SWIVEL AIR HOSE REEL 30M, 6MM ID
1. SAFETY
9 Familiarise yourself with the application and limitations of the hose reel, as well as the specific hazards.
WARNING! Disconnect the hose reel from the supply before servicing or performing any maintenance.
9 Maintain the hose reel in good condition (use an authorised service agent).
9 Replace or repair damaged parts. Use recommended parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
9 Locate and fix the hose reel in a suitable working area, ensure that the correct fixings are used to secure the unit to the wall.
8 DO NOT position the hose in direct sunlight, or in areas of extreme heat or cold.
8 DO NOT mount inside a spray booth/oven.
9 Ensure there is adequate lighting.
WARNING! Ensure maximum air pressure is not exceeded (300psi/20bar).
9 Keep extended air hose away from heat, oil and sharp edges.
9 Check hose for wear before each use and ensure all connections are secure.
9 Keep the unwound hose away from wet, damp, oily surfaces to avoid debris accumulation in between the hose reel.
WARNING! Always wear approved eye protection when operating the air hose reel.
9 Maintain correct balance and footing. Ensure the floor is not slippery and wear non-slip footwear.
9 Keep children and unauthorised persons away from the working area.
8 DO NOT operate the hose reel if any parts are damaged or missing as this may cause failure and/or personal injury.
8 DO NOT use the hose reel for any purpose other than that for which it is designed.
8 DO NOT pull the hose from the supply.
8 DO NOT operate the hose reel when you are tired or under the influence of alcohol, drugs or intoxicating medication.
8 DO NOT direct air from the air hose at yourself or others.
9 When not in use ensure the air supply is turned off and tools disconnected. Disconnect from the supply..
2. iINTRODUCTION
Heavy-duty steel construction with corrosion resistant powder coated finish ensures long-lasting performance. 30m Hose that showcases
a maximum pressure of 300psi(20bar). Experience versatility and effortless use with the swivel base that rotates 360°. Enhance ease-of-
use and enable compact storage with the folding handle feature. Fitted with 1/4”BSP male connectors and a 1m inlet hose to connect the
hose reel to a compressor.
3. SPECIFICATION
4. CONTENTS
WARNING! Ensure the hose is disconnected from the supply.
DO NOT position the hose in direct sunlight or in areas of
extreme heat or cold.
4.1. REMOVE ALL ITEMS FROM THE PACKAGING
4.2. WALL MOUNTING
WARNING! Ensure the wall is capable of holding the weight of
unit and operation.
4.2.1. Assemble as in g.1.
Refer to
instructions
Wear eye
protection
SA827 Issue: 4 07/02/25
Model No/ SA827
Hose Size (ID/OD) Ø6/12.3mm
Hose Type Hybrid
Inlet Size 3/8”BSP
Length 30m
Maximum Pressure 300psi
Nett Weight 9.5kg
Outlet Size 1/4”BSP
Wear protective
gloves
Wear ear
protection
Wear a mask
MODEL NO:
SA827
fig.
1
4.2.2. Using the bracket, as a template, mark the wall, where the hose reel is to be mounted and drill four centres and x to the wall. (xings
not supplied.)
4.2.3. Connect to an air line. DO NOT connect directly to an air tool, connect a leader hose to the tool rst and then connect the leader hose
to the air hose reel.
4.3. EXTENDING THE HOSE
4.3.1. Pull the hose out slowly to the length required and stop.
4.4. RETRACTING THE HOSE
4.4.1. Rewind the hose manually.
5. MAINTENANCE
WARNING! Before attempting maintenance or inspection, vent any pressure remaining in the hose.
To ensure reliable operation, clean the hose and casing regularly. DO NOT spray or wet the product, but clean with a damp cloth and
warm water. DO NOT use solvents or detergents, as these may permanently damage the item. The hose reel does not require special
maintenance as it is lubricated for life. Replacement of the supply hose should be carried out by skilled personnel only, consult your
authorised service agent.
5.1. STORAGE
5.1.1. Before storing the air hose, ensure it is clean and dry. Store it in a dark, safe, dry, childproof location, where the temperature will remain
reasonably stable.
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted,
taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product
becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and
dispose of the product and fluids according to local regulations.
