Baridi DH254 Mini Tabletop Fridge/Freezer, 31L Capacity User Manual

Baridi Mini Tabletop Fridge/Freezer, 31L Capacity - White/ Black

Model No: DH254, DH255

Thank you for purchasing a Baridi product from the Dellonda range. Manufactured to a high standard, this product will, if used according to these instructions,

and properly maintained, give you years of trouble free performance.

DH254, DH255 Issue 3 14/10/24

• ELECTRICAL SAFETY

• WARNING! It is the user’s responsibility to check the following:

• Check all electrical equipment and appliances to ensure that they are safe before using.

• This product is not designed to be used with an inverter.

• Inspect power supply leads, plugs and all electrical connections for wear and damage.

• Ensure that the insulation on all cables and on the appliance is safe before connecting it to the power supply.

• DO NOT use worn or damaged cables, plugs or connectors.

• DO NOT use with an extension cord.

• Ensurethatanyfaultyitemisrepairedorisreplacedimmediatelybyaqualiedelectrician.

• If the cable or plug is damaged during use, switch off the electricity supply and remove from use.

• Ifthesupplycordisdamaged,itmustbereplacedbythemanufacturer,itsserviceagentorsimilarlyqualiedpersonsinordertoavoidahazard

• Ensurethatrepairsarecarriedoutbyaqualiedelectrician.

• Dellonda recommend that an RCD (Residual Current Device) is used with all electrical products.

• Important:Ensurethatthevoltageratingontheappliancesuitsthepowersupplytobeusedandthattheplugisttedwiththecorrectfuse.

• DO NOT pull or carry the appliance by the power cable.

• DO NOT pull the plug from the socket by the cable.

• GENERAL SAFETY

• Children from age 8 years and above, persons with reduced physical, sensory, or mental capabilities those with lack of experience and knowledge can

usetheappliance,iftheyhavebeengivensupervisionorinstructionconcerninguseoftheapplianceinasafewaytounderstandthehazardsinvolved.

• Children aged from 3 to 8 years are allowed to load and unload refrigeration devices.

• Children shall NOT play with the appliance.

• Cleaning and user maintenance on the appliance shall not be made by children without supervision.

• The appliance shall be disconnected from its power source during service and when replacing parts and, if that the removal of the plug is foreseen, it

shall be clearly indicated that the removal of the plug has to be such that an operator can check from any of the points to which he has access that

the plug remains removed.

• This refrigeration appliance is not intended to be used as a built-in appliance.

• This refrigerant appliance is intended to be used at ambient temperatures ranging from 16°C to 38°C.

• DO NOTstoreexplosivesubstancessuchasaerosolcanswithaammablepropellantinthisappliance.

• This appliance is intended to be used in household and similar applications such as:

• –staffkitchenareasinshops,ofcesandotherworkingenvironments

• – farm houses and by clients in hotels, motels and other residential type environments

• – bed and breakfast type environments

• – catering and similar non-retail applications.

• To avoid contamination of food, please respect the following instructions:

• -Openingthedoorforlongperiodscancauseasignicantincreaseofthetemperatureinthecompartmentsoftheappliance.

• - Regularly clean surfaces that can come in contact with food and accessible drainage systems.

• -Cleanwatertanksiftheyhavenotbeenusedfor48h;ushthewatersystemconnectedtoawatersupplyifwaterhasnotbeendrawnfor5days.

• Storerawmeatandshinsuitablecontainersintherefrigerator,sothatitisnotincontactwithordripontootherfood.

• Two-starfrozen-foodcompartmentsaresuitableforstoringpre-frozenfood,storingormakingice-creamandmakingicecubes.

• One-,two-andthree-starcompartmentsarenotsuitableforthefreezingoffreshfood.

• If the refrigerating appliance is left empty for long periods, switch off, defrost, clean, dry, and leave the door open to prevent mould developing within

the appliance.

• WARNING! When positioning the appliance, ensure the supply cord is not trapped or damaged.

• WARNING! DO NOT locate multiple portable socket-outlets or portable power supplies at the rear of the appliance.

• The appliance shall not be exposed to rain.

• COMPRESSION TYPE APPLIANCES WHICH USE FLAMMABLE REFRIGERANTS

• WARNING! Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.

• WARNING! DO NOT use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the

manufacturer.

• WARNING! DO NOT damage the refrigerant circuit.

• WARNING! DO NOT use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the

manufacturer.

• WARNING! When positioning the appliance, ensure the supply cord is not trapped or damaged.

• WARNING! DO NOT locate multiple portable socket-outlets or portable power supplies at the rear of the appliance.

• LOCKS

• IfyourRefrigeratoristtedwithalock,keepthekeyoutofreachandnotinthevicinityoftheappliancetopreventchildrenbeingentrapped.When

disposing of an old Refrigerator, break off any old locks or latches as a safeguard.

Important Information

Please read these instructions carefully and note any safe operational requirements, warnings & cautions. Use the product correctly and with care for

the purpose for which it is intended. Failure to do so may cause damage and/or personal injury and will invalidate the warranty. Keep these instructions

safe for future use.

Refer to

instructions

Indoor use

only

WARNING!

Flammable

material

• FREON-FREE

• The freon-free refrigerant (R600a) and the foaming insulation material (cyclopentane) that is environmentally friendly are used for the refrigerator,

causingnodamagetotheozonelayerandhavingaverysmallimpactontheglobalwarming.R600aisammable,andsealedina 

refrigeration system, without leakage during normal use. But, in case of refrigerant leakage due to the refrigerant circuit being damaged, be

suretokeeptheapplianceawayfromopenamesandopenthewindowsforventilationasquicklyaspossible.

• PRODUCT FEATURES

• DOOR REVERSAL INSTRUCTIONS

1. Make sure that your refrigerator is unplugged.

2. Remove the hinge cover and upper hinge from the top right side of the cabinet. Remove the screw hole cover from the top left side of the

cabinet.

3.Removethefreezercompartmentdoorfromthecabinet.

4. Remove the screws that secure the lower hinge to the right side of the cabinet, then remove the hinge. Then remove the adjustable foot.

5.Removetheadjustablefootonthelowerhingeshaft,andremovethewasherandnut.

6. Turn the lower hinge by180°

7. Install the washer and nut into the hole on the pin shaft, and then install the adjustable foot.

8. Install the lower hinge on the left side of the cabinet. Install the adjustable foot at the right.

9.Removethescrewthatsecuresthedoorstopfromthebottomrightofthefreezercompartmentdoor,thenremovethedoorstopandinstalltothe

bottom left side.

NO DESCRIPTION

1 Shelf

2 Thermostat control

3 Water tray

4 Adjustable Feet

10.Installthefreezercompartmentdoor.

11.Movethedoorbushingfromthetoprightsideofthefreezerdoortothetopleftsideofthedoor.Andmovetheleftholecovertotherightside.

12. Secure the upper hinge to the top left side of the cabinet with the three screws you removed previously. Before you tighten the upper hinge screws,

make sure that the top of the door is level with the cabinet and that the rubber gasket makes a good seal.

• INSTALLATION INSTRUCTIONS

• VENTILATION CONDITION

The position you select for the refrigerator installation should be well-ventilated and has less hot air. Do not locate the refrigerator near a heat

source such as cooker, and avoid it from direct sunlight, thus guaranteeing the refrigeration effect while saving energy consumption. Do not

locate the refrigerator in the damp place, so as to prevent the refrigerator from rusting and leaking electricity. The result of the refrigerant

charge amount of the refrigerator being divided by the total space of the room in which the refrigerator is installed shall be less than 8g/ m³.

NOTE: The amount of refrigerant charged for the refrigerator can be found on the nameplate.

• HEAT DISSIPATION SPACE

When working, the refrigerator gives off heat to the surroundings. Therefore, at least 30mm of free space should be spared at the top side,

 morethan100mmonbothsides,andabove50mmatthebacksideoftherefrigerator.

Dimensions in mm:

Note: Figure 1, Figure 2 only illustrate the space demand of the product.

LEVEL GROUND

Placetherefrigeratoronthesolidandatground(oor)tokeepitstable,orelse,itwillgiverisetovibrationandnoise.Whentherefrigeratoris

placedonsuchooringmaterialsascarpet,strawmat,polyvinylchloride,thesolidbackingplatesshouldbeappliedunderneaththe 

refrigerator, (not supplied) so as to prevent colour change due to heat dissipation.

NOTE: Unobstructed ventilation shall be maintained around the appliance or in an embedded structure.

PREPARATIONS FOR USE

1. STANDING TIME

After the refrigerator is properly installed and well cleaned, do not switch it on immediately. Make sure to energise the refrigerator after more than 1

hour’s standing, so as to ensure its normal operation.

W D H A B C (°) E F

474 447 496 800 875 130±5

100

5

2. CLEANING

Conrmtheaccessorypartsinsidetherefrigeratorandwipetheinsidewithasoftcloth.

3. POWER-ON

Insert the plug into the solid socket to start the compressor. After 1 hour, open the refrigerator door, if the temperature inside the refrigerator

compartment drops obviously, it indicates the refrigeration system is working normally.

4. STORAGE OF FOOD

After the refrigerator runs for a period of time, the internal temperature of the refrigerator will be automatically controlled according to the user’s

temperature setting. After the refrigerator is fully cooled, put in foods, which usually need 3 hours to be fully cooled. In summer, when the temperature

is high, it takes more than 4 hours for the foods to be fully cooled. Open the refrigerator door as little as possible before the internal temperature cools

down.

• NOTE: If the refrigerator is installed where there is high humidity, make sure to check whether the ground wire and leakage circuit breaker are normal.

If vibration noises are produced due to the refrigerator contacting the wall or if the wall gets blackened by air convection around the compressor,

movetherefrigeratorawayfromthewall.Settinguptherefrigeratormaycausejammingnoiseorimagechaostomobilephones,xed-line

telephones, radio receivers, and televisions surrounding it, so try to keep the refrigerator as far away as possible in such case.

• OPERATION

• TEMPERATURE SELECTION

• Temperature control

• The temperature of the appliance can be adjusted by turning the thermostat knob.

• Freezertemperaturerange:MINabout-15°CMAXabout-24°C.

• Refrigeratortemperaturerange:about0to10°C.Thethermostatdialcanbesetbetween1to5

• The temperature decreases as the setting number goes up.

• Internal temperature of the appliance can vary based on ambient temperature, the quantity of items

stored and how frequently the door is opened.

• LOCATION

• DO NOT placeyourrefrigerator/freezernearaheatsource,e.g.cooker,boilerorradiator.Avoid     

direct sunlight in out-buildings or sun lounges.

• LEVELLING

• Makesuretolevelyourrefrigerator/freezerusingthefrontlevellingfeet.Ifnotlevel,the      

refrigerator/freezerdoorgasketsealingperformancewillbeaffected,orevenitmayleadtotheoperatingfailureofyourrefrigerator/freezer.

• Afterlocatingtherefrigerator/freezerinposition,waitfor4hoursbeforeusingit,soastoallowtherefrigeranttosettle.

• DO NOT cover or block the vents or grilles of your appliance.

• APPLIANCE STORAGE

• Iftheappliancewillnotbeusedforseveralmonths,turnitoffrst,andthenunplugtheplugfromthewalloutlet.

• Take out all foods.

• Clean and dry the interior thoroughly. To prevent odour and mould growth, leave the door ajar: block it open or have the door removed if necessary.

• Keep the cleaned appliance in a dry, ventilated place and away from the heat source, place the appliance smoothly, and do not place heavy objects on

top of it.

• NOTE: When using the fridge mode, you need to pour away the defrosting water in the drip tray inside the cabinet timely after a period of use, in order

topreventthedefrostingwaterfromoverowingtotheoor.

• WARNING!

• The information regarding the temperature range of the appliance is provided on the rating plate.

• The internal temperature could be affected by such factors as the location of refrigerating appliance, ambient temperature, and frequency of door

open, etc/ The setting of the temperature control thermostat might have to be varied to allow for these factors.

• Effervescentdrinksshouldnotbestoredinthefreezercompartmentorthelow-temperaturecompartment,andsomeproductssuchaswaterices

should not be consumed too cold.

• FOOD STORAGE LOCATIONS

• DO NOTputtoomuchweightinsidetherefrigerator.Keepenoughspacebetweenfoods;iftooclose,thecoldairowwillbeblocked,thusaffecting

the refrigeration effect. DO NOT store excessive quantities or overweight foods, to avoid the shelf from being crushed

• When storing the foods, keep a distance away from the inner wall; and do not place the water-rich foods too close to the refrigerator rear wall, so they

don’tgetfrozenontheinnerwall.

• COMPARTMENT

• Long-termstorageoffoods:Thefreezercompartment,wherethetemperatureisgenerallycontrolledbelow-18°C,issuitableforthepreservationof

foods for a long term, but the shelf life indicated on the food packages should be followed.

• Allowhotfoodstocooldowntoroomtemperaturebeforeputtingtheminthefreezercompartment.

• DO NOTputaglasscontainerwithliquidorcannedliquidsthataresealedintothefreezercompartmenttoavoidburstingduetovolumeexpansion

aftertheliquidgetsfrozen.

• Divide the food into appropriately small portions

• Packthefoodupbeforefreezingit,andthepackingbagusedshouldbedry,incasethepackingbagsarefrozentogether.Foodsshouldbepackedor

coveredwithasuitablematerialsasarerm,tasteless,impervioustoairandwater,non-toxicandpollution-free,toavoidcross-  

contamination and transfer of odour.

TIPS FOR SHOPPING FOR FROZEN FOODS

1.Whenyouarebuyingfrozenfood,lookattheStorageGuidelinesonthepackaging.Youwillbeabletostoreeachitemoffrozenfoodfortheperiod

shown against the star rating. This is usually the period stated as “Best to use them before date”, found on the front of the packaging.

2.Checkthetemperatureofthefrozenfoodcabinetintheshopwhereyoubuythefrozenfoods.

3.Makesurethefrozenfoodpackageisinperfectcondition.

4.Alwaysbuyfrozenproductslastonyourshoppingtriporvisittothesupermarket.

5.Trytokeepfrozenfoodtogetherwhilstshoppingandonthejourneyhome,asthiswillhelptokeepthefoodcooler.

6.Don’tbuyfrozenfoodunlessyoucanfreezeitstraightaway.Specialinsulatedbagscanbeboughtfrommostsupermarketsandhardwareshops.

Thesekeepthefrozenfoodscoldlonger.

7.Forsomefoods,thawingbeforecookingisunnecessary.Vegetablesandpastacanbeaddeddirectlytoboilingwaterorsteamcooked.Frozen

sauces and soups can be put into a saucepan and heated gently until thawed.

8.Usequalityfoodandhandleitaslittleaspossible.Whenfoodsarefrozeninsmallquantities,itwilltakelesstimeforthemtofreezeupandthaw.

9.Estimatethenumberoffoodtobefrozen.Whenfreezinglargeamountsoffreshfood,adjustthetemperaturecontrolknobtothelowmode,withthe

freezertemperaturelowered.So,foodscanbefrozenupinafastmanner,withthefoodfreshnessretained.

• ICE TRAY

Placetheice-makingboxintheupperpositionofthefreezercompartment,sothatiticesupassoonaspossible.

• CLEANING

• Afteraperiodofuse,athinlayeroffrostwillbeformedonthefreezercompartmentinnerwall(orevaporator)surface,whichmayaffectthe

refrigerationeffectifexceeding5mminthickness.Insuchcase,youneedtogentlyscrapethefrostoffusinganicescraperratherthanthemetalor

sharp hardware. Frosts need to be cleared off every 3 months or so, and if the normal use of drawers and normal access of foods are affected by

frosting, make sure to remove the frost in a timely manner. Follow the following steps to remove frost:

1.Takeoutthefrozenfoods,shutoffthemainspowersupply,opentherefrigeratordoor,andgentlyremovethefrostfromtheinnerwallwithanice

scraper.Tospeedupthethawingprocess,placeabowlofhotwaterinsidetherefrigerator/freezer,andwhenthesolidicefrostbecomeloose,usean

ice scraper to scrape them off and then take them out.

2.Afterdefrosting,cleantherefrigerator/freezerinside,andswitchonthepowersupply.

• TROUBLESHOOTING

• If the product is not working properly, please refer to the following table. If the problem cannot be resolved, please contact a Dellonda authorised

service centre.

PROBLEM POSSIBLE CAUSE / SOLUTION

The refrigerator doesn't work. Check the power supply is connected and free from damage.

The refrigerator is noisy. Ensuretherefrigeratorisplacedonat,stableground,awayfromotherobjectsorwalls.Use

the adjustable feet as necessary to level the appliance.

The internal temperature is too high. Select the appropriate temperature. Ensure the door is closed and there is enough ventilation

space around the appliance. DO NOT leave the door open for long periods.

• DISPOSAL

• Dispose according to local regulations in force.

Dellonda Limited, Sole UK Distributor of Baridi

Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR

01284 757575 suppor[email protected] www.dellonda.co.uk

Environment Protection, Waste Electrical and Waste Electronic Equipment

Regulations (WEEE)

Recycle unwanted packaging materials. When this product is no longer required, or has reached the end of its

usefullife,pleasedisposeofinanenvironmentallyfriendlyway.Drainanyuids(ifapplicable)intoapproved

containers, in accordance with local waste regulations. It is our policy to continually improve products and we

reservetherighttoalterdata,specicationsandpartswithoutpriornotice.Noliabilityisacceptedforincorrect

Baridi DH254 Mini Tabletop Fridge/Freezer, 31L Capacity

Product's Documents

Instructions

Specifications

Baridi DH254 Questions and Answers
