental,
or consequential damage, so the above limitations may not apply to you.
If you have a claim under this warranty, please call our Customer Service number: 1-855-VISSANI.
For faster service, please have the model number, serial number, and receipt ready for the operator
to assist you.
Model Number
Part& Labor Type of ServiceMagnetron (Parts Only)
VSCMWE11S2W2102 Carry InEight YearsOne Year
Questions, problems, missing parts? Before returning to the store,
call VISSANI Customer Serive
8 a.m -8 p.m., EST, Monday-Friday, 8 a.m.-6 p.m., EST, Saturday
1-855-847-7264
HOMEDEPOT.COM
Retain this manual for future use.
